  9. Envision Fairway Railing P310 User guide

Envision Fairway Railing P310 User guide

P310
CPVC
RAILING
INSTALL ATION
QUICK GUIDE
Number of Balusters Provided Per Kit TOOLS NEEDED:
• Drill with #2 Square Drive Bit
• Circular Saw
• Speed Square
• Tape Measure
• Drill Extension
SQUARE CPVC BALUSTERS
LEVEL
14 – 6’ Kit
19 – 8’ Kit
24 – 10’ Kit
STAIR
14 – 6’ Kit
19 – 8’ Kit
N/A – 10’ Kit
LEVEL & STAIR*
KIT INCLUDES:
1– Top Rail with
Aluminum Insert
1– Top Sub Rail with Rail with
Aluminum Insert
1– Bottom Rail with Rail with
Aluminum Insert
4– Mounting Brackets with
Screws
1– Rail Support per 6' & 8' Kit
2– Rail Supports per 10' Kit
Number of balusters per kit
shown
left.
™
BY ™
BEFORE STARTING
• Review all local building codes.
• Wear proper safety equipment.
STEP 1 GETTING STARTED
• Plumb all posts or mounting surfaces, install optional post trim at this time.
• Determine required bottom rail height from deck surface to bottom of rail
based on local building codes.
STEP 2 INSTALL BOTTOM RAIL MOUNTING SCREW
• Find center of post/mounting surface. Mark center line on surface. Determine distance
from nished deck to bottom of rail. Add 3/8" and mark. Drill 3/16" hole on center of
center line. Install #14 x 1" screw to within 1/8" of mounting surface. Check screw head
clearance using a bottom bracket and adjust clearance between screw head and
post/mounting surface to obtain a snap fit.
STEP 3 CUT RAILS
• Measure distance between posts.
• Mark bottom rail to correct length.
• Ensure there is equal and maximum distance from baluster holes on both
ends of top and bottom rails. Cut bottom rail with insert inside to length. Cut top rail the
same, ensuring baluster holes line up.
NOTE: The top aluminum insert should be cut 1/4” shorter than the top rail. The bottom
aluminum insert should be inserted into the bottom rail with DEEP SIDE of channel facing
the routed side of rail.
STEP 4 INSTALL RAIL MOUNTING BRACKETS & RAIL SUPPORT
• Place bottom rail bracket on underside of bottom rail, aluminum insert with post
mounting ange up. Make certain post ange is ush with the end of the bottom
rail and mark the elongated slot. Install one each #10 x 3/4" mounting screw for each
bracket. Adjust bracket if necessary.
• With baluster pockets facing up, slide top rail brackets with mounting anges pointing
down on end of top aluminum insert. On elongated slot, nd center & install one
#10 x 3/4" screw. Adjust bracket if necessary and install second screw.
• Find center of rail and install rail support with one #10 x 3/4” screw.
NOTE: TWO RAIL SUPPORTS ARE REQUIRED FOR 10’ KITS
STEP 5 INSTALL RAIL SECTION
• Snap bottom rail onto bottom rail mounting screws between posts.
• Insert balusters into bottom rail.
• With bottom rails in place, set sub-rail in place and starting from one end, work
the balusters into sub-rail
• Pre-drill two 1/8"holes through top mounting brackets holes into post/mounting
surface and install #10 x 1-1/4" screws in both ends of rail.
STEP 6 FINISHING STEPS
• Carefully snap top rail cap over top aluminum insert. Ensure that cap is seated entirely.
• With rail mounted in place, measure and mark post sleeves to desired height.
• Cut post to desired height with a saw and clean edge of cut.
• Apply a small bead of silicone to the inside of edge of post cap and install on top of
post sleeve (let set 12 hours for adhesive to cure).
P310
LEVEL INSTALLATION
STEP 5
Fairway Architectural Railing Solutions will not be held liable for incorrect or unsafe installations by the installer. It is the installer’s responsibility to secure
proper building permits, review local codes and safety needs and meet or exceed them. The instructions provided by Fairway are a guide and may not
account for every special circumstance. The installer must indentify and execute the installation approach that is appropriate for every application.
STEP 2
STEP 3
Bottom
Rail
2" Space
Baluster
Bottom
Rail
Aluminum Inserts
Equal & Maximum Spacing
STEP 4
Top Rail Bottom Rail
BEFORE STARTING
• Review all local building codes.
• Wear proper safety equipment.
STEP 1 GETTING STARTED
• Plumb all posts or mounting surfaces, install optional post
trim at this time.
• Determine required bottom rail height from deck surface
to bottom of rail based on local building codes.
STEP 2 CUT RAILS & BALUSTERS
• Lay bottom rail against post resting on stair and deck nosing.
Balance out spacing between post and closest baluster with
equal and maximum distance. Mark rails where it intersects with
posts (Top & Bottom)
• If posts are plumb, top rail will be the same length. Top
aluminum insert will be 1/4” shorter than top rail (to allow for
mounting brackets). Cut rails with a saw. You may cut both pvc
and aluminum at the same time.
• Determine angle of stairs and cut one end of each baluster to
same angle. Make note to check baluster length with desired rail
height .
STEP 3
INSTALL BRACKETS
,
BALUSTERS & RAIL
• Bottom Rail Brackets: Place bottom rail bracket on bottom of
aluminum insert with post mounting ange pointing up. Make
certain post ange is ush with the end of the bottom sub-rail
and mark the elongated slot. Drill a 1/8 hole in the center of
elongated slot and install a #10 x 3/4" mounting screw.
•Top Rail Brackets: Top Rail Brackets with mounting anges
pointing down on end of top sub-rail. Find center of elongated
slot and drill a 1/8 pilot hole. Install two
#10 x 3/4” screws. Adjust bracket angles if necessary.
• Using pre-routed holes on bottom pvc rail, align and attach
balusters on angle cut end. Attach with provided screws. Slide
sub-rail into bottom rail with bracket anges facing down.
• Find center of post/mounting surface. Mark center line on
surface. Determine distance from nished deck to bottom of
rail. Add 3/8” and mark. Drill 3/16” hole on center of center
line. Install #14 x 1” screw to within 1/8” of mounting surface.
Check screw head clearance using a bottom bracket and adjust
clearance between screw head and post/mounting surface to
obtain a snap fit.
• Install bottom rail with installed balusters onto mounting screws.
• Set top sub-rail between posts and insert balusters.
TIP: Start at the bottom of stair run and work up.
• With all balusters inserted, center top rail brackets on post and
install 2 each #10 X 1 ¼” screws
• With all mounting screws installed, carefully snap top rail cover
over aluminum insert.
STEP 4 FINISHING STEPS
• With rail mounted in place, measure and mark post sleeves to
desired height.
• Cut post to desired height with a saw and clean edge of cut.
• Apply a small bead of silicone to the inside edge of post cap
and install on top of post sleeve (let set 12 hours for adhesive to
cure).
P310
STAIR INSTALLATION
STEP 3
STEP 1
Fairway Architectural Railing Solutions will not be held liable for incorrect or unsafe installations by the installer. It is the installer’s responsibility to secure
proper building permits, review local codes and safety needs and meet or exceed them. The instructions provided by Fairway are a guide and may not
account for every special circumstance. The installer must indentify and execute the installation approach that is appropriate for every application.
Cutaway of Top Rail Cutaway of Bottom Rail
Top Rail Brackets Bottom Rail Brackets
STEP 2
EnvisionOutdoorLiving.com 1-800-598-5245
#909980
© 2021 FAIRWAY ARCHITECTURAL RAILING SOLUTIONS
