Entel CCAHX User manual

CCAHX
Quick Start User Guide
Lithium-Ion Battery Charger
Designed in the United Kingdom
V3 V1.2

Quick Start User Guide V1.2
CCAHX V3
Thank you for purchasing the CCAHX charger.
This product should reach you in perfect condition.
Should you notice any defects or experience any
problems with this product, please contact the
dealer you purchased it from immediately.
FEATURES
• The CCAHX charger can be used to recharge
Entel’s lithium-Ion battery packs.
• Free range power supply facilitates AC
voltages in the range 100V to 240V.
• The time required to recharge a fully discharged
CNB Series battery pack is approximately 6
hours.
• This charger has been designed to sit on a at
surface or be wall/ bulkhead mounted for your
convenience.
OPERATING INSTRUCTIONS
1. Connect the Entel adapter (CWC series) to the
CCAHX charger pod.
2. Plug the AC power main plug of the adapter into
the wall outlet.
3. If attached to the battery, ensure the radio is
switched o󰀨.
4. Insert the battery pack into the charging pod,
either with or without the radio attached. The
charger pod’s LED illuminates red to indicate
that the battery is charging.
5. When charging is complete the LED will
illuminate green.
MAINS ADAPTER (CWC SERIES)
Input Voltage 100-240VAC 50Hz/60Hz
Output Voltage 12VDC 500mA
Weight 80g
Adapter Type CWCEA – 2 Pin (Australia)
CWCED – 2 Pin (Europe)
CWCEE – 3 Pin (UK)
CWCES – 2 Pin (US)
CCAHX CHARGING POD
Input Voltage 11.5~14.4VDC 400mA
Output Voltage 8.4VDC 400mA
Dimensions (H)75mm x (W)84mm x (D)80mm
Weight 120g
Battery
Compatibility
Operational
Temperature - 20°C to +55°C
Range
CNB420E, CNB450E, CNB451E,
CNB450E-IS

BULKHEAD MOUNTING
For your convenience the CCAHX charger can
be seated on its base, or bulkhead mounted.
A bulkhead screw and spacer kit is available
separately (Part Number ASPACKCAHV3).
PRECAUTIONS
• The CCAHX charger is designed exclusively for
use with Entel lithium- ion battery packs. Do not
use it to charge any other type of battery pack.
• Do not use CCAHX with any other adapter other
than CWC series.
• The Entel adapter is designed for use with an
AC power supply voltage between 100V and
240V. Do not connect it to a power source
outside this range.
• Never charge the transceiver whilst it is
switched on.
• Unplug the adapter from the mains when it is
not in use.
• Do not dismantle the CCAHX or the CWC
adapter.
• Never insert any metal or other conductive
objects into the charger.
• Do not touch the charger terminals.
• Never short the charge contacts with metal or
any other conductive object.
• The CCAHX must only be stored /used in a well
ventilated, dry area.
NOTE
In the event that your CCAHX or CWC adapter gets
wet, do not connect to the mains or switch on.
Consult your dealer immediately.

Contact
For more information about our products please contact us:
[phone] [email protected] entel.co.uk
All Rights Reserved. Copyright Entel UK Ltd.
