EMPORIA MASS-MINGUN1-BL User manual

QUICK-START
GUIDE
MINI MASSAGE
GUN
with 6 massage heads

02
Thank you for choosing the Emporia
Mini Massage Gun.
The device is handy and fits in any pocket.
It produces an effective massage pulse,
offers a long-lasting battery life and 4 intensity
levels. The Massge Gun can effectively relieve
muscle soreness caused by lactic acid build-up after
strenuous exercise.
To use this product properly, please read
the instructions and safety precautions carefully
before use.
Scope of delivery
· Massage Gun
· Spherical massage head
· Conical massage head
· U-shaped massage head
· Shovel-shaped massage head
· Flat massage head
· Thumb-shaped massage head
· USB-C charging cable
· Carrying case
· Quickstart Guide
Keep the packaging materials in a safe place in case you need to
transport the unit later. Keep the receipt, it is your warranty.
WELCOME

03
Usage ......................................................................................................................04
Fields of application........................................................................................05
· Contraindications ...................................................................................................05
Device description ...........................................................................................06
· The massage heads................................................................................................06
Starting ..................................................................................................................07
· Charging the battery .............................................................................................07
· Power indicator.......................................................................................................07
· Changing the massage head ...............................................................................07
Instructions for use..........................................................................................08
· Selecting the intensity level.................................................................................08
· Changing the massage head ...............................................................................08
· Massage heads and their areas of application.................................................09
Muscles ..................................................................................................................10
· Shoulder................................................................................................................... 10
· Abdomen .................................................................................................................10
· Back ........................................................................................................................... 11
· Arms .......................................................................................................................... 12
· Thigh ......................................................................................................................... 13
· Lower leg.................................................................................................................. 13
Troubleshooting................................................................................................ 14
Appendix............................................................................................................... 15
· Cleaning and care................................................................................................... 15
· Precautions .............................................................................................................. 15
· Warranty................................................................................................................... 17
· Technical data .........................................................................................................18
· Declaration of conformity (DoC)......................................................................... 18
TABLE OF CONTENTS

04
The deep action of the device reduces pain, bursitis, muscle spasms,
neuralgia and other musculoskeletal disorders caused by joint
sprains in a short time. Almost all tissue disorders are associated
withinjury trauma, excessive muscle use or abnormal posture
andmost of the calluses associated with these disorders can be
treated with this device.
Do not use the device if you are already undergoing
prolongedphysiotherapy unless your therapist
specicallyadvisesyou to do so.
Do not use the device if you are in an excessively stressful situation,
relax before use. Sensitive areas such as the head, face and cervical
vertebrae should be avoided. If there is inammation, swelling or
pain, stop use immediately.
Current research is looking at the eect of vibration training on
certain medical conditions. It is expected that it will reduce the
above-mentioned complaints, and practical experience has shown
that in many cases integrating vibration training into physiotherapy
is also a recommendation. This must be done in consultation with a
doctor or physiotherapist.
USAGE

05
· Fields of application
· Relief of pain and cramps in muscle bruises, sprains, strains
· Supports the drainage of oedema in the swollen area
· Relaxes thickened connective tissue and fasciae
· Reduces the accumulation of lactic acid in the muscles
· Increases joint mobility
· Faster muscle recovery after exercise
Contraindications
· Aneurysms, bleeding, heart disease
· Use of blood thinners, pacemaker, debrillator
· Pregnancy, cancer
· Within 90 days of intra-articular xation, do not use the device
within8 cm for internal xation.
· Exclude sensitive areas of the body: Head, face, cervical vertebrae,
spine, vertebral bodies.
· Muscle-covered position near bone: humerus, dorsum of foot,
dorsum of hand, etc.
FIELDS OF APPLICATION

06
01 Massage head
Choice of 6 dierent massage heads
02 Intensity display (3 LEDs)
03 Main switch
04 USB-C charging socket
05 Power indicator light
The massage heads
06 Spherical massage head
07 Cone massage head
08 U-shaped massage head
09 Thumb-shaped massage head
10 Shovel-shaped massage head
11 Flat massage head
DEVICE DESCRIPTION
1 3 4 5
6 7 8 9 10 11
2

07
Charging the battery
Before using the massager for the rst time,
you must rst charge it for at least 3½ hours.
· Connect the supplied USB-C charging cable to the massager.
Theconnection for the charging cable is located on the underside
ofthe handle.
· Plug the charging cable into a suitable power adapter.
A full battery charge is sucient for up to 4 hours of operation,
depending on the intensity.
Power indicator
> Charging indicator
· Charging Red, ashes slowly
· Charging completed Green, steady light
> Display during operation
· Charging status ≤20 % Red, ashes
· Charging status 30-50% Green, lit
· Charging status 60-75% Green, ashing
· Charging status 80-100% Green, ashes quickly
Changing the massage head
Before you start massaging, you must rst select the appropriate
attachment. In chapter »Instructions for use« on page08 you will
nd a list of all attachments and their areas of application.
STARTING

08 INSTRUCTIONS FOR USE
Selecting the intensity level
· Press and hold the main switch for 1½seconds to switch on
theappliance and start the rst intensity level.
· Each time you press the main switch, the intensity increases until
youreach the fourth and highest level.
> Intensity display
Intensity level 1:
Intensity level 2:
Intensity level 3:
Intensity level 4: (continuous ashing)
Changing the massage head
Before you start the massage, you must rst select
the appropriate attachment.
To change a massage head, proceed as follows:
· Pull the previous attachment horizontally out of the appliance.
· Push the desired attachment rmly into the massager until you feel
itclick into place.

09
Massage heads and their areas of application
The thumb-shaped massage head is also used for
massaging deep tissues such as joints, palms and soles.
The at massage head is used for the abdominal muscles
and sensitive areas.
The scoop-shaped massage head is suitable for a relaxing
massage of all parts of the body.
The U-shaped massage head is used for massaging
thespine and neck area.
The cone massage head is suitable for massaging deep
tissues such as joints, palms, soles of the feet.
The spherical massage head is used for massaging
thearms, hips and back, as well as large muscle groups.
Apply the massage gun in 20 to 30-second intervals, up to three
times per treatment, taking breaks between intervals for best results.
The direction of massage should be downward.
INSTRUCTIONS FOR USE

10
Shoulder
1. Shoulder blade hyoid muscle
(omohyoid muscle)
2. Anterior stair muscle
(Musculus scanelus anterior)
3. Head turner (sternocleidomastoid muscle)
4. Clavicle (clavicle)
5. Deltoid muscle
(deltoid muscle)
6. Raven's beak process-upper arm muscle
(Musculus coracobrachialis)
7. Two-headed upper arm muscle - biceps
(Musculus biceps brachii)
8. Large pectoral muscle
(pectoralis major muscle)
Abdomen
9. External oblique abdominal muscle
(Musculus obliquus externus abdominis)
10.
Straight abdominal muscle
(Musculus rectus abdominis)
11.
Internal oblique abdominal muscle
(Musculus obliquus internus abdominis)
12.
Iliac crest (Crista iliaca)
13.
Transverse abdominal muscle
(Musculus transversus abdominis)
14.
Pyramidal muscle (Musculus pyramidalis)
MUSCLES
1
2
3
4
5
6
7
8
10
9
11
12
13
14

11
Back
15.Trapezius muscle (trapezius muscle)
16.
Shoulder blade spine
(Spina scapulae)
17.
Infraspinatus muscle
(infraspinatus muscle)
18.
Small round muscle
(Musculus teres minor)
19.
Greater round muscle
(Musculus teres major)
20.
Broad back muscle
(latissimus dorsi muscle)
21.
External oblique abdominal muscle
(Musculus obliquus externus abdominis)
22.
Medial gluteus medius
(Musculus gluteus medius)
23.
Greater gluteus maximus
(Musculus gluteus maximus)
MUSCLES
15
16
17
18
19
20
21
22
23

12
Arms
1. Trapezius muscle (Musculus trapezius)
2. Large pectoral muscle
(Musculus pectoralis major)
3. Deltoid muscle (Musculus deltoideus)
4. Two-headed upper arm muscle – biceps
(Musculus biceps brachii, Caput breve,
Caput longum)
5. Upper arm muscle - arm exor
(Brachialis muscle)
6. Three-headed upper arm muscle – triceps
(musculus triceps brachii, caput laterale,
caput longum, caput mediale)
7. Cartilage muscle (anconeus muscle)
8. Upper arm-spoke muscle
(Brachioradialis muscle)
9. Long radial hand extensor
(Musculus extensor carpi radialis longus)
10.
Radial hand exor
(exor carpi radialis muscle)
11.
Long palmaris tendon
(Musculus palmaris longus)
12.
Supercial nger exor
(Musculus exor digitorum supercialis)
13.
Retaining ligament of
theextensortendons
(Retinaculum musculorum extensorum)
MUSCLES
1
2
3
4
5
8
10
11
12
13
14
15
16
17
18
19
20
24
25
26
27

13
Thigh
14.Thigh band tensioner
(Musculus tensor fasciae latae)
15.
Iliac muscle (Musculus iliacus),
Great lumbar muscle (Musculus psoas
major), ridge muscle (Musculus pectineus)
16.
Slender muscle (Musculus gracilis)
17.
Sartorius muscle (Musculus sartorius)
18.
Straight thigh muscle
(Musculus rectus femoris)
19.
Outer thigh muscle
(vastus lateralis muscle)
20.
Inner thigh muscle
(vastus medialis muscle)
21.
Two-headed thigh muscle
(Musculus biceps femoris, caput longum)
22.
Semi-membranous muscle
(Musculus semitendinosus)
23.
Semi-membranous muscle
(Musculus semimembranosus)
Lower leg
24.Anterior tibial muscle
(Musculus tibialis anterior)
25.
Long bular muscle
(Musculus bularis longus)
26.
Inner calf muscle
(Musculus gastrocnemius, Caput mediale)
27.
Long toe extensor
(Musculus extensor digitorum longus)
28.
Outer calf muscle
(Musculus gastrocnemius, Caput laterale)
29.
Achilles tendon (tendo calcaneus)
MUSCLES
6
7
9
21
22
23
26
28
29

14 TROUBLESHOOTING
Problem Possible cause Solution
Cannot be switched on Battery is weak Charge the product
Turns o during use Battery is low Charge the product
Cannot be charged Voltage and/or
currenterror
Replace the charging
cable and/or AC adapter
Long charging time Charging cable or
ACadapter defective
Replace the charging
cable and/or AC adapter
Does not charge Charging cable or
ACadapter defective
Replace the
chargingcable and/or
the ACadapter

15
Emporia Service Centre
· Emporia Service Centre
[email protected]
Monday-Friday, 12-4 pm
· United Kingdom · EN
www.emporiatelecom.co.uk/
support/contact
[phone]
· Ireland · EN
www.emporiatelecom.ie/
support/contact
[phone]
· Please have your proof of
purchaseready.
Cleaning and care
· Wipe the surface of the product with
a slightly damp cloth and dry it with
asoft cloth.
· When storing the product for a longer
period of time or when travelling,
placeit in the original box of
theappliance and keep it dry.
Precautions
· To reduce the risk of malfunction,
electric shock, injury, re and
equipment damage, please read all
instructions and warnings about this
product in this manual before using
theproduct.
· This product is not intended for medical
use and is for personal massage only.
· Please keep this product out of the
reach of children. Do not allow children
or unauthorised persons to use
thisproduct.
· It is recommended to use the product
on dry, clean skin surface.
· Do not use the product on the head or
on hard or bony parts of the body; use
the product only on the soft tissues
of the body without causing pain or
discomfort.
· Do not use the massager in areas of
bruising, pain or discomfort.
· Excessive use may cause the product
to overheat and shorten the life of
the product. For repeated use, allow
theproduct to cool down for a while
before use.
· Do not use the product in a humid
environment, e.g. in a bathroom.
Do not immerse the product in water
orother liquids to avoid a short circuit
or electric shock.
· Do not place the product near a stove
or in direct sunlight.
APPENDIX

16
· Do not insert foreign objects into the
openings of the product and make sure
that openings remain free of dirt.
· Do not cover the massager during use
to avoid malfunctions due to increased
motor temperature.
· Make sure that ngers, hair or other
parts of the body are not near the
oscillating head, as they can become
trapped.
Disclaimer
· Do not handle the USB-C charging
cable and the massager with wet hands
to avoid short circuit, malfunction or
electric shock.
· Replace the charging cable if it has
been exposed to rain, liquid or heavy
moisture.
· The following persons should not use
the device: Persons with an implanted
pacemaker, persons suering from
heart disease, persons with a straining
back condition, pregnant women
or women shortly after childbirth,
persons with fractures, osteoporosis,
joint diseases, persons with malignant
tumours, traumatic skin conditions or
eczema. If you are not sure whether you
are allowed to use the device, please
consult your doctor rst.
· Do not expose the unit to high
temperatures, such as sunlight, or heat
generating devices, such as heaters,
microwave ovens, cookers or water
heaters. Overheating the unit may
cause an explosion.
· Do not disassemble, modify, insert
foreign objects or immerse the unit in
water or other liquids to avoid battery
leakage, overheating, re or explosion.
APPENDIX

17
Disposal
· Disposing of the packaging
The packaging and packaging
aids are recyclable and should
berecycled.
· Disposing of the battery
Batteries should never be
disposed of as domestic refuse!
As a consumer you are legally
required to return used batteries.
They can be handed in at one of your
community’s local collection points or
at specialist stores.
· Disposing of the device
If this product ever wears out,
please don’t dispose of it as
domestic refuse. To ensure you
don’t cause damage to the
environment, take it to a collection or
recycling centre where used devices
are processed for recycling in an
environmentally friendly manner.
Warranty
· The consumer (customer) is granted
a durability guarantee under the
following conditions, without prejudice
to his claims for defects against the
seller:
· This guarantee applies to new devices
purchased in the European Union.
The guarantor is emporia telecom
GmbH + CoKG, Industriezeile 36,
A-4020Linz.
· New devices and their components that
show a defect due to manufacturing
and/or material faults within 12months
of purchase will be replaced or repaired
free of charge with a device that
corresponds to the state of the art.
· This guarantee does not apply if the
defect in the equipment is due to
improper handling and/or failure to
observe the operating instructions.
· The proof of purchase, with the date of
purchase, is valid as proof of guarantee.
· To redeem this guarantee,
pleasecontact our hotline.
APPENDIX

18 APPENDIX
Technical data
· Model: MASS-MINGUN1-BL (PM18)
· Product size: 43 × 146 × 89 mm
· Weight: approx. 359 g
· Power: Stage 1 ~1800 rpm,
speed 2 ~ 2200 rpm, speed 3 ~ 2600 rpm,
speed 4 ~ 3000 rpm
· Noise decibel: 25 Hz - 45 Hz
· Rated power: 60W/max
· Rated voltage: 7.4V
· Product charging: 5V, 2 A
· Battery runtime: up to 5 h
Declaration of conformity (DoC)
· Manufacturer: emporia telecom GmbH + CoKG
Industriezeile 36 · 4020 Linz · Austria
· Importer: Emporia UK and Ireland Limited
Cardinal Point, Park Road, Rickmansworth,
Hertfordshire,WD3 1RE, UnitedKingdom
· Website: www.emporiatelecom.co.uk or
www.emporiatelecom.ie
· Brand name: emporia
· Model: MASS-MINGUN1-BL (PM-18 Fascia Gun)
· Item description: Muscle fascial massager
The object of the declaration described above complies with the relevant
harmonisation legislation: Directive SI 2016 No.1091
The full text of the Declaration of Conformity is available at the Internet address:
http://www.emporia.eu/doc
Responsible for the accuracy of this data
Eveline Pupeter,
CEO, emporia Telecom
09/05/2022

19

MASS-MINGUN1-BL_BDA-V1-EN· 052022 Misprints, errors and technical changes reserved.
EMPORIA Telecom
GmbH & Co. KG
customercar[email protected]
Industriezeile 36
4020 Linz · Austria
www.emporia.eu
