INSTAT+ 3R Manual

User and installation guide
+3R
Room temperature Controller
468 931 003 116-1
06490046001 Iss E

I. User Guide
Operation (Overview)
1. Principle of function
INSTAT+the programmable room thermostat allows you to set time periods (up to 6
per day) and temperatures to suit your own lifestyle. Once fully installed and powered
the device will automatically set the correct time and in auto mode will control your
heating system according to pre-set program 1 (see 6.). The temperature is controlled
by sensing air temperature, switching on the heating when the air temperature falls
below the thermostat setting and switching it off once this set temperature has been
reached.
The adjusted values (while programming) will be accepted automatically after ~5 sec.
2. Automatic mode (AUTO)
In this mode, the room temperature is automatically controlled according to the pre-
set program. The pointer indicating the mode is set to AUTO. The number at the bot-
tom right indicates the program event during the day. (Fig. 1)
3. How to change the temperature for a short period of time
(override)
When in AUTO mode, you can override the existing temperature setting for a short
period of time.
Press the + or – buttons to change the temperature setting.
While in temperature override the pointer indicates both AUTO and MAN (Fig. 2).
When the next programmed time/temperature event is reached, the device will revert
to the AUTO mode.
4. How to set a constant room temperature (manual operation)
In this mode, a constant temperature can be set and the pre-set program is ignored.
The temperature last selected is chosen as the initial temperature.
How to activate this mode
Press the < button until the pointer indicates MAN (Fig. 3).
Set the temperature by pressing the +- button
Exit the mode
by pressing the > button
5. How to set the room temperature for a set time
(holiday/party mode)
In this mode, the temperature can be set for periods of time ranging from a few hours
up to 199 days, e.g. when you are away from home for longer periods of time (holi-
days).
The remaining hours/days are shown. Time periods between 1 hour and 23 hours and
1 day and 199 days can be set.
How to activate this mode
Press the < button until the pointer indicates the suitcase icon (Fig. 4)
Set the temperature by pressing the +- button
Select the time by pressing the < button
Set the time by pressing the +– button
Once you have set your time period, the time will flash for 10 seconds and then start
the holiday/party period.
To exit this mode, press < or >.
When hours have been set, the controller will return to AUTO mode once the set
hours have passed.
When days have been set, the controller will return to AUTO mode at midnight of the
last day.
Note: the current day (today) must be included in the setting.
e.g. 1 day is set; the controller returns to AUTO today at midnight.
Fig. 1 Fig. 2
Fig. 3 Fig. 4
Days
Temperature
see note below
+ or – buttons
for setting
values e. g.
temperature
Pointer indicates
the day of the week
Flame icon
(heating on)
Time
Pointer indicates
the current mode
Modes:
automatic, manual,
holiday, day, program
(see 2., 3., 4., 5.)
Moves the pointer
to the left e. g. to
select the mode
Moves the pointer
to the right e. g. to
select the mode
Setting the clock
(see 9.)
Time / Temperature
Program events 1…6
in sequence morning,
midday and night (see 6.)
Note: Temperature displayed is actual room temperature.
After pressing + or - button the set temperature is displayed. Once adjustment
is complete and after 5 seconds display will show actual room temperature.
6. Pre-set programs
There are 3 pre-set time/temperature programs which are already available in the con-
troller. Pre-set program 1 (as shown below) is the default. Therefore, if pre-set pro-
gram 1 is the best program to suit your lifestyle, you do not need to change the
time/temperature settings on the device.
To select an other program see 8.3
Program 1 (home during the day)
Monday to Friday
Events 123456
Time 6:00 8:30 12:00 14:00 17:00 22:00
Temperature °C 21,0 18,0 21,0 18,0 21,0 15,0
Saturday and Sunday
Events 123456
Time 7:00 10:00 12:00 14:00 17:00 23:00
Temperature °C 21,0 18,0 21,0 21,0 21,0 15,0
Program 2 (home for lunch and on weekends)
Monday to Friday
Events 123456
Time 6:00 8:30 12:00 14:00 17:00 22:00
Temperature °C 21,0 18,0 21,0 18,0 21,0 15,0
Saturday and Sunday
Events 123456
Time 7:00 10:00 12:00 14:00 17:00 23:00
Temperature °C 21,0 21,0 21,0 21,0 21,0 15,0
Program 3 (at work all day)
Monday to Friday
Events 123456
Time 6:00 8:30 12:00 14:00 17:00 22:00
Temperature °C 21,0 18,0 18,0 18,0 21,0 15,0
Saturday and Sunday
Events 123456
Time 7:00 10:00 12:00 14:00 17:00 23:00
Temperature °C 21,0 18,0 21,0 21,0 21,0 15,0
7. How to adjust the pre-set time/temperature program to suit
personal needs
Select the day function by pressing the > button up to position "Day"
Select the day by pressing the +- button
Set the times for this day
Select the event (1…6) by pressing the > button
Set the time by pressing the +- button
Select the temperature by pressing the > button
Set the temperature by pressing the +- button
The > button must be pressed to accept a setting.
If you wish to change other events or days, repeat the actions described above. To
return to the auto mode, press the < button.
Note: The last event of the current day can be extended up to the first event of the
following day.
If operating mode "7 days" is chosen (see installer options, option 1), the days can be
selected as blocks or individual days (Fig. 5 to 8).
The blocks are selected by repeatedly pressing the > button.
Note: To facilitate programming, blocks of days with the same times/temperatures can
be formed before starting.
6:00 h 8:00 h 10:00 h 12:00 h 14:00 h 16:00 h 18:00 h 20:00 h 22:00 h
∞C
22
21
20
19
18
17
16
15
14
Mon – Fri
Sat – Sun
6:00 h 8:00 h 10:00 h 12:00 h 14:00 h 16:00 h 18:00 h 20:00 h 22:00 h
°C
22
21
20
19
18
17
16
15
14
Mon – Fri
Sat – Sun
6:00 h 8:00 h 10:00 h 12:00 h 14:00 h 16:00 h 18:00 h 20:00 h 22:00 h
°C
22
21
20
19
18
17
16
15
14
Mon – Fri
Sat – Sun
Table 1 User Options
User
options Description Select between Default
1 Change 12 h or 24 h clock 12 24 24
2 Change he manual set point temperature 7 32 20
3 Change to another pre-set program 1 3 1
4 Change the number of program events per day 2, 4 or 6 6
5 Switch on/off automatic daylight savings time/standard time change ON OFF ON
6 Change temperature display –5.0 5.0 0.0
7 Restore the built in time temperature programs ON OFF OFF
8 Switch off the thermostat ON OFF OFF
Fig. 5: Fig. 6:
Monday to Friday as one block Saturday and Sunday as one block
(working days) (days off)
Fig. 7: Fig 8:
Each day is individual day Monday to Sunday as one block (all days)
8. How to change user options
The controller offers a number of options that can be changed by the user (see Table 1).
To activate the menu, in AUTO Mode press the < and > buttons simultaneously
for 3 seconds
Select an option by pressing the < or > button
Change an option by pressing the +- button
Press < or > to accept each change.
To exit the menu, press the < and > buttons simultaneously for 3 seconds.
If no button is pressed within 2 minutes, the device will return to the auto mode.
8.1 How to change from 24h to 12h clock (option 1, table 1)
Shows the time as 24 hours or 12 hours
8.2 How to change the manual set point temperature (option 2, table 1)
Setting the temperature used when the manual mode is selected for the first time, e.g.
20°C
8.3 How to change to another pre-set program (option 3, table 1)
Selection of a pre-set program to be used for programming events (see 6.).
8.4 How to change the number of events per day (option 4, table 1)
2, 4 or 6 time/temperature events can be selected for all days according to individual
need (not used events will be skipped). If there is no need for e.g. 6 events, choosing
4 makes programming easier.
8.5 How to switch on/off the automatic daylight savings time/standard time
change (option 5, table 1)
You can select whether or not you want the time change to be carried out automati-
cally. If it is not carried out automatically, the time has to be adjusted manually (see
9.).
8.6 How to change the temperature display (option 6, table 1)
The temperature display can be adjusted to individual needs, e.g. 3 = +0,3°; -15 = -1,5°.
8.7 How to restore the built in time temperature programs (option 7, table 1)
Restores the pre-set programs to its original factory settings.
8.8 How to switch off the programmable thermostat (option 8, table 1)
When switched off, the programmable thermostat no longer controls the room tem-
perature and the room is not heated. The display will show OFF, and the buttons will
not function.
In the installer options (refer to Installation Guide) you can select whether or not frost
protection is to active (heating is called for if the temperature falls below 5°C) when
the programmable thermostat is switched off.
9. How to change the time, day, month and year
The controller comes with a pre-set clock, which also automatically switches from day-
light savings time to standard time.
There should be no need to change these settings. However, should the need arise, the
settings can be changed in the following way.
Activate the clock mode:
Select DAY with button > and then Sunday with button +
With button > move through all 6 time/temperature events (without any modifiaction)
until the pointer indicates the clock icon.
The time will now flash.
Set the time by pressing the +- button
Press the > button to select the day Press the +- button to change the setting
Press the > button to select the month Press the +- button to change the setting
Press the > button to select the year Press the +- button to change the setting
Press the > button to return to the AUTO mode

II. Installation Guide
1. Applications:
The electronic thermostat INSTAT+ 3R can be used for temperature controls together
with:
• Actuators of floor heating systems or radiators
• Oil and gas warm water heating
• Circulating pumps
• Heat pumps
• Electric radiators
2. Installation:
Installation location:
The device should be installed in a location in the room which:
• is easily accessible for operation
• is free of curtains, cabinets, shelves, etc.
• allows for free air circulation
• is not subject to direct sunlight
• is not subject to draught (e.g. when windows/doors are opened)
• is not subject to direct influence from the heating sources
• is not on an outside wall
• is about 1.5 m above the floor
The controller must be installed directly onto the wall or on a flush-mounting socket.
1. Remove the front cover using a flat screwdriver and separate from back plate.
2. Attach the back plate to a flush-mounting socket using suitable wall plugs and
screws.
3. Complete the wiring to the heating source according to the wiring diagram inside
the product or below.
4. Replace the front cover by pushing it fully onto the back plate.
The controller is now installed and will automatically start to control the room tem-
perature according to the pre-set program 1 (refer to User Guide).
All important functions are set ex-factory. If you wish to change any of the settings,
please refer to the options in the User Guide.
According to the heating type, refer to item 3.10 (option 11)
LN
Relay
H
L
N
C
On
H = Heating, actuators normally closed
K = Heating, actuators normally open or cooling only
KOff
Caution!
The device must only be opened by a competent electrician and installed accord-
ing to the wiring diagram in the housing cover or this guide. The existing safety
regulations must be complied with.
Appropriate installation measures must be taken to achieve protection class II.
This electronic device which can be installed independently may only be used to
control the temperature in dry and enclosed rooms in a normal environment. The
device is radio-interference suppressed according to VDE 0875 T.14 resp. EN 55014
and functions according to method of operation 1C (EN 60730).
Warning!
Switch off mains supply before removing an existing room thermostat or installing
this controller.
3. Installer options
Attention: The settings should only be carried out by the installer only, as settings may
affect the functions and security of the heating system. List of Installer options see
Table 2.
To activate the menu, press the < and + buttons simultaneously for 5 seconds
Select an option by pressing the < or > button
Change an option by pressing the +- button
Press < or > to accept each change.
To exit the menu, press the < and + buttons simultaneously for 5 seconds.
If no button is pressed within 2 minutes, the controller will return to the auto mode.
3.1 Kind of program (option 1, table 2)
The operating mode of the controller is set via this function.
7 days (7d):
Different time/temperature settings can be chosen for each day individually.
5/2 days (5:2):
Different time/temperature settings can be chosen for the weekdays (Monday to
Friday) and the weekend (Saturday and Sunday) in this mode.
24 hours (24h):
The same time/temperature settings are used for all days of the week in this mode.
3.2 Access protection lock / child lock (option 2, table 2)
When this function is activated, all buttons will be locked.
To switch off the protection lock, enter the installer options and set option 2 to OFF.
3.3 Frost protection (option 3, table 2)
The frost protection of the controller can be activated via this option.
Frost protection will switch on the heating if the room temperature falls to 5°C and
will then control the temperature at 7°C.
When in Off mode frost protection will still be active.
3.4 Low and high limit set points (option 4, 5, table 2)
These limits can be used to prevent temperatures from being set too high or too low.
The set point default values are 32°C (high limit) and 7°C (low limit).
3.5 Optimum start (option 6, table 2)
If this function is activated, the controller will automatically calculate the warm up time
for the heating system in order to achieve the desired temperature for each event.
This function is a major energy saving factor.
Note: This function is only possible in the AUTO mode.
After commissioning, it takes a couple of days for the controller to gather enough
information to correctly calculate this function.
3.6 Heating/cooling (option 7, table 2)
Use this function to select whether the controller is used exclusively for either heating
or cooling applications.
HEATING: The relay will switch on when the temperature falls below the set point.
COOLING: The relay will switch on when the temperature rises above the set point.
3.7 Valve protection (option 8, table 2)
If valve protection is selected, the controller's relay will be switched on once a day at
10 o’clock.
This function is designed to prevent the valves and pumps from getting stuck during
the summer months.
If this is required, select ON in the installer options.
The operating period can be chosen via option 9.
3.8 Valve protection time (option 9, table 2)
The valve protection time can be set between 1 and 5 minutes (default: 3 minutes).
3.9 Emergency heating in case of sensor failures (option 10, table 2)
The following message is shown in case of sensor failures:
E1 for an internal sensor failure
A sensor failure can have the following effects:
1. If this function is activated, the heating is switched on for 30% of the time (this pre-
vents the room from being too cold or overheating)
2. When this function is not activated, the heating is switched off
3.10 Application type (option 11, table 2)
This function is used to select the application type of the controller.
0 = Radiator control or Electric Heat (= default)
1 = Water Floor heating
4. Technical data
Order Type INSTAT+3R
Supply voltage 230 V AC 50 HZ (195 … 253 V)
Temperature setting range 7°C to 32°C
Temperature resolution 0,1°C
Switching current 10mA …. 16(2)A AC 230 V~
Output Relay change over contact, voltage free
Output signal Pulse width modulation (PWM)
Timing resolution 1 minute
Accuracy of clock < 4 Min / year
Ambient temperature Operating 0°C bis 40 °C
Storage –20°C bis 85 °C
Ambient humidity Operating 25 % to 85%
(without condensation)
Storage 15% to 95%
Rated impulse voltage 2,5 kV
Ball pressure test 75°C
Voltage and Current for the for
purposes of interferncemeasurements 230V, 0,1A
Pollution degree 2 (see Caution)
Degree of protection IP 30
Software class A
Weight ~ 200 g
Dimensions
5. Troubleshooting:
1. It is getting warm too late
a. Are clock and program events set correctly?
b. Is the Optimum Start switched on (see 3.5)?
c. Did the thermostat have enough time (some days) to determine the room data?
2. The thermostat does not accept any changes
Is the access protection lock switched on (see 3.2)?
3. E1 is shown in the display:
Sensor failure (see 3.9)
6. Battery handling
Table 2 Installer Options
Installer-
Options Descriptions Select between Default
1 Kind of program 5:2 days (5:2) 7 days (7d) 24 hours (24h) 7 days
2 Access protection lock (child lock) ON OFF OFF
3 Frost protection ON OFF ON
4 Low limit set point °C 7 High limit 7
5 High limit set point °C Low limit 32 32
6 Optimum start ON OFF ON
7 Heating/Cooling Heat Cool Heat
8 Valve protection ON OFF ON
9 Valve protection time 1 … 5 3
10 Emergency heating (sensor failure) ON OFF OFF
11 Application type Radiator (0) Water Floor heating (1) 0
Batteries, rechargeable or not, should not to be disposed of into
ordinary household waste. Instead, they must be recycled properly to
protect the environment and cut down the waste of precious resources.
Your local waste management authority can supply details concerning
the proper disposal of batteries.
In compliance with the EU Directive 2006/66/EC, the button cell battery located on
the printed circuit board inside this product, can be removed at the end of the
product life, by professional personnel only.
