ENERGY SISTEM Energy Music Box CM1 Bluetooth User manual

1/6 energysistem.com
ENGLISH
Introduction 4 .....................................................................................................................................................................
Changing play mode 4 ....................................................................................................................................................
Charging the battery 4 ...................................................................................................................................................
Bluetooth Pairing 4 ............................................................................................................................................................
Playback control 5 ..............................................................................................................................................................
Audio-in input connector. 5 ..............................................................................................................................................
Warranty 5 ...........................................................................................................................................................................
Warranty Procedure 5 .......................................................................................................................................................
Trademarks 5 .................................................................................................................................................................
Declaration of Conformity 5 .............................................................................................................................................

2/6 energysistem.com

3/6 energysistem.com

4/6 energysistem.com
Introduction
Thank you for your trust in us and for buying the new Music Box CM1 Bluetooth. We hope you enjoy it.
MP3/WAV player with Bluetooth® technology. Enjoy your music without cables from any Bluetooth® and take it
wherever you are with its lithium rechargeable battery.
Before you start using your smartphone we recommend you to read this manual and familiarize yourself with it. It only
takes a couple of minutes and it will help you to enjoy your device with maximum performance.
## Care and maintenance Do not expose your *Box CM1 Bluetooth* to impacts, dust, direct sunlight, humidity or high
temperatures. Do not use corrosive nor abrasive cleaning products. Keep the speaker clean and dust free, use for this a
soft dry cloth. Do not disassemble the device. All reparation should be done exclusively Energy Sistem Technology, S.A.
qualified staff. Be sure to keep your Music Box CM1 Bluetooth turned off while not in use. Do not store or leave the
device disused for a long period of time with the battery completely discharged. ## Features ## Main features * Pair
the music of your smartphone or tablet via the wireless connection thanks to the Bluetooth® technology. * Total
compatibility with smartphones and tablets iOS, Android™, Windows Mobile, BlackBerry, etc. * Freedom of sound: Listen
and share your music wherever you are, without cables. * Loudspeakers with acoustic enhancement system: Clear
sound and rich bass. * Total output power (RMS): 6W. * Compact and portable design, it will allow you to take it with you
anywhere and amplify your music. * USB memory decoder: plays MP3 files from USB memory drives with capacity up to
32 GB. * 3.5 mm "Audio-In" port: listen to music with any portable player or even computer. * Rechargeable battery. *
microUSB port battery charger. ### Technical features * Bidirectional Bluetooth®. 4.0 version, up to 10m range. *
Supports A2DP and AVRCP profiles. * USB memory decoder: plays MP3 files from USB memory drives with capacity up to
32 GB. * 2.0 Loudspeakers with acoustic enhancement system. * Total output power (RMS): 6W. * Frequency response:
80 Hz ~ 20 KHz * S/N ratio: >80 dB. * 3.5 mm "Audio-In" port. * Rechargeable lithium battery. * Earphones output ###
Battery specifications * Nominal capacity: 1600 mAh. * Nominal voltage: 3.7V. * Autonomy in radio mode: 12 hours.* *
Battery life in radio mode: 10 hours.* ( * ) Approximate battery life. Higher volume means higher battery consumption.
## Product Content * Tower CM1 Bluetooth * Audio cable: 3,5mm. * Charging USB cable ## General Overview | | | |:-----
--|:-------|
|![Imagen1](https://static2.energysistem.com/energysistem/html/energysistem/images/manuals/42498/560ce841de58c.
jpg)
|![Imagen1](https://static2.energysistem.com/energysistem/html/energysistem/images/manuals/42498/560ce83891aa6.
jpg)| ## Main Functions ### Turn ON/OFF To turn on your device, press and keep 2 seconds the ON/OFF button (4).
The POWER ON INDICATOR (11) will turn on. To turn on your device, press and keep the ON/OFF button (4) for 2
seconds. When the device is on, the POWER ON INDICATOR (11) will be illuminated.
Changing play mode
When you turn the device, pairing mode will start automatically. To change into "Audio-In" mode, you only need to
connect the audio cable (included) to the AUDIO IN CONNECTION (12).
Charging the battery
When the speaker stops emitting sound or the battery icon starts blinking, it is time to charge it. Connect the mcroUSB
end of the included USB cable to your Music Box CM1 Bluetooth (8) and the other end to any USB port that can provide
energy (PC, USB wall charger, car, etc). The LED CHARGER INDICATOR (9) will turn on in red colour and when the charge
is completed the LED will turn off.
Note: It is recommended to turn off the device when charging. Do not store or leave the device disused for a long period
of time with the battery completely discharged.
Bluetooth Pairing
Every time you turn on your Music Box CM1 Bluetooth, pairing mode will start automatically; at the same time, the
search and pairing process will start on your Bluetooth® device (smartphone, tablet, laptop, etc). Once you have
identified the Music Box CM1 Bluetooth on your device, select connect. It will immediately connect without codes. The
speaker will play a sound indicating that the connection has been established.
To pair the speaker with the last device again, you only need to turn on the Music Box CM1 Bluetooth and the
synchronization will start automatically.

5/6 energysistem.com
If you want to pair another Bluetooth® device, you should press the FOLDER CHANGE (5) button. That way the current
pairing will end and it will start searching for other Bluetooth® devices.
Playback control
Once the Music Box CM1 Bluetooth paired you can control the playback volume from the speaker. To do this, press the
"VOLUME - " (1) or "VOLUME + " (2) buttons.
To pause or resume the playback, press the PLAY/PAUSE button (4) once.
To go forward or backward a song keep the NEXT (7) or PREVIOUS (6) pressed.
To change the folder in the USB mode, press the FOLDER CHANGE (5) button.
Audio-in input connector.
It is also possible to enjoy your Music Box CM1 Bluetooth without pairing it with any Bluetooth device thanks to its
AUDIO-IN CONNECTOR (12) in which you can connect an audio cable with a 3.5mm jack connector and the other end to
your player.
Your Music Box CM1 Bluetooth must be turned on in order to use this function.
NOTE: While using the device in Audio-In mode, it is not possible to control the playback neither the volume from the
speaker. You have to do it from the player connected.
Warranty
Energy Sistem Technology, S.A. is liable for any lack of conformity which exists at the time the goods were purchased
during a period of 36 months. Batteries are excluded from the 36-month warranty, having a warranty period of 12
months.
This warranty covers any defects in workmanship or materials. This warranty does not cover any failure of the product
due to accidents, misuse or alteration made by an unauthorized person.
The special 36-months warranty is valid for the European Union. For other countries, please refer to your specific
legislation or your local distributor.
Warranty Procedure
Visit the Support section at http://www.energysistem.com/en/support and select your product to view the FAQ
(Frequently Asked Questions), user manuals, drivers and updates available.
You can check the availability of the user manual in your language at http://www.energysistem.com/en/guide/42498
Alternatively, you may contact the distributor from which you purchased the product, presenting the purchase receipt
or invoice.
Important: This warranty does not cover any damage or loss to any data stored in warranty products, therefore Energy
Sistem's Technical Service will not assume any loss of the above mentioned information. So it is recommended to make
a backup of your data and remove any data or personal data from its internal memory before you send the product, or
to send it only with the original data.
Specifications are subject to change without notice.
Trademarks
All company, brand and product names are trademarks or registered trademarks of their respective companies.
© 2015 by Energy Sistem Technology, S.A. All rights reserved
Declaration of Conformity
Manufacturer Name:
Energy Sistem Technology, S.A.
Address: C/ Calpe, 1.
03509 Finestrat - Alicante (España).
Tel: [phone] // Fax: [phone]

6/6 energysistem.com
NIF: A53107488
We declare under our own exclusive responsibility that the product:
Music Box CM1 Bluetooth
Manufacturing country: China
Is in compliance with the essential norms and standards of the Directive 1999/05/EC of the European Parliament and of
the Council of March 09th 1999. Other rights property of other companies or individuals. You may request a copy of the
declaration of conformity at C/ Calpe, 1 - 03509 Finestrat - Alicante (España) Tel. [phone]
Finestrat, 1 october 2015
This symbol on the product or
the instructions means that your
electrical and electronic
equipment should be disposed at
the end of life separately from
your household waste. For more
information, please contact the
local authority or dealer where
you purchased the product.
