ENERGY SISTEM Frame Speaker User manual

1/8 energysistem.com
ENGLISH
Care and maintenance 3 ...................................................................................................................................................
Technical specifications 3 .................................................................................................................................................
Audio 3 .........................................................................................................................................................................................
Wireless connection 4 ..................................................................................................................................................................
FM radio 4 .....................................................................................................................................................................................
MicroSD and USB player 4 ............................................................................................................................................................
TWS compatible with 4 .................................................................................................................................................................
Power supply 4 .............................................................................................................................................................................
Built-in battery 4 ..........................................................................................................................................................................
Other features 4 ...........................................................................................................................................................................
Product content 4 ...............................................................................................................................................................
General overview 4 ............................................................................................................................................................
Switching on and off the device 5 ...................................................................................................................................
Charging the battery 6 ......................................................................................................................................................
Bluetooth - microSD - USB - FM Radio 6 .........................................................................................................................
Bluetooth 6 ..........................................................................................................................................................................
True Wireless Stereo 6 ......................................................................................................................................................
USB and microSD playback 7 ...........................................................................................................................................
Browsing folders 7 ..........................................................................................................................................................
FM radio 7 ............................................................................................................................................................................
Battery life 7 .......................................................................................................................................................................
Declaration of conformity 7 ............................................................................................................................................

2/8 energysistem.com

3/8 energysistem.com
Thank you for your trust in our company and for buying the new Frame Speaker. Before you start using your speaker,
we strongly recommend to read this manual to get used to it.
Care and maintenance
Please take into account the following considerations in order to avoid any product damage:
Do not use neither corrosive nor abrasive cleaning products.
Do not disassemble the device. All repair works should be carried out exclusively by qualified staff of Energy
Sistem Technology, S.A.
Turn it off when you are not using it and do not let it completely discharged for a long time.
Technical specifications
Audio
Sound system: 2.1 stereo system

4/8 energysistem.com
Power: 50 W
2 mid-range speakers: 10 W, 2"
1 subwoofer: 30 W, 4"
Bass reflex
Frequency response: 85 Hz ~ 16 KHz
THD < 1%
S/N ratio: > 90 dB
Wireless connection
Bluetooth 5.0, class II
Frequency band: 2.4 GHz
Maximum output signal: <20.00 dBm
Supported Bluetooth protocols: HFP / A2DP / AVRCP
Up to 10 m distance range
True Wireless Stereo (TWS) Technology with a distance range of up to 10 m
FM radio
Built-in antenna
FM frequency band: 87.5 ~ 108 MHz
MicroSD and USB player
MicroSD and USB decoder: reads MP3/ WAV/ WMA files stored on external storage units (up to 128 GB) with FAT/
FAT32 file system.
TWS compatible with
Frame Speaker
Power supply
5 V/2 A microUSB
Device connector: microUSB
Power cable length: 150 cm
Built-in battery
Capacity: 4400 mAh/ 7.4 V
Type: Li-Ion
Battery life @ medium volume level: 20 hours*
Charging time: 7 hours
Charging method: microUSB
This value is approximate. Battery life depends on the selected volume level and type of music.
Other features
Remote control with up to 10 meters range
Wooden cabinet speaker
Product content
Frame Speaker
Remote control
USB Type-A to microUSB cable
Quick guide
General overview

5/8 energysistem.com
1. USB playback port
2. MicroSD slot
3. LED mode indicator
4. On/ Off/ Play/ Pause
5. Volume +/ Next
6. Volume -/ Back
7. Change function
8. LED charge indicator
9. MicroUSB charging port
10. IR emitter
11. Enter/ Exit Standby mode
12. Change function
13. Play/ Pause
14. Back
15. Next
16. Volume +
17. Volume -
18. Mute
19. True Wireless pairing
20. Playback modes
Switching on and off the device
Press and hold the On/ Off button (4) for 2 seconds to turn on the device. You will see that the LED mode indicator (3)
lights up. You will also hear a confirmation sound when switching on the device.
Press and hold the On/ Off button (4) for 2 seconds to turn off your device. You will hear a confirmation sound. At this
point the LED mode indicator (3) switches off.

6/8 energysistem.com
If you press the On/Off button on the remote control, the LED mode indicator (3) will blink red. This means the speaker
has gone into "Standby" mode. You won't be able to turn the device on and off using the remote control. Please take
into account that this mode uses up your speaker's battery. The device will automatically shut down after 30 minutes.
Charging the battery
When the battery level is below 10%, you will hear a sound to remind you to charge it. Please plug the power adapter
(not included) into the Charging port (9) of your Frame Speaker. Plug then the other end into your home power socket.
The Charge indicator (8) lights up and switches off once the charging process has been completed. The charging time is
approximately 7 hours.
Important:
Turn off the device before charging it to optimise the charging process.
Do not leave your Frame Speaker completely discharged for a long time.
Use a 5 V charger with at least 1.5 A output or more to optimise the charging time.
Playback modes
Press the Change function button (7) to select one of the following playback modes:
Bluetooth - microSD - USB - FM Radio
The LED mode indicator (3) will light up as follows: blue for Bluetooth, red for FM Radio and violet for microSD and USB
mode.
Bluetooth
Once Bluetooth mode is enabled, press and hold the Change function button (7) for 2 seconds to start searching for
Bluetooth devices. Access the list of available devices on your smartphone or tablet and once there, select your "Frame
Speaker". The devices will be connected without codes. Once the connection has been established, you will hear a
confirmation sound.
At this point, you will be able to start music playback on your smartphone or tablet. The Bluetooth wireless connection
range is up to 10 meters.
Press Next (5), Back (6) and Play/ Pause (4) on the speaker to control music playback.
Your speaker saves the last connected device and pairs with it automatically when you turn on the speaker once again.
Press and hold once again the Change function button (12) for 2 seconds to start a new Bluetooth search and pair your
speaker with a different smartphone or tablet.
True Wireless Stereo
This technology allows you to wirelessly pair another Frame Speaker within a maximum distance of 10 m to increase
power.
Switch on both devices and enable Bluetooth mode. Do not pair your smartphone or tablet yet. Quickly press the
Change Function button (12) twice, or the True Wireless Pairing button (19) on the remote control. At this point, you will
see the LED mode indicator (3) blinking fast, until both speakers are paired.
Once the speakers are paired, volume adjustment will apply to both units. Quickly press the Change function button
(12) twice or the True Wireless pairing button (19) on the remote control to end the TWS connection. TWS pairing may
only be selected when Bluetooth mode is enabled. If you select another mode on any of both speakers, the connection

7/8 energysistem.com
will end.
USB and microSD playback
Play .mp3, .wav and .wma files stored on your microSD cards and USB sticks (up to 128 GB). The contents play
automatically a few seconds after inserting the microSD card or USB stick.
If you turn off the speaker or remove the storage unit, the internal memory will save the moment when you paused
playback. If you connect the same removable storage unit once again, playback will resume and the last song that you
listened to will be then played.
Press Next (5) or Back (6) to move to the next or previous track.
The folders and files of your removable cards or sticks will be read in chronological order.
Browsing folders
Press and hold the Change function button (7) for 2 seconds to move to the next memory card folder.
FM radio
Once FM radio mode is enabled, press and hold the Change function button (7) for 2 seconds to start searching for FM
radio stations. The process may take a few minutes. Once the search has been completed, press and hold Next (5) or
Back (6) to select the radio station you want to hear from all saved radio stations.
If you place the speaker somewhere else, you will have to carry out a new search to obtain a proper radio wave
reception.
Your Frame Speaker saves the last selected radio station when you turn it off and on once again.
Battery life
The battery life of your Frame Speaker depends on the selected volume level and the type of music. Please take a look
at this comparative table to find out more about the approximate battery life of your device:
LOW VOLUME LEVEL (20%)
-
MEDIUM VOLUME LEVEL
(50%)
HIGH VOLUME LEVEL (70%)
-
MAXIMUM VOLUME LEVEL
(100%)
22 hours 20 hours 14 hours 5 hours
## Warranty
You can check the warranty terms here
Declaration of conformity
Issuer?s name: Energy Sistem Technology, S.A. - CIF: A53107488
Address: C/ Calpe, 1 - 03509 Finestrat - Alicante (Spain)
Tel: + 34 966 830 324
We declare under our own exclusive responsibility that the product
Description: Portable wireless speaker
Brand: Energy Sistem
Model: Frame Speaker
Manufacturer: Energy Sistem Technology, S.A.
Manufacturing country: China
referred to in this declaration is in compliance with the essential norms and standards
EN 60065 : 2014

8/8 energysistem.com
EN62479 : 2010
EN301 489-1 V2.1.1 : 2017-02
EN301489-17 V3.1.1 : 2017-02
EN300328V2.1.1 : 2016-11
in conformity with the provisions of the Directive 2014/53/EU of the European Parliament and of the Council of 16th
April 2014.
Finestrat, 01st February 2019.
Daniel Havillio
Product Management Director
