Engenius Durafon-uhf-hc User manual

User Manual

DuraFon-UHF-HC

Durable, Long-Range, Dual Mode Radio Phone

~2~

Table of Contents

Safety Instructions................................................................................................... 4

General Safety Instructions ................................................................................ 4

Product Safety Instructions ................................................................................ 4

Battery Safety Instructions ................................................................................. 6

Regulatory Information ........................................................................................... 7

Equipment Checklist.............................................................................................. 11

Handset Illustration ............................................................................................... 12

Handset Features .................................................................................................. 14

Basic Handset Features..................................................................................... 14

Additional Handset Features ............................................................................ 16

Administrator Features (Register to PRO base)................................................ 19

Charger Illustration................................................................................................ 20

Charger Features ................................................................................................... 21

Getting Started ...................................................................................................... 22

Handset and Charger Installation ..................................................................... 22

Basic Operations.................................................................................................... 23

Operation Modes.............................................................................................. 23

Base Operation Modes................................................................................. 23

Handset Operation Modes ........................................................................... 23

Menu Tree (Register to PRO base only)............................................................ 24

Making a Telephone Call................................................................................... 25

Making an 2-Way/ Intercom Call...................................................................... 25

Handset to Handset Calls ............................................................................. 25

Making a Broadcast via 900MHz ...................................................................... 26

Handset to Handset Calls ............................................................................ 26

Making a Broadcast via UHF ............................................................................. 27

Handset to UHF walkie-talkie....................................................................... 27

Redial ................................................................................................................ 27

Receiving a Telephone Call ............................................................................... 28

Receiving an Intercom Call ............................................................................... 28

Ending a Call...................................................................................................... 29

Adjusting Receiver (Earpiece) Voice Volume.................................................... 29

Adjusting Speaker Volume................................................................................ 29

Placing a Call On Hold ....................................................................................... 30

Mute ................................................................................................................. 30

Do Not Disturb (Silent Ring).............................................................................. 30

KeyGuard .......................................................................................................... 31

~3~

To View Missed Call(s) ...................................................................................... 31

To Call back from Call Log................................................................................. 31

Battery Recharge and Replacement ................................................................. 32

Walkie-Talkie Mode.......................................................................................... 33

Advanced Operations ............................................................................................ 34

Handset Registration (Register to PRO base only)............................................ 34

Advanced Registration (Register to PRO base only) ......................................... 35

Handset Group Subscription............................................................................. 37

Call Transfer (Register to PRO base only) ......................................................... 37

3-Way Conferencing (Register to PRO base only)............................................. 38

Base Select (Register to PRO base only ) .......................................................... 39

Call Waiting (Register to PRO base only) .......................................................... 39

Auto Attendant (AA) (Register to PRO base only) ............................................ 40

AA Configuration by Administrator (Register to PRO base only)...................... 41

Change AA Parameters (Register to PRO base only) ........................................ 42

Line Dedication (Register to PRO base only) .................................................... 43

Line Selection (Register to PRO base only) ....................................................... 43

Change System and Line Settings by Admin (Register to PRO base only) ........ 44

Phonebook Operations (Register to PRO base only) ........................................ 45

Programmable PBX Options (Register to PRO base only)................................. 49

Broadcast through PBX (Register to PRO base only) ........................................ 50

UHF Frequencies and Codes.................................................................................. 52

Menu Operations (Register to PRO base only)...................................................... 54

Technical Specifications......................................................................................... 60

Index...................................................................................................................... 62

FCC Part 68 Statement .......................................................................................... 64

~4~

Safety Instructions

Caution: Your wireless telephone gives you freedom and flexibility to

stay in touch while you move around. However, when using your phone

equipment, safety instructions should be followed to avoid the risks of

fire, electric shock, injury to person, and damage to property.

General Safety Instructions

1. When using your wireless handset, ensure your safety and the safety of others:

a. Always watch where you are walking and standing.

b. Don’t let a phone call distract you from working safely.

c. If power goes out, the phone won’t work. A backup power source or

landline is recommended.

2. In an emergency:

a. If an emergency occurs, dial the emergency phone number. Remember: if

you are in an area where your phone does not have a clear signal from the

base, it is highly probable that the call may not go through. Locate the

nearest landline telephone or other communications device to call for help.

b. Emergency calls may not automatically provide emergency personnel with

your name, phone number or location.

3. Notice to hearing aid users: This phone system is compatible with inductively

coupled hearing aids.

4. Notice to cardiac pacemaker users: Preliminary studies done by the US FDA and

others have shown that, although interference to the implanted cardiac

pacemaker may occur when operating very closely, wireless telephones “do not

seem to pose a significant problem for pacemaker wearers.” However, until

more is known, the FDA suggests that people with pacemakers may want to

take precautions when using or carrying a wireless telephone to ensure that

there is ample distance between the telephone and the pacemaker. Do not

carry the handset in a breast pocket. If you have any reason to suspect that

interference is taking place, turn off your handset immediately.

Product Safety Instructions

1. Read and understand all instructions.

~5~

2. Follow all warnings and instructions including those marked on the product.

3. Changes or modifications to this product not expressively approved by the

manufacturer will void the warranty and the FCC authorization to operate the

equipment. Use only manufacturer-provided accessories.

4. Do not use the telephone near water. Never spill liquid of any kind on this

product.

5. Unplug the product from the wall telephone jack and power outlet before

cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

6. Do not place this product on an unstable cart, stand, or table. The product may

fall and cause personal injury or damage to the product or other property.

7. In the event of a power outage, your handset charger will not recharge the

handset battery, and the base station will not allow you to make an outgoing

call or take an incoming call. Both the charger and the base station require

electricity for operation. You should have a telephone that does not require

electricity available for use during power outage, or have a temporary backup

power supply.

8. Slots or openings in the product’s housing are provided for ventilation. These

openings must not be blocked or covered. Placing the product on a bed,

carpeting, or other similar surface may block these openings and should be

avoided. This product should never be placed near or over a radiator or heat

9. Never push objects of any kind into this product through housing

slots/openings as they may damage the product, touch dangerous voltage

points, or short-circuit parts that could result in fire, electric shock, or injury.

10. This product should be operated only from the type of power source indicated

on the label. If you are not sure of the type of power supply to your home,

consult your dealer or local power company.

11. Do not overload wall power outlets or extension cords as this may result in fire

or electric shock.

12. To avoid electric shock or burn, do not disassemble this product. Send this

product to an authorized service center when service or repair work is required.

Call Customer Service for locations near you. Opening or removing covers may

expose you to dangerous voltages, electrical currents, or other risks. Incorrect

reassembling of the product may cause electric shock when the product is

subsequently used.

13. Avoid using the product during a storm. There may be a risk of electric shock

from lightning.

14. Do not place the product where persons can step, trip, or fall on it.

~6~

15. Do not place conductive objects over or near the antenna.

16. Do not use the product to report a gas leak while in the vicinity of the leak.

17. Do not install the base station or the handset charger near microwave ovens,

radios, TV sets, speakers, or other electrical equipment. These appliances may

cause interference to the product or experience interference from the product.

18. Unplug the base station or the charger adaptor from the power outlet and refer

to an authorized service center under the following conditions:

a. Liquid has been spilled into the product.

b. The power supply cord or plug is damaged or frayed.

c. The product has been exposed to rain or water.

d. The product does not operate normally when following the operating

instructions.

e. The product has been dropped or housing has been damaged.

f. The product shows a distinct change in performance.

Battery Safety Instructions

1. Use only manufacturer-approved Li-ion rechargeable batteries and charger. Do

not use other types of rechargeable batteries or non-rechargeable batteries.

The batteries could short-circuit and damage the battery enclosure, causing a

hazardous condition.

2. Follow the charging instructions in this manual and instruction labels and

markings in the handset and charger compartments.

3. Batteries must be recycled or disposed of properly. Do not dispose of batteries

in a fire, as the cells may explode.

4. Do not dispose of batteries in municipal waste. Check with local codes for

disposal instructions.

5. Exercise care in handling batteries. Conductive materials such as rings,

bracelets, keys, pocketknives, and coins may cause the battery or conductive

material to short-circuit, overheat, and cause burns or fire.

6. Do not expose batteries to rain or water.

7. Do not open or mutilate the battery. The released electrolyte is corrosive and

may cause injury to eyes or skin. The electrolyte may be toxic if swallowed.

8. During charging, the battery heats up. This is normal and is not dangerous.

~7~

Regulatory Information

DuraFon-UHF-HC (SPR-922U1)

FCC ID: A8J-SPR922U1

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received, including

interference that may cause undesired operation.

Privacy of communications may not be ensured when using this phone.

Base Station

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate this

equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

~8~

and (2) this device must accept any interference received, including

interference that may cause undesired operation.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with the FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated

with a minimum distance of 20cm between the radiator and your body.

This transmitter must not be co-located or operating in conjunction with any

other antenna or transmitter.

Industry Canada Statement:

This device complies with RSS-210 of the Industry Canada rules. Operation is

subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause

undesired operation.

IMPORTANT NOTE:

Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated

with minimum distance 20cm between the radiator and your body.

This device has been designed to operate with an antenna having a maximum

gain of 1.5 dBi. Antennae having a higher gain are strictly prohibited per

regulations of Industry Canada. The required antenna impedance is 50 ohms.

Portable Handset
