LG LG-E405 User manual

Internal Use Only
Service Manual
LG-E405
Date: May, 2012 /Issue 1.0

- 2 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
2. PERFORMANCE...................................................................... 5
2.1 Product Name............................................................................................5
2.2 Supporting Standard..............................................................................5
2.3 Main Parts : GSM Solution.....................................................................5
2.4 HW Features ...............................................................................................6
2.5 SW Features............................................................................................. 10
2.6 HW SPEC. ................................................................................................. 13
3. CIC AND SERVICE CENTER .................................................. 20
3.1 CIC FAQ...................................................................................................... 20
4. TROUBLE SHOOTING .......................................................... 26
4.1 RF Component ....................................................................................... 26
4.2 SIGNAL PATH ...........................................................................................28
4.3 Checking TCXO Block........................................................................... 31
4.4 Checking GSM TX Module(GSM PAM + ASM) Block ............... 33
4.5 Checking WCDMA Block .................................................................... 36
4.6 Checking GSM Block............................................................................47
4.7 GPS/WIFI/BT RF Component ............................................................55
4.8 GPS/WIFI/BT SIGNAL PATH ................................................................57
4.9 GPS/WIFI/BT Trouble shooting ........................................................58
4.10 Power ON Trouble Shooting...........................................................64
4.11 Charging Trouble Shooting............................................................ 67
4.12 3MFF Camera Trouble Shooting................................................... 69
4.13 Main LCD trouble................................................................................ 72
4.14 Proximity Sensor on/o Trouble Shooting............................... 74
4.15 Motion Sensor on/o Trouble Shooting...................................76
4.16 Compass Sensor on/o Trouble Shooting ............................... 78
4.17 DC Motor Trouble Shooting........................................................... 80
4.18 SIM detect Trouble Shooting......................................................... 82
4.19 Audio Troble.......................................................................................... 85
5. DOWNLOAD......................................................................... 95
6.Block diagram ....................................................................115
7. CIRCUIT DIAGRAM ............................................................120
8. BGA PIN MAP.....................................................................129
9. PCB LAYOUT.......................................................................135
10. CALIBRATION...................................................................137
11. HIDDEN MENU.................................................................157
12. DISASSEMBLE GUIDE .................................................163
13. EXPLODED VIEW & REPLACEMENT PART LIST .............168
13.1 EXPLODED VIEW................................................................................168
13.2 Replacement Parts ...........................................................................169
13.3 Accessory .............................................................................................192

- 3 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
1.1 Purpose
This manual provides the information necessary to repair, calibration, description and download the features
of this model.
1.2 Regulatory Information
A. Security
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example,
persons other than your company’s employees, agents, subcontractors, or person working on your
company’s behalf) can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated
with your telecommunications system. System users are responsible for programming and configuring the
equipment to prevent unauthorized use. The manufacturer does not warrant that this product is immune
from the above case but will prevent unauthorized use of common carrier telecommunication service of
facilities accessed through or connected to it. The manufacturer will not be responsible for any charges that
result from such unauthorized use.
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly causing
harm or interruption in service to the telephone network, it should disconnect telephone service until repair
can be done. A telephone company may temporarily disconnect service as long as repair is not done.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these
changes could reasonably be expected to affect the use of the phones or compatibility with the net work, the
telephone company is required to give advanced written notice to the user, allowing the user to take
appropriate steps to maintain telephone service.
D. Maintenance Limitations
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore,
note that unauthorized alternations or repair may affect the regulatory status of the system and may void
any remaining warranty.
1. INTRODUCTION

- 4 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
E. Notice of Radiated Emissions
This model complies with rules regarding radiation and radio frequency emission as defined by local
regulatory agencies. In accordance with these agencies, you may be required to provide information such as
the following to the end user.
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly different.
G. Interference and Attenuation
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
H. Electrostatic Sensitive Devices
ATTENTION
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the sign.
Following information is ESD handling:
• Service personnel should ground themselves by using a wrist strap when exchange system boards. • When
repairs are made to a system board, they should spread the floor with anti-static mat which is also grounded.
• Use a suitable, grounded soldering iron. • Keep sensitive parts in these protective packages until these are
used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as described.

2. PERFORMANCE
- 5 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.1 Product Name
LG-E405 : WCDMA900/2100+EGSM/GSM850/DCS/PCS
(HSDPA 3.6Mbps / GPRS Class 12 / EDGE Class 12 but Rx only)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard WCDMA(FDD1,8)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD8) TX : 880 - 915 MHz
WCDMA(FDD8) RX : 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM7225A: Qualcomm
Analog Baseband PM8029 : Qualcomm
RF Chip RTR6285A : Qualcomm
2. PERFORMANCE
2.1 Product Name
LG-E405 : WCDMA900/2100+EGSM/GSM850/DCS/PCS
(HSDPA 3.6Mbps / GPRS Class 12 / EDGE Class 12 but Rx only)
2.2 Supporting Standard
2.3 Main Parts : GSM Solution

2. PERFORMANCE
- 6 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.4 HW Features
Item Feature Comment
Form Factor DOP type
Battery 1) Capacity
Standard : Li-Ion, 1500mAh
2) Packing Type : Soft Pack
Size Standard :
102.6X 61.6X11.85 mm
Weight 108.46g With Battery
RX sensitivity WCDMA(FDD1) : -106.7 dBm
WCDMA(FDD8) : -103.7 dBm
EGSM : -105dBm
GSM850 : -105 dBm
DCS 1800 : -105 dBm
PCS 1900 : -105 dBm
TX output power WCDMA/22.5dBm/3.84MHz,+1/-3dBm
GSM850, EGSM : 32.5dBm
DCS1800, PCS1900 : 29.5dBm
GPRS
Class3(WCDMA)
Class4
(GSM850,EGSM)
Class1 (DCS, PCS)
EDGE compatibility GPRS Class 12
SIM card
type
EDGE Class
12
Class3(WCDMA)
Class4 (EGSM)
Class4 (GSM850)
Class1 (PCS)
Class1 (DCS)
Plug-In SIM
3V /1.8V
E2 (GSM900)
E2 (PCS)
E2 (DCS)
Display Main LCD
TFT Main LCD(3.2 inch, 320 x 480 )
Built-in Camera 3M CMOS Camera
Status Indicator Yes
Keypad Full Touch Screen
Side Key : 3
Side Key : Power On
Volume up/down
ANT Main : Internal Fixed Type
System connector 5 Pin u-USB
2.4 HW Features

2. PERFORMANCE
- 7 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Ear Phone Jack 3.5 pi type
PC synchronization Yes
Memory eMMC : 2GB
SDRAM : 3Gb
Speech coding FR, EFR, HR,AMR
Vibrator Built in Vibrator
Blue Tooth Bluetooth 3.0+EDR
MIDI(for Buzzer
Function)
SW Decoded 72Poly
Music Player MP3/WMA/AAC/MIDI/EAAC+/HE AAC/OGG
Video Player MPEG4, H.264
Camcorder MPEG4 or H.263
Voice Recording Yes
Speaker Phone mode
Support
Yes
Travel Adapter Yes
CDROM No
Stereo Headset Yes
Data Cable Yes
T-Flash
(External Memory)
Yes ( Up to 32GB )
1) RSSI Display
RSSI BAR WCDMA GSM
BAR 4 --> 3 -89 ±2dBm -91 ±2dBm
BAR 3 --> 2 -97 ±2dBm -99 ±2dBm
BAR 2 --> 1 -105 ±2dBm -104 ±2dBm
BAR 1 --> 0 -110 ±2dBm -106 ±2dBm
Measure RSSI after 10 seconds if you change power.
2) Charging Time
210 minutes under
1) RSSI Display

2. PERFORMANCE
- 8 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
3) Travel Charger
Input : 100 ~ 240 V, 50/60 Hz
Output : 5.1V, 700 mA
4) Battery Type
Li-ion Battery Pack, 1500 mAh
Standard Voltage : 3.7 V, Battery Full Charge Voltage : 4.1V ~ 4.2V
5) Current Consumption
Stand by Voice Call Measurement
Condition
Bluetooth Off Bluetooth
Connected
WCDMA+GSM 7 mA under,
=214 hours over
(DRX=7, PP=5 )
10 mA under
=150 hours over
(DRX=7, PP=5)
300mA under
=300 min over
(Tx=12dBm)
LCD Backlight off
GSM+GSM 4.5 mA under
=333 hours over
(PP5, PP=5)
7.5 mA under
=200 hours over
(PP5, PP=5)
330mA under
=270 min over
(Tx=Max)
LCD Backlight off
WCDMA only 3.0 mA under
=500 hours over
(DRX=7)
6 mA under
=250 hours over
(DRX=7)
300mA under
=300 min over
(Tx=12dBm)
Measure standby
current after 10
minutes after
backlight off.
2) Charging Time
210 minutes under
3) Travel Charger
Input : 100 ~ 240 V, 50/60 Hz
Output : 5.1V, 700 mA
4) Battery Type
Li-ion Battery Pack, 1500 mAh
StandardVoltage : 3.7 V, Battery Full Charge Voltage : 4.1V ~ 4.2V
5) Current Consumption

2. PERFORMANCE
- 9 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
6) Battery Bar
Battery Bar Specification Unit Battery Bar Specification Unit
BAR 20 (Full) OVER 98%
Soc %
BAR 9 -> 8 43% 42%
Soc %
BAR 20 -> 19 98% 97% BAR 8 -> 7 38% 37%
BAR 19 -> 18 93% 92% BAR 7 -> 6 33% 32%
BAR 18 -> 17 88% 87% BAR 6 -> 5 28% 27%
BAR 17 -> 16 83% 82% BAR 5 -> 4 23% 22%
BAR 16 -> 15 78% 77% BAR 4 -> 3 18% 17%
BAR 15 -> 14 73% 72% BAR 3 -> 2 13% 12%
BAR 14 -> 13 68% 67% BAR 2 -> 1 8% 7%
BAR 13 -> 12 63% 62% BAR 1 -> 0 3% 2%
BAR 12 -> 11 58% 57% Low Battery Pop-
up
4% ~ 15% : One Time
popup (No call)
BAR 11 -> 10 53% 52% Critical Low
Battery Pop-up
0% ~ 3% : Every Level
change popup
(No call)
BAR 10 -> 9 48% 47% POWER OFF Below 1%
6) Battery Bar

2. PERFORMANCE
- 10 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.5 SW Features
Item Feature Comment
RSSI 0 ~ 4 Levels
Battery Charging 0 ~ 20 Levels
Key Volume 0 ~ 7 Level
Audio Volume 0 ~ 7 Level
Time / Date Display Yes
Multi-Language Yes English/French/German/Spanish/Italia
n/Danish/Dutch/Korean
Quick Access Mode Dialing/ Contact /Message/Menu
The user can edit as desired icon. (Menu
icon excluded)
Icon on the menu is the LONG-PRESS.
DRAG icon to where you want to
register.
PC Sync Yes
Speed Dial Yes
Profile Yes not same with feature phone setting
CLIP / CLIR Yes
Phone Book
Name / Number / Email /
Website/Postal
addresses/Organizations/Groups/
Birthday / Ringtone
There is no limitation on the number
of items.
It depends on
available memory amount.
Ringtone can be specified in the detail
view screen.
Last Dial Number Yes
Last Dial Numbers, Last Received
Numbers and Last Missed Numbers
can store up to a total of 500.
Last Received
Number Yes
Last Dial Numbers, Last Received
Numbers and Last Missed Numbers
can store up to a total of 500.
Last Missed Number Yes
Last Dial Numbers, Last Received
Numbers and Last Missed Numbers
can store up to a total of 500.
Search by Number
/ Name Name
Group Yes
There is no limitation on the number
of items. It depends on
available memory amount.
2.5 SW Features

2. PERFORMANCE
- 11 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Fixed Dial Number Yes
Service Dial Number No
Own Number Yes
Read only
(add/edit/delete are not
supported)
Voice Memo Yes
Call Reminder No
Network Selection Automatic
Mute Yes
Call Divert Yes
Call Barring Yes
Call Charge (AoC) Yes
Call Duration Yes
SMS (EMS)
There is no limitation on the
number of items. It depends on
available memory
amount.
EMS does not support.
SMS Over GPRS No
EMS Melody /
Picture No
Send / Receive /
Save No
MMS MPEG4
Send / Receive /
Save
Yes
Long Message MAX 2000 characters
Cell Broadcast Yes
Download Over the Web
Game No
Calendar Yes
Memo No
World Clock No
Unit Convert No

2. PERFORMANCE
- 12 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Stop Watch No
Wall Paper Yes
WAP Browser No
Support only web browser based on
webkit. WAP stack and wml are not
supported.
Download Melody /
Wallpaper Yes Over web browser
SIM Lock Yes Operator Dependent
SIM Toolkit Class 1, 2, 3, C
MMS Yes Google MMS Client
EONS Yes
CPHS Yes V4.2
ENS No
Camera Yes 3M FF /
Digital Zoom : x4
JAVA No
Voice Dial No
IrDa No
Bluetooth Yes Ver. 3.0
FM radio Yes
GPRS Yes Class 12
EDGE Yes Class 12
Hold / Retrieve Yes
Conference Call Yes Max. 6
DTMF Yes
Memo pad No
TTY No
AMR Yes
SyncML Yes
IM No
Email Yes

2. PERFORMANCE
- 13 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.6 HW SPEC.
1) GSM transceiver specification
Item Specification
Phase Error Rms : 5°
Peak : 20 °
Frequency Error GSM : 0.1 ppm
DCS/PCS : 0.1 ppm
EMC(Radiated Spurious Emission
Disturbance) GSM/DCS : < -28dBm
Transmitter Output power and Burst
Timing
GSM : 5dBm – 33dBm ± 3dB
DCS/PCS : 0dBm – 30dBm ± 3dB
Burst Timing <3.69us
Spectrum due to modulation out to
less than 1800kHz offset
200kHz : -36dBm
600kHz : -51dBm/-56dBm
Spectrum due to modulation out to
larger than 1800kHz offset to the
edge of the transmit band
GSM :
1800-3000kHz :< -63dBc(-46dBm)
3000kHz-6000kHz : <-65dBc(-46dBm)
6000kHz < : < -71dBc(-46dBm)
DCS :
1800-3000kHz :< -65dBc(-51dBm)
6000kHz < : < -73dBc(-51dBm)
Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0), -23dBm
600kHz : -21dBm/-24dBm(5/0), -26dBm
Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)
Usable receiver input level range 0.012(-15 - -40dBm)
Intermodulation rejection – Speech
channels
± 800kHz, ± 1600kHz
: -98dBm/-96dBm (2.439%)
AM Suppression
-GSM : -31dBm
- DCS : -29dBm
-98dBm/-96dBm (2.439%)
Timing Advance ± 0.5T
2.6 HW SPEC.
1) GSM transceiver specication

2. PERFORMANCE
- 14 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2) WCDMA transmitter specification
Item Specification
Transmit Frequency Band1 : 1920 MHz ~ 1980 MHz
Band8 : 880 - 915 MHz
Maximum Output Power +22.5 dBm / 3.84 MHz, +1 / -3 dB
Frequency Error within ±0.1 PPM
Open Loop Power Control Normal Conditions : within ±9 dB,
Extreme Conditions : within ±12 dB
Minimum Transmit Power < -50 dBm /3.84 MHz
Occupied Bandwidth < 5 MHz at 3.84 Mcps (99% of power)
Adjacent Channel Leakage
Power Ratio (ACLR)
> 33 dB @ ±5 MHz,
> 43 dB @ ±10 MHz
Spurious Emissions
|f-fc| > 12.5 MHz
< -36 dBm / 1 kHz RW @ 9 kHz ≤ f < 150 kHz
< -36 dBm / 10 kHz RW @ 150 KHz ≤ f < 30 MHz
< -36 dBm / 100 kHz RW @ 30 MHz ≤ f < 1 GHz
< -30 dBm / 1 MHz RW @ 1 GHz ≤ f < 12.75 GHz
< -60 dBm / 3.84 MHz RW @ 869 MHz ≤ f ≤ 894 MHz
< -60 dBm / 3.84 MHz RW @ 1930 MHz ≤ f ≤ 1900 MHz
< -60 dBm / 3.84 MHz RW @ 2110 MHz ≤ f ≤ 2155 MHz
< -67 dBm / 100 kHz RW @ 925 MHz ≤ f ≤ 935 MHz
< -79 dBm / 100 kHz RW @ 935 MHz < f ≤ 960 GHz
< -71 dBm / 100 kHz RW @ 1805 MHz ≤ f ≤ 1880 MHz
< -41 dBm / 300 kHz RW @ 1884.5 MHz < f < 1919.6 MHz
Transmit Intermodulation < -31 dBc @ 5 MHz & < -41 dBc @ 10 MHz
when Interference CW Signal Level = -40 dBc
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm
Peak Code Domain Error < -15 dB at Pout ≥-20 dBm
2) WCDMA transmitter specication

2. PERFORMANCE
- 15 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
3) WCDMA receiver specification
Item Specification
Receive Frequency Band1 : 2110 ~ 2170 MHz
Band8 : 925 - 960MHz
Reference Sensitivity Level Band1 : BER < 0.001 when Îor = -106.7 dBm / 3.84 MHz
Band8 : BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
Maximum Input Level BER < 0.001 when Îor = -25 dBm / 3.84 MHz
Adjacent Channel Selectivity
(ACS)
ACS > 33 dB where BER < 0.001 when
Îor = -92.7 dBm / 3.84 MHz
& Ioac = –52 dBm / 3.84 MHz @ ±5 MHz
Blocking Characteristic BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
& Iblocking = -56 dBm / 3.84 MHz @ Fuw(offset) = ±10 MHz
or Iblocking = -44 dBm / 3.84 MHz @ Fuw(offset) = ±15 MHz
Spurious Response BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
& Iblocking = -44 dBm
Intermodulation BER < 0.001 when Îor= -103.7 dBm / 3.84 MHz
& Iouw1 = -46 dBm @ Fuw1(offset) = ±10 MHz
& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(offset) = ±20 MHz
Spurious Emissions < -57 dBm / 100 kHz BW @ 9 kHz ≤ f < 1 GHz
< -47 dBm / 1 MHz BW @ 1 GHz ≤ f ≤ 12.75 GHz
Inner Loop Power Control
In Uplink
Adjust output(TPC command)
cmd 1dB 2dB 3dB
+1 +0.5/1.5 +1/3 +1.5/4
0 -0.5/+0.5 -0.5/+0.5 -0.5/+0.5
-1 -0.5/-1.5 -1/-3 -1.5/-4
group(10equal command group)
+1 +8/+12 +16/+24
3) WCDMA receiver specication

2. PERFORMANCE
- 16 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
4) HSDPA transmitter specification
Item Specification
Transmit Frequency Band1 : 2110 ~ 2170 MHz
Band8 : 925MHz ~ 960 MHz
Maximum Output Power Sub-Test
1=1/15, 2=12/15 21~25dBm / 3.84 MHz
3=13/15 4=15/8 20~25dBm / 3.84 MHz
5=15/7 6=15/0 19~25dBm / 3.84 MHz
HS-DPCCH
Sub-
test
in table
C.10.1.4
Power
step
Power step slot
boundary
Power
step size,
P [dB]
Transmitter power
step tolerance [dB]
5
1 Start of
Ack/Nack
6 +/- 2.3
2 Start of CQI 1 +/- 0.6
3 Middle of CQI 0 +/- 0.6
4 End of CQI 5 +/- 2.3
Spectrum Emission Mask
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
Frequency offset
from carrier △f Minimum requirement Measurement
Bandwidth
2.5 ~ 3.5 MHz -35-15×(△f-2.5)dBc 30 kHz
3.5 ~ 7.5 MHz -35-1×(△f-3.5)dBc 1 MHz
7.5 ~ 8.5 MHz -35-10×(△f-7.5)dBc 1 MHz
8.5 ~ 12.5 MHz -49dBc 1 MHz
Adjacent Channel
Leakage
Power Ratio (ACLR)
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
> 33 dB @ ±5 MHz
> 43 dB @ ±10 MHz
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm
4) HSDPA transmitter specication

2. PERFORMANCE
- 17 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
5) HSDPA receiver specification
Item Specification
Receive Frequency Band1 : 2110 ~ 2170 MHz
Band8 : 925 ~ 960Hz
Maximum Input Level
(BLER or R), 16QAM Only
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
BLER < 10% or R >= 700kbps
6) WLAN 802.11b transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm under
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy
(Peak EVM)
≤ 35%
Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -85dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
5) HSDPA receiver specication
6) WLAN 802.11b transceiver specication

2. PERFORMANCE
- 18 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
7) WLAN 802.11g transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask ≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation
error
(rms EVM)
≤ -5dB
Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※ACR shall be measured by setting the desired signal's strength 3 dB
above the rate-dependent
sensitivity specified in min input sensitivity
7) WLAN 802.11g transceiver specication

2. PERFORMANCE
- 19 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
8) WLAN 802.11n transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask ≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -45 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM)
≤ -5dB
Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity PER ≤ 10%
[email protected], -79dBm@13Mbps, -77dBm@19.5Mbps
-74dBm@26Mbps, -70dBm@39Mbps, -66dBm@52Mbps
[email protected]ps, -64dBm@65Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ [email protected], ACR ≥ 13dB@13Mbps,
ACR ≥ [email protected], ACR ≥ 8dB@26Mbps,
ACR ≥ 4dB@39Mbps, ACR ≥ 0dB@52Mbps
ACR ≥ [email protected], ACR ≥ -2dB@65Mbps
※ACR shall be measured by setting the desired signal's strength 3
dB above the rate-dependent
sensitivity specified in min input sensitivity
9) GPS receiver specification
Item Specification
Receive Frequency 1574.42 MHz ~ 1576.42 MHz
Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding
8) WLAN 802.11n transceiver specication
9) GPS receiver specication

3. CIC AND SERVICE CENTER
- 20 - Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3. CIC AND SERVICE CENTER
3.1 CIC FAQ
No FAQ Q&A
1QI can’t remember the PhoneLock password.
A
1. How to disable Pattern Lock, password, and pin
-> Combine HW Factory Reset key
2. Conrm if it can be written on User manual
-> to be included on E1 manual
3. Instruction of how to set combination of HW Factory Reset key
-> When phone is powered o, press power key and the bottom volume key on E1
-> factory reset starts
1. How to disable Pattern Lock, Password and PIN.
2. Requesting conrmation if it can be noted on User manual.
3. Explanation of HW Factory Reset key combination&methods.
2QWhat should I do to add or remove les to and from the SD card?
A
Plug in a USB cable to transfer your le into SDCard. Install proper USB drivers on your
PC in advance.
1. Attach your phone to the PC with a USB cable. A popup message will be displayed.
Select USB Storage on the popup window. Then, your phone recognizes the
connection and the computer displays a new mobile disk window through which you
can open the folder you want. Choose le to be transferred from PC and copy to the
mobile disk window.
2. If you want to transfer le to PC, follow the same procedure as described above.
Choose le from mobile disk window and copy to PC.
1.PC<-> SD CARD
2.PHONE<-> SD CARD
