Enerzone Solution 2.9 User manual

45863A
Printed in Canada 18-05-2016
ENERZONE WOOD STOVE MANUAL
Solution 2.9 (EB00004 model)
US ENVIRONMENTAL
PROTECTION AGENCY
PHASE II CERTIFIED
WOOD STOVE
Fabriqué par :
STOVE BUILDER INTERNATIONAL INC.
250, rue de Copenhague,
Saint-Augustin-de-Desmaures
(Quebec) G3A 2H3
After-sale service: 418-908-8002
E-mail: [e-mail]
www.enerzone-intl.com
Verified and tested
following ULC S627
and UL 1482 Standards
by an accredited
laboratory
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer’s web site. It is a copyrighted
document. Resale is strictly prohibited. The manufacturer may update this manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.

2
INTRODUCTION
Stove Builder International, one of the most important wood stoves and fireplace manufacturers
in North America, congratulates you on your purchase and wishes to help you get maximum
satisfaction from your wood stove. In the pages that follow, we will give you advice on wood
heating and controlled combustion as well as technical specifications regarding installation,
operation and maintenance of the model you have chosen.
The instructions pertaining to the installation of your wood stove in North America comply with
ULC-S627 and UL-1482 standards.
We recommend that our wood-burning hearth products is installed and serviced by professionals
who are certified in the United States by NFI (National Fireplace Institute®) or in Canada by
WETT (Wood Energy Technology Transfer) or in Quebec by APC (Association des
Professionnels du Chauffage).
Read this entire manual before you install and use your new stove. If this stove is not
properly installed, a house fire may result. To reduce the risk of fire, follow the installation
instructions. Failure to follow instructions may result in property damage, bodily injury,
or even death.
Consult your municipal building department or fire officials about restrictions and
installation requirements in your area and the need to obtain a permit.
KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
CAUTIONS:
THE INFORMATION GIVEN ON THE CERTIFICATION LABEL AFFIXED TO THE APPLIANCE ALWAYS
OVERRIDES THE INFORMATION PUBLISHED,IN ANY OTHER MEDIA (OWNER’S MANUAL,
CATALOGUES,FLYERS,MAGAZINES AND/OR WEB SITES).
HOT WHILE IN OPERATION.KEEP CHILDREN,CLOTHING AND FURNITURE AWAY.CONTACT MAY
CAUSE SKIN BURNS.
DO NOT USE CHEMICALS OR FLUIDS TO IGNITE THE FIRE.
DO NOT LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SLIGHTLY OPENED DURING
IGNITION.
DO NOT BURN WASTE,FLAMMABLE FLUID SUCH AS GASOLINE,NAPHTHA,OR MOTOR OIL.
DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM.
ALWAYS CLOSE THE DOOR AFTER IGNITION.

3
TABLE OF CONTENTS
1. SOLUTION 2.9 SPECIFICATIONS ............................................................................................................... 4
2. INSTALLATION .............................................................................................................................................. 7
2.1 GENERAL INSTALLATION ...................................................................................................................... 7
2.1.1 Pedestal or leg kit assembly................................................................................................................................8
2.1.2 Installation of the decorative u-shaped inserts....................................................................................................9
2.1.3 Door overlay installation ....................................................................................................................................9
2.1.4 Optional air mate installation............................................................................................................................10
2.2 POSITIONING THE STOVE .................................................................................................................... 10
2.3 CLEARANCES TO COMBUSTIBLES AND FLOOR PROTECTOR ................................................. 11
3. CHIMNEY (FLUE SYSTEM)........................................................................................................................ 17
3.1 DEFINITIONS ............................................................................................................................................. 17
3.2 CHIMNEY ................................................................................................................................................... 17
3.2.1 Step by step installation of your factory-built chimney ....................................................................................19
3.2.2 Typical installation through an existing masonry chimney...............................................................................22
3.3 CHIMNEY CONNECTOR......................................................................................................................... 24
3.4 DRAFT ......................................................................................................................................................... 26
3.5 FRESH AIR INTAKE KIT......................................................................................................................... 26
3.6 THE ADVANTAGE OF INSTALLING A BLOWER ............................................................................. 27
4. OPERATION................................................................................................................................................... 28
4.1 SAFETY INFORMATION ......................................................................................................................... 29
4.2 FUEL............................................................................................................................................................. 30
4.2.1 The use of manufactured logs...........................................................................................................................31
4.2.2 Simple Wood Moisture Test.............................................................................................................................32
4.3 NOTES ABOUT FIRST FIRING............................................................................................................... 32
4.4 LIGHTING A FIRE .................................................................................................................................... 32
4.5 MAINTAINING THE FIRE....................................................................................................................... 33
4.6 BLOWER OPERATION ............................................................................................................................ 34
5. MAINTENANCE ............................................................................................................................................ 35
5.1 CLEANING AND PAINTING YOUR STOVE ........................................................................................ 35
5.2 GLASS .......................................................................................................................................................... 35
5.3 GASKETING ............................................................................................................................................... 36
5.4 ASH REMOVAL USING THE ASH DRAWER ...................................................................................... 36
5.5 CHIMNEY (FLUE) CLEANING ............................................................................................................... 37
5.6 BAFFLE INSTALLATION ........................................................................................................................ 38
5.7 SECONDARY AIR TUBE REPLACEMENT .......................................................................................... 39
ENERZONE LIMITED LIFETIME WARRANTY.............................................................................................. 40

4
1. SOLUTION 2.9 SPECIFICATIONS
Fuel Type Cordwood
Test Standards ULC S627 & UL 1482 residential.
Recommended surface: 750 to 2300 sq. ft.
Heating capacity* –BTU/hr., EPA test wood: 29,400 BTU/h.
Heating capacity* –BTU/hr., seasoned cordwood: 85,000 BTU/h.
Optimum efficiency: 76%
*Why is the BTU indicated on the EPA label smaller than the one advertised?
You will notice a difference between the BTU output as indicated on the unit’s white EPA label affixed to the glass
and the BTU as advertised on our web site and/or product literature. The maximum BTU output we advertise for
this unit is what will be obtained with a full load of seasoned cordwood inserted inside the firebox. The EPA output,
on the other hand, is what has been obtained during emissions testing. The EPA test procedure requires that a
special type of wood be used and positioned inside the firebox in a manner that does not represent the way the
firebox volume would normally be utilized using seasoned cordwood. The EPA test load is typically much smaller.
Hence, the BTU as per the EPA label is reduced. The BTU output that should be considered by a normal user is the
one we advertise for seasoned cordwood.
Shipping Weight 420 lbs (191 kg)
Firebox Volume 2.9 cu.ft. (0,082 m3)
Firebox Floor Area 16.75’’W x 19,125’’D (425 mm x 486 mm)
Door Opening Size 15.5” wide x 9.75” high (398 mm x 248 mm)
Maximum 19” (483 mm) if loading sideways
Log Size
Flue Outlet 6” (152 mm) diameter (vertical)

5

6
622mm

7
2. INSTALLATION
When installed and operated as described in these instructions, the Enerzone wood stove is
suitable for use as a freestanding wood stove in residential installations. The Enerzone wood
stove is not intended for installation in a bedroom.
In Canada, the CSA B365 Installation Code for Solid Fuel Burning Appliances and Equipment
and the CSA C22.1 Canadian National Electrical Code are to be followed in the absence of local
code requirements. In the USA, the ANSI NFPA 70 National Electrical Code and NFPA 211
Standard for Chimneys, Fireplaces, Vents and Solid Fuel-Burning Appliances are to be followed
in the absence of local code requirements.
In addition to the national installation and/or local building codes, fire officials (or other
authorities having jurisdiction) should be contacted to determine what restrictions and installation
requirements might apply locally.
2.1 GENERAL INSTALLATION
CAUTION:
MIXING OF APPLIANCE OR FLUE SYSTEM COMPONENTS FROM DIFFERENT SOURCES OR MODIFYING THE
DIMENSIONAL SPECIFICATION OF COMPONENTS MAY RESULT IN HAZARDOUS CONDITIONS.WHERE
SUCH ACTION IS CONSIDERED,THE MANUFACTURER SHOULD BE CONSULTED IN THE FIRST INSTANCE.
DO NOT CONNECT THIS UNIT TO ANY AIR DISTRIBUTION SYSTEM.
CRACKED AND BROKEN COMPONENTS,e.g. GLASS PANELS OR CERAMIC TILES,MAY RENDER THIS
INSTALLATION UNSAFE.
ASOURCE OF FRESH AIR INTO THE ROOM OR SPACE HEATED SHALL BE PROVIDED WHEN REQUIRED.
INSTALL A SMOKE DETECTOR IN THE ROOM WHERE THE STOVE IS LOCATED
CONNECT THE STOVE ONLY TO A LINED MASONRY CHIMNEY CONFORMING TO NATIONAL AND LOCAL
BUILDING CODES FOR USE WITH SOLID FUEL,OR TO A LISTED FACTORY BUILT CHIMNEY SUITABLE FOR
USE WITH SOLID FUEL.

8
2.1.1 Pedestal or leg kit assembly
We suggest assembling the leg kit or pedestal before positioning the stove. See table below:
1- Unscrew the 4 bolts in order to remove the
2 steel supports. Dispose of the two steel
supports. They are no longer required.
Note: Parts may vary slightly from one model to
another but the assembly procedure remains the
same.
2 (A) - Fix the pedestal base using the 4 bolts and
washers removed in the previous step.
2 (B) - Fix the 2 legs supports using the 4 bolts
and washers removed in the previous
step.
Table 2.1.1 Pedestal or leg kit assembly

9
2.1.2 Installation of the decorative u-shaped inserts
Your freestanding Enerzone wood stove is equipped with decorative u-shaped inserts. See table
below for installation instructions:
1- Remove the 7 screws that retain the
side panels and the rear heat shield
deflector.
2- Remove the side panels and clip the
U-shaped inserts (choose between gold
or nickel finish) at the top and bottom of
each panel.
3- Screw the side panels and heat shield
deflector back into place.
Table 2.1.2 Installation of the decorative u-shaped inserts
2.1.3 Door overlay installation
In order to complete the assembly of your freestanding Enerzone wood stove, you need to install
the door overlay. See table 2.1.3 below for installation instructions:
1- Position the overlay on the door frame
and fix it in place from behind using the
4 screws.
Note: It is not necessary to remove the
glass or any other component to install
the overlay.
Table 2.1.3 Door overlay installation

10
2.1.4 Optional air mate installation
Most freestanding Enerzone wood stoves can be equipped with an optional air mate. This device
accumulates heat and increases the airflow. See below for installation instructions:
1- Remove the 3 screws holding the rear eat shield deflector.
2- Position the air mate on top of the stove and fix it in place using the 3 screws removed in
step #1.
2.2 POSITIONING THE STOVE
It is very important to position the wood stove in an area that will favour the most efficient heat
distribution throughout the house. The stove should therefore be installed in the room where the
most time is spent, and in the most spacious room possible. Recall that wood stoves produce
radiating heat, the heat we feel when we are close to a wood stove. A wood stove also functions
by convection, which is through the displacement of hot air accelerated upwards and its
replacement with cooler air at the floor level. The stove’s convection effect is facilitated by the
installation of a blower.

11
2.3 CLEARANCES TO COMBUSTIBLES AND FLOOR PROTECTOR
To install your appliance correctly, it is extremely important to respect all clearances to any
combustibles as indicated on your stove’s certification label.
See figure 2.3 to match each letter to a clearance.
APPLIANCE CLEARANCES
(INSTALLATION WITH SINGLE
WALL PIPE CONNECTOR)
CANADA
USA
A
14" (356 mm)
10" (254 mm)
B
14" (356 mm)
14" (356 mm)
C
7" (178 mm)
6" (152 mm)
K
48" (1220 mm)
48" (1220 mm)
L
84" (213 cm)
84" (213 cm)
APPLIANCE CLEARANCES
(INSTALLATION WITH DOUBLE
WALL PIPE CONNECTOR)
CANADA
USA
A
6" (152 mm)
6" (152 mm)
B
12" (305 mm)
12" (305 mm)
C
6" (152 mm)
6" (152 mm)
K
48" (1220 mm)
48" (1220 mm)
L
84" (213 cm)
84" (213 cm)
If the above clearances are met, then the distances measured from the flue outlet will be:
DISTANCES* FROM PIPE
CONNECTOR TO THE
COMBUSTIBLE MATERIALS
CANADA
USA
D
18" (457 mm)
14" (356 mm)
E
23" (584 mm)
23" (584 mm)
F
18" (457 mm)
17" (432 mm)
DISTANCES* FROM PIPE
CONNECTOR TO THE
COMBUSTIBLE MATERIALS
CANADA
USA
D
10" (254 mm)
10" (254 mm)
E
21" (533 mm)
21" (533 mm)
F
17" (432 mm)
17" (432 mm)
*The pipe distances listed in this table refer to the distances obtained when the stove is
installed in accordance with the appliance clearances above mentioned. However, you can
install the stove at reduced clearances; follow the instructions in Section Reducing Wall and
Ceiling Clearances Safely. Where they are followed, the new distance of the pipe to
combustible materials must be respected in the appropriate certification of the pipe.

12
FIGURE 2.3 Clearances to combustible materials and floor protection

13
Floor protector
If the stove is to be installed on top of a combustible floor, it must be guarded by a non
combustible material as shown on figure 2.3 (see the dotted line area).
FLOOR PROTECTOR*
CANADA
USA
G
8" (203 mm) –Note 1
N/A (Canada only)
H
8" (203 mm)
N/A (Canada only)
I
18" (457 mm)
From door opening
16" (406 mm)
From door opening
J
N/A (USA only)
8" (203 mm)
M
8" (203 mm)
N/A (Canada only)
N
N/A (USA only)
Note 2
*Steel with a minimum thickness of 0.015" (0.38 mm) or ceramic tiles sealed together with
grout. No protection is required if the unit is installed on a non-combustible floor (ex:
concrete).
Note 1: The floor protection at the back of the stove is limited to the stove’s required
clearance if such clearance is smaller than 8 inches (203 mm).
Note 2: Only required under the horizontal section of the connector. Must exceed each side
of the connector by at least 2 inches (51 mm).

14
Reducing Wall and Ceiling Clearances Safely
It is often desirable to reduce the
minimum installation clearances
by placing the stove closer to
walls so the installation takes up
less floor space. You can safely
reduce the minimum clearances
by permanently installing a
shield between the stove and
combustible material. The rules
for safe shields can be
complicated, so read them
carefully and follow them
exactly. Note that there may be
minor regional differences in
clearance reduction rules so be
sure to check with your building
or fire inspector before
proceeding.
Shield Construction Rules
See figure Clearances for shield construction to match each letter to a clearance.
-
Adhesives used in shield construction must not ignite or lose adhesive qualities at temperatures
likely to be encountered.
-
Mounting hardware which extends from the shield surface into combustibles may be used only
at the edges of the shield.
-
Mounting hardware must allow full vertical ventilation.
A
Minimum clearance between the appliance top and an unshielded combustible ceiling:
1283 mm (50 1/2 po.)
B
Shield extension above appliance: 500 mm (20 in.).
C
Minimum space behind shield: 25 mm (1 in.). In Canada 21 mm (7/8 in).
D
Clearance along the bottom of shield: minimum: 25 mm (1 in.) and maximum: 75 mm (3 in.).
E
Minimum clearance along the top of shield at ceiling: 75 mm (3 in.).
F
Mounting hardware must not be located closer than 200 mm (8 in.) from the vertical centre line
of the appliance.
G
Edge clearance for ceiling shields to side and back walls: 75 mm (3 in.).
H
Shield extension beyond each side of appliance: 450 mm (18 in.).

15
Clearances for shield construction

16
Table of Clearance Reduction Percentages
Type of shield
Clearances may be reduced by these
percentages
Sides
and rear %
Top %
(ceiling)
Can/USA
(%)
USA
min.
Can/USA
(%)
USA
min.
Sheet metal, a minimum of 24 gauge
(0.61 mm) in thickness , spaced out at
least 25 mm (1 in)* by non-
combustible spacers
67
12 in
50
18 in
Ceramic tiles, or equivalent non-
combustible material, on non-
combustible board spaced out at least
25 mm (1 in)* by non-combustible
spacers
50
18 in
33
24 in
Ceramic tiles, or equivalent non-
combustible material, on non-
combustible board, with a minimum of
24 gauge (0.61 mm) sheet metal
backing spaced out at least 25 mm
(1 in)* by non-combustible spacers
67
12 in
50
24 in
Brick, spaced out at least 25 mm
(1 in)* by non-combustible spacers
50
18 in
N/A
N/A
Brick, with a minimum of 24 gauge
(0.61 mm) sheet metal backing,
spaced out at least 25 mm (1 in)* by
non-combustible spacers
67
12 in
N/A
N/A
* In Canada this space can be 21 mm (7/8 in).

17
3. CHIMNEY (FLUE SYSTEM)
3.1 DEFINITIONS
For clarity, the following definitions should be used with respect to these instructions:
A chimney system consists of a connector off the top of the stove, and a chimney, which
attaches to the connector and terminates outside the house.
A chimney can be a masonry chimney (of masonry construction with an inside liner), or a
factory built chimney.
A factory built chimney can be a double-walled chimney (two concentric pipes with
insulation - sometimes referred to as an insulated solid pack) or an air-cooled chimney
(three concentric pipes, with insulation between the first and second pipes, and air
between the second and third pipes).
A single-wall connector is a single pipe.
A double-wall connector has two concentric pipes, no insulation, and is an air-cooled
connector.
3.2 CHIMNEY
CAUTION:
DO NOT fill any framed space around the factory-built chimney with insulation or any
other material. Insulation placed in this area could cause adjacent combustibles to
overheat.
Do not use makeshift compromises during installation as they may be safety hazards, and
a fire could result.
Do not connect this unit to a chimney system serving another appliance.
Do not cut rafters or ceiling joists without first consulting a building official to ensure
structural integrity is not compromised.

18
Your wood stove may be hooked up with a factory built or masonry chimney. If you are using a
factory built chimney, it must comply with UL 103 (USA) or ULCS629 (Canada) standards. It
must therefore be a 6” (152 mm) HT Type (2100°F) chimney. It is extremely important that it
be installed according to the manufacturer's specifications. The manufacturers’ installation
instructions and specified clearances should always be followed in accordance with local and
national installation codes. In Canada the CSA B365 and the CSA C22.1 installation codes are to
be followed. In the USA the ANSI NFPA 70 and ANSI NFPA 211 installation codes are to be
followed.
If you are using a masonry chimney, it is important that it be built in compliance with the
specifications of the Building Code. It must be lined with fire-clay bricks, or clay tiles, sealed
together with fire cement, or have a listed solid fuel burning stainless steel liner. Round
chimneys are the most efficient.
The interior diameter of the chimney should be identical to the stove's smoke exhaust. A
chimney which is too small may cause draft problems, since it may not have the required volume
to properly evacuate the quantity of smoke resulting from the combustion. A chimney which is
too large may also cause draft problems. In fact, a large chimney will be harder to warm up and
may not reach high enough temperatures to create a proper draft effect. Note that it is the
chimney which creates the draft effect, not your stove. Your stove's performance is
therefore directly dependent on an adequate draft from your chimney.
The following recommendations may be useful for the installation of your chimney:
Do not connect your stove to a chimney serving another appliance.
The chimney must rise above the roof at least 3' (0.9 mm) from the uppermost point of
contact. See Figure 3.2.
The chimney must exceed any part of the building or other obstruction within a 10' (3.04
m) distance by a height of at least 2' (0.6 m). See Figure 3.2.
The minimum overall height of the chimney system, measured from the stove top to the
exterior termination cap of the chimney should be at least 12' (3.66m). A chimney which
is too short may lack the “tunnel effect” required to obtain a proper draft.
Installation of an interior chimney is always preferable to an exterior chimney. Chimneys
constructed outside of the home on an exterior wall should be avoided if possible,
especially in colder climates. The gas which circulates into an interior chimney will cool
more slowly, thus reducing the build-up of creosote and the risk of flue fires.
All else being equal, cooler chimneys will have less draft than hotter ones. This problem
will be amplified if the chimney is excessively long. A chimney which is excessively long
may be very hard to warm up due to its higher volume. A cool chimney may even down
draft (reverse flow) due to the difficulty in heating it up to operating temperature while
trying to evacuate the stack gases.

19
If an exterior chimney is used, the best results will be obtained by using a connector
vertically off the unit to the highest possible point before elbowing off horizontally to the
exterior chimney. For efficiency and safety reasons the stove must not be installed with an
insulated chimney connected directly to the appliance.
Using a fire screen at the extremity of the chimney requires regular inspection in order to
ensure that it is not obstructed, thus blocking the draft. It should be cleaned when
necessary.
FIGURE 3.2 Minimum Height of the Chimney
3.2.1 Step by step installation of your factory-built chimney
The way to install your chimney may vary from one chimney manufacturer to another. For
installation instructions, we advise you to consult your chimney manufacturer whose products are
sold at many North American retailers of wood stoves and related heating accessories.
