Energizer NiMH User manual

COMPACT CHARGER
INSTRUCTION MANUAL
IMPORTANT SAFETY INSTRUCTIONS:
• For Nickel Metal Hydride (NiMH) and Nickel Cadmium (NiCd) rechargeable AA, AAA 9V
batteries only.
• Never charge NiCd and NiMH batteries together.
• Do not use to charge Alkaline, Carbon Zinc, Lithium or any other kind of battery not
specified on the charger.
• Remove the batteries from the unit once they are charged, and disconnect the charger from
the power outlet.
• Automatic charging current control for different battery sizes (NiMH only)
• For indoor use only.
OPERATING INSTRUCTIONS:
1. Insert batteries in the charger respecting the polarity (+/-). If the polarity is reversed, the
charger has a safety protection and will not start charging. See Picture B for how to insert
the batteries into the compartments.
2. Load either:
AA/HR6/RC6/Mignon 2 or 4 pieces at a
time
AAA/HR03/RC3/Micro 2 or 4 pieces at a
time
9V/HR22/E-Block 1 or 2 pieces at a
time
DO NOT MIX THE BATTERY SIZES & CAPACITIES IN SAME CHANNEL WHILE CHARGING.
3. Plug the charger into a correct household electric outlet. The red LED will illuminate
indicating that charging is in progress.
4. If NiMH batteries are charged, after the pre-set charging time is reached, the red LED will
turn off.
5. If NiCd batteries are charged, the charging operation is manually controlled (refer to
charging-time table for guidance). The red LED does not automatically switch-off after
charging. Switch off the unit and manually remove the battery after charging. Do not exceed
manual charging times.
6. After use, disconnect the charger from the outlet and remove the batteries. ALWAYS
UNPLUG BETWEEN CHARGES.

BATTERY CHARGING TIMES:
SIZE Battery Capacity Appr.
Charging
Time
Charging
Mode
AA HR6 NiMH 1300-2100
mAh
12.5H –15H Timer Control
AA RC6 NiCd 500-600 mAh
RC6 NiCd 700 –800 mAh
RC6 NiCd 900 mAh
4H – 5H
6H-6.5h
7.5H
Manual
Operation
AAA HR3 NiMH 500-800 mAh 10H –15H Timer Control
AAA RC03 NiCd 180 – 220
mAh
RC03 NiCd 240 mAh
4H-5H
6H Manual
Operation
9V HR22 NiMH 150-160 mAh 15H Timer Control
9V RC22 NiCd 110 mAh 10H Manual
Operation
Channel to channel loading ± 15%
CAUTION:
• Never use an extension cord or any attachment not recommended by Energizer, may result
in a risk of fire, electric shock or personal injury.
• Never alter the plug provided. If the plug does not fit the outlet, install the proper outlet using
a qualified electrician. Improper connection can result in a risk of an electric shock.
• Do not operate the charger if it has been subjected to shock or damage. Take it to a
qualified technician for repair.
• Do not disassemble the charger. Incorrect reassembly may result in risk of electric shock or
fire hazard.
• During charging, unit may feel warm.
• Never use as a power source for any electrical equipment.
• Do not expose charger to rain, snow or excessive moisture.
