ENERGY SISTEM Pro 4G User manual

1/23 energysistem.com
ENGLISH
Introduction 3 .....................................................................................................................................................................
Care and maintenance 3 ...................................................................................................................................................
Main features 3 ...................................................................................................................................................................
Product contents 5 .............................................................................................................................................................
General overview 5 ............................................................................................................................................................
Power supply 5 ...................................................................................................................................................................
Switch on and off 6 ............................................................................................................................................................
How to insert the microSIM 1/nanoSIM 2/microSD cards 6 .............................................................................................
Main gestures 6 ..................................................................................................................................................................
Basic gestures 6 .............................................................................................................................................................
Main screen 7 ......................................................................................................................................................................
Widgets 9 .......................................................................................................................................................................
SIM card settings 9 .........................................................................................................................................................
Bluetooth setup 10 .........................................................................................................................................................
Wi-Fi settings 11 .............................................................................................................................................................
Internet browser 12 ........................................................................................................................................................
E-mail settings 13 ...........................................................................................................................................................
Music player 14 ..............................................................................................................................................................
Video Player 15 ..............................................................................................................................................................
Camera 16 ............................................................................................................................................................................
Gallery 17 .............................................................................................................................................................................
MicroSD / USB 19 ................................................................................................................................................................
Updates 20 ..........................................................................................................................................................................
Troubleshooting 21 ............................................................................................................................................................
Safety precautions and SAR 22 ........................................................................................................................................
Safety precautions 22 .....................................................................................................................................................
Exposure information (SAR) 22 .......................................................................................................................................
Warranty 22 .........................................................................................................................................................................
Warranty procedure 22 .....................................................................................................................................................
Trademarks 22 ....................................................................................................................................................................
Declaration of conformity 23 ............................................................................................................................................

2/23 energysistem.com

3/23 energysistem.com
Introduction
Thank you for your trust in our company and for buying the new Phone Pro 4G Pearl. We hope you enjoy it.
Your new phone has an AMOLED HD 5" display (1280x720 pixels) with anti-fingerprint coating, Octa Core Qualcomm®
Snapdragon™ 616 1.5 GHz processor, Bluetooth 4.0, Wi-Fi, GPS, 4G/3G connection, front camera with flash, rear camera
with autofocus and flash as well as Corning® Gorilla® Glass 3 rear protection.
Before you start using your smartphone we recommend you to read this manual and familiarize yourself with it. It will
only take a few minutes and will help you enjoy your device with maximum performance.
Care and maintenance
Do not expose your Phone Pro 4G Pearl to impacts, dust, direct sunlight, humidity or high temperatures.
Do not use corrosive nor abrasive cleaning products.
Keep the device clean and free of dust using a soft and dry cloth.
Charge the battery when the display shows the low battery icon.
Please do not dismantle the device. All reparation works should be carried out exclusively by qualified staff of
Energy Sistem Technology, S.A.
Main features
DISPLAY

4/23 energysistem.com
5" anti-fingerprint touch screen
AMOLED technology
HD Resolution (1280x720 pixels)
100% NTSC colour gamut
PROCESSOR
Qualcomm® Snapdragon™ 616 processor - MSM8939 Octa Core ARM Cortex A53 1.5 GHz
Integrated Adreno 405 GPU
DESIGN
Aluminium alloy frame
Highly resistant Corning® Gorilla® Glass 3 rear protection
OPERATING SYSTEM
Android™ 5.1 Lollipop
CAMERAS
13 Mpx rear camera with autofocus and LED flash
5 Mpx front camera with 84.3º FOV and LED flash
MEMORY
3 GB RAM DDR3
32 GB internal memory expandable by a further 128 GB via microSD-HC/XC cards
CONNECTIVITY
4G: 800/1800/2600 MHz (BANDS FDD-LTE XX / III / VII)
3G: 900/2100 MHz (BANDS WCDMA VIII / I )
2G: 850/900/1800/1900 MHz (GSM BANDS)
Bluetooth® 4.0
WI-FI 802.11 b/g/n
A-GPS, GLONASS
CONNECTIONS
2 configuration options: microSIM + nanoSIM or microSIM + microSD
MicroUSB 2.0 connection with OTG function
Audio Jack 3.5 mm with CTIA standard
BATTERY
Battery capacity: 2600 mAh Li-Po
AC/DC (Europlug) power adapter. Input: 100-240 VAC 50-60 Hz. Output: 5V 1A
Battery life: up to 165 hours on standby and 15 hours conversation time.
OTHER FEATURES
Notification LED in power On/Off button
Motion sensor (accelerometer)
Proximity sensor
Luminosity sensor
Integrated speaker
Integrated omnidirectional microphone
Noise cancelling microphone
87.5 to 108 MHz FM radio with presets
SAR rate: 0.431 (W/Kg) at the head and 0.408 (W/Kg) at the body (10 mm distance)

5/23 energysistem.com
Product contents
Phone Pro 4G Pearl.
Quick guide.
Screen protector.
USB cable.
AC/DC 5V 1A (Europlug) 100-240V AC 50-60Hz power adapter.
SIM/microSD extraction tool.
General overview
Power On/Off button and notification led1.
MicroSIM 1/nanoSIM 2/microSD card slots2.
Rear flash3.
Rear camera4.
Headphones output5.
Noise cancelling microphone6.
Front flash7.
Receiver8.
Proximity and luminosity sensors9.
Front camera10.
Volume button "+"11.
Volume button "-"12.
MicroUSB input13.
Speaker14.
Microphone15.
System touch buttons: Recent Apps, Home, Back16.
SIM/microSD extraction tool17.
Power supply
Your Phone Pro 4G Pearl includes a rechargeable Li-Ion Polymer battery that cannot be removed. The charging time
ranges from 2 to 3 hours, depending on whether the device is on or off. Always charge your phone through the USB
cable and the power adapter that come with the product to comply with the battery charging times.

6/23 energysistem.com
Switch on and off
Please verify that the SIM/microSD cards are correctly inserted in the corresponding slots as explained in the "How to
insert the microSIM 1/nanoSIM 2/microSD cards" section before turning on your Phone Pro 4G Pearl. After that, press the
power button (1) located on the right side of the device for one second. Once the operating system has loaded
completely, please unlock the device to start using it. Enter the PIN number of your microSIM/nanoSIM cards and then
slide your finger upwards on the screen.
In order to turn off the device, hold the power button (1) until you see the power off menu, then select "Switch off".
Briefly press the power button (1) to lock/unlock the device thus, turning the screen on/off and activating the screen.
How to insert the microSIM 1/nanoSIM 2/microSD cards
To place the SIM/microSD cards you should remove the slot (2) using the tool (17) located on the external part of the
envelope that comes with the product. Insert the tool into the slot hole (2). Once removed, you will see that there are
two possible combinations to use SIM or SD storage cards:
Option A: MicroSIM card 1 + microSD storage card.
Option B: MicroSIM 1 card + nanoSIM 2 card.
Main gestures
Basic gestures
Tap
Touch the screen briefly
Double tap
Touch the screen twice quickly
Drag
Move your finger over the screen while maintaining continuous contact
Slide
Slide your finger quickly over the screen

7/23 energysistem.com
Press
Touch the screen for an extended period of time
Zoom
Zoom in and out the image on screen
Main screen

8/23 energysistem.com
Search: Direct access to Google™ search engine.1.
Status Bar: Displays information about the signal status, battery and clock. If you slide down your finger over2.
this area twice, you will access the basic settings menu that manages notifications as well as the main settings
menu.
Voice Search: Access to Google's™ voice search and much more.3.
Play Store™: Download the best and most popular apps for your Android™ system.4.
Music: Music player.5.
E-mail: E-mail service.6.
Internet: Web browser.7.
Menu: Access to the application and widget menu.8.
Touch button: Back.9.
Touch button: Home.10.
Touch button: Recent Apps.11.
Phone: Calls and call log.12.
Contacts: Contact management.13.
Camera: Access to the built-in camera.14.
Gallery: Image gallery.15.

9/23 energysistem.com
Widgets
In order to add a Widget to one of your desktops, tap the centre of the desktop (1) and then, select "WIDGETS" at the
bottom of the screen (2). You can slide your finger to the right (3) to see all your installed Widgets. Select the one you
want to add to your desktop by keeping it pressed and then release it on the desktop.
Widgets can be easily removed or relocated to other screen areas. To relocate a widget, press it and keep it selected for
a few seconds. Once the app has been highlighted, you can move it to another desktop position.
To remove the widget, keep it pressed for a few seconds without releasing it until the X icon appears on top of the
screen. Then, drag the widget to that icon and release it.
SIM card settings

10/23 energysistem.com
Your Phone Pro 4G Pearl offers the possibility of using a microSIM card and a nanoSIM card at the same time or a
microSIM card and a microSD card. In Settings > SIM Management, you can manage the use of both cards.
In this section you can set the default card to make or receive calls, send and receive text messages and set the data
connection.
Bluetooth setup
Your Phone Pro 4G Pearl has Bluetooth 4.0 to connect your device to headphones, computers, tablets or any device that
supports such communication protocol. You just need to go to Settings > Bluetooth and turn the switch to ON. Then, the
device will start a search of all available devices and once it has finished, you will only have to select one of them to
establish the connection.
