PowerView®
Model PV380 R3
Installation Manual
Web View Only
*

00-02-1224 2 2023-01-26
*Products covered in this document comply with European Council electromagnetic
compatibility directive 2004/108/EC and electrical safety directive 2006/95/EC.
In order to consistently bring you the highest quality, full-featured products, we reserve
the right to change our specifications and designs at any time. The latest version of this
manual can be found at support.enovationcontrols.com, then search for PV380 R3.
Warranty - A limited warranty on materials and workmanship is given with this Murphy product. A copy of
the warranty may be viewed or printed by going to enovationcontrols.com/warranty
Table of Contents
Hardware Installation........................................................................................ 3
Inspecting Package Contents...............................................................3
Dash-Mounted Installation....................................................................3
Dimensions...........................................................................................4
Wiring Information ............................................................................................ 5
Pin Specifications for PV380.................................................................5
Wiring Diagram for PV380....................................................................6
PV380 Features and Operations ..........................................................7

00-02-1224 3 2023-01-26
Hardware Installation
The following instructions will guide you through installing the PowerView®PV380 R3
display.
Inspecting Package Contents
Before attempting to install the product, it is recommended that you ensure all parts are
accounted for and inspect each item for damage (which sometimes occurs during
shipping). The items included in the box are:
•PV380 R3 display
•Dash gasket
•Read First Insert with QR codes to Online versions of this document
(P/N 00-02-1222)
The PV380 R3 Operations Manual can be found online at:
support.EnovationControls.com
Then search for PV380 R3.
Dash-Mounted Installation
Tools needed
•Jig saw or
•3.5” Hole saw or
•3.5” knockout (chassis) punch
Preparing the Dash
Determine the location of the PowerView in the dash. Refer to the Mounting Hole
Options sheet at the end of this document for the appropriate opening sizes.
Mounting the Unit
1. Place the dash gasket over the prepared dash opening.
2. Place the back side of the display through the opening in the dash.
3. Push the unit through the opening until the case is flush.
4. Place the screw-on type mounting clamp behind the dash and install on the unit
until it is hand tight.

00-02-1224 4 2023-01-26
Dimensions

00-02-1224 5 2023-01-26
Wiring Information
Pin Specifications for PV380
PV380 Mating Connector Part Numbers:
•Deutsch DT06-12SA plug housing
•Deutsch DT06-6S plug housing
•W6S and W12S wedge locks
•Deutsch 0462-201-16141 contact (socket)

00-02-1224 6 2023-01-26
Wiring Diagram for PV380

00-02-1224 7 2023-01-26
PV380 Features and Operations
Flat Screen Display
A 3.8” QVGA monochrome LCD screen displays gauges, soft key commands and fault
messages as well as menu options for setup and configuration.
Soft Keys and Commands
The five tactile push buttons on the bottom of the display correspond to the options
available for the screen being displayed.
Alarms
Red and amber warning LEDs; set point triggered output for external piezo buzzer or
shut-down relay.
Operations Manual
The PV380 Murphy Standard Configuration Operation manuals can be found at
support.EnovationControls.com
Then search for PV380 R3.

00-02-1224 8 2023-01-26
Specifications
Electrical
Display
3.8” monochrome LCD
Resolution
QVGA, 320 x 240 pixels
Orientation
Landscape
Backlighting
LED, white
Flash Memory
2Mb
RAM
256kb
Operating Voltage
6 - 36 VDC, protected against reverse polarity and load-
dump
Power Consumption
10 W max
Communications
(1) CAN 2.0B
(1) RS485 serial (Modbus)
Protocols
J1939, FreeForm CAN
Connection
PV380: 6 pin and 12 pin Deutsch DT series connectors
Keyboard
5 tactile buttons
Inputs
(4) resistive analog
(3) analog, 0-5V / 4-20 mA
(1) frequency, 20-10,000 Hz, 3.6-120 VAC
Output
PV380: (2) 500 mA; switched low-side
Environmental
Operating Temperature
-40º C to +85º C
Storage Temperature
-40º C to +85º C
Protection
IP67, front and back, IP66 panel seal
Standards Compliance
Electrical Safety: 2006/95/EC
Electromagnetic Compatibility:
•2004/108/EC:
•EN 61000-6-4:2001 (emission)
•EN 61000-6-2:2001 (immunity)
•EN 50121-3-2 and EN 12895
•SAE J1113/2, 4, 11, 12, 21, 24, 26 and 41
Vibration
Random vibration, 7.86 Grms (5-2000 Hz), 3 axes
Shock
+/- 50G in 3 axes
Mechanical
Case Material
PC/ABS

00-02-1224 9 2023-01-26
Mounting Hole Options
