ENDA ET2011 User manual

ON/OFF and PID TEMPERA
ET2011-E-04-R
1/4
230V AC +%10 -%20, 50/60Hz or 24V AC %10, 50/60Hz
Max. 5VA
Power connector: 2.5mm²' screw-terminal, Signal connector: 1,5mm² screw-terminal conenction.
EEPROM (minimum 10 years)
Max. 100ohm
12 bit
100ms
Röle : 250V AC, 8A (for resistive load), Selectable as NO+NC Control or Alarm2 output.
°C
Withot load 30.000.000 mechanical operation; 250V AC, on the 8A resistive load 100.000
electrical switching
C/A2 output
ENDA ET2011 TURE CONTROLLER
* 77 x 35mm sized.
Thank you for choosing ENDA ET2011 temperature controller.
TECHNICAL SPECIFICATIONS
* Selectable dual-set value.
* Selectable thermocouple types or Pt100 input.(Selection must be
* Soft-Start feature.
* Automatic calculation of PID parameters.(SELF TUNE).
* Selectable heating/cooling control.
* C/A2 Relay output can be programmable as alarm or control output.
* Selectable SSR control output.
* Input offset feature.
* In the case of sensor failure periodical running or relay state can be
selected.
* CE marked according to European Norms.
Input type Temperature range
J (Fe-CuNi) Thermocouple
K (NiCr-Ni) Thermocouple
T (Cu-CuNi) Thermocouple
S (Pt10Rh-Pt) Thermocouple
R (Pt13Rh-Pt) Thermocouple
EN 60584
EN 60584
EN 60584
EN 60584
EN 60584
0... 600
0...1300
0... 400
0...1700
0...1700
°C
°C
°C
°C
°C
Accuracy
0,5% (of full scale)
0,5% (of full scale)
1 digit
1 digit
0,5% (of full scale)1 digit
0,5% (of full scale)1 digit
0,5% (of full scale)1 digit
+32... +1112
+32... +2372
+32... +752
+32... +3092
+32... +3092
°F
°F
°F
°F
°F
°C °F
SSR output Max 20mA 12Volt (as control output)
SET
°C
SET
ET2011
ENDA
°F C/A2 SSR
A1
F
Pt 100 Resistance thermometer
Pt 100 Resistance thermometer
EN 60751
EN 60751 -200...600 °C -328...1112 °F
-99.9...300.0 °C -99.9...543.0 °F
0,5% (of full scale) 1 digit
0,5% (of full scale) 1 digit
specified in order).
Enter PID parameters of the system if they are known at the beginning.
Otherwise, Self-Tune should be activated.
ENVIRONMENTAL CONDITIONS
Height Max. 2000m
80 up to 31 decreasing linearly 50 at 40. % %
Ambient/storage temperature
Max. Relative humidity
0 ... +50 / °C -25... +70°C (with no icing)
Rated pollution degree According to EN 60529 Front panel : IP65
Rear panel : IP20
Do not use the device in locations subject to corrosive and flammable gases.
OUTPUTS
Life expectancy for relay
ELECTRICAL CHARACTERISTICS
Supply
Power consumption
Wiring
Line resistance
Data retention
EMC
Safety requirements
EN 61326-1: 2006
EN 61010-1: 2010 (Pollution degree 2, overvoltage category II)
CONTROL
Control type Single set-point and alarm control
Control algorithm
A/D converter
Sampling time
Proportional band
Control period
Hysteresis
Output power
Adjustable between 0 and 100 . If Pb=0 , On-Off control is selected.% % %
and 250 secondsAdjustable between 1
1 and 50 Adjustable between °C/F
The ratio of power at a set point can be adjusted between 0 and 100% %
HOUSING
Housing type Suitable for flush-panel mounting according to DIN 43 700.
Dimensions W77xH35xD71mm
Weight Approx. 200g (after packing)
Self extinguishing plastics.
Enclosure material
While cleaning the device, solvents (thinner, benzine, acid etc.) or corrosive materials must not be used.
Read this document carefully before using this device. The guarantee will be expired by
damaging of the device if you don't attend to the directions in the user manual. Also we don't
accept any compensations for personal injury, material damage or capital disadvantages.
Röle : 250V AC, 16A (for resistive load), Selectable as NO Control or Alarm2 output.

SET SET
C.s.lo.= Control set point lower limit.(for
selected output)
Adjustable between 0 and C.s.Hi.
C.s.Hi.= Control setpoint upper limit.(for
selected output)
Adjustable between C.s.Lo. and Upper scale
value.
a2.s.l= Alarm2 set value lower limit.
Adjustable between 0 and A2.S.H
parameter value.
a2.s.H= Alarm2 set value upper limit.
Adjustable between A2.S.L
parameter value and upper scale
value.
a2.Hy= Hysteresis of the Alarm2
output.
Adjustable between 1 and 50 °C.
A2.st. = The state of Alarm2 output.
Hi= If A2 output is above the set
value. (on)
lo= If A2 output is above the set
value.(off)
A2.Er. = State of Alarm2 output in the
case of sensor failure.
on= A2 output is probe failure (on).
off= A2 output is probe faiure (off).
A2.tp = Function of Alarm2 type.
Four kinds of functions can be
selected.
indE.= Independdnt alarm
(Independent)
dE. = Deviation
bAnd = Band alarm (Band)
bAn.i = Band with inhibition
inp.t. = Input type selection.
FE.cn.= J type ,nc.nA.= K type c.cn.= T
type p10.r.=S type , P13.r.= R type
thermocouple selection.
This parameter varies when changing
some parameters.
Unit = The temperature unit.
°C= °C,°F= °F
(This parameter varies when
changing some parameters.)
C.o.sE = Control output selection
C-A2= C/A2 (Relay) output selection
SSR = SSR output selection
F.kE.C. = Function key setting parameter
nonE= Function key is off.
C2.S.A.= The function key with 2.set value is used.
manu. = Manual mode can be achieved with the
function key.
dSP.o.= Only the temperature display mode is
entered with function key.
C. Pb = Proportional band.(for selected
output)
Adjustable between %0.0 and %100.0.
C. Pb= %0.0,On-Off control is selected.
C. ti = Integral time.(for selected output)
Adjustable between 0 and 100.0 minutes.
C. ti = 0.0,integral impact is disable.
parameter is different from “0”,this
parameter appears.
C. Pb
C.Hys = Hysteresis of the output.(for
selected output)
Adjustable between 1 and 50 °C.
= 0,this parameter is active.C. Pb
C. td = Derivative time.(for selected output)
Asjustable between 0.00 and 25.00 minutes.
C. td = 0.0, derivative time is disable.
parameter is different from”0”,this
parameter appears.
C. Pb
C. Ct. = Period time.(for selected output)
Adjustable between 1 and 250 second.
parameter is different is different
from“0”,this parameter appears.
C. Pb
C.p.st = The ratio of output power at the
setpoint.Adjustable between %0 and %100.
C.E.P.s. = The percentage of faulty sensor
selected output power.Adjustable between
%0 and %100.
C.typ. = Control output type
C.typ. = HEAt means heatign control.
C.typ. = CooL means cooling control.
While the parameter names appear,if and
keys are pressed together, returns to the program
mode.
S.Cod = Security menu access
code.
It should be 2011.
Cosc. = Parameters of CoN.o.
menu security access level code.
nonE = Invisible.
P.yEs = Modification can be done.
P. no = Only visible.
m.SEt. = The percentage of manual output parameter.
Adjustable between %0 and %100.
This parameter allows manual adjustment of the output
power when the manual output selection.
C. Pb.= 0, this parameter is not seen.
If co.SE parameter is different
from C-A2,this parameter is seen.
a.2.sc. = Parameters of al2.o.
menu security access level code.
nonE = Invisible.
P.yEs = Modification can be done.
P. no = Only visible.
Co.sc. = Parameters of Conf.
menu security access level code.
nonE = Invisible.
P.yEs = Modification can be done.
P. no = Only visible.
S.t.Sc. = Parameters of S.tun.
menu security access level code.
nonE = Invisible.
P.yEs = Modification can be done.
Co.sc. = Parameters of Conf.
menu security access level code.
no = Parameter settings are not
change.
yEs = Parameter setting will be
restored.
2/4
C.s.Lo.
C.s.Hi.
C. pb
C. ti
C. td
C.p.st
C.Hys
C. Ct.
C.typ
s.s.t.s.
C.E.p.s.
Con.o. AL2.o. ConF. S.tun. SEcu.
S.Cod.
Co.sc.
m.SEt.
a.2.sc.
Cn.sc.
S.t.sc.
dEF.P.
inp.t.
Unit
fltr.
C.o.sE
offs.
s.t.Co.
F.k.E.C.
A2.S.L
A2.S.H
A2.HY
A2.tP
A2.St.
A2.Er.
ET2011-E-04-R
SET SET SET SET SET
F
Programming mode
This parameter indicates the time to reach set point
value when the device is first enegised.
Adjustable between 0 and 250 minutes.
If 0 is selected, soft start feature will be enable and the
device reaches set point value quickly.
Setting Pb = 0, soft start feature will be disable.
Sst.S =Sofy starter timer set value
fLtr.= Coefficient of digital filter.
Filter for display value.
Adjustable between 1 and 200. If this parameter is 1,
digital filter runs most quick. If the parameter is 200,
the filter run most slow. The value of parameter should
be increased in interference.
oFfS. =
Offset value is added to the measurement value.
Adjusted between -100 and +100°C.The normal value is 0.
Offset value.
St.Cu = Self tune control
no= Self tune is stopped.
yES= Self tune is started.
Pressing key after the yes or no
selection, selt tune is started or
stopped.
Selt tune begins when the measurement,
PIdt. message and measurement value
are shown alternately.Self tune process
completed automatically after the stco
parameter is done no and is entered to the
working mode. Self tune process begin when
the measured temperature is expected fall
below 90% of the set value the display shows
te.HImessage alternately.Expected to fall
below the temperature set point 60% evolved
and then self tune process starts automatically.
If asked to abort the self tune process,St.Co
parameter is done no and key is
pressed.
SET
If key is pressed while holding key, the programming mode is enabled.
SET
F
Entering from the programming mode to the run mode:
If no key is pressed within 20 seconds during programming mode, the data is stored automatically and the run mode is entered.
Alternatively, the same function occurs first pressing key and key is pressing programming mode is entered.Then and keys are pressing
together,data is recorded and running mode is entered.
Modification Of Parameter Diagram
When holding key, the value of parameter flashes and using
keys the requested value can be adjusted.
If key is pressed and held 0.6 seconds, the value of the selected
parameter changes rapidly. If waited enough,the value increases 100 at each
step. After 1 second following the release of the key, initial condition is
returned.The same procedure is valid for the decrement key.
Chys
6 5 6
SET SET SET
SET
C.s.lO.inp.t.
A2.s.l Co.sc.
C1.sE.
C.s.Hi.Unit
A2.s.H A2.Sc.
C2.SE.
C. PB Fltr.
A2Hy. Cn.Sc.
A2.SE.
C.HyS C.o.SE.
A2.tp S.t.Sc.
C. ti offs.
a2.st. dEf.P.
C. td f.k.E.C.
a2.Er.
a2.Er.
C. Ct.m.sEt.
C.P.St.
C.EP.S.
S.s.t.S.
C.typ.
TC input TC input TC input
TC input TC input
Pt100 input Pt100 input Pt100 input
Pt100 input Pt100 input
0
FE.cn.
0
025
2
2C-A2
indE P.yEs
P.yEs
400
P.yEs
400
P.yEs
500
4.0 0
Hi no
1.00 nonE
on
no
20 50
0
0
0
HEat
-200 Pt.
-200
600 °C
600
DEFAULT PARAMETERS
Set parameters Control output
parameters Alarm2 output
parameters Configuration
parameters
Self tune
parameters
Security
parameters

SET
°C
SET
ET2011
ENDA
°F C/A2 SSR
A1
F
TERMS
12 mm
( 1 ) Measurement value and set value indicator Running mode)
Parameter name and value (Programming mode)
( 2 ) Value increment key (Programming mode)
If only this key is pressed in normal operation,software version
number is seen. (F.k.E.C. parameter processing)
( 2) Value decrement and parameter selection key.
(Programming mode)
( 4 ) Control ve Alarm set selection key (Running mode)
Parameter set key (Programming mode)
7 segment, 4 digits red LED display
Mikro switch
For control, Alarm1 and SSR outputs 3 digits red LED
MODIFICATION OF CONTROL AND ALARM SET POINTS
ERROR MESSAGES
Character heights
( 2 ),( 3 ),( 4 ) Keypad
( 5 ) State indicator
ALARM2 OUTPUT TYPES
Independent Alarm
A2.tp.=indE Deviation Alarm
A2.tp= dE.
Band Alarm
A2.tp.= bAnd
Band Alarm With Inhibition
A2.tp.= bAn.i
A2.St.= Hi
A2.St.= lo
A1.St.= Lo
A2.St.= Hi
ASV
SV SV
SV
SV+ASV
SV+ASV
SV-ASV
OFF OFF
OFF
OFF OFF
OFF
-300
300
+300
300
ON ON
ON
ON ON
ON
ON ON
OFF OFF
Beginning
SV =Set point of CONT output ASV = Set point of AL2 output (ASV min. = 0, ASV maks. = 300 )
SV = Set point of CONT output ASV = Set point of alarm output
(ASV min. =-300, ASV max. = +300)
(ASV min. = 0, ASV maX. = +300)
(ASV min. = beginning of scale
ASV max. = end of scale)SV =Set point of CONT output ASV = Set point of AL2 output
Band alarm is possible Band alarm is possible
Beginning
SV SV
SV+ASV SV+ASV
SV-ASV SV-ASV
a2,Hy A2.Hy
A2.Hy
A2.Hy
SET
( 1 ) PV and SV display
3/4
( 5 )
3 seconds later
3 seconds later
3 seconds later
3 seconds later
250
pfa
psC
____
C1.SE.
C2.SE.
a2.SE.
400
398
500
399
399
499
SET
C.O.SE.parameter is set to the output of SSR,this
parameter is seen.
Sensor is broken
Pt100 sensor is short circuit
Temperature value is
higher than the value
Temperature value is
lower than the scale
F.kE.C. parameter, is set to the C2.S.A. parameter,this
parameter is displayed.
----
ET2011-E-04-R

SİSEL MÜHENDİSLİK ELEKTRONİK SAN. VE TİC. A.Ş.
Yukarı Dudullu Barbaros Cd. No:18 34775 - ÜMRANİYE/İSTANBUL-TÜRKİYE
Tel : [phone] Pbx. Fax : [phone]
url : www.enda.com.tr 4/4
ET2011-E-04-R
35mm
77mm
5
6
SUPPLY:
NOTE :
184-253V AC
50/60Hz 5VA
Phase
Neutral 230V AC
Supply
Switch
Cable size: 1,5mm²
Fuse
F 100 mA
250V AC
Fuse should
be connected.
Order Code: ET2011-X- XXX- X
Supply voltage
230VAC......230V AC
110VAC......110V AC
024VAC........24V AC
SM.......9-30VDC/7-24V AC
Contact current selection
None......8A contact output
P....16A contact output
Input selection
RT....PT100 input
T....TC input
SET
°C
SET
ET2011
ENDA
°F C/A2 SSR
A1
F
Flush
mounting
clamp
28mm
Panel cut-out
1
Flush mounting
clamp Panel
2
73mm 5mm
Depth
Connection
cable
CONNECTION DIAGRAM
DIMENSIONS
Note
1) Panel thickness should be maximum 7mm.
2) If there is no 60mm free space at back side of the device,
it would be difficult to remove it from the panel.
To remove the device from panel:
ENDA ET2011 is intended for installation in control panels. Make sure that the device is used only for intended
purpose. The shielding must be grounded on the instrument side. During an installation, all of the cables that are
connected to the device must be free of energy. The device must be protected against inadmissible humidity,
vibrations, severe soiling and make sure that the operation temperature is not exceeded. All input and output lines
that are not connected to the supply network must be laid out as shielded and twisted cables. These cables should
not be close to the power cables or components. The installation and electrical connections must be carried on by
a qualified staff and must be according to the relevant locally applicable regulations.
1) Mains supply cords shall meet the requirements
of IEC 60227 or IEC 60245.
2) In accordance with the safety regulations, the
power supply switch shall bring the identification of
the relevant instrument and it should be easily
accessible by the operator.
Note
Holding screw
0.4-0.5Nm
Equipment is protected throughout
by DOUBLE INSULATION.
-While pushing the clamp in direction 1,
pull out it in direction 2.
71mm
8 68040 7 7 11246
8 68040 7 7 11284
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
ENDA INDUSTRIAL ELECTRONICS
ENDA INDUSTRIAL ELECTRONICS
SN: XXXXXXXXX
SN: XXXXXXXXX
ET2011-T-230
PID DIGITAL THERMOSTAT
ET2011-T-230-P
PID DIGITAL THERMOSTAT
230V AC +10% -20%
50/60Hz 5VA
230V AC +10% -20%
50/60Hz 5VA
11
11
12
12
C/A2
250V AC 8A
RESISTIVE LOAD
C/A2
250V AC 16A
RESISTIVE LOAD
TC
TC
++
-
-
-
-
++
SSR OUT
SSR OUT
MADE IN TURKEY
MADE IN TURKEY
8 68040 7 7 11321
1 2 3 4 5 6 7 8 9 10
ENDA INDUSTRIAL ELECTRONICS
SN: XXXXXXXXX
ET2011-RT-230
PID DIGITAL THERMOSTAT
230V AC +10% -20%
50/60Hz 5VA
11 12
C/A2
250V AC 8A
RESISTIVE LOAD
-
+
SSR OUT
PT100
MADE IN TURKEY
8 68040 7 7 11369
PT100
1 2 3 4 5 6 7 8 9 10
ENDA INDUSTRIAL ELECTRONICS
SN: XXXXXXXXX
ET2011-RT-230-P
PID DIGITAL THERMOSTAT
230V AC +10% -20%
50/60Hz 5VA
11 12
C/A2
250V AC 16A
RESISTIVE LOAD
-
+
SSR OUT
MADE IN TURKEY
8
680407711246
1 2 345 6 78910
ENDA INDUSTRIAL ELECTRONICS
SN: XXXXXXXXX
ET2011-T-230
PID DIGITAL THERMOSTAT
230V AC +10% -20%
50/60Hz 5VA
11 12
C/A2
250V AC 8A
RESISTIVE LOAD
TC
+
-
-
+
SSR OUT
MADE IN TURKEY
8
680407711246
1 2 345 6 7810
ENDA INDUSTRIAL ELECTRONICS
SN: XXXXXXXXX
ET2011-T-230
PID DIGITAL THERMOSTAT
230V AC +10% -20%
50/60Hz 5VA
11 12
C/A2
250V AC 8A
RESISTIVE LOAD
TC
+
-
-
+
SSR OUT
MADE IN TURKEY
