EnviroPureFX EPFX HEPA375VSC User manual

OWNER’S MANUAL
MODEL EPFX HEPA375VSC
CONSOLE TRUE HEPA AIR CLEANER
IMPORTANT: PLEASE READ MANUAL BEFORE OPERATING UNIT
Features
Long-life, Certified True HEPA (High Efficiency Particulate Air) Filter is
99.97% efficient at removing particles 0.3 micron
Activated Carbon Prefilter removes lint and unpleasant odors, to extend life of HEPA Filter
Carbon VOC After Filter removes additional unpleasant odors and gases
Easy-to-change filters
Powerful Variable Speed motor delivers up to 305 CFM of filtered air
Ideal for rooms up to 750 ft² (70 m²) for one room air change every 20 minutes
FOR TECHNICAL SUPPORT AND REPLACEMENT FILTERS CALL: 1-866-998-9909
[email protected]

WHAT THE HEPA AIR CLEANER DOES
The Console True HEPA Air Cleaner has been
designed to remove particulate such as
atmospheric and household dust, coal dust,
insecticide dust, mites, pollen, mold spores, fungi,
bacteria, viruses, pet dander, cooking smoke and
grease, tobacco smoke and more. It also removes
odors with the Carbon Prefilter and the Carbon
VOC After Filter.
BENEFITS
Helps provide relief from allergies, asthma,
and other respiratory illness.
Helps reduce housekeeping time and
redecorating costs.
Provides a healthier, more comfortable
environment, year-round.
HOW IT WORKS
Millions of airborne pollutants are carried to the
Air Cleaner by a powerful variable speed motor
where they passes through a 3-stage filtration
system.
The Activated Carbon Prefilter (activated carbon
impregnated polyester filter) first removes lint and
odors before they enter the HEPA filter.
Smaller particles then pass through a long-life,
True HEPA (High Efficiency Particulate Air) Filter
which captures 99.97% of particles 0.3 micron
(1/84,000 of an inch) and larger. This HEPA filter
has more than 100 ft² of collection surface area.
The filtered air passes through a Carbon VOC
After Filter to further remove odors.
Clean air is discharged back into the room.
OPERATING INSTRUCTIONS
Remove the Air Cleaner from the box. If your unit
has any signs of damage, immediately contact the
store where the Air Cleaner was purchased.
Keep the shipping carton and packaging in case
the need arises to store or transport the unit.
Remove all packaging from the unit. Casters are
packaged inside the Air Cleaner. Open top cover,
remove casters, and install casters on bottom of
unit. See Maintenance for installation of filters.
Choose a suitable location to allow unobstructed
circulation from the sides and back of the unit. If
unit has to be placed against a wall, allow at least
6-8 inches (15-20 cm) for circulation.
The Air Cleaner plugs into a regular outlet at the
voltage shown on rating label.
The Control Switch for the Air Cleaner is located
on the rear of the unit. To turn the Air Cleaner on,
rotate the Control Switch knob clockwise. This
controls the power to the Fan. When the Control
Switch is turned just past the click position, the
fan is on high speed. Rotating the Control Switch
completely clockwise reduces the fan speed to it’s
lowest setting.
The Air Cleaner is designed to run continuously
to provide clean, filtered air 24 hours a day.
The top cover must be secured for the Air Cleaner
to operate. All filters must be in place for the unit
to operate properly.
MAINTENANCE
For efficient operation, the filters must be changed
on a regular basis. If you notice a reduction in air
flow from the system, check the filters.
1. To access the filters, turn the Air Cleaner OFF
at the switch and remove the top cover.
2. Carefully remove the filters to avoid spilling of
collected contaminants. Dispose of filters in a
plastic bag and discard with regular household
trash.
3. Remove plastic from the new filters before
installing. Discard plastic safely. Take care not
to damage the filters.
4. Date the replacement HEPA filter in the space
provided.
5. Place the Carbon prefilter around the outside
of the HEPA filter and secure with the Velcro
strips.
6. Place the Carbon VOC After filter inside the
perimeter of the filter.
7. Place the HEPA filter into the cabinet insuring
the open end of the filter is toward the motor.
8. Replace the filter hold down bar.
9. Replace the cover of the Air Cleaner.
10. Use genuine replacement filters only.
Note: When the filters are new, you may notice a
new smell from the system. This is normal and will
dissipate within a few hours.
The outside of cabinet and grills can be cleaned
with a damp cloth.
Carbon Prefilter (Part #W4-0855): This must be
replaced every 3 - 6 months and may be
vacuumed between changes. Use a soft brush
attachment when cleaning. If there are heavy
odors in the home from cooking, smoking,
painting or other sources, the filter will require
changing more often.
CAUTION
When replacing the filters wear disposable gloves
and a dust mask.
CAUTION
Make sure to turn Air Cleaner OFF before
performing any maintenance or replacing any
filters.

True HEPA Filter (Part #W4-0840): Replace every
2-4 years. The life of this filter depends on the
amount of contaminants in the air and the
frequency in which the prefilter has been changed.
Renovations in the home that create wood or
drywall dust or similar contaminants will shorten the
life expectancy of the HEPA filter. To improve
airflow, the HEPA filter can be vacuumed between
changes, preferably outdoors. Use a soft brush
attachment for vacuuming this filter.
Note: Handle the HEPA filter carefully. The paper
is fragile and a puncture or tear will reduce
efficiency.
VOC AFTER Filter (Part #W4-0810): This filter is
positioned inside the HEPA filter, and must be
replaced every 6-12 months. If there are heavy
odors in the home from cooking, smoking, painting
or other sources, the filter may require changing
more often.
IMPORTANT SAFEGUARDS
Safety points you should know about your Air Cleaner
Caution:
** Read Owner’s Manual and safeguards before using
** Save Owner’s Manual for later use
** Follow all warnings and instructions marked on Air Cleaner
FOR YOUR PERSONAL SAFETY
1. The Air Cleaner is equipped with a grounded plug.
Do not defeat the purpose of this plug by removing
the grounding pin, as this may result in an
electrical shock or create an unsafe condition.
2. When the power cord or plug is damaged or
frayed, unplug the Air Cleaner from the wall outlet
and refer servicing to qualified service personnel.
3. Do not overload wall outlets and extension cords,
as this can result in fire or electric shock.
4. Do not allow anything to rest on or roll over the
power cord, and do not place the unit where power
cord is subject to traffic or abuse. This may result
in a shock or fire hazard.
5. Do not attempt to service the Air Cleaner yourself
as opening or removing switch cover may expose
you to dangerous voltage or other hazards. Refer
all servicing to qualified personnel.
6. Never push objects of any kind into the Air Cleaner
through cabinet slots, as they may touch
dangerous voltage points, or short out parts that
could result in a fire or electric shock.
7. If the Air Cleaner has been dropped or the cabinet
has been damaged, unplug the unit from the wall
outlet and refer servicing to qualified service
personnel.
8. Unplug the Air Cleaner from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners on cabinet. Use a damp, lint-free cloth for
cleaning.
9. Do not use the Air Cleaner near water, i.e. near a
bathtub, sink, laundry tub, in a wet basement, in
the rain or near a swimming pool, etc.
If liquid has been spilled into the Air Cleaner,
unplug the unit from the wall outlet and refer
servicing to qualified service personnel.
10. Do not use the Air Cleaner near open fire or flame,
or sources of heat i.e. fireplaces, wood burning
stoves, kerosene heaters, stove tops, ovens, etc.
11. Do not use the Air Cleaner on soft surfaces i.e.
beds, sofas.
12. Do not use the Air Cleaner when oxygen is being
used or when combustible gases are present.
13. The Air Cleaner has slots or openings in the
cabinet for ventilation purposes, to provide reliable
operation of the unit, and to protect it from
overheating. These openings must not be blocked
or covered.
14. The Air Cleaner should be operated only from the
type of power source indicated on the rating label.
If you are not sure of the type of power supply at
your home, consult your local power company.
15. If the Air Cleaner does not operate normally by
following the operating instructions, unplug the unit
from the wall outlet and refer servicing to qualified
service personnel.

EPFX HEPA375VSC
06/20
TECHNICAL DATA
Dimensions Length
Width
Height
16.25 in
17.5 in
19.0 in
41.3 cm
44.5 cm
48.3 cm
Unit Weight 43 lbs 19.5 kg
Input Voltage 120 V 60 Hz
Power Consumption 75 Watts
Air Flow: Variable Speed up to 305 CFM up to 518.5 m³/hr
Power Cord 10.0 ft 3.05 m
Filter Dimensions Carbon Prefilter
HEPA Filter
Carbon VOC After Filter
47 x 11.5 x 0.25 in
12 (H) x 14.25 (Dia) x 2.375 in
26.63 x 11.5 x 0.5 in
119.4 x 29.2 x 0.63 cm
30.5 (H) x 36.2 (Dia) x 6 cm
67.6 x 29.2 x 1.3 cm
Carbon Prefilter Collecting Surface Area 3.75 ft² 0.35 m²
HEPA Collecting Surface Area 100 ft²9.29 m²
Carbon VOC After Filter (optional) Surface Area 2.13 ft² 0.20 m²
CONSOLE HEPA AIR CLEANER
LIMITED FIVE (5) YEAR WARRANTY
FIVE YEAR WARRANTY - This EnviroPureFX product is warranted to the original owner, to be free from electrical and mechanical defects in
material and workmanship, under normal use and maintenance, within its listed capacity, for a period of FIVE (5) years from the date of purchase.
The warranty does not include the Carbon Prefilter, HEPA or VOC Filter. A new or remanufactured part to replace the defective part will be
provided without charge for the part itself, through EnviroPureFX, provided the defective part is returned to EnviroPureFX prepaid, together with
the serial number and proof of purchase. Defective parts must be packaged well and depending on the part, may require images emailed prior to
shipping, to confirm condition of parts. If goods arrive damaged due to improper packaging, warranty will be void. The replacement part assumes
the unused portion of the warranty. Failing this, EnviroPureFX will guarantee the unit for a period of sixty (60) months from the date of
manufacture, according to the manufacturer’s records.
THIS WARRANTY DOES NOT INCLUDE ANY ADDITIONAL LABOR ALLOWANCE OR OTHER COSTS incurred for diagnosis, repairing,
removing, installing, shipping, servicing, or handling of either defective parts or replacement parts.
LIMITATIONS OF WARRANTY - All implied warranties (including implied warranties of merchantability) are hereby limited in duration to the period
for which the limited warranty is given. The expressed warranties made in this warranty are exclusive and may not be altered, enlarged, or
changed by any distributor, dealer or other person whatsoever.
ENVIROPUREFX WILL NOT BE RESPONSIBLE FOR:
1. Normal maintenance as outlined in the Owner’s Manual including cleaning and/or replacement of filters.
2. Damage or repairs needed as a consequence of any misapplication, negligent handling, improper servicing, unauthorized alteration, or
improper operations.
3. Damage or repairs required as a consequence of faulty installation or application by others.
4. Failure to start due to voltage conditions, blown fuses, open circuit breakers or other damages due to the inadequacy or interruption of
electrical service.
6. Damage as a result of floods, winds, fires, lightning, accidents, corrosive atmosphere, or other conditions beyond the control of EnviroPureFX.
7. Parts, including filters, not supplied or designated by EnviroPureFX.
8. EnviroPureFX products installed outside of Canada.
9. Any personal injury, special indirect or consequential property or commercial damage of any nature whatsoever.
Model No. Serial No.
Date of Purchase Owner’s Name & Address
RETAIN THIS CERTIFICATE WITH YOUR DOCUMENTS
91 Rylander Blvd, Unit 102, Scarborough, ON M1B 5M5
Tel: [phone] (FILTERS)
Toll Free: [phone]
[email protected] www.enviropurefx.com
