Enterasys Vertical Horizon VHIM1000-S1TX User manual

9033666
VERTICAL HORIZON
VHIM1000-S1TX
GIGABIT ETHERNET
EXPANSION MODULE
USER GUIDE

Notice
9033666 i
NOTICE
Enterasys Networks reserves the right to make changes in specifications and other information
contained in this document without prior notice. The reader should in all cases consult Enterasys
Networks to determine whether any such changes have been made.
The hardware, firmware, or software described in this manual is subject to change without notice.
IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT
NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR
THE INFORMATION CONTAINED IN IT, EVEN IF ENTERASYS NETWORKS HAS BEEN
ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH
DAMAGES.
2001 by Enterasys Networks, Inc., P.O. Box 5005, Rochester, NH 03866-5005
All Rights Reserved
Printed in Taiwan, R.O.C.
Order Number: 9033666 January 2001
Enterasys, Enterasys Networks, and Vertical Horizon are trademarks or registered trademarks of
Enterasys Networks, Inc.
Microsoft, Windows, Windows 95, Windows 98, and Windows NT are either trademarks or registered
trademarks of Microsoft Corporation.
Netscape and Netscape Navigator are trademarks of Netscape Communications Corporation.
All other product names mentioned in this manual may be trademarks or registered trademarks of
their respective companies.
Only qualified personnel should perform installation
procedures.

Notice
ii 9033666
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment uses, generates, and can radiate radio frequency energy and if not installed in
accordance with the operator’s manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause interference in which case the user
will be required to correct the interference at his own expense.
WARNING: Changes or modifications made to this device which are not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.
INDUSTRY CANADA NOTICE
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.
VCCI NOTICE
This is a Class A product based on the standard of the Voluntary Control Council for Interference by
Information Technology Equipment (VCCI). If this equipment is used in a domestic environment,
radio disturbance may arise. When such trouble occurs, the user may be required to take corrective
actions.

Notice
9033666 iii
SAFETY INFORMATION
WICHTIGE SICHERHEITSHINWEISE (GERMANY)
1. Bitte lesen Sie diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder
Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen
könnte Beschädigungen hervorrufen.
7. Die Belüftungsöffnungen dienen der Luftzirkulation, die das Gerät vor Überhitzung schützt.
Sorgen Sie dafür, daß diese Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.
9. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es sollte auch nichts
auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen, die sich am Gerät befinden, sind zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom Stromnetz
trennen. Somit wird im Falle einer Überspannung eine Beschädigung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten in das Gerät
gelangen. Dies könnte einen Brand bzw. elektrischen Schlag auslösen.
13. Öffnen sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von
authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer
qualifizierten Servicestelle zu überprüfen:
a. Netzkabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe
dieser Anleitung keine Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. Zum Netzanschluß dieses Gerätes ist eine geprüfte Leitung zu verwenden. Für einen Nennstrom
bis 6A und einem Gerätegewicht größer 3kg ist eine Leitung nicht leichter als H05VV-F, 3G,
0.75mm2einzusetzen.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder
weniger.

Notice
iv 9033666
ENTERASYS NETWORKS, INC.
PROGRAM LICENSE AGREEMENT
BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT,
CAREFULLY READ THIS LICENSE AGREEMENT.
This document is an agreement (“Agreement”) between You, the end user, and Enterasys Networks,
Inc. (“Enterasys”) that sets forth your rights and obligations with respect to the Enterasys software
program (“Program”) in the package. The Program may be contained in firmware, chips or other
media. UTILIZING THE ENCLOSED PRODUCT, YOU ARE AGREEING TO BECOME BOUND
BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND THE
LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO NOT AGREE
TO THE TERMS OF THIS AGREEMENT, RETURN THE UNOPENED PRODUCT TO
ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE
OF RECEIPT FOR A FULL REFUND.
IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS
NETWORKS [phone]. Attn: Legal Department.
1. LICENSE. You have the right to use only the one (1) copy of the Program provided in this
package subject to the terms and conditions of this License Agreement.
You may not copy, reproduce or transmit any part of the Program except as permitted by the
Copyright Act of the United States or as authorized in writing by Enterasys.
2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or disassemble the
Program.
3. APPLICABLE LAW. This License Agreement shall be interpreted and governed under the
laws and in the state and federal courts of New Hampshire. You accept the personal jurisdiction and
venue of the New Hampshire courts.
4. EXPORT REQUIREMENTS. You understand that Enterasys and its Affiliates are subject to
regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which
prohibit export or diversion of certain technical products to certain countries, unless a license to
export the product is obtained from the U.S. Government or an exception from obtaining such license
may be relied upon by the exporting party.
If the Program is exported from the United States pursuant to the License Exception CIV under
the U.S. Export Administration Regulations, You agree that You are a civil end user of the Program
and agree that You will use the Program for civil end uses only and not for military purposes.
If the Program is exported from the United States pursuant to the License Exception TSR under
the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in
Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source
code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania,
Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan,
Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China,
Romania, Russia, Rwanda, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other
countries as may be designated by the United States Government), (ii) export to Country Groups D:1
or E:2 (as defined herein) the direct product of the Program or the technology, if such foreign
produced direct product is subject to national security controls as identified on the U.S. Commerce
Control List, or (iii) if the direct product of the technology is a complete plant or any major
component of a plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major
component thereof, if such foreign produced direct product is subject to national security controls as
identified on the U.S. Commerce Control List or is subject to State Department controls under the
U.S. Munitions List.

Notice
9033666 v
5. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Product (i) was
developed solely at private expense; (ii) contains “restricted computer software” submitted with
restricted rights in accordance with section 52.227-19 (a) through (d) of the Commercial Computer
Software-Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data
belonging to Enterasys and/or its suppliers. For Department of Defense units, the Product is
considered commercial computer software in accordance with DFARS section 227.7202-3 and its
successors, and use, duplication, or disclosure by the Government is subject to restrictions set forth
herein.
6. EXCLUSION OF WARRANTY. Except as may be specifically provided by Enterasys in
writing, Enterasys makes no warranty, expressed or implied, concerning the Program (including its
documentation and media).
ENTERASYS DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE SUPPLIED TO
YOU BY ENTERASYS IN WRITING, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, WITH RESPECT TO THE PROGRAM, THE ACCOMPANYING
WRITTEN MATERIALS, AND ANY ACCOMPANYING HARDWARE.
7. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL
ENTERASYS OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS, PROFITS,
BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL, INCIDENTAL,
CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS) ARISING OUT OF THE
USE OR INABILITY TO USE THIS ENTERASYS PRODUCT, EVEN IF ENTERASYS HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES, OR IN THE DURATION OR LIMITATION OF IMPLIED
WARRANTIES IN SOME INSTANCES, THE ABOVE LIMITATION AND EXCLUSIONS MAY
NOT APPLY TO YOU.

Notice
vi 9033666
DECLARATION OF CONFORMITY
Application of Council Directive(s): 89/336/EEC
73/23/EEC
Manufacturer’s Name: Enterasys Networks, Inc.
Manufacturer’s Address: 35 Industrial Way
PO Box 5005
Rochester, NH 03867
European Representative Name: Mr. J. Sims
European Representative Address: Enterasys Networks Limited
Nexus House, Newbury Business Park
London Road, Newbury
Berkshire RG14 2PZ, England
Conformance to Directive(s)/Product Standards: EC Directive 89/336/EEC
EC Directive 73/23/EEC
EN 55022
EN 50082-1
EN 60950
Equipment Type/Environment: Networking Equipment, for use in a
Commercial or Light Industrial
Environment.
We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged
with this notice conforms to the above directives.
Manufacturer Legal Representative in Europe
Mr. Thomas Whissel Mr. J. Sims
___________________________________ ___________________________________
Full Name Full Name
Compliance Engineering Manager Managing Director - E.M.E.A.
___________________________________ ___________________________________
Title Title
Rochester, NH, USA Newbury, Berkshire, England
___________________________________ ___________________________________
Location Location

9033666 Table of Contents vii
TABLE OF CONTENTS
1. DESCRIPTION OF HARDWARE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Gigabit Uplink Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Gigabit Port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1000Base-T Cable Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Cable Testing for Existing Category 5 Cable. . . . . . . . . . . . . . . . . . 2
Adjusting Existing Category 5 Cabling. . . . . . . . . . . . . . . . . . . . . . . 2
2. INSTALLING THE MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Handling the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
APPENDIX A. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
APPENDIX B. TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 9
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Data Rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Environmental Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Port Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
10Base-T and 100Base-TX Ports . . . . . . . . . . . . . . . . . . . . . . . . . 11
MDI/MDI-X Crossover Cable Wiring . . . . . . . . . . . . . . . . . . . . . . . 11
1000Base-T Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
APPENDIX C. MAXIMUM CABLE LENGTHS . . . . . . . . . . . . . . . . . . . . . . . . . 13

viii Table of Contents VHIM1000-S1TX

9033666 Description of Hardware 1
1. DESCRIPTION OF HARDWARE
Gigabit Uplink Module
The Enterasys Networks VHIM1000-S1TX module is designed for use in
Vertical Horizon switch models that have a Gigabit Ethernet transceiver
slot. At present, suitable units include these Vertical Horizon models –
VH-2402S and VH-4802. Detailed information about configuring these
modules and advice about Gigabit Ethernet configuration rules can be
found in the switch’s User Guide.
Enterasys’ VHIM1000-S1TX module provides a Gigabit port which can be
used for a high-speed backbone or server connection. It contains one
1000Base-T port that can support a link of up to 100 m (328 ft) using
Category 5 cable.
Gigabit Port LEDs
Port LEDs are located on the module as well as on the front panel of the
switch for “at-a-glance” network monitoring. The following table details the
indicator functions provided by the switch:
WARNING: Before installing or removing the
VHIM1000-S1TX module, first disconnect the switch from
the main power supply. For full safety instructions, please
refer to the User Guide that accompanies the switch.
Name Function
Indicators on module’s front panel
10 LED Lights steady to indicate that the port is operating at 10 Mbps.
100 LED Lights steady to indicate that the port is operating at 100 Mbps.
1000 LED Lights steady to indicate that the port is operating at 1000 Mbps.
Indicators on switch’s front panel
Status LED Lights steady to indicate that a module is installed in this slot.
Activity LED Lights steady to indicate that traffic is passing through the port.
CAUTION

2 Description of Hardware VHIM1000-S1TX
1000Base-T Cable Requirements
All Category 5 UTP cables that are used for 100Base-TX connections
should also work for 1000Base-T, providing that all four wire pairs are
connected. However, it is recommended that for all critical connections,
or any new cable installations, Category 5e (enhanced Category 5) cable
should be used. The Category 5e specification includes test parameters
that are only recommendations for Category 5. Therefore, the first step in
preparing existing Category 5 cabling for running 1000Base-T is a simple
test of the cable installation to be sure that it complies with the IEEE
802.3ab standards.
Cable Testing for Existing Category 5 Cable
Installed Category 5 cabling must pass tests for Attenuation, Near-End
Crosstalk (NEXT), and Far-End Crosstalk (FEXT). This cable testing
information is specified in the ANSI/TIA/EIA-TSB-67 standard.
Additionally, cables must also pass test parameters for Return Loss and
Equal-Level Far-End Crosstalk (ELFEXT). These tests are specified in
the ANSI/TIA/EIA-TSB-95 Bulletin, “The Additional Transmission
Performance Guidelines for 100 Ohm 4-Pair Category 5 Cabling.”
Note that when testing your cable installation, be sure to include all patch
cables between switches and end devices.
Adjusting Existing Category 5 Cabling
If your existing Category 5 installation does not meet one of the test
parameters for 1000Base-T, there are basically three measures that can
be applied to try and correct the problem:
1. Replace any Category 5 patch cables with high-performance
Category 5e cables.
2. Reduce the number of connectors used in the link.
3. Reconnect some of the connectors in the link.

9033666 Installing the Module 3
2. INSTALLING THE MODULE
The VHIM1000-S1TX module is field installable. Just follow the
instructions below.
Package Contents
This package includes:
•One VHIM1000-S1TX module
•This document
Handling the Module
The VHIM1000-S1TX module can easily be damaged by electrostatic
discharge.
To prevent electrostatic damage, observe the following guidelines:
•Do not remove the module from its packaging until you are ready to
install it.
•Do not touch any of the module’s pins, connectors or components.
•Hold the module only by its edges or front panel.
•Wear an anti-static wristband connected to a suitable earth ground
whenever handling the module.
•Store or transport this module only in appropriate anti-static
packaging.
CAUTION: Do not install this module in any unit other
than the VH-2402S or VH-4802. Contact Enterasys for
advice on newly released switches that may be designed
for use with these modules.
CAUTION: The VHIM1000-S1TX module can easily be
damaged by electrostatic discharge.

4 Installing the Module VHIM1000-S1TX
Instructions
1. Power off the switch: Disconnect the AC power cord from the
switch. If a redundant power unit (RPU) is present, disconnect its DC
cable connection from the switch.
2. Remove network cables: If you are replacing a module, remove the
cable attached to any port on the module.
3. Loosen the screws on the installed module or slot faceplate:
Using your fingers or a flathead screwdriver, turn the screws securing
the module (or faceplate on the slot) in a counter-clockwise direction
until they are free of the chassis. Be sure not to completely remove
the screws from the module or faceplate.
4. Remove the installed module or faceplate: Firmly pull on the
screws until the module is free of the switch. Carefully slide the
module straight out of the slot.
Keep the original faceplate for future use. If you should remove the
module, replace the faceplate to prevent dust and debris from
entering the unit and to maintain proper air flow.
CAUTION: The switch must be powered off before
installing or replacing any module.

9033666 Installing the Module 5
5. Insert the new module into the switch: Holding the new module
with the text on the front panel upright, carefully slide the module into
a lower slot on the rear panel, and press gently until it snaps into
place. Be sure the new module’s front panel is flush with the switch
panel.
6. Secure the new module: Secure the new module in place by
screwing the attached screws clockwise into the switch’s chassis.
Tighten them enough to secure the module, but not so tight as to
prevent them from being unscrewed by hand.
NOTE: Media expansion modules can only be placed in the
lower slots.

6 Installing the Module VHIM1000-S1TX
7. Connect the network cable to the module: Connect Category 5
twisted-pair cable to the port on the newly installed module. See
“Maximum Cable Lengths” on page 13 in this guide for further
information.
8. Power on the switch: Reconnect the previously removed power
sources to the switch. Check the LED indicators for the module port
on the switch’s front panel to be sure that it is operating correctly.
Refer to “Gigabit Port LEDs” on page 1 for a description of the LED
indications. If the module does not respond, see “Troubleshooting”
on page 7.
Refer to the following manuals for the base unit for further details on using
this module:
User Guide- connection options and network applications
Management Guide- configuration options

9033666 Troubleshooting 7
APPENDIX A. TROUBLESHOOTING
If you experience any problems with the module, check the following
items before contacting Enterasys Technical Support:
•Ensure that the switch with the module is powered up.
•Ensure that the device attached to the module is powered up and
operating correctly.
•Ensure that the module is properly seated in the slot.
•Verify that the module port is configured to match the communication
speed (10, 100, or 1000 Mbps) and mode (full or half duplex) used by
the attached device.
•Make sure that network cables comply with the IEEE 802.3ab Gigabit
Ethernet standard for 1000 Mbps operation. Also, be sure cable
lengths are 100 m (328 ft) maximum.
•Inspect all network cables and connections. Check the connectors on
both ends of a cable to be sure they are properly engaged.

8 Troubleshooting VHIM1000-S1TX

9033666 Technical Specifications 9
APPENDIX B. TECHNICAL SPECIFICATIONS
General
Standards Compliance
IEEE 802.1D Transparent Bridging Specifications (ISO/IEC 10038)
IEEE 802.1p Traffic Class Expediting and Dynamic Multicast Filtering
IEEE 802.1Q Virtual Bridged Local Area Networks
IEEE 802.2 Local Area Networks, Logical Link Control (LLC)
IEEE 802.3 CSMA/CD 9 (ISO/IEC 8802-3)
IEEE 802.3i 10Base-T (ISO/IEC 8802-3, clause 14)
IEEE 802.3u 100Base-TX (ISO/IEC 8802-3, clause 25)
IEEE 802.3ab 1000Base-T
IEEE 802.3x Flow Control
Regulatory Compliance
Safety: UL 1950, CSA C22.2 No 950, 73/23/EEC, EN 60950, IEC 950
Electromagnetic Compatibility (EMC): FCC Part 15, CSA C108.8,
89/336/EEC, EN 55022, EN 61000-3-2, EN 61000-3-3, EN 50082-1,
AS/NZS 3548, VCCI V-3
Data Rate
10 Mbps Manchester encoded, 100 Mbps 4B/5B encoded, 1000 Mbps
8B/10B encoded.
Environmental Specifications
Operating temperature: 32° to 122° F (0° to 50° C)
Operating humidity: 5 to 95% relative, non-condensing
Storage temperature: -40° to 158° F (-40° to 70° C)
Storage humidity: 5 to 95% relative, non-condensing
Electrical Specifications
Maximum power consumption: 2.4 VA

10 Technical Specifications VHIM1000-S1TX
Physical Specifications
Height: 1.08 in. (2.74 cm)
Length: 3.57 in. (9.07 cm)
Width: 4.82 in. (12.25 cm)
