Robert Juliat SULLY 1156 User manual

Manual
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : [phone] - fax : [phone] - [email protected]
www.robertjuliat.com
LED FOLLOWSPOT
DN41202000 (EN)
115 W FOLLOWSPOT
Model Standard North American
10.5° – 22.5° Warm White 1156WW 1156CWW
10.5° – 22.5° Cool White 1156CW 1156CCW
VALIDATION : 14/04/22
V1
- FIRMWARE: V3.0
- RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is
available for download at robertjuliat.com/LED/PDF_PAGE

Robert Juliat reserve the right to change or alter any of the items detailed on this page,
to increase or improve manufacturing techniques without prior notice.
Table of Contents
1 User’s instructions ...............................................................................................................................................................................................................................................................................................1
2 Presentation .........................................................................................................................................................................................................................................................................................................2
2.1 Functions ................................................................................................................................................................................................................................................................................................. 2
2.2 Identication labels................................................................................................................................................................................................................................................................................ 2
2.2.1 label on LED compartment........................................................................................................................................................................................................................................................................................... 2
2.2.2 label on lighting unit...................................................................................................................................................................................................................................................................................................... 3
2.3 Accessories included............................................................................................................................................................................................................................................................................... 3
2.4 Accessories............................................................................................................................................................................................................................................................................................... 4
3 Set-up ....................................................................................................................................................................................................................................................................................................................5
3.1 Mechanics................................................................................................................................................................................................................................................................................................ 5
3.1.1 Operating positions........................................................................................................................................................................................................................................................................................................ 5
3.1.2 Minimum distance between a ammable material and the lighting unit ....................................................................................................................................................................................................... 5
3.1.3 Instructions for use ......................................................................................................................................................................................................................................................................................................... 5
3.1.4 Lifting................................................................................................................................................................................................................................................................................................................................. 5
3.1.5 Stand set-up ..................................................................................................................................................................................................................................................................................................................... 6
3.2 Electrical information ............................................................................................................................................................................................................................................................................ 6
3.2.1 LED source......................................................................................................................................................................................................................................................................................................................... 6
3.2.2 Power supply. ................................................................................................................................................................................................................................................................................................................... 6
3.3 DATA.........................................................................................................................................................................................................................................................................................................7
3.3.1 DMX 512-A / RDM ........................................................................................................................................................................................................................................................................................................... 7
3.3.2 Art-Net / sACN.................................................................................................................................................................................................................................................................................................................. 8
3.3.3 Ethernet / DMX node ...................................................................................................................................................................................................................................................................................................... 8
3.4 Accessories............................................................................................................................................................................................................................................................................................... 9
3.4.1 Iris........................................................................................................................................................................................................................................................................................................................................ 9
3.4.2 Gobo holder...................................................................................................................................................................................................................................................................................................................... 9
3.4.3 Internal lter holder..................................................................................................................................................................................................................................................................................................... 10
3.4.4 Colour changer unit - push-pull ................................................................................................................................................................................................................................................................................ 10
3.4.5 Double slot front cassette for front accessories (option)..................................................................................................................................................................................................................................... 11
3.4.6 Double-condenser set.................................................................................................................................................................................................................................................................................................. 12
4 Operations ......................................................................................................................................................................................................................................................................................................... 13
4.1 Light intensity .......................................................................................................................................................................................................................................................................................13
4.1.1 Range...............................................................................................................................................................................................................................................................................................................................13
4.1.2 Control ............................................................................................................................................................................................................................................................................................................................ 13
4.1.3 Parameters......................................................................................................................................................................................................................................................................................................................13
4.1.3.1 Dimming resolution - DMX only.................................................................................................................................................................................................................................................................. 13
4.1.3.2 Dimming curve................................................................................................................................................................................................................................................................................................ 14
4.1.3.3 Master control.................................................................................................................................................................................................................................................................................................. 14
4.1.3.4 Set maximum position .................................................................................................................................................................................................................................................................................. 14
4.1.3.5 Dimming mode ...............................................................................................................................................................................................................................................................................................15
4.2 Strobe.....................................................................................................................................................................................................................................................................................................15
4.2.1 Range...............................................................................................................................................................................................................................................................................................................................15
4.2.2 Control............................................................................................................................................................................................................................................................................................................................. 15
4.3 Response time .......................................................................................................................................................................................................................................................................................15
4.3.1 Range...............................................................................................................................................................................................................................................................................................................................15
4.3.2 Control ............................................................................................................................................................................................................................................................................................................................ 16
4.4 Beam size adjustment..........................................................................................................................................................................................................................................................................16
4.4.1 Range...............................................................................................................................................................................................................................................................................................................................16
4.4.2 Control............................................................................................................................................................................................................................................................................................................................. 16
4.5 Orientation............................................................................................................................................................................................................................................................................................ 17
4.5.1 Range...............................................................................................................................................................................................................................................................................................................................17
4.5.2 Control ............................................................................................................................................................................................................................................................................................................................ 17
4.6 Iris ...........................................................................................................................................................................................................................................................................................................18
4.6.1 Range...............................................................................................................................................................................................................................................................................................................................18
4.6.2 Control............................................................................................................................................................................................................................................................................................................................. 18
4.7 Gobo.......................................................................................................................................................................................................................................................................................................18
4.7.1 Range...............................................................................................................................................................................................................................................................................................................................18
4.8 Colour.....................................................................................................................................................................................................................................................................................................18
4.8.1 Range .............................................................................................................................................................................................................................................................................................................................. 18
5 Controls and parameters ................................................................................................................................................................................................................................................................................ 20
5.1 Web interface ........................................................................................................................................................................................................................................................................................20
5.1.1 Control............................................................................................................................................................................................................................................................................................................................. 20
5.1.2 Default IP address......................................................................................................................................................................................................................................................................................................... 20
5.1.3 Network IP of the computer........................................................................................................................................................................................................................................................................................ 20
5.1.4 Connect to web interface ............................................................................................................................................................................................................................................................................................20
5.1.5 CCT selection .................................................................................................................................................................................................................................................................................................................. 21
5.2 LEDs Feedback ......................................................................................................................................................................................................................................................................................22
5.2.1 Trouble shooting ........................................................................................................................................................................................................................................................................................................... 22
5.2.2.1 Intensity.............................................................................................................................................................................................................................................................................................................. 22
5.2.2.2 Auto-OFF........................................................................................................................................................................................................................................................................................................... 22
5.3 DMX512 - A remote control .................................................................................................................................................................................................................................................................23
5.3.1 Protocol ........................................................................................................................................................................................................................................................................................................................... 23
5.3.2 Conguration................................................................................................................................................................................................................................................................................................................. 23
5.3.3 Parameters......................................................................................................................................................................................................................................................................................................................23
5.3.3.1 DMX Hold........................................................................................................................................................................................................................................................................................................... 23
5.3.4 DMX chart.......................................................................................................................................................................................................................................................................................................................24
5.3.5 DMX ranges.................................................................................................................................................................................................................................................................................................................... 24
5.3.5.1 Strobe duration ............................................................................................................................................................................................................................................................................................... 24
5.3.5.2 Strobe speed..................................................................................................................................................................................................................................................................................................... 24
5.3.5.3 Response time.................................................................................................................................................................................................................................................................................................. 24
5.3.5.4 Control mode ...................................................................................................................................................................................................................................................................................................24
5.4 RDM remote control .............................................................................................................................................................................................................................................................................25
5.4.1 Protocol ............................................................................................................................................................................................................................................................................................................................ 25
5.4.2 Functions.........................................................................................................................................................................................................................................................................................................................25
5.5 Art-Net remote control.........................................................................................................................................................................................................................................................................27
5.5.1 Protocol ........................................................................................................................................................................................................................................................................................................................... 27
5.5.2 Conguration................................................................................................................................................................................................................................................................................................................. 27
5.6 sACN remote control.............................................................................................................................................................................................................................................................................27
5.6.1 Protocol ...........................................................................................................................................................................................................................................................................................................................27
5.6.2 Conguration................................................................................................................................................................................................................................................................................................................ 27
6 Service ................................................................................................................................................................................................................................................................................................................ 28
6.1 Preventive maintenance......................................................................................................................................................................................................................................................................28
6.1.1 Frequency....................................................................................................................................................................................................................................................................................................................... 28
6.1.2 General cleaning ...........................................................................................................................................................................................................................................................................................................28
6.1.3 General visual check.....................................................................................................................................................................................................................................................................................................28
6.1.4 LED source....................................................................................................................................................................................................................................................................................................................... 28
6.1.5 Optics ...............................................................................................................................................................................................................................................................................................................................28
6.1.6 LED house cleaning......................................................................................................................................................................................................................................................................................................28
6.2 Analysis..................................................................................................................................................................................................................................................................................................29
6.3 Electronic thermal management system........................................................................................................................................................................................................................................... 30
6.4 Firmware update ..................................................................................................................................................................................................................................................................................30
6.5 Factory defaults ....................................................................................................................................................................................................................................................................................31
6.5.1 Modes............................................................................................................................................................................................................................................................................................................................... 31
6.5.2 Control............................................................................................................................................................................................................................................................................................................................. 31

EN
EN - 1 -
GENERAL INSTRUCTIONS
1. Not for residential use.
2. These fixtures must only be serviced by a qualified technician.
3. In addition to the instructions indicated on this page, relevant health and safety requirements of the appropriate EU
Directives must be adhered to at all times.
4. This fixture is in compliance with section 17 - Lighting appliance for theatre stages, television, cinema and photograph studios.
Standards NF EN 60598-1, NF EN 60598-2-17, Low Voltage Directive 2014/35/UE & EMC Directive 2014/30/UE.
5. This fixture is rated as IP20, and is for indoor use only.
FIXTURE
6. Ensure fixture is correctly mounted on an appropriate support.
7. Protection screens and lenses must be replaced in the event of any damage, such as cracks or deep scratches, since these might
reduce performance.
8. When hung or flown the fixture must be secured by an additional hanging accessory (such as a safety cable or bond) of suitable
length.
9. Safety bonds or cables must be securely attached to the back of the fixture and be as short as possible, or rolled up as necessary,
to minimise travel distance should the fixture be dislodged.
10. Movable accessories (scroller, etc.) must also be secured with a suitable safety cable or bond at the front of the fixture.
11. The combined weight of both the fixture and the accessories must be considered when choosing the load-bearing capability of
safety cable or bond.
12. Do not open lighting fixture when the source is on.
13. WARNING: LED source become hot during use. Allow fixture to cool before servicing.
14. Do not tamper with design of fixture nor any of its safety features.
15. Tighten electrical mains cable connections regularly and replace with one of identical specification if damaged.
16. Use only with correct power supply.
VENTILATION
17. Keep well away from flammable material.
18. Not for outdoor use. Do not cover. Do not permit fixture to get wet.
19. To avoid overheating, do not obstruct air vents.
20. Ensure any cooling fans are in correct working order. If fans are not working, turn fixture off immediately and service as necessary.
CLEANING
21. Do not touch the LED source with your fingers.
22. To clean the optical parts, use a soft cloth in combination with distilled water or isopropyl alcohol recommended for coated optics.
Do not use any cleaning product that contains solvents or abrasives, as these can cause surface damage. Dry with a soft lint-free cloth.
23. Regularly remove dust with a soft lint-free cloth.
24. If the fixture has filters, they must be cleaned frequently.
POWER SUPPLY
25. Disconnect from the mains before servicing.
26. Mains connection only. Do not connect to "electronic output" such as dimmer.
27. Ensure power supply circuit breakers, always remain accessible.
PLEASE NOTE
This product has been built to conform to European standards relating to professional lighting equipment.
Any modification made to our products will void the manufacturers' warranty.
1 User’s instructions
Minimum
distance
Risk
group 2
0,8m (2.63 ft ) 10,6m (34.78 ft )
Risk
group 1
Photobiological safety according to EN62471
Risk group 2
CAUTION: Possibly hazardous optical
radiation emitted from this product.
Do not stare at operating lamp.
Maybe harmful to the eye.
Group risk 2. Luminaires should be positioned so that
prolonged staring into luminaire at a distance closer than
10,6m is not expected.

EN
EN - 2 -
2 Presentation
2.1 Functions
2.2 Identication labels
2.2.1 label on LED compartment
Description
1. Identification plates
2. Data connector (IN and OUT)
3. Power connector (IN and OUT)
4. RJ45 network connector
5. Handle
6. Safety cable attachment point
7. Tilt index
8. Yoke
9. Locking handle
10. Focus adjustment
11. Lens tube access
12. Colour changer
13. Zoom adjustment
14. Gate: slots for gobo holder and/or iris
15. Iris
16. Gobo holder
17. Dimmer
1
1
3
2 4
6
5
11
7
15
16
17 14
8
10
12
13
9
Description
Units :
- Weight = kilogram (kg).
- Intensity = Ampere (A).
- Voltage = Volt (V).
- Frequency = Hertz (Hz).
- Temperature = degree Celsius (°C).
1. MOD. : Model
2. VERS. : Version
3. U : Nominal voltage input (V)
4. I : Nominal intensity (A)
5. P : Maximum power input (W)
6. IP : International Protection Rating
7. t°a : Maximum ambient temperature (°C)
8. t°c : Maximum external temperature of the unit (°C)
9. Net weight (kg)
10. Minimum distance between a flammable
material and the lighting unit (m)
11. Colour temperature version
12. Serial number
13. Replace broken glass
14. Class 1 product label
15. Read manual first label
16. European conformity label
17. WEEE directive label
18. CEI-TR-62778 - Do not stare at light source
19. EN62471 - Risk group
20. UKCA (UK Conformity Assessed) label
1 2
34
5 6
7 8
9
10
11
12
13 14
18 15 16 2019 17

EN
1
243 5 6 7
EN - 3 -
2.2.2 label on lighting unit
2.3 Accessories included
Reference Description
1 CAL03 Power cable with CEE 7/7 type in connectors (standard version)
2 CAL04 UL/CSA power cable without connector (North-American version)
3 DN41202400 Quick Start manual
4 SGUX Universal "A" size gobo holder (metal, glass or frosted glass)
5 IS750 Full closing iris with holder
6 PF1114 Ø165 mm metal filter holder (x6)
7 M165TP 6-way "push/pull" colour changer
Description
Units :
- Weight = kilogram (kg).
- Intensity = Ampere (A).
- Voltage = Volt (V).
- Frequency = Hertz (Hz).
- Temperature = degree Celsius (°C).
1. Model beam angles
2. Net weight (kg) without LED compartment
3. Serial number
4. Class 1 product label
5. Read manual first label
6. European conformity label
7. WEEE directive label
8. Operating positions
9. UKCA (UK Conformity Assessed) label
3 6 9
7
5
124 8

EN
EN - 4 -
5
8
9
76
2.4 Accessories
1 2 3 4
15
12 13 1411
10
Reference Description
1 VD120 120 x 120 mm frosted glass
2 GT800 Tripod stand GT800 - SWL: 40 kg max. height 1550 mm
3 GT1000 Tripod stand GT1000 - SWL: 40 kg max. height 1550 mm
4 T1000 TV spigot with followspots swivel head
5 Kit TELRAD Followspot sight with riser
6 APH 68LED Double-condenser set for Led profile
7 CAV600A Double slot front cassette for 180x180mm accessories
8 PCP1716A 16A blue 2P+E 6h IEC60309 power connector
9 T/1650SXCW SULLY 115W LED compartment with potentiometer - Cool White - 3 meter power cable with
CEE 7/7 (2P+T NF/SCHUKO) connector
10 T/1650SXWW SULLY 115W LED compartment with potentiometer - Warm White - 3 meter power cable with
CEE 7/7 (2P+T NF/SCHUKO) connector
11 FC1124/S Transport flight-case for ultra compact range followspots
12 W/GT800 Set of 3 wheels for GT800/1000 stands
13 SDUP Followspot cue sheet holder with universal mounting kit
14 T4000 Followspot mount for Ø50 mm pipe (suspension or overhead) - SWL= 100 Kg
15 DMXcat Bluetooth DMX/RDM Multifunction test tool - City Theatrical DMXcat®

EN
EN - 5 -
3 Set-up
3.1 Mechanics
3.1.1 Operating positions
3.1.2 Minimum distance between a ammable material and the lighting unit
3.1.3 Instructions for use
3.1.4 Lifting
• Net weight: 15.6 Kg (34,3 lbs).
Minimum : 40°C
104°F
5°C
40°F
IP20 - Indoor use only
Maximum :
0,8 m
2.6 ft

EN
EN - 6 -
Power supply
Voltage Frequency Input power Connectors
100 T264 V 50-60 Hz
0,7 A / 130 W @ 230V
1,15 A / 135 W @ 120V
1,40 A / 135 W @ 100V
Max: 1,5A
Standby mode: 10W
Neutrik powerCON TRUE1 TOP
Input :
ref. NAC3FPX-TOP
3.2 Electrical information
3.2.1 LED source
Never touch or scratch the LED surface.
See 6.1.4 LED cleaning procedure if cleaning is necessary.
3.2.2 Power supply
• Class 1 product. This luminaire must be earthed.
• Must be connected directly to AC power. Do not connect to dimmer power.
• Automatic mains voltage detection.
Power
Maximum :
22 units @ 230V
11 units @ 120V
3.1.5 Stand set-up
• Compatible stands : GT800 & GT1000
Please refer to the relevant user manual for further details.
Daisy chain (with delivered power cable):

EN
2
1
In Out
DMX OUT DMX IN
1
22
3
3
4
4
55
1
EN - 7 -
Power cable
Power cable Connector Mains plug Cable type Cable length Wiring
1 Standard
version Neutrik®powerCON
TRUE1 TOP
NAC3FX-W-TOP
CEE7/7 3G1.5
H07RNF
3 m
9.8 ft
Live: Brown
Neutral: Blue
Ground: Yellow/Green
2
North
American
version
-
14AWG
SJ TYPE
(UL/CSA)
1.5 m
4.9 ft
Live: Black
Neutral: White
Ground: Green
DATA connectors
PIN # DMX Description
1 Shielding Foil & Braided Shield
2 DMX (-) 1st conductor of 1st twisted pair
3 DMX (+) 2nd conductor of 1st twisted pair
4 Not used 1st conductor of 2nd twisted pair
5 Not used 2nd conductor of 2nd twisted pair
3.3 DATA
3.3.1 DMX 512-A / RDM
Protocol Input connector Output connector
USITT DMX 512-A
RDM XLR 5-pin XLR 5-pin
Maximum :
31 units total
Daisy chain:
DMX Console

EN
EN - 8 -
3.3.2 Art-Net / sACN
Protocol Input connector Output connector
Art-Net
sACN RJ45 -
Protocol Input connector Output connector
Art-Net
sACN RJ45 DMX
3.3.3 Ethernet / DMX node
Network
switch*
Art-Net
sACN
(*) A 1000 base-T switch that supports IGMP (Internet Group Management Protocol) is necessary if the unit is connected
to a network switch to control multiple devices. The usage of non IGMP switch capability can cause erratic behavior of all
connected devices.
For further reading: https://en.wikipedia.org/wiki/Internet_Group_Management_Protocol
RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is available for download at robertjuliat.com/LED/PDF_PAGE
Web
interface
Web
interface Lighting desk
Lighting desk
Daisy chain:
Fixture Fixture
Fixture
Network
switch
Fixture Fixture (NODE)Fixture
- Node function must be activated only on the first unit of the daisy chain
(see Web Interface section of the manual).
- Web interface is always available regardless of the protocol (Art-Net / sACN) selected.
DMX
Art-Net
sACN
Limited to
15 Fixtures
Daisy chain:

EN
EN - 9 -
3.4 Accessories
3.4.1 Iris
Gobo
For filter dimensions,
see section 4.7
"Click":
Correctly in place.
Iris / Gobo holder
Filter holder
3.4.2 Gobo holder
"Click":
Correctly in place.

EN
EN - 10 -
3.4.3 Internal lter holder
For filter dimensions,
see section 4.8
3.4.4 Colour changer unit - push-pull
Gel filter
DImensions, see section 4.8
Paper fastener (Parisien)
(3 pieces on each frame)

EN
EN - 11 -
For filter dimensions,
see section 4.8
Front filter holder / Safety grid
3.4.5 Double slot front cassette for front accessories (option)

EN
EN - 12 -
For full procedure,
see page EN-29
APH68 LED only possible with LED version
(not with halogen).
3.4.6 Double-condenser set

EN
0% 100%
or
RDM
Web
interface
RDM
compatible
device
HTP mode (Highest Takes Precedence):
Light output is the highest value of DMX512 command or local control
EN - 13 -
4 Operations
4.1 Light intensity
4.1.1 Range
4.1.3 Parameters
4.1.3.1 Dimming resolution - DMX only
TSet through RDM protocol or web interface
Resolution DMX mode
8 bits – 255 steps 1 - 3
16 bits – 65 535 steps 2 - 4
4.1.2 Control
DMX512-A
Remotely with DMX512-A /
Art-Net / sACN protocols.
TSet through RDM protocol
or web interface
Locally via rotary knob
Rotary knob

EN
EN - 14 -
4.1.3.4 Set maximum position
TSet through RDM protocol or web interface
4.1.3.3 Master control
In order to supervise the operator from the console, master control DMX channel can be used.
This channel limits the maximum value of the dimmer shutter.
By using this function, it is possible to obtain synchronised fades with several spots or to give intensity
limits (minimum and maximum) to the operator . Master is only active when DMX is detected.
100%
100%
0% 0%
----> Maximum (80%)
Light Output
4.1.3.2 Dimming curve
TSet through RDM protocol or web interface

EN
X ms
DMX 0 = 0 ms
1 = 100 ms
255 = 4000 ms
DMX512-A
EN - 15 -
4.3 Response time
4.3.1 Range
4.2 Strobe
4.2.1 Range
Strobe duration
Strobe speed
4.2.2 Control
0 = OFF
0 = 0.1Hz
1 = 1ms 255 = 20ms
255 = 10Hz
TRemotely with DMX512-A / Art-Net / sACN protocols.
Mode 3 – 4
4.1.3.5 Dimming mode
TSet through RDM protocol or web interface
Mode Result
Without PWM Flicker-Free, perfect for filming
PWM 17 kHz Good dimming quality (Default Value)
PWM 3,2 kHz Very good dimming

EN
TSet through RDM protocol or web interface
Mode Speed
NONE OFF
SLOW 700 ms
MEDIUM 470 ms
FAST 350 ms
CUSTOM 0 - 4000 ms
or
RDM
Web
interface
RDM
compatible
device
DMX512-A
EN - 16 -
4.3.2 Control
TRemotely with DMX512-A / Art-Net / sACN protocols.
Mode 3 – 4
Model Minimum angle Maximum angle
1156 10.5° 22.5°
4.4 Beam size adjustment
4.4.1 Range
4.4.2 Control
Field angle
Zoom
Focus

EN
Lock
Unlock
EN - 17 -
Function Range
PAN 0 T360°
TILT
TU = 0 T38°
TD = 0 T56°
4.5 Orientation
4.5.1 Range
4.5.2 Control

EN
EN - 18 -
4.6 Iris
4.6.1 Range
• Irising
4.6.2 Control
0% 100% Closed iris
4.7 Gobo
4.7.1 Range
Type Coloured gel filter
Dimension
Installation See 3.4.4
Type Standard gobo - A size
Dimensions
Installation See 3.4.3
4.8 Colour
• Fixed colour: place dark colours towards the rear end.
4.8.1 Range
72 mm
Maximum
image size
100 mm
Values are in millimeters (mm)
• Metal
• Glass
165 mm
75 mm
100 mm
