Courtyard Creations KFS563F-WM User manual

KFS563F-WM
PARTS LIST
#6 BOLT M6*20
20
Attention:
Make sure that each bolt needed for all steps
matches the corresponding figure to ensure proper
assembly.
Step 1:
Insert the seat assembly (#1) into the leg B (#2) and
the leg A (#3). Fasten them together by using bolts
(#6) and washers (#8). Keep the bolts loose.
See Figure 1.
Note:
The number labels “1, 3” attached on the legs
should coincide with Figure 1, 2 to ensure proper
assembly.
FIGURE 1
PAGE 1 OF 2
STOP DON’T RETURN TO STORE!
COURTYARD CREATIONS INC.
PART
NO.
PART
NO.
PART PARTQ’TY Q’TY
KFS563F-CS01 17C33A0708001Y4
17C33A0703001Y4
17FA05040301-Y4
18000337004
17KAA0101----Y4
1 1 6 4
2
6
6
1
7
8
9
10
1
1
1
2
2
3
4
5
KFS562F-CS03
KFS563F-CS02
61K563FX00001BA
61K563FY00001BA
SEAT ASSEMBLY BOLT M6*20
BOLT M6*12
WASHER d6.5*D13*1.0
BOLT CAP
HEX.KEY WRENCH 4MM
LEG B
LEG A
BACK CUSHION
SEAT CUSHION
MATERIAL CODE MATERIAL CODE
ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
1
3
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
!
!
!
!
!
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
1

STOP DON’T RETURN TO STORE!
PAGE 2 OF 2
Cleaning and Maintenance
• Wash frame and fabric parts with mild soap and water, rinse thoroughly, and dry frame completely.
Do not use bleach, acid, or other solvents on the frame or fabric parts.
• Cushions may be washed on the surface only by using mild soap and water or commercial foaming
upholstery cleaner if necessary. If washed, rinse well and hang to dry. Do not machine wash or dry.
• We recommend the use of furniture covers when not in use.
• Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and
safety of your chair.
• In order to prolong the life and beauty of your chair, we recommend that it be stored in a dry and
protected area during off season periods.
FIGURE 3
#7 BOLT M6*12
Step 2:
Fasten the back to the legs (#2 and #3) by using
bolts (#7) and washers (#8). Make sure that all
of the bolts have been tightened completely and
cover them with bolt caps (#9). See Figure 2.
Step 3:
Place the cushions (#4 and #5) onto the chair.
Secure the cushions to the chair by using the
velcro straps. See Figure 3.
FIGURE 2
12
3
1
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
Missing A Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANY DIFFICULTY DURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT
1-877-539-7436 BEFORERETURNING THIS ITEM TO THE STORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS
LIST.
MOST PROBLEMS CAN BERESOLVED WITHOUT RETURNING THIS
PRODUCT TO THERETAILER.
