• Replacethecoverontheterminalblock.
• Lifttheproductintoplaceandalignthescrewholesup
withtheholesonthebracket.
• Using the supplied allen key, tighten the screws to
secure.Takecarenottotrapanywiring.
• Replacefuseorcircuitbreakerandswitchon.Yourlight
isnowreadyforuse.
• Whenchangingabulb,alwaysswitchoffatthemains
andallowthebulbtocoolbeforehandling.Usedbulbs
shouldnotbedisposedofwithhouseholdwaste.Please
recyclewherefacilitiesexist.
• Alwaysusethecorrecttypeandwattagebulb.Usingthe
incorrectwattagebulbwilldamagetheproduct.
• Useasoftclothtohandlebulbs,avoiddirectlytouching
thebulbsasthiswillshortentheirlife.
• Unscrewtheshadesanticlockwise.Removebulbby
turningaquarterturnanticlockwiseandpullingout.
• Pushthebulbgentlyintothelampholderandtwista
quarterturnclockwisetoengagepins.Replacetheshade
bygentlyscrewingon.
Commissioning
Fitting/replacing bulbs
Instructionleaflet
Knight Spotlight
39166
Foryoursafety,alwaysswitchoffthesupplybeforechanginglightbulbs,orcleaning.
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilitiesexist.
CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
EndonLightingLS90SE
Werecommendcleaningwithasoftdrycloth.
Donotusesolventsorabrasivecleanersasthesecould
damagethefinish.
Glassparts–Wipecleanwithadampcloth.Donotuse
abrasivematerialsasthesewilldamagethefinish.
Thisbulbisprotectedbyaglassshade.Thispartmustbereplacedimmediatelyshouldtheglass
shadebecomecrackedordamaged.Thisfittingmustnotbeusedwithouttheglassshadeinplace.
ReplaceCrackedShade
35W GU10
Mains Halogen
Iss.313022017

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeandsatisfactory
operationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
This light fitting is double insulated (class 2) and
does not require connection to an Earth circuit
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisunitmustbefittedbyacompetentandqualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
beforeinstallingormaintainingthisfitting.Ensureother
personscannotrestoretheelectricalsupplywithoutyour
knowledge.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Ifreplacinganexistingfitting,makeacarefulnoteofthe
connections.
Alwaysusethecorrecttypeandwattagebulb.Never
exceedthewattagestated.
Whenchangingabulb,alwaysswitchoffatthemainsand
allowtheoldbulbtocooldownbeforehandling.
Disposeofusedbulbscarefullyandresponsibly.
Thisproductissuitablefordimmingwhenusedin
conjunctionwithadimmablelamp.Pleaseensure
verificationofdimmingabilitieswiththelamp
manufacturepriortouse.
Wasteelectricalproductsshouldnotbedisposedofwith
householdwaste.Pleaserecyclewherefacilitiesexist.
Checkwithyourlocalauthorityorretailerforrecycling
advice.
Specification
Voltage: 240V50Hza.c.
Lamp: 1x35WGU10Halogen
IPrating: 44
Layout
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Beforeremovingtheexisting
fitting,carefully note the position of each set of wires.
• Undothescrewsholdingthefixingbracket
 inplaceandsetaside
• Holdtheproductinplaceandmarkthepositionofthe
holes.
• Ensuretheceilingiscapableofholdingtheweightof
theproduct.Takecaretoavoiddamaginganyconcealed
wiringandpipes.Thecorrectfixingsshouldbeused.
Ensurethereisajoistatthepointoffixingtosupportthe
weightoftheproduct.
• Fixtheceilingbracketintoposition.
Installation
Wiring
Havingcorrectlyidentifiedthewiringfromyourexistinglight
fitting,pullthewirethroughtheholeandconnecttothe
connectionblockinsidetheproductinthefollowingway:
Thisunitisdoubleinsulatedandmustnotbeearthed.If
thereareanyincomingearthcables,theymustbejoined
togetherandwellinsulatedwithgoodqualityinsulationtape.
Thisistoensureearthcontinuitythroughoutyourproperty.
Check that...
• Youhavecorrectlyidentifiedthewires
• Theconnectionsaretight
• Noloosestrandshavebeenleftoutoftheconnection
block.
0.2m
OUTSIDE ZONES
ZONE
2
ZONE
1
0.6m
0.6m
2.25m
Ceiling
Spotlightsgiveaconcentratedbeam
oflightandmustnotbepositioned
anycloserthan0.2M(20cm)tothe
illuminatedsurface.
ThisproductissuitableforuseinZone
2andoutsideZonesofabathroom.
Seediagram.Ifthisunitisbeing
fittedinaroomcontainingabathor
shower,a30mARCDmustbeused,in
accordancewithIEEregulations.
• Planthedesiredlayoutofthisfittingcarefully,ensuring
thecableswillreachthedistancebetweenthejunction
boxandthelightfitting
• Avoidlocatinganycablesinpositionsthatwouldcause
ahazard.Positioncablesandjunctionboxes(not
supplied)awayfromareaswheretheymaybeatrisk
frombeingcut,trappedordamaged
• Themainssupplycablemusthaveaminimumcross
sectionalareaof1.0mm²
• Thisproductmustbemountedoutofarmsreach.
• Thisproducthasspecialprotectionagainsttheingress
ofmoistureandisIP44rated.
