EQUALIZER - TREBLE ADJUST
Treble Adjust
In EQ adjust mode, when source indicator• 2is
flashing, the keypad is in treble adjust mode.
The center volume indicator will light, showing a•
“flat” adjustment for the treble, no treble increase or
decrease.
Use the• VOL ▲and VOL ▼buttons
to adjust the treble level. Lit indicators
above the center show more treble.
Lit indicators below the center show
less treble.
EQUALIZER - BALANCE ADJUST
Balance Adjust
In EQ adjust mode, when source indicator• 3is
flashing, the keypad is in balance adjust mode.
The center volume indicator will light, showing a•
“center” adjustment for the balance, no extra left
or right.
Use the• VOL ▲and VOL ▼buttons to
adjust the balance. Lit indicators above
the center show more right balance. Lit
indicators below the center show more
left balance.
EQ LOUDNESS OR LIMITER ON & OFF
Loudness On/Off or Limiter/Compressor On/Off
In EQ adjust mode, when source indicator• 4is
flashing, the keypad is in loudness setting mode.
In EQ adjust mode, when source indicator• Lis
flashing, the keypad is in limiter/compressor mode.
Loudness adds extra bass. Limiter/•
compressor automatically limits volume.
Use the• VOL ▲button to turn the option on
(top volume indicator lights).
Use the• VOL ▼button to turn the option off
(bottom volume indicator lights).
DO NOT DISTURB MODE
Preventing a Keypad from Going Into
Whole-house Mode
Press a keypad’s• MUTE button for about
three seconds to prevent the keypad
from allowing whole-house mode.
The keypad will flash to display that if whole-house•
mode is selected by another keypad, this keypad will
not participate.
To allow whole-house mode for the keypad, press the•
MUTE button again for about three seconds.
EQUALIZER & AUDIO DYNAMICS
Adjusting the Keypad’s Sound
Press the• EQ button to enter equalizer
adjustment mode. Press EQ again
to exit.
Equalizer adjustment mode automatically exits after•
30 seconds of keypad inactivity.
The source indicators will light up, then one will flash•
to indicate that the keypad is in equalizer adjustment
mode.
Use the SOURCE button to cycle•
through the five adjustment modes.
EQUALIZER - BASS ADJUST
Bass Adjust
In EQ adjust mode, when source indicator• 1is
flashing, the keypad is in bass adjust mode.
The center volume indicator will light, showing a “flat”•
adjustment for the bass, no bass increase or decrease.
Use the• VOL ▲and VOL ▼buttons to
adjust the bass level. Lit indicators above
the center show more bass. Lit indicators
below the center show less bass.
Copyright © 2009 Linear LLC 229171 B
