Entel CSAHX V3 Setup guide

CSAHX
Quick Start User Guide
Intelligent Rapid Charger
Designed in the United Kingdom
Contact
For more information about our products please contact us:
[phone] [e-mail] entel.co.uk
All Rights Reserved. Copyright Entel UK Ltd.
V3

Quick Start User Guide V1.0
CSAHX V3
Thank you for purchasing the CSAHX Rapid
charger. This product should reach you in
perfect condition. Should you notice any defects
or experience any problems with this product,
please contact the dealer you purchased it from
immediately.
FEATURES
• The CSAHX charger can be used to recharge
Entel’s lithium-Ion battery packs.
• Free range power supply facilitates AC
voltages in the range 100V to 240V.
• The time required to recharge a fully discharged
CNB Series battery pack is approximately 3
hours.
• When charging is complete the CSAHX
automatically switches to standby.
• This charger has been designed to sit on a fl at
surface or be wall/ bulkhead mounted for your
convenience.
OPERATING INSTRUCTIONS
1. Connect the Entel adapter (CWC series) to the
CSAHX charger pod.
2. Plug the AC power main plug of the adapter into
the wall outlet.
3. If attached to the battery, ensure the radio is
switched off.
4. Insert the battery pack into the charging pod,
either with or without the radio attached. The
charger pod’s LED illuminates red to indicate
that the battery is charging.
5. When charging is complete the LED will
illuminate green.
NOTE
If the LED on your CSAHX fl ashes amber/red this
indicates that there is a fault with the battery pack.
Switch off at the mains socket and unplug, then
remove the battery from the charger and contact
your Entel Dealer.
SPECIFICATIONS
MAINS ADAPTER (CWC SERIES)
Input Voltage 100-240VAC 50Hz/60Hz
Output Voltage 12VDC 1000mA
Weight 80g
Adapter Type CWCEA – 2 Pin (Australia)
CWCED – 2 Pin (Europe)
CWCEE – 3 Pin (UK)
CWCES – 2 Pin (US)
CSAHX CHARGING POD
Input Voltage 11.5~14.4VDC 1000mA
Output Voltage 8.4VDC 900mA
Dimensions (H)75mm x (W)84mm x (D)80mm
Weight 120g
Battery
Compatibility
Operational
Temperature - 20°C to +55°C
Range
BULKHEAD MOUNTING
PRECAUTIONS
• The CSAHX charger is designed exclusively for
use with Entel lithium- ion battery packs. Do not
use it to charge any other type of battery pack.
• Do not use CSAHX with any other adapter other
than CWC series.
• The Entel adapter is designed for use with an
AC power supply voltage between 100V and
240V. Do not connect it to a power source
outside this range.
• Never charge the transceiver whilst it is
switched on.
• Unplug the adapter from the mains when it is
not in use.
• Do not dismantle the CSAHX or the CWC
adapter.
• Never insert any metal or other conductive
objects into the charger.
• Do not touch the charger terminals.
• Never short the charge contacts with metal or
any other conductive object.
• The CSAHX must only be stored /used in a well
ventilated, dry area.
NOTE
In the event that your CSAHX or CWC adapter gets
wet, do not connect to the mains or switch on.
Consult your dealer immediately.
For your convenience the CSAHX rapid
charger can be seated on its base,
or bulkhead mounted.
A bulkhead screw and spacer kit is available
separately (Part Number ASPACKCAHV3).
CNB420E, CNB450E, CNB451E
