ENERGY SISTEM Stream Radio&TV 120 User manual

User manual

23
ENGLISH
INTRODUCTION
Energy Sistem® thanks you for buying the new Energy™ Stream Radio&TV 120, we
wish you enjoy using it.
Please be sure to read all safety information before using this product
This manual provides you how use the product; please keep this information for
future reference.
SAFTY CONSIDERATIONS
≥Do not disassemble or modify the product.
≥Do not expose the device to dripping, splashing or humid conditions.
≥Do not allow the device to get wet.
≥Keep the product away from direct sunlight and heat source such as radiators or
stoves.
≥Do not place naked flame sources, such as candles near to the device.
≥Avoid any drop or hit.

24
MAIN FEATURES
≥2.4” LCD display.
≥WLAN connection with IEEE802.1 b/g.
≥TF card slot.
≥WLAN security: Support WPA, WPA2, WEP.
≥Calendar and clock function
≥UPNP function.
≥Integrated Multimedia-Player.
≥Speaker with 1x 2 Watts power.
≥3.5mm output for hearphones.
≥Rechargeable Li-Ion battery 1800mA / 3.7V.
≥USB 2.0 host for charge and data transfer.
≥Supports up to 16GB memory cards.

25
ENGLISH
PRODUCT CONTENT
≥Energy™ Stream Radio&TV 120.
≥USB cable.
≥User Manual.

26
GENERAL OVERVIEW
Top View
1. ON / OFF.
Front view
2. LCD display.
3. Speaker.
4. HOME.
5. BACK.
6. OK.
7. Volume adjust.
8. Charging LED.
9. UP.
10. DOWN.
11. RIGHT.
12. LEFT.
RESET
ENERGY
Stream Radio&TV 120
8
2
16
3 712
74
14
15 13
5
9
10
1
11
6
RESET
ENERGY
Stream Radio&TV 120
8
2
16
3 712
74
14
15 13
5
9
10
1
11
6

27
ENGLISH
Rare view
13. TF card slot.
14. Earphone output / FM connection antenna.
15. USB host.
16. RESET button.
RESET
ENERGY
Stream Radio&TV 120
8
2
16
3 712
74
14
15 13
5
9
10
1
11
6
≥Realiza copias de seguridad periódicamente en otro dispositivo de almacenamien-
to. Energy Sistem no se hará responsable en ningún caso de la pérdida o daño de
los datos almacenados.

28
FIST BATTERY CHARGE
Please fully charge the battery of your Energy™ Stream Radio&TV 120 before use
the product for first time.
≥When power off, charging LED is red.
≥When the charge complete the charging LED is blue.
SWITCHING ON / OFF
To power ON your Energy™ Stream Radio&TV 120 press ON (1), you will see that
the screen turning on and start with the small presentation. Press OFF (1) for a few
seconds to power off the device, the screen has to be completely off.
SETTING
When you power on your Energy™ Stream Radio&TV 120 in the main menu you
have to select the SETTING and press OK (6), you can see the setting options.
You can select the language, time, date, WiFi setup, etc.

29
ENGLISH
NETWORK CONNECTION
The Energy™ Stream Radio&TV 120 is equipped with Internet TV, Internet Radio,
Shoutcast, Podcast, etc; for which you need to set up and establish a wireless
Internet connection.
To connect the device to a wireless Internet connection, you have to:
1. Go to the main menu and select Network setup.
2. Press OK on WiFi setup.
3. Select the option AUTO SCAN and confirm to search for available wireless
networks.
4. Select your WiFi connection.
5. Enter the password on the OSD keypad using the (9), (10), (11) and (12) buttons
and confirm

30
The Wi-Fi icon will display the signal status of Wi-Fi
The device can store only one wireless network and one password.
When you power on the device using the same Networks as the last time, the device
will detect it and you do not have to enter the password again, please wait for a few
seconds and on the screen you can see the next message
You can keep listening the last radio station/TV channel or search for a new one.
MAIN MENU
In the HOME menu you can find the next options:
≥Network.
≥Play stored media.
≥Settings
≥My favorite.
≥FM Radio.
Select your option and you can find a different sub-menus for each option.

31
ENGLISH
Network
Include five main functions: Web Radio, Web TV, UPNP, Shout cast and Podcast.
Web Radio: Access to more than 15000 Radio stations; use the buntons (9),
(10), (11) and (12) to selection that you want (genes or region). You can long-
press (9) and (10) buttons to quickly navigate through long lists.
Web TV: Access to more than 2000 TV channels; use the buttons (9), (10), (11)
and (12) to selection that you want (genes or region). You can long-press (9)
and (10) buttons to quickly navigate through long lists.
UPnP: This feature allows you to share your favourite list. Install the UPnP
function on computers which are involved. Make sure that the device is in the
same local Network.
Shout cast: You can find websites with an alternative radio and broadcasting
option.
Podcast: Pod cast refers to the production and provision of subscription-media
files (audio or video) over the Internet.

32
Play stored media
You can store and play your favourite files, using the internal 4GB memory or with a
TF card (up to 16GB).
In this menu you can select any of these options.
Setting
In this option you can configure the system settings as the language, connection,
wallpaper, screensaver time, time zone, date and time, firmware update, sleep
mode, etc.
My favorite
You can create your favorite list and find them in this option. To add any TV
channel, Radio station, Podcast or Shout cast you only have to do a long-press on
the OK button (6) when the channel in playing, in the same moment the channel is
now included in the favourite list.
To delete a channel from the favorite list, you just have to do a long-press on the
button BACK (5) when you are viewing the list.
FM Radio
Your Energy™ Stream Radio&TV 120 has an integrated FM Radio. Under setting
menu, select FM search in the list, the available frequencies will be displayed after
scanned, enjoy the radio as you wish.

33
ENGLISH
Using RIGHT or LEFT buttons to select the previous/next radio station, if you use
UP or DOWN you can do the fine tune increasing/decreasing frequency 0.05MHz.
ADITIONAL FUNCTIONS
Calendar: Press UP button to display calendar at the main menu.
Clock: Press DOWN button to display the clock at the main menu.
.

34
Item Specification
Screen size 2.4” LCD
Resolution 320 x 240 Pixel
Connectivity
Speaker 1x2W
USB USB host for charge and transfer
Memory card TFcard
Earphone jack 3.5mm
WLAN
WLANsecurity WPA, WPA2 y WEP
WiFisearch
Auto and manual search
WiFi Standard IEEE 802.11 b/g
Power
AC/DC: 5V by USB or PC TXT, PDB, PDF, HTML, FB2,EPUB,WTXT
Li-battery 1800mAh
Supported
Audio MP3 - WMA - AAC - WAV - OGG – FLAC
Video AVI - MP4 - MKV - MOV - VOB - MPG
- FLV - RM - RMVB – WMV
Photo JPG - BMP - PNG – GIF

35
ENGLISH
TROUBLESHOOTING
≥Have any other question? Check the product F.A.Q. section at the Energy Sistem
webpage www.energysistem.com
Technical support email addres: support@energysistem.co.uk
WARRANTY
Energy Sistem Soyntec S.A. warrants its products to be free from defects in materials
and workmanship at the time of purchase.
The 36 months warranty is valid for the European Union. For other countries, please
refer to your specific legislation or your local distributor.
WARRANTY PROCEDURE
1. Visit the Support section at http://support.energysistem.com and select your
product to view the FAQ (Frequently Asked Questions). The solution to your
problem is very likely to have been already published there. You will also be able to
download user manuals, user guides, drivers and updates.
2. If you cannot find an appropriate solution in the Support section, you may send us
your enquiry or warranty service request by email: support@energysistem.co.uk

3636
3. Alternatively you may prefer to contact the distributor from which you purchased
the product, presenting the purchase receipt or invoice.
IMPORTANT: we recommend you to make a backup of the data inside the player
memory, because on the process of warranty management by our aftersales
department the memory is likely to be formatted, thus erasing all the content. Energy
Sistem help desk team will not perform any backup of the memory contents, so it is
advisable to deliver the player with blank memory or with the original factory content.
Specifications are subject to change without notice.
© 2011 / 2012 by Energy Sistem®. All rights reserved.
Trademarks. All companies, brands and products names are trademarks or
registered trademarks of their respective companies.

37
ENGLISH
This symbol on the product or the instructions means that your electrical and electronic
equipment should be disposed at the end of life separately from your household waste. For more
information, please contact the local authority or dealer where you purchased the product.
DECLARATION OF CONFORMITY
Manufacturer Name: Energy Sistem Soyntec S.A.
Address: Pol. Ind. Finestrat, C/.Calpe, 1 - 03509, Finestrat Alicante (Spain)
Tel: 902 388 388 Fax: 902 119 034 NIF: A53107488
We declare under our own exclusive responsibility that the product:
Energy Sistem®Energy™ Stream Radio&TV 120
Manufacturing country: China
Is in compliance with the essential directives, norms and standards of the European
Union 89/336/EEC (EMC Directive).
