Enterasys RoamAbout RBT-4102 User manual

P/N 9034148-14
RoamAbout
RBT-4102, RBT-4102-BG, and RBT-4102-EU
Wireless Access Point
Installation Guide

i
NOTICE
ENTERASYS NETWORKS reserves the right to make changes in specifications and
other information contained in this document and its web site without prior notice. The
reader should in all cases consult ENTERASYS NETWORKS to determine whether
any such changes have been made.
The hardware, firmware, or software described in this document is subject to change
without notice.
IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING
BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS
DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF
ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE
KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES.
Enterasys Networks, Inc.
50 Minuteman Road
Andover, MA 01810
©2006 Enterasys Networks, Inc. All rights reserved.
Part Number: 9034148-14 June 2006
ENTERASYS, ENTERASYS NETWORKS, ENTERASYS ROAMABOUT, LANVIEW,
NETSIGHT, ROAMABOUT, WEBVIEW, and any logos associated therewith, are
trademarks or registered trademarks of Enterasys Networks, Inc. in the United States and
other countries.
All other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies.
Documentation URL: http://www.enterasys.com/support/manuals
Documentacion URL: http://www.enterasys.com/support/manuals
Dokumentation URL: http://www.enterasys.com/support/manuals
ELECTRICAL HAZARD: Only qualified personnel should perform
installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar
procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch
ausgebildetes und qualifiziertes Personal vorgenommen werden.

ii
COMPLIANCES
RBT-4102
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
• Consult the dealer or an experienced radio/TV technician for help
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment. This
device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to
channels 1 through 11.
IMPORTANT NOTE:
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
70 centimeters (27.5 inches) between the radiator and your body. This transmitter must not
be co-located or operating in conjunction with any other antenna or transmitter.
Wireless 5 GHz Band Statements:
As the Access Point can operate in the 5150-5250 MHz frequency band it is limited by the
FCC, Industry Canada and some other countries to indoor use only so as to reduce the
potential for harmful interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users (meaning they have priority) of the
5250-5350 MHz and 5650-5850 MHz bands. These radars could cause interference and /or
damage to the access point when used in Canada.
The term “IC:” before the radio certification number only signifies that Industry Canada
technical specifications were met.

iii
Wireless 4.9 GHz Band Statement:
Installation and operation requires an approved license from the FCC.
Industry Canada - Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the interference-causing equipment standard entitled “Digital
Apparatus,” ICES-003 of Industry Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe B prescrites dans la norme sur le matérial brouilleur:
“Appareils Numériques,” NMB-003 édictée par l’Industrie.
Industry Canada Statement
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause
undesired operation of the device
This device has been designed to operate with an antenna having a maximum gain of
23 dB. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada.
The required antenna Impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the EIRP is not more than required for successful communication.
Because high power radars are allocated as primary users (meaning they have priority) in
5250-5350 MHz, these radars could cause interference and/or damage to license exempt
LAN devices.
RBT-4102-EU
Australia/New Zealand AS/NZS 4771
Japan Telec Approval
003NY05152
003GZ05053
003WY05076
003UX05009
A
N826

iv
EC Conformance Declaration
Marking by the above symbol indicates compliance with the Essential Requirements of the
R&TTE Directive of the European Union (1999/5/EC). This equipment meets the following
conformance standards:
• EN 60950 (IEC 60950) - Product Safety
• EN 301 893 - Technical requirements for 5 GHz radio equipment
• EN 300 328 - Technical requirements for 2.4 GHz radio equipment
• EN 301 489-1 / EN 301 489-17 - EMC requirements for radio equipment
Countries of Operation & Conditions of Use in the European Community
This device is intended to be operated in all countries of the European Community.
Requirements for indoor vs. outdoor operation, license requirements and allowed channels
of operation apply in some countries as described below:
Note: The user must use the configuration utility provided with this product to ensure the
channels of operation are in conformance with the spectrum usage rules for
European Community countries as described below.
• This device requires that the user or installer properly enter the current country of operation
in the command line interface as described in the user guide, before operating this device.
• This device will automatically limit the allowable channels determined by the current
country of operation. Incorrectly entering the country of operation may result in illegal
operation and may cause harmful interference to other system. The user is obligated to
ensure the device is operating according to the channel limitations, indoor/outdoor
restrictions and license requirements for each European Community country as described
in this document.
• This device employs a radar detection feature required for European Community operation
in the 5 GHz band. This feature is automatically enabled when the country of operation is
correctly configured for any European Community country. The presence of nearby radar
operation may result in temporary interruption of operation of this device. The radar
detection feature will automatically restart operation on a channel free of radar.
• The 5 GHz Turbo Mode feature is not allowed for operation in any European Community
country. The current setting for this feature is found in the 5 GHz 802.11a Radio Settings
Window as described in the user guide.
• The 5 GHz radio's Auto Channel Select setting described in the user guide must always
remain enabled to ensure that automatic 5 GHz channel selection complies with European
requirements. The current setting for this feature is found in the 5 GHz 802.11a Radio
Settings Window as described in the user guide.
• This device is restricted to indoor use when operated in the European Community using
the 5.15 - 5.35 GHz band: Channels 36, 40, 44, 48, 52, 56, 60, 64.
• This device may be operated indoors or outdoors in all countries of the European
Community using the 2.4 GHz band: Channels 1 - 13, except where noted below.
- In France outdoor operation is only permitted using the 2.4 - 2.454 GHz band: Channels
1 - 7.

v
Operation Using 5 GHz Channels in the European Community
The user/installer must use the provided configuration utility to check the current channel of
operation and make necessary configuration changes to ensure operation occurs in
conformance with European National spectrum usage laws as described below and
elsewhere in this document.
Countries of Operation & Conditions of Use in the Asia, Pacific, and Middle
East Communities
This device is intended to be operated in all countries listed below of the Asia, Pacific, and
Middle East Community. Requirements for indoor vs. outdoor operation, license
requirements and allowed channels of operation apply in some countries as described
below:
Note: The user must use the configuration utility provided with this product to ensure the
channels of operation are in conformance with the spectrum usage rules for
countries as described below.
• This device requires that the user or installer properly enter the current country of operation
in the command line interface as described in the user guide, before operating this device.
• This device will automatically limit the allowable channels determined by the current
country of operation. Incorrectly entering the country of operation may result in illegal
operation and may cause harmful interference to other system. The user is obligated to
ensure the device is operating according to the channel limitations, indoor/outdoor
restrictions and license requirements for each country as described in this document.
• This device employs a radar detection feature required for operation in the 5 GHz band.
This feature is automatically enabled when the country of operation is correctly configured
for any of the countries listed below. The presence of nearby radar operation may result in
Allowed 5GHz Channels in Each European Community Country
Allowed Frequency Bands Allowed Channel Numbers Countries
5.15 - 5.35* & 5.470 - 5.725 GHz 36, 40, 44, 48, 52, 56, 60, 64,
100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140
Austria, Belgium,
Cyprus, Czech
Republic, Denmark,
Estonia, Finland,
France, Germany,
Iceland, Ireland, Italy,
Latvia, Liechtenstein,
Lithuania,
Luxembourg, Malta,
Netherlands, Norway,
Poland, Portugal,
Slovakia, Slovenia,
Spain, Sweden,
Switzerland, U.K.
5 GHz Operation Not Allowed None Greece, Hungary
* Outdoor operation is not allowed using 5.15-5.35 GHz bands (Channels 36 - 64).

vi
temporary interruption of operation of this device. The radar detection feature will
automatically restart operation on a channel free of radar.
• The 5 GHz Turbo Mode feature is not allowed for operation in any of the countries. The
current setting for this feature is found in the 5 GHz 802.11a Radio Settings Window as
described in the user guide.
• The 5 GHz radio's Auto Channel Select setting described in the user guide must always
remain enabled to ensure that automatic 5 GHz channel selection complies with
requirements. The current setting for this feature is found in the 5 GHz 802.11a Radio
Settings Window as described in the user guide.
• This device is restricted to indoor use when operated using the 5.15 - 5.35 GHz band:
Channels 36, 40, 44, 48, 52, 56, 60, 64.
Operation Using 5 GHz Channels in the Asia, Pacific, and Middle East
Community
The user/installer must use the provided configuration utility to check the current channel of
operation and make necessary configuration changes to ensure operation occurs in
conformance with the spectrum usage laws as described below and elsewhere in this
document.
EC-Konformitätserklärung
Die Kennzeichnung mit dem obigen Symbol zeigt die Übereinstimmung mit den wichtigen
Anforderungen der R&TTE-Direktive der Europäischen Union (1999/5/EC) an. Dieses Gerät
erfüllt die folgenden Konformitätsstandards:
• EN 60950 (IEC 60950) - Produktsicherheit
• EN 301 893 - Technische Anforderungen für 5-GHz-Hochfrequenzgeräte
• EN 300 328 - Technische Anforderungen für 2,4-GHz-Hochfrequenzgeräte
• EN 301 489-1 / EN 301 489-17 - EMV-Anforderungen für Hochfrequenzgeräte
Asia, Pacific, and Middle East usage of 5GHz Channels
Country Allowed Frequency Band Allowed Channel Numbers Usage
Singapore 5.15 - 5.35 GHz 36 - 64 Indoors only
Israel 5.15 - 5.35 GHz 36 - 64 Indoors/Outdoors
Korea 5.15 - 5.35
5.725 - 5.825
36 - 64
149- 161
Indoors only
Indoors/Outdoors

vii
Betriebsländer und Bedingungen für die Verwendung in der Europäischen
Gemeinschaft
Dieses Gerät ist für den Betrieb in allen Ländern der Europäischen Gemeinschaft
vorgesehen. Anforderungen für den Betrieb in Räumen bzw. im Freien, Lizenzbedingungen
und zulässige Betriebskanäle treffen entsprechend der folgenden Ausführung zu:
Hinweis:Der Benutzer muss das für das Gerät bereitgestellte Konfigurationsprogramm
verwenden, um sicherzustellen, dass die Betriebskanäle mit den unten
beschriebenen Vorschriften zur Verwendung des Spektrums für die Europäische
Gemeinschaft übereinstimmen.
• Bevor dieses Gerät in Betrieb genommen wird, muss der Benutzer oder Installierende für
dieses Gerät entsprechend der Bedienungsanleitung in die Befehlszeile das richtige
Betriebsland eingeben.
• Durch die Festlegung des Betriebslands werden automatisch die zulässigen Kanäle
begrenzt. Eine falsche Eingabe des Betriebslands kann zu einem illegalen Betrieb führen
und schädliche Interferenzen bei anderen Systemen verursachen. Der Benutzer muss
sicherstellen, dass das Gerät entsprechend der Kanallimitierung, den Beschränkungen für
den Betrieb in Räumen und im Freien und den Lizenzbedingungen jedes in dieser
Dokumentation beschriebenen Lands der Europäischen Gemeinschaft betrieben wird.
• Dieses Gerät verfügt über eine Radarerkennungsfunktion, die für den Betrieb im
5-GHz-Band in der Europäischen Gemeinschaft erforderlich ist. Diese Funktion wird
automatisch aktiviert, wenn für das Land der Europäischen Gemeinschaft die
Betriebslandeinstellung richtig konfiguriert wurde. Ein Radarbetrieb in der Nähe kann zu
einer vorübergehenden Betriebsunterbrechung dieses Geräts führen. Die
Radarerkennungsfunktion sorgt dafür, dass das Gerät den Betrieb automatisch auf einem
radarfreien Kanal neu startet.
• Der 5-GHz-Turbomodus wird in keinem Land der Europäischen Gemeinschaft
zugelassen. Die aktuelle Einstellung für diese Funktion ist wie im Benutzerhandbuch
beschrieben im Fenster "5 GHz 802.11a Radio Settings" zu finden.
• Die im Benutzerhandbuch beschriebene Auto Channel Select-Einstellung des
5-GHz-Radios muss immer aktiviert bleiben, um sicherzustellen, dass die automatische
5-GHz-Kanalwahl den Anforderungen der Europäische Gemeinschaft entspricht. Die
aktuelle Einstellung für diese Funktion ist wie im Benutzerhandbuch beschrieben im
Fenster "5 GHz 802.11a Radio Settings" zu finden.
• Bei der Verwendung des Geräts in der Europäische Gemeinschaft im 5,15 - 5,35
GHz-Band ist es auf die Verwendung in Räumen beschränkt: Kanäle 36, 40, 44, 48, 52,
56, 60, 64.
• Bei der Verwendung des 2,4-GHz-Bands darf das Gerät in allen Ländern der
Europäischen Gemeinschaft sowohl in Räumen als auch im Freien benutzt werden:
Kanäle 1 - 13, außer wenn unten aufgeführt.
- In Frankreich ist der Betrieb im Freien nur bei der Verwendung des 2,4 - 2,454
GHz-Bands zugelassen: Kanäle 1 - 7.

viii
Betrieb bei Verwendung der 5-GHz-Kanäle in der Europäische Gemeinschaft
Der Benutzer/Installierende muss das für das Gerät bereitgestellte Konfigurationsprogramm
verwenden, um den aktuellen Betriebskanal zu prüfen und um die erforderlichen
Einstellungen zu konfigurieren, damit das Gerät entsprechend der Gesetze zur Verwendung
des Spektrums für die Europäische Gemeinschaft, die nachfolgend und in der gesamten
Dokumentation beschrieben werden, betrieben wird.
Declaration of Conformity in Languages of the European Community
Zulässige 5-GHz-Kanäle in der Europäischen Gemeinschaft
Zulässige Frequenz-bänder Zulässige Kanalnummern Länder
5.15 - 5.35* & 5.470 - 5.725 GHz 36, 40, 44, 48, 52, 56, 60, 64,
100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140
Frankreich, Schweiz,
Liechtenstein ,
Österreich, Belgien,
Zypern, Tschechien,
Dänemark, Estland,
Finnland,Deutschland,
Island, Irland, Italien,
Lettland, Litauen,
Luxemburg, Malta,
Niederlande,
Norwegen, Polen,
Portugal, Slowakei,
Slowenien, Spanien,
Schweden, UK
5 GHz Operation Not Allowed None Griechenland, Ungarn
* Der Betrieb in den Bändern 5,15 - 5,35 GHz ist im Freien nicht zulässig (Kanäle 36 -64).
English Hereby, Enterasys, declares that this Radio LAN device is in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC.
A copy of the original Declaration of conformity can be obtained from
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
Finnish (FI) Valmistaja Enterasys vakuuttaa täten että Radio LAN device tyyppinen
laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien
direktiivin muiden ehtojen mukainen.
Yhdenmukaisuuden alkuperäisen julistuksen kopio voidaan saada
Enterasys Networks, 50 Minuteman Road, Andover, Ma 01810, USA.
Dutch (NL) Hierbij verklaart Enterasys dat het toestel Radio LAN device in overeen-
stemming is met de essentiële eisen en de andere relevante bepalingen
van richtlijn 1999/5/EG.
Bij deze Enterasys dat deze Radio LAN device voldoet aan de essentiële
eisen en aan de overige relevante bepalingen van Richtlijn 1999/5/EC.
Een exemplaar van de oorspronkelijke Verklaring van overeenstemming
kan worden verkregen uit Enterasys Networks, 50 Minuteman Road,
Andover, Ma 01810, USA.
