Eneo PM-9 User manual

Before installing and using this product, please read the instructions fully and carefully,
And be sure to keep it handy for late use.
DIMENSIONS: mm
PM-9 #219780
POLE MOUNT & CORNER BRACKET
Ø121.00
Ø106.50
160.00
160.00
85.56
92.00
66.00 85.56 130.50
110.00
120.00
90
70.00
90.00 20.00
20.00
15.00
5.00
20.00
160.00
70.00
25.00
4-57.00
30.00 57.20
Pole
20.00
VIDEOR E. Hartig GmbH
Carl-Zeiss-Straße 8
63322 Rödermark/Germany
Tel. [phone] / 888-0
Fax [phone] / 888-100
www.videor.com
www.eneo-security.com
Technical changes reserved
© Copyright by VIDEOR E. Hartig GmbH
Version 06/2018

Prior to Use
Avoid installing the mount onto an unstable structure such as a gypsum wall panel.
Install the mount onto a strong structure such as a concrete wall, steel beam, etc.
Confirm that the following parts are included.
Use concrete screws with plugs or other installation tools when installing the mount onto
a concrete structure, make sure that all the screw parts are metallic.
(Avoid screwing too close to the edge of a piece of wood when screwing into a wooden structure)
Composition
Mounting to the poles or the corners of building structure.
Feed the hose bands through the vertical stills
located on the four corners of the mounting flaps
as shown below. Wrap the hose bands around
the pole like structure then use the driver to rotate
the screw that is attached at the end of the hose
bands clockwise. Rotating the screw shortens the
bands thereby fastening the around the structure.
Composition
Instruction Manual Stainless Hose Band(2pcs)
Using the pole & Mount as a template,
mark the locations of the six screw
holes where the mounting adaptor will go.
Install the plastic anchors(D6) at the
six pre-marked locations. Use the screws
with washers to affix the mount adaptor
to the corner of a building structure.
Using the appropriate screws and nuts
supplied, affix the power box base to the
pole & corner mount at the four corners
of the mounting surface.
Mounting the power box or wall mount to the pole & corner mount.
Using the appropriate screws supplied,
affix the power box base to the pole &
corner mount at the four corners of the
mounting surface as shown the below.
Using the appropriate screws and nuts supplied, affix the wall mount to the pole & corner
mount at the four corners of the mounting surface as shown the below.
A
B
Screw Machine(PH M5x20L : 4EA)
Screw Machine(PH M5x20L : 4EA)
Screw Machine(PH M5x20L : 3EA)
C
Pole Mount & Corner Bracket
AK-6
Dome-WB4
AK-8
HCM160
POLE MOUNT & CORNER BRACKET
Beforeinstalling and using this product, please read the instructions fully and carefully,
And be sureto keep it handy for late use.
Stainless Hose Band
D=260mm(10.24inch)
Plastic Anchor(D6)
Screw Tapping
BH 6x35L Stainless
Plastic Anchor(D6)
4pcs
Screw Tapping
BH 6x35L Stainless
4pcs
Screw Machine(SEMS)
PH M5x16L Stainless
4pcs
A
B
C
