ENSIM SENSORS WATERSENS User manual

OPERATING
MANUEL
LIQUID WARNING DEDECTOR
WATERSENS
Model :
Model : 29-2022-005
Information in this manual is reviewed and completely reliable. Responsibility is not assumed due to any typing error.
Products in this manual are available only for information purpose and they may be changed without notice.
1
WATERSENS
WATERSENS-K
WATERSENS-P / N / R
Models :
Important Notes:
Used Symbols :
: Caution : Note : Disposal
Please read this manual carefully before installation of the liquid warning dedector. User is responsible for accidents and losses arising
from failure to comply with the warnings in this manual.
In the event that liquid warning dedector is broken, take measures in order to prevent accidents and losses which can occur in its system.
There is not any fuse and circuit breaker on the instrument; they should have been added to the system by the user.
This manual should be stored in an easily accessible place for subsequent use.
The manufacturer's liability cannot exceed the purchase price of the device according to the law.
Do not make any modification on the instrument and do not try to repair it. Reparation should be made by authorized service staff.
Do not operate the system before making assembly in compliance with the assembly chart related to the instrument.
Products which do not contain label and serial number are considered to be excluded from the warranty scope.
The instrument's useful life, determined and announced by the ministry, is 10 years.
Table of Contents :
General Information...........................................................................................................................................................................2
Installation .........................................................................................................................................................................................6
Failure Detection..............................................................................................................................................................................8
Disassembly of Instrument ............................................................................................................................................................8
Service .............................................................................................................................................................................................8
Recalibration....................................................................................................................................................................................8
Repair................................................................................................................................................................................................8
Disposal ...........................................................................................................................................................................................8
Terms of Warranty ..........................................................................................................................................................................8
Terms of Return ................................................8
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.

2
1. General Information :
1.1. Material Acceptance
Check that there is no damage on the packages during the transportation immediately after the material acceptance. If packages are
damaged, open the packages immediately and check whether products are affected or not, if there is any damage, send your
complaint report to the transporter company and its photocopy to the address of our company.
1.2. Information about Areas of Use
WATERSENS is used in order to detect the flood in advance and to take precaution at homes and offices. It can be powered by 9V. battery.
It can be ensured to stop any water leakage by commanding relay output to a solenoid valve. It can avail people around it to take
precautions by attracting their attention through siren.
Applications:
Operation rooms, computer rooms, warehouses, generator rooms, compressor rooms, air conditioner
rooms, baths, kitchens and
all locations having possibility of flood, fire alarm systems etc
WATERSENS P / N / R is used in order to determine the water level and to take precaution in the facilities. It ensures the people
in the ambient to take precaution by attracting their attention through siren in order to determine high water or low water level.
Its electronic card is in the upper box and it is insulated with resin.
It is not affected by water. Electrode material has been selected as stainless steel and its electronic design has been performed
specially in order that there is no electrolysis in the lead terminals. It is appropriate to submerge a weight onto the tooth on the submersion probe.
WATERSENS - K is used in order to determine the water level and to take precaution in the facilities. It ensures
the people in the ambient to take precaution by attracting their attention through siren in order to determine high water or low water level.
Its electronic card is in the upper box and it is insulated with resin.
It is not affected by water. Electrode material has been selected as stainless steel and its electronic design has been
performed specially in order that there is no electrolysis in the lead terminals. It is appropriate to submerge a weight onto the tooth
on the submersion probe.
Applications:
Wells, warehouse, the possibility of overflowing places, for high water detection , ship tanks, water level control, water leakage.
Ambient Conditions: Relative Humidity: 5-95 %RH Ambient temperature: 50 °C (It is not used under -5 °C)
1.3. Working Principle
When at least two of the electrodes under the body come into contact with water, the siren will sound a warning.
Advantages :
* Easy to assembly
* Long life battery
* Can be connected to the panel
* Economical

1.4. Features and Material Information
3
Technicial Specifications : WATERSENS
Electrical Connections:
Note: The probe cable must supply
by the customer
With Klemens Type
WATERSENS
With Cable Type
WATERSENS
Sample applications:
COM
NO
24 VDC
24 VAC
48 VAC
110 VAC
220 VAC
Solenoid Valve
3 ea. Alarm LED
1 ea. Siren + On /Off Button
Bipolar Cable, 1 m. std.
Three sensors can connect devices
1 x 9 V (6LR22) Battery or 24 VDC
2 A / 125 VAC NO / NC
2 years for storage
ABS Plastic, Black Colour (Opt.Grey)
(Inbox; 1 ea. watersens and probe
1 ea. Battery, 1 ea. Double-sided tape
2 ea. Wall mounting bracket)
190 g.
70 mm x 100 mm x 22 mm
Display
Siren
Sensor
Supply
Output
Battery life
Housing
Weight (With package)
Dimenson
GROUND
WALL
Probe
1
Probe
2
Probe
3
Double-sided
tape
WATERSENS
SUPPLY
Input 1
Input 2 Input 3
RELAY
Black: COM
Brown: NC
Blue: NO
Blue: V-
Red: V+
Brown: COM
White: L1
Green: L2
Yellow: L3

4
Technicial Specifications :
Supply
Cable
Output
Connection
Body Material
Working Temperature
Working Pressure
Mounting
Protection Class
Min. Conductivity
18 - 29 VDC
3 x 022 mm² or 5 x 022 mm² , 2 m. Std.
PNP-NO or NC Max. 100 mA
NPN-NO or NC Max. 100 mA
RELAY-NO / NC Max. 300 mA
In order to be indicated.
3/4  NPT Double Sided
Polypropylene Opt. Stainless Steel
Max. 85 °C
Max. 20 bar
Connected Vertically or Horizontally
IP 67
100 microSiemens / cm
WATERSENS-P / N / R
B Type Probe
3/4  NPT
3/4  NPT
2011.52054
105,5
WATERSENS-Po / Pc
WATERSENS-No / Nc
WATERSENS-R
Std. Product
Electric Conncection:
WATERSENS-P / N / R
Brown: 18-29 VDC
Black: NPN NO or NC, Max. 100 mA
Blue: GND
Brown: 18-29 VDC
Green: Relay NO, Max. 300 mA
White: Relay NC, Max. 300 mA
Yellow: Relay Coomon Pole
Blue: GND
Brown: 18-29 VDC
Black: NPN NO or NC, Max. 100 mA
Blue: GND

5
WATERSENS-K
Technicial Specifications :
Supply
Cable
Output
Battery Life
Housing
Connection
Body Material
Working Temperature
Working Pressure
Mounting
Protection Class
Min. Conductivity
1 x 9 V (6LR22) Battery or 24 VDC
3 x 022 mm² or 5 x 022 mm² , 2 m Std.
2 A / 125 VAC NA / NK
2 years for storage
ABS Plastic, Black Colour (Opt.Grey)
(Inbox; 1 ea watersens and probe
1 ea. Battery, 1 ea. Double-sided tape
2 ea. Wallmounting bracket)
3/4  NPT Double Sided
Polypropylene Opt. Stainless Steel
Max. 85 °C
Max. 20 bar
Connected Vertically or Horizontally
IP 67
100 microSiemens / cm
WATERSENS-K
K Type Probe
P Type Probe
Stainless Steel
Probe
Cable
L
Device
GROUND
WELL
WALL
Double-sided
tape

2. Installation
2.1. General Notes
Installation of the instrument should be made only by authorized personnel.
Do not apply force to the instrument during the installation!
Do not use the dedector with a greater pressure than recommended pressure.
Do not forget that instrument is precise, carry it carefully and prevent to be damaged.
It should be guaranteed that there are not any magnetic particles.
2.2. General Installation Stages
-Remove the device from cardboard box.
-Remove the battery from nylon and attach it by opening back cover of the device.
-Open ties of sensor and concact output cables and remove them without drawing.
-Check the end of sensor by touching wet cloth to it. Alarm has LED light and siren sound (while bottom button is ON).
When you turn the button OFF, siren will stop. But LED will continue to light. Whenever probe gets off the humid atmosphere,
LED will go OFF. Turn the button ON
-Assemble the sensor onto the surface through the adhesive behind it.
-Assemble the device onto an upper point through the adhesive behind it.
-If you use the relay output, you can attach it to your alarm panel, solenoid valve or similar control system.
-Due to the fact that device does not consume any energy other other than alarm position, you do not need to replace the battery.
Battery waiting life is 2 years according to production date.
6
2.3. Electrical Installation
Make the electrical connection of the device according to the data on the label and the tables and cable shapes in this manual.
1.5. Target Group
This operating manual has been prepared for qualified technical personel.
1.6. Security Notes
Following notes should be taken into consideration in order to avoid dangers which can occur on the operator and around the ambient.
Installation, operation and maintenance of this instrument should be made only by people who have read the operating
manual and who are knowledgeable about work safety!
It should be complied with work safety, accident prevention regulations and national installation standards.
Escaping steam or hot water when working on boilers.Wait for the pressure gets down to zero to intervene the device
Electrical shock while working with terminal strip which has 220-240 VAC on all terminals possibly.always cut off the power before interventions.
Product should be used only within the scope of stated specifications!
You can assemble the instrument only when pressure is not available!
1.7. Content of Package
Please check whether you have taken delivery of below listed content completely or not and check its conformity with criterions in your order:
·Liquid Warning Dedector
·This operating manual
Wat ersens
Yap k an
Aç k /Kapal
Yer
Butonu
Röl e Ç k
Watersens
Siren Aç k / Kapal
Butonu
Siren

7
2.4. Order Form
Order Form: Please consider sample models when coding!..
2
CERTIFICATE
None.....................................................................0 (EN10204-3-1)Material Certification.............................1
1MODEL
....................................................WATERSENS
.................................................WATERSENS-K
..........................................................WATERSENS-P
...........................................................WATERSENS-N
..........................................................WATERSENS-R
3HOUSING
ABS , Gray , B026p.........................................304 ABS , Black, B025p....................................................303
Special ............................................................................x
4ELECTRICAL CONNECTION
Terminal (For Housing Models) .......................00
PVC Cable (max. 60 ° C) ................................ 80
PVC Cable (Max.105 ° C) ............................... 81
Silicon Cable ................................................................82
Probe.............................................................................xp
Special ............................................................................x
5CONTACT STRUCTURE
NPN - NO.......................................................00
NPN - NC.....................................................01
PNP - NO......................................................................03
PNP - NC......................................................................04
Relay NO / NC.........................................................10
Special ............................................................................x
7CABLE LENGTH
....................................................................mm
8
OPTIONAL
None.................................................................../ 0
EXAMPLE
WATERSENS - 0 - 304 -00 - 10 - 0 - 00 - 3 / 0
WATERSENS , Relay NO / NC , Grey Boxed
6PROBE TYPE
Without Probe..................................................0
Cable Probe.....................................................1
With Supply B Type Probe.............................................3
Without Supply K Type Probe........................................4
Without Supply P Type Probe........................................5
Special ............................................................................x
Special ............................................................................x

8
2.5. WARNINGS!!!
Please pay attention to following matters in order to operate your level switch properly.
Do not fasten switch reversely ,
otherwise its characteristics
might be changed.
In case vapour splash cable
potting points,insulation
problem may cause.
Do not pull the cable strongly,
otherwise the characteristics
might be changed.
It should not be placed
on metal conductive surfaces.
Excess current , to be drawn as
a result of direct connection to motor,
may burn relay of switch
It can be fixed to the wall with screws.
Do not remove the float from
connection part. Because its pin
might be damaged.
Please avoid using with liquids which
damage materials of parts ,otherwise
quality can not be maintained accurately.
Tighten the cable connections firmly.
Excess current , to be drawn as
a result of direct connection to motor,
may burn relay of switch

9
Breakdown
No relay output
/ Continous relay output
3. Failure Detection
Probable
-The whole device is stuck in the water.
-A high current was applied to the contacts of the device.
-The battery may be low, please check it.
-The probe cable was torn off while replacing the battery.
Failure detection/correction
-Notify the authorized service.
Broken or dissolved housing -Product was dropped or hit from outside -Notify the authorized service.
If you find an error, try to eliminate it by using this table or send the instrument to our service address for repair.
The instrument should be repaired only by authorized service!
4. Disassembly of Instrument
Instrument should be disassembled while feeding and pressure is not available!
5. Service
6. Recalibration
Calibration is not required during long period useful life of a liquid warning dedector.
7. Repair  Manufacturer Address
If irreparable breakdowns occur, the instrument should be sent to us for repair purpose. Before this, the instrument should be
cleaned carefully and packaged so as not to be broken. Furthermore, you should also add a detailed explanation which
describes the breakdown while instrument is sent. If your instrument contacts with harmful substances, decontamination
report should be also sent additionally. In the event that instrument does not have any decontamination report or our service
department has doubts about instrument, repair process will not start until an acceptable report is sent.
If the instrument contacts with hazardous substances, necessary measures should be taken for decontamination!
Service -Manufacturer Company Name and Address:
LONCA MAK. SAN. TÝC. A.Þ.Ferhatpaþa Mahallesi Gazipaþa Caddesi No:104 A 34888 Ataþehir / ÝSTANBUL - TÜRKÝYE
Tel:[phone] Faks:[phone] E-Mail: [email protected] Web: www.ensim.com.tr
8. Disposal
The instrument should be disposed according to 2002/96/EC and 2003/108/EC European Directives (waste electrical and
electronic instruments). Waste electrical and electronic equipment should not be mixed with domestic wastes!
If the instrument has contacted with harmful substances, special attention should be paid for its disposal!
9. Terms of Warranty
The instrument has warranty legally for 24 months after delivery date. Warranty demands are not accepted in case of
inappropriate operation, damage on the instrument or any modification on the instrument.
10. Terms of Return
In the return of materials, user should send an open list related to damage or problem, malfunction of the material
to be returned or its operation in the different modification, with the instrument. If it is required to return the
material, used in the dangerous, corrosive or toxic fluid, in this case, used part should be cleaned very carefully.
Security of personnel should be ensured. All products to be returned should be sent to our company address, which
we have stated.
The instrument does not require maintenance. If it is desired, residue accumulated inside should be blown according to kind
of fluid and instrument can be cleaned with soft cleaning solutions. Measures should be taken during the disassembly.
