Enerzone Solution 1.8 User manual

Printed in Canada
ENERZONE E.P.A. WOOD STOVE MANUAL
US ENVIRONMENTAL
PROTECTION AGENCY
PHASE II CERTIFIED
WOOD STOVE
After
E
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer’s web site. It is a copyrighted
document. Re-
sale is strictly prohibited. The manufacturer may update this manual from time
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.
ENERZONE E.P.A. WOOD STOVE MANUAL
Solution 1.8
Solution 2.9
Fabriqué par :
STOVE BUILDER INTERNATIONAL INC.
250, rue de Copenhague,
Saint-Augustin-de-Desmaures
(Quebec) G3A 2H3
After
-sale service: 418-908-8002
E
-mail: [e-mail]
www.enerzone-intl.com
Verified and tested
following
and UL 1482 Standards
by an accredited
laboratory
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer’s web site. It is a copyrighted
sale is strictly prohibited. The manufacturer may update this manual from time
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.
45189A
02-09-2015
ENERZONE E.P.A. WOOD STOVE MANUAL
Verified and tested
ULC S627
and UL 1482 Standards
by an accredited
laboratory
This manual is available for free download on the manufacturer’s web site. It is a copyrighted
sale is strictly prohibited. The manufacturer may update this manual from time
to
time and cannot be responsible for problems, injuries, or damages arising out of the use of

2
INTRODUCTION
Stove Builder International, one of the most important wood stove and fireplace manufacturers in
North America, congratulates you on your purchase and wishes to help you get maximum
satisfaction from your wood stove. In the pages that follow, we will give you advice on wood
heating and controlled combustion as well as technical specifications regarding installation,
operation and maintenance of the model you have chosen.
The instructions pertaining to the installation of your wood stove in North America comply with
ULC-S627 and UL-1482 standards.
We recommend that our wood burning hearth products be installed and serviced by professionals
who are certified in the United States by NFI (National Fireplace Institute
®
) or in Canada by
WETT (Wood Energy Technology Transfer) or in Quebec by APC (Association des
Professionnels du Chauffage).
Read this entire manual before you install and use your new stove. If this stove is not
properly installed, a house fire may result. To reduce the risk of fire, follow the installation
instructions. Failure to follow instructions may result in property damage, bodily injury,
or even death.
Consult your municipal building department or fire officials about restrictions and
installation requirements in your area and the need to obtain a permit.
K EEP THIS INSTRUCTIONS MANUAL FOR FUTURE REFERENCE .
CAUTIONS:
•T HE INFORMATION GIVEN ON THE CERTIFICATION LABEL AFFIXED TO THE APPLIANCE ALWAYS
OVERRIDES THE INFORMATION PUBLISHED , IN ANY OTHER MEDIA ( OWNER ’ S MANUAL ,
CATALOGUES , FLYERS , MAGAZINES AND / OR WEB SITES ).
• HOT WHILE IN OPERATION . KEEP CHILDREN , CLOTHING AND FURNITURE AWAY . CONTACT MAY
CAUSE SKIN BURNS .
• DO NOT USE CHEMICALS OR FLUIDS TO IGNITE THE FIRE .
• DO NOT LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SLIGHTLY OPENED DURING
IGNITION .
• DO NOT BURN WASTE , FLAMMABLE FLUID SUCH AS GASOLINE , NAPHTHA , OR MOTOR OIL .
• DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM .
• ALWAYS CLOSE THE DOOR AFTER IGNITION .

3
TABLE OF CONTENTS
1. INSTALLATION .............................................................................................................................................. 4
1.1 GENERAL INSTALLATION......................................................................................................................4
1.1.1 Pedestal or leg kit assembly................................................................................................................................5
1.1.2 Installation of the decorative u-shaped inserts....................................................................................................6
1.1.3 Door overlay installation ....................................................................................................................................6
1.1.4 Optional air mate installation..............................................................................................................................7
1.2 POSITIONING THE STOVE ......................................................................................................................8
1.3 CLEARANCES TO COMBUSTIBLES AND FLOOR PROTECTOR ...................................................8
2. CHIMNEY (FLUE SYSTEM)........................................................................................................................ 14
2.1 DEFINITIONS.............................................................................................................................................14
2.2 CHIMNEY ...................................................................................................................................................14
2.2.1 Step by step installation of your factory-built chimney....................................................................................16
2.2.2 Typical installation through an existing masonry chimney...............................................................................19
2.3 CHIMNEY CONNECTOR.........................................................................................................................21
2.4 DRAFT .........................................................................................................................................................23
2.5 FRESH AIR INTAKE KIT.........................................................................................................................23
2.6 THE ADVANTAGE OF INSTALLING A BLOWER.............................................................................24
3. OPERATION................................................................................................................................................... 25
3.1 SAFETY INFORMATION.........................................................................................................................26
3.2 FUEL.............................................................................................................................................................27
3.2.1 The use of manufactured logs...........................................................................................................................28
3.2.2 Simple wood moisture test................................................................................................................................29
3.3 NOTES ABOUT FIRST FIRING...............................................................................................................29
3.4 LIGHTING A FIRE ....................................................................................................................................29
3.5 MAINTAINING THE FIRE.......................................................................................................................31
3.6 BLOWER OPERATION............................................................................................................................31
4. MAINTENANCE ............................................................................................................................................ 32
4.1 CLEANING AND PAINTING YOUR STOVE ........................................................................................32
4.2 GLASS..........................................................................................................................................................32
4.3 GASKETING...............................................................................................................................................33
4.4 ASH REMOVAL USING THE ASH DRAWER......................................................................................33
4.5 CHIMNEY (FLUE) CLEANING...............................................................................................................34
4.6 BAFFLE INSTALLATION........................................................................................................................35
4.6.1 Baffle installation for Solution 1.8 model.........................................................................................................35
4.6.2 Baffle installation for Solution 2.9 model.........................................................................................................36
4.7 SECONDARY AIR TUBE REPLACEMENT..........................................................................................37
5. SPECIFICATIONS......................................................................................................................................... 38
5.1 SOLUTION 1.8............................................................................................................................................38
5.2 SOLUTION 2.9............................................................................................................................................39
ENERZONE LIMITED LIFETIME WARRANTY.............................................................................................. 40

4
1. INSTALLATION
When installed and operated as described in these instructions, the E.P.A Enerzone wood stove is
suitable for use as a freestanding wood stove in residential installations. The E.P.A Enerzone
wood stove is not intended for installation in a bedroom.
In Canada, the CSA B365 Installation Code for Solid Fuel Burning Appliances and Equipment
and the CSA C22.1 Canadian National Electrical Code are to be followed in the absence of local
code requirements. In the USA, the ANSI NFPA 70 National Electrical Code and NFPA 211
Standard for Chimneys, Fireplaces, Vents and Solid Fuel-Burning Appliances are to be followed
in the absence of local code requirements.
In addition to the national installation and/or local building codes, fire officials (or other
authorities having jurisdiction) should be contacted to determine what restrictions and installation
requirements might apply locally.
Only Solution 1.8 model is mobile home approved. Refer to the mobile home installation section
for details.
1.1 GENERAL INSTALLATION
CAUTION:
• MIXING OF APPLIANCE OR FLUE SYSTEM COMPONENTS FROM DIFFERENT SOURCES OR MODIFYING THE
DIMENSIONAL SPECIFICATION OF COMPONENTS MAY RESULT IN HAZARDOUS CONDITIONS . WHERE
SUCH ACTION IS CONSIDERED , THE MANUFACTURER SHOULD BE CONSULTED IN THE FIRST INSTANCE .
•D O NOT CONNECT THIS UNIT TO ANY AIR DISTRIBUTION SYSTEM .
• CRACKED AND BROKEN COMPONENTS , e.g. GLASS PANELS OR CERAMIC TILES , MAY RENDER THIS
INSTALLATION UNSAFE .
•A SOURCE OF FRESH AIR INTO THE ROOM OR SPACE HEATED SHALL BE PROVIDED WHEN REQUIRED .
• INSTALL A SMOKE DETECTOR IN THE ROOM WHERE THE STOVE IS LOCATED
•C ONNECT THE STOVE ONLY TO A LINED MASONRY CHIMNEY CONFORMING TO NATIONAL AND LOCAL
BUILDING CODES FOR USE WITH SOLID FUEL , OR TO A LISTED FACTORY BUILT CHIMNEY SUITABLE FOR
USE WITH SOLID FUEL .

5
1.1.1 Pedestal or leg kit assembly
We suggest assembling the leg kit or pedestal before positioning the stove. See table 1.1.1 below:
1- Unscrew the 4 bolts in order to remove the
2 steel supports. Dispose of the two steel
supports. They are no longer required.
Note: Parts may vary slightly from one model to
another but the assembly procedure remains the
same.
2 (A) - Fix the pedestal base using the 4 bolts and
washers removed in the previous step.
2 (B) - Fix the 2 leg supports using the 4 bolts
and washers removed in the previous
step.
Table 1.1.1 Pedestal or leg kit assembly

6
1.1.2 Installation of the decorative u-shaped inserts
Your freestanding Enerzone wood stove is equipped with decorative u-shaped inserts. See table
1.1.2 below for installation instructions:
1- Remove the 7 screws that retain the side
panels and the rear heat shield deflector.
2- Remove the side panels and clip the U-
shaped inserts (choose between gold or
nickel finish) at the top and bottom of
each panel.
3- Screw the side panels and heat shield
deflector back into place.
Table 1.1.2 Installation of the decorative u-shaped inserts
1.1.3 Door overlay installation
In order to complete the assembly of your freestanding Enerzone wood stove, you need to install
the door overlay. See table 1.1.3 below for installation instructions:
1- Position the overlay on the door frame and
fix it in place from behind using the 4
screws.
Note: It is not necessary to remove the glass
or any other component to install the
overlay.
Table 1.1.3 Door overlay installation

7
1.1.4 Optional air mate installation
Most freestanding Enerzone wood stoves can be equipped with an optional air mate. This device
accumulates heat and increases the air flow. See tale1.1.4 below for installation instructions:
1- Remove the 3 screws holding the rear eat shield deflector.
2- Position the air mate on top of the stove and fix it in place using the 3 screws removed in step
#1.
Table 1.1.4 Optional air mate installation

8
1.2 POSITIONING THE STOVE
It is very important to position the wood stove in an area that will favour the most efficient heat
distribution throughout the house. The stove should therefore be installed in the room where the
most time is spent, and in the most spacious room possible. Recall that wood stoves produce
radiating heat, the heat we feel when we are close to a wood stove. A wood stove also functions
by convection, which is through the displacement of hot air accelerated upwards and its
replacement with cooler air at the floor level. The stove’s convection effect is facilitated by the
installation of a blower.
1.3 CLEARANCES TO COMBUSTIBLES AND FLOOR PROTECTOR
To install your appliance correctly, it is extremely important to respect all clearances to any
combustibles as indicated on your stove’s certification label.
Clearances to combustible materials
(see figure 1.3 to match each letter to a clearance)
CLEARANCES (SINGLE WALL PIPE)
CANADA / USA
MODEL A B C D E F K L
Solution 1.8
14"
(356 mm) 12" (305 mm) 7" (178 mm) 18" (457 mm) 22" (559 mm) 18" (457 mm) 48" (1220 mm)
84"
(213 cm)
Solution 2.9
14"/10"
(356/254
mm)
14"
(356 mm) 7"/6" (178/152
mm)
18"/14"
(457/356
mm)
23"
(584 mm) 18"/17" (457/432
mm)
48"
(1220 mm)
84"
(213 cm)
CLEARANCES (DOUBLE WALL PIPE)
CANADA / USA
MODEL A B C D E F K L
Solution 1.8
6"
(152 mm) 11" (279 mm) 5" (127 mm) 10" (254 mm) 21" (533 mm) 16" (406 mm) 48" (1220 mm)
84"
(213 cm)
Solution 2.9
6"
(152 mm) 12" (305 mm) 6" (152 mm) 10" (254 mm) 21" (533 mm) 17" (432 mm) 48" (1220 mm)
84"
(213 cm)

9
FIGURE 1.3 Clearances to combustible materials and floor protection

10
Floor protector
If the stove is to be installed on top of a combustible floor, it must be guarded by a non
combustible material as shown on figure 1.3 (see the dotted line area).
FLOOR PROTECTOR*
CANADA USA
G 8’’ (203 mm) – Note 1 N/A (Canada only)
H 8’’ (203 mm) N/A (Canada only)
I 18’’ (457 mm)
From door opening 16’’ (406 mm) From door opening
J N/A (USA only) 8’’ (203 mm)
M 8’’ (203 mm) N/A (Canada only)
N N/A (USA only) Note 2
*Steel with a minimum thickness of 0.015’’ (0.38 mm) or ceramic tiles sealed together with
grout. No protection is required if the unit is installed on a non-combustible floor (ex:
concrete).
Note 1: The floor protection at the back of the stove is limited to the stove’s required
clearance if such clearance is smaller than 8 inches (203 mm).
Note 2: Only required under the horizontal section of the connector. Must exceed each side
of the connector by at least 2 inches (51 mm).
Reduced clearances using shielding
You may decrease the clearances by installing heat radiation shields between the walls or the
ceiling and the stove. These heat radiation shields must be installed permanently, and can include
sheet metal, a rigid non-combustible sheet or a masonry wall.
Clearances of not less than 1" (25 mm) and not more than 3" (76 mm) between the bottom of the
shield and the floor and not less than 3" (76 mm) between the top of the shield and the ceiling
must be respected to allow vertical air circulation behind the shield. The shield must extend 20"
(500 mm) above the stove top and 18" (450mm) to each side of the stove (see graphic 1).
Following the installation of such a heat radiation shield, the clearances mentioned on the stove
certification plate may be reduced as stated in the following table.

11
TYPE OF PROTECTION
Reducing Clearances With
Shielding
Sides and
Rear/Back Top
Sheet metal, a minimum of 0,024" (0,61mm) spaced out at
least 1" (25mm) by non-combustible spacers (see
graphic 2). 67% 50%
Ceramic tiles, or an equivalent non-combustible material on
fire-proof supports spaced out at least 1" (25 mm) by non-
combustible spacers (see graphic 3). 50% 33%
Ceramic tiles, or an equivalent non-combustible material on
fire-proof supports with a minimum of 0,024" (0,61 mm) sheet
metal backing spaced out at least 1" (25 mm) by non-
combustible spacers (see graphic 4)
67% 50%
Brick spaced out at least 1" (25 mm) by non-combustible
spacers (see graphic 5) 50% N/A
Brick with a minimum of 0,024" (0,61 mm) sheet metal
backing spaced out at least 1" (25 mm) by non-combustible
spacers (see graphic 6). 67% N/A
1.1.4.1 Graphic 1

12
A- Minimum clearance required between the appliance and an unshielded combustible ceiling.
B- 20 in. (500 mm) minimum;
C- 1 in. (25 mm) minimum;
D- Between 1 in. and 3 in. (25 mm and 75 mm);
E- 3 in.(75 mm) minimum;
F- 18 in. (457 mm) minimum.
1- Shielding;
2- Non-combustible spacers;
3- Ceiling protector;
4- Combustible wall;
5- Ceiling;
6- Appliance (side view);
7- Appliance (top view).
1.1.4.2 Graphic 2
A- 1 in. (25 mm) minimum;
1- Combustible wall;
2- Non-combustible spacers;
3- 0.02 in (0.61mm) sheet metal.
Graphic 3
A- 1 in. (25 mm) minimum;
1- Combustible wall;
2- Non-combustible spacers;
3- Non-combustible support;
4- Ceramic tile or non-combustible material.

13
Graphic 4
A- 1 in. (25 mm) minimum;
1- Combustible wall;
2- Non-combustible spacer;
3- 0.024 in (0.61 mm) thick sheet metal;
4- Non-combustible support;
5- Ceramic tile or non-combustible material.
Graphic 5
A- 1 in. (25 mm) minimum;
1- Combustible wall;
2- Non-combustible spacers;
3- Brick.
Graphique 6
A- 1 in. (25 mm) minimum;
1- Combustible wall;
2- Non-combustible spacers;
3- 0.024 in (0.61 mm) thick sheet metal;
4-Brick.

14
2. CHIMNEY (FLUE SYSTEM)
2.1DEFINITIONS
For clarity, the following definitions should be used with respect to these instructions:
•A chimney system consists of a connector off the top of the stove, and a chimney, which
attaches to the connector and terminates outside the house.
•A chimney can be a masonry chimney (of masonry construction with an inside liner), or a
factory built chimney.
•A factory built chimney can be a double walled chimney (two concentric pipes with
insulation - sometimes referred to as an insulated solid pack) or an air cooled chimney
(three concentric pipes, with insulation between the first and second pipes, and air
between the second and third pipes).
•A single walled connector is a single pipe.
• A double walled connector has two concentric pipes, no insulation, and is an air cooled
connector.
2.2 CHIMNEY
CAUTION:
•DO NOT fill any framed space around the factory-built chimney with insulation or any
other material. Insulation placed in this area could cause adjacent combustibles to
overheat.
•Do not use makeshift compromises during installation as they may be safety hazards, and
a fire could result.
•Do not connect this unit to a chimney system serving another appliance.
•Do not cut rafters or ceiling joists without first consulting a building official to ensure
structural integrity is not compromised.

15
Your wood stove may be hooked up with a factory built or masonry chimney. If you are using a
factory built chimney, it must comply with UL103 (USA) or ULCS629 (Canada) standards. It
must therefore be a 6” (152mm) HT Type (2100°F) chimney. It is extremely important that it
be installed according to the manufacturer's specifications. The manufacturers’ installation
instructions and specified clearances should always be followed in accordance with local and
national installation codes. In Canada the CSA B365 and the CSA C22.1 installation codes are to
be followed. In the USA the ANSI NFPA 70 and ANSI NFPA 211 installation codes are to be
followed.
If you are using a masonry chimney, it is important that it be built in compliance with the
specifications of the Building Code. It must be lined with fire clay bricks, or clay tiles, sealed
together with fire cement, or have a listed solid fuel burning stainless steel liner. Round
chimneys are the most efficient.
The interior diameter of the chimney should be identical to the stove's smoke exhaust. A
chimney which is too small may cause draft problems, since it may not have the required volume
to properly evacuate the quantity of smoke resulting from the combustion. A chimney whish is
too large may also cause draft problems. In fact, a large chimney will be harder to warm-up and
may not reach high enough temperatures to create a proper draft effect. Note that it is the
chimney which creates the draft effect, not your stove. Your stove's performance is
therefore directly dependent on an adequate draft from your chimney.
The following recommendations may be useful for the installation of your chimney:
•Do not connect your stove to a chimney serving another appliance.
•The chimney must rise above the roof at least 3' (0.9 mm) from the uppermost point of
contact. See Figure 2.2.
•The chimney must exceed any part of the building or other obstruction within a 10' (3.04
m) distance by a height of at least 2' (0.6 m). See Figure 2.2.
•The minimum overall height of the chimney system, measured from the stove top to the
exterior termination cap of the chimney should be at least 12' (3.66m). A chimney which
is too short may lack the “tunnel effect” required to obtain a proper draft.
•Installation of an interior chimney is always preferable to an exterior chimney. Chimneys
constructed outside of the home on an exterior wall should be avoided if possible,
especially in colder climates. The gas which circulates into an interior chimney will cool
more slowly, thus reducing the build-up of creosote and the risk of flue fires.
•All else being equal, cooler chimneys will have less draft than hotter ones. This problem
will be amplified if the chimney is excessively long. A chimney which is excessively long
may be very hard to warm-up due to its higher volume. A cool chimney may even down
draft (reverse flow) due to the difficulty in heating it up to operating temperature while
trying to evacuate the stack gases.

16
•If an exterior chimney is used, the best results will be obtained by using a connector
vertically off the unit to the highest possible point before elbowing off horizontally to the
exterior chimney. For efficiency and safety reasons the stove must not be installed with an
insulated chimney connected directly to the appliance.
• Using a fire screen at the extremity of the chimney requires regular inspection in order to
insure that it is not obstructed, thus blocking the draft. It should be cleaned when
necessary.
FIGURE 2.2 Minimum Height of the Chimney
2.2.1 Step by step installation of your factory-built chimney
The way to install your chimney may vary from one chimney manufacturer to another. For
installation instructions, we advise you to consult your chimney manufacturer whose products are
sold at many North American retailers of wood stoves and related heating accessories.

17
Typical installation through the wall
Wall support system
If your chimney must rise along an outside wall, you need to connect it to your stove through an
adjacent wall. For this type of installation, the following items are normally required:
Chimney
•Suitable lengths of chimney (enough to go up to your roof)
•An adjustable wall support
•A wall thimble
•An adequate number of wall bands (one for every 8 feet of chimney, excluding the roof
portion)
•A stove pipe adapter
•One insulated tee & plug
•A roof flashing kit (if necessary)
•A chimney cap.
•Roof guys (if required)
Stove pipe
•An adequate number of stove pipe sections.
•A 90
o
elbow
FIGURE 2.2.1 (A) Typical installation through the wall

18
Typical installation through the ceiling
Ceiling support system
If your chimney must rise inside the house and go through the ceiling, you need to connect it to
your stove at the ceiling level. For this type of installation, the following items are normally
required:
Chimney
•An adequate number of chimney sections (enough to go up to your roof)
•A ceiling support kit with stove pipe adapter
•An attic insulation shield
•A roof flashing kit
•A chimney cap
•Roof guys (if necessary)
Stove pipe
•Suitable lengths of stove pipe
FIGURE 2.2.1 (B) Typical Installation Through the Ceiling

19
2.2.2 Typical installation through an existing masonry chimney
You can also install your stove using your existing masonry chimney. To do so, follow the
guidelines below. You may want to use a factory-built thimble, on construct your own brick
thimble. If you are using a masonry chimney, it is important that it be built in compliance with
the specifications of the Building Code in your region. It must normally be lined with fire clay
bricks, metal or clay tiles sealed together with fire cement. (Round flues are the most efficient).
FIGURE 2.2.2 (A) Typical Installation Through an Existing Masonry
Chimney

FIGURE 2.2.2 (B
FIGURE 2.2.2 (C
FIGURE 2.2.2 (B
) Factory Built Thimble
FIGURE 2.2.2 (C
) Brick Thimble
20
