EMPORIA TOUCHsmart User manual

English
Eveline Pupeter, emporia Telecom
www.emporia.eu
Thank you for purchasing an emporia product!
Please read this user guide before
attempting to use your phone.
TOUCH
smart
Wi-Fi
connection or
mobile data tariff
required

2
1
4
16
7
9
12
11
3
13 14
21
18
20
19
5
10
› YOUR MOBILE PHONE AT A GLANCE
1Speaker
2Home screen
3Navigation ring
4Left function key
5Selection key
6Right function key
7Phone book key
8Camera key
9Green key
10 WhatsApp key
11 Red key
12
1
key (voicemail)
13 Camera lens and ash
14 Emergency button
(extra battery cover without
an emergency button)
15 Headset port
16 Torch button
17 Volume controls
and
18 Battery cover
19 Speaker
20 Microphone
21 Port for USB charging cable
6
15
17
8
›Symbols on the
external display
Reception indicator
Battery
12:3012:30 Time
21.0821.08 Date
SunSun Day
Incoming call
Missed call
New SMS
New WhatsApp
message
›Other symbols on
the home screen
Vo LTE
Reception indicator
Wi-Fi
Alarm
Silent mode
Bluetooth
12 °C12 °C Temperature

› SYMBOLS AND OPERATING THE PHONE
ENGLISH–03
›How do I return a missed call?
1. Tap on the word View on the screen below
the notication Missed call.
2. The call function will open and the number or name
ofthecaller will be highlighted by a red bar.
›How do I access a new SMS message?
1. Tap on the word View on the screen below
thenoticationNew message.
2. The text message function will open.
3. The number or name of the sender will be highlighted byabar.
4. Tap on the new SMS to read it.
›How do I access a new WhatsApp message?
• Tap on the WhatsApp button to open the app.
›How do I remove indicators for missed calls, SMS messages
and WhatsApp notifications?
The symbols on the external display and along the top of the
screen will disappear as soon as you've read the SMS, opened
WhatsApp or had a look to see who the missed call was from.

ENGLISH–04
› CONTENTS
› Your mobile phone at
aglance ................02
› Symbols and operating
thephone ..............03
1. Getting started .........06
1.1 Inserting a SIM card........06
1.2 Inserting and charging
thebattery................06
1.3 Turning on the phone......07
1.4 Entering a PIN code........07
1.5 Saving battery power......07
2. Setting up your phone...08
2.1 Setting up WhatsApp......08
2.2 Personalising the menu ....09
2.3 Optimising use of
thememory...............09
3. Using the phone ........10
3.1 Using the home screen ....10
3.2 Dual-function keys ........10
3.3 Using the menu ...........11
3.4 Writing text ...............12
4. Calls ...................13
4.1 Accepting, rejecting
orendinga call............13
4.2 Calling someone ..........13
5. Contacts................14
5.1 Searching for a contact
inthephone book.........14
5.2 Adding a contact ..........14
5.3 Transferring contacts ......15
5.4 Opening and editing
acontact record ...........16
5.5 Contact options ...........17
6. Messages (SMS) .........18
6.1 Writing and sending
amessage ................18
6.2 Reading a message ........18
7. WhatsApp ..............19
7.1 Using WhatsApp ..........19
7.2 Closing WhatsApp.........19

ENGLISH–05
8. Info centre .............20
8.1 Receiving a notification ....20
8.2 Opening a notification.....20
8.3 Deleting notifications......20
9. Camera.................21
9.1 Taking a photo or
recordingavideo..........21
9.2 Changing the camera
settings...................21
10. Photo album............22
10.1 Viewing a photo or video ..22
10.2 Sending or editing a photo 22
11. Settings ................24
11.1 Alarm.....................24
11.2 Automatic switch-on/-off ..24
11.3 Silent mode ...............25
11.4 Wi-Fi......................25
11.5 Bluetooth .................26
11.6 Mobile data . . . . . . . . . . . . . . . 26
11.7 Flight mode ...............26
11.8 Location (GPS).............27
11.9 Open to answer calls.......27
11.10 More settings............27
12. Internet ................29
13. Calendar ...............30
13.1 Entering a new event ......30
13.2 Opening an event
you've entered ............31
13.3 Searching for an event .....31
14. System updates.........32
15. Weather ................33
16. Emporia emergency
callfunction ............34
17. Guarantee and service...36

ENGLISH–06
1. GETTING STARTED
1.1 Inserting a SIM card
1. Remove the battery cover (opening in the bottom left-hand
corner).
2. Slide the SIM card into the SIM card holder with the gold
contacts facing down.
3. To add more storage, insert an memory card into the memory
card holder with the gold contacts facing down.
1.2 Inserting and charging the battery
1. Insert the battery, making sure that the battery contacts touch
the phone's gold contacts.
2. Place the battery cover over the battery and click it into place.
3. Insert the charging cable into the USB port of the phone and
the power plug into a mains outlet.
Charge the battery for at least four hours before the rst time you
use it. Only use batteries and chargers that are permitted for use
with this specic model.

ENGLISH–07
1.3 Turning on the phone
• Press and hold the key for at least 2seconds until
theemporia logo appears. It will take a few seconds for
thehome screen to be displayed.
• To turn the phone o, press and hold the key for
2seconds again.
1.4 Entering a PIN code
• Enter the four-digit PIN code for your SIM card when asked
todo so and conrm the entry.
• You can change or turn o the PIN code in Menu _Settings
_More settings _SIM card lock.
You have a maximum of three attempts to enter the correct
number. If you enter the wrong number three times in a row, you
will only be able to unblock the SIM card with the PUK code. You
will nd your original PIN code and PUK code in the documents
supplied with your SIM card by your network operator.
1.5 Saving battery power
After a few seconds of inactivity, the display will turn o
tosave battery power. In the event of an incoming call or you
pressing any key, the screen will automatically light up again.

ENGLISH–08
2. SETTING UP YOUR PHONE
When you use a new SIM card for the rst time, you need to set
the language, date, time and any data connections. You can also
congure and change these later in Menu _Settings if you wish
(See »11. Settings« on page 24).
If you use the phone's mobile data facility, your network tari
must include mobile data. Ask your retailer or network provider
formore information.
2.1 Setting up WhatsApp
1. When on the home screen, press the WhatsApp key .
2. Tap on AGREE AND CONTINUE to conrm you accept
theWhatsApp privacy policy and terms of service.
3. Enter your phone number and then conrm it by tapping
onNEXT.
4. Tap on OK to conrm verication of your number.
5. Grant permission for SMS messages so that the number can
be veried automatically; otherwise enter the code you have
received by SMS.
6. Enter the name you would like to be called on WhatsApp.
Youcan supplement this prole information with a photo too.
You can now delete the SMS you received from WhatsApp.

ENGLISH–09
2.2 Personalising the menu
• The menu has been preset to display the following functions:
Contacts, Messages, WhatsApp, Calendar, Camera, Photo
album, Settings and Applications.
• The placement of each of these functions can be
altered individually, apart from that of the unmovable
Applications button.
• To replace a function with another one, tap and hold one of
the buttons for approx. 3seconds and select your chosen
function from the list that appears.
2.3 Optimising use of the memory
This device is a feature phone that has been enhanced by
the WhatsApp function. It doesn't oer all the functions of a
smartphone, because its storage space doesn't allow that.
• Switch o the device once a day or enable the Automatic
switch-on/switch-off function in Settings to help
performance.
• Regularly delete photos and videos you have taken yourself
or received via WhatsApp from the device and/or save them
elsewhere to free up storage space on your phone.
• Recording and sending videos that are too large can prevent
the device from running smoothly.

ENGLISH–10
3. USING THE PHONE
This phone can be controlled both via its touchscreen and via its
numeric keypad and navigation ring. In the following, operating
the phone using the keys has been prioritised.
3.1 Using the home screen
• Left function key : opens the menu
• Right function key :opens the Info centre
(can be made visible for present notications)
• Phone book :opens Contacts
• Camera :opens the photo function
• key: opens your call history
• WhatsApp :opens WhatsApp
3.2 Dual-function keys
Some keys have additional functions if they are pressed
andheld down for a few seconds:
•
1
key: allows you to listen to your voicemail
Changing your voicemail settings:
Menu _Contacts _Settings _Voicemail _Setup
_Voicemail number
• key: + for country code, e.g. +49 for Germany
• key: turns the torch on continuously

ENGLISH–11
3.3 Using the menu
1. When on the home screen, press the left function key to
open the Menu.
2. Scroll through the menu items with the navigation ring.
Yourcurrent selection will be highlighted by a blue border.
3. Press the selection key to open the selected menu item.
4. Options which you can select with the function keys will be
shown at the bottom of the screen.
The left function key is normally the OK button,
while the right function key is normally for BACK.
Note the terms displayed along the bottom of the screen and
match these with the function keys below them.
• To return to the home screen, press the red key .

ENGLISH–12
3.4 Writing text
You enter text using the keypad.
• To input text, press a number key multiple times (e.g. 2x
4ghi
,
1x
2abc
, 3x
5jkl
, 3x
5jkl
and 3x
6mno
for Hallo).
• Special characters and symbols have been assigned to
thevarious keys, but can dier in some languages:
1
. , ! ? 1 ‘ “ @ :
2abc
 abc2äàåāâæ
3def
 def3đéēè€êë
4ghi
 ghi4îïìíğîι
5jkl
j k l 5 £
6mno
m n o 6 ö ñ ô œ ó
7pqrs
 pqrs7ß$ş
8tuv
t u v 8 ü ù û ú
9 wxyz
 wxyz9ŵýÿ
0
Space 0
+ * # - _ = < > % ( ) [ ] : ; / \ & ~ ^
• Use the
aA1
key to switch between the abc, ABC, Abc and
123 input methods.
The virtual keyboard has been preset to be o, but can be enabled
in Menu _Settings _Advanced settings
_Language/input _Virtual keyboard _On.
Once you've done this, the virtual keyboard will be available as a
fth option assigned to the
aA1
key.

ENGLISH–13
4. CALLS
4.1 Accepting, rejecting or ending a call
• To answer: Open the phone and press Accept.
• To reject or end a call:
Press the red button or close thephone.
• To mute the ringtone temporarily,
press the volume control button.
The open-to-answer-calls function is preset to be o, but can be
enabled in Menu _Settings _Open to answer calls _On.
4.2 Calling someone
›Dialling a number
1. Enter the phone number you want to dial (incl. the area code)
using the keypad.
2. Start the call by pressing .
›Using the redial function
1. When on the home screen, press the green key .
Your call history will be displayed.
2. Use the navigation ring to select a number.
3. Start the call by pressing .
To go hands-free during a call, open Options and turn on
thespeaker.

ENGLISH–14
5. CONTACTS
5.1 Searching for a contact in the phone book
1. When on the home screen,
press the phone book key or open Menu
_Contacts _Phone book.
2. Use the navigation ring to scroll through the entries or
use the keypad to type the rst letters of the contact you
arelooking for in the search bar.
3. Start the call by pressing .
5.2 Adding a contact
1. Open Menu _Contacts _Phone book _Add contacts.
2. Enter the contact's phone number and
then conrm it by pressingNext.
3. Enter the person's name and save it. You have now created a
contact record for this person and can expand it by adding
other details such as a contact photo, their landline number,
their email address and their birthday.
Always save names and numbers with the international dialling
code, e.g.+41 for Switzerland, +43 for Austria and +49 for
Germany.

ENGLISH–15
5.3 Transferring contacts
›Importing contacts from your SIM card
1. Save all your contacts onto the SIM card while the SIM card is
in your old phone.
2. As soon as you insert the SIM card into your new device for the
rst time, you will be asked if you want to transfer the contacts
that are stored on the SIM card.
3. Once you've done this, the imported contacts will appear in
the phone book.
4. To import contacts from the SIM card later on, select Menu
_Contacts_Phone book _Import/export contacts
_Import from SIM card. Tap on the contact you want to
import or open Options and select Import all.
›Importing contacts in a VCF file
1. Save all the contacts on your old phone in a VCF le.
2. Transfer the le to your new device on an SD card or via a
Bluetooth connection.
3. Select Import/export contacts _Import from memory
at the end of the list in the phone book. The VCF le will be
detected automatically and the contacts imported.

ENGLISH–16
5.4 Opening and editing a contact record
There are two ways to open a saved contact record.
›Using the physical buttons:
1. Open Menu _Contacts _Phone book.
2. Use the navigation ring to select the contact record.
Your current selection will be highlighted by a blue border.
3. Press the left navigation button for Options.
A menu consisting of Call, Send message
andContact details will appear.
4. Select Contact details. The contact record containing
thecontact's Photo, Mobile number, Landline number,
Email address and Birthday will then be displayed.
5. Select Edit using the left function key.
You can then change any of the contact details.
6. Conrm any changes you make by selecting Save.
›Using the touchscreen:
1. Open Menu _Contacts _Phone book.
2. Search for the contact and tap on the contact picture
(photo or head icon) next to the name.
3. A menu button containing icons forCall , Send message
and Contact information will appear.
4. Tap on and the Contact details will appear.

ENGLISH–17
5.5 Contact options
›Sending a message
Write the contact currently open a text message.
›Sending the contact details
Copy the name and number of the contact currently open into
a text message and send them to a third person.
›Call history for a contact
In the call history, you will see all the calls you've had with this
contact. As well as the date, time and, if applicable, duration of
the call, you can see the type of call beside each entry here:
Outgoing calls (duration)
Incoming calls (duration)
Missed calls
›Setting the contact as a favourite
If you set the contact as a favourite, it will be displayed at
thebeginning of the list in the phone book.
It is not possible to use one of the number keys to put a contact on
speed dial.
›Deleting a contact
If you tap on Delete, the contact will be permanently deleted
from your phone.

ENGLISH–18
6. MESSAGES SMS
6.1 Writing and sending a message
1. Open Menu _Messages.
2. Select Write message.
3. Enter the text using the keypad.
4. To specify a recipient for the SMS,
open Options and select Send.
5. You can now select a Contact from the phone book,
type in a Phone number using the keypad,
select a number from your Recent calls list or
select Multiple contacts at the same time.
6.2 Reading a message
• When you receive a new message, a note and
a symbol will appear on the home screen.
• The number of new messages will then be displayed in a red
circle next to the messages icon
1
on the menu screen.
1. Open Menu _Messages.
2. Unread messages will be highlighted by a blue bar.
3. To read a message, tap on it.

ENGLISH–19
7. WHATSAPP
7.1 Using WhatsApp
Instructions for WhatsApp's most important
functions are provided in a separate booklet that
comes with this device.
Please pay attention to the following too:
• The emporia TouchSMART doesn't have all the functions
of a smartphone. With regard to WhatsApp, the device has
been designed in a way that enables messages in chats
including photos, short videos and audio les to be received
and replied to.
• Make sure you regularly delete photos and videos received or
sent via WhatsApp to free up storage space. Recording and
sending videos that are too large can prevent the device from
running smoothly.
• This device is not connected to a Google account.
It is therefore also not possible to back up WhatsApp
communication using Google.
7.2 Closing WhatsApp
It is best to close WhatsApp by pressing the red key or
simply closing the phone.
If you exit WhatsApp by pressing the Back key, notications for
new WhatsApp messages may be aected.

ENGLISH–20
8. INFO CENTRE
The Info centre basically collects all the information
your phone wants to share with you. This gives
you a better overview and ensures you don't miss
any notications. These can include missed call
notications, new messages, WhatsApp message notications and
update notices for new available system updates.
8.1 Receiving a notication
• If you have missed a call or received a new message
(SMS or WhatsApp), a notice will appear on the home screen.
• Select View to see the call or message immediately
(See »Symbols and operating the phone« on page 03).
8.2 Opening a notication
As soon as an unread notication is available, INFO will be
displayed in the bottom right-hand corner of the home screen.
1. To open the Info centre, press the right function key or
select Menu _Info centre.
2. Tap on a notication in the list displayed. You will be taken
straight to the app the notication refers to.
8.3 Deleting notications
A notication will normally disappear as soon as you have
tapped on it. Regardless of this, however, you can also delete
the entire list by tapping on Delete all.
