ASSEMBLY INSTRUCTIONS
FBW6R 6  Parkway Recycled Plastic Flat Bench
TOOLS NEEDED:
1/2” Open-end or Box-end Wrench•
5/16” Open-end or Box-end Wrench•
Ratchet with 1/2” Socket•
Ratchet with 5/16” Socket•
Square•
ASSEMBLY:
Inspect the shipping container contents for damage and to1.
determine that all components and hardware are present.
Assemble the bench over the packaging cardboard or padded2.
work bench to avoid scratching the product.
Layout the Planks on the work area with the predrilled holes3.
facing upward.
NOTE: Two of the Planks have two extra holes toward one end. These
Planks must be placed in the center of the bench with the
additional holes located near the bench centerline. The additional
holes are placed to mount the Gusset Brackets.
ASI 274-F S529_HRD103
BENCH COMPONENTS:
2 x Cast Iron Bench Leg
4 x Outer Plank
Recycled Plastic
1 x Cross Support2 x Bench Bracket
ASSEMBLY HARDWARE:
12 x
5/16”
Washer
4 x
5/16”
Flanged Hex Nut
6 x
5/16” X 1.25”
Hex Head Bolt
18 x
5/16” X 2.0”
Lag Screw
4 x
No. 12 X 1.5”
Pan Head Screw
2 x Gusset Bracket
2 x Center Plank
Recycled Plastic
1 x Bench Channel
Leave the two center
holes empty
5/16” Lag Screws
Packaging cardboard or
other so work surface
IMPORTANT:
Note location and orientation of
Gusset Brace mounting holes
Place the Cross Support across the center of the Planks and line4.
up the holes in the Cross Support with the predrilled holes in the
middle of the Planks. Start a 5/16” Lag Screw into each of the
Bench Support holes, except for the two center mounting holes.
These two holes will be used to fasten the Bench Channel.
Before tightening the Lag Screws, place the “L”-shaped Bench5.
Brackets across the planks with the raised edge facing outward at
each end of the Planks. Start a 5/16” Lag Screw through each of
the holes in the Brackets into the predrilled holes in the Planks.
Aer all 18 of the Lag Screws have been started, use the 1/2”
Socket to tighten them down.

Do not drag the assembled unit across any surface.•
This product requires only periodic cleaning with a sponge and a solution of mild detergent and water to•
remove surface dirt. Do not clean with a solvent or petroleum based products.
Furniture must not be used other than for its intended purpose and should be inspected regularly for loose,•
missing, or broken hardware, and general instability.
Furniture that is damaged or appears to be unstable must be removed from service and be repaired or replaced.•
Repairs must be made using only factory authorized parts and methods.•
WARNING
CARE AND
MAINTENANCE
211 North Lindbergh Blvd.
St. Louis, MO 63141
tel: [phone]
web: anovafurnishings.com
11/2012
Washer
5/16” Bolt
Washer
5/16” Bolt
Bench Leg
Bench Bracket
Washer
Flange Nut
Bench Channel
Bench Leg
5/16” Lag Screws
Drive the Screw closer to
the Leg rst
Bench Bracket
Bench Channel
Washer
Flange Nut
5/16” Bolt
Washer
Washer
Flange Nut
Gusset Bracket
Place the Bench Channel down the center of the Bench Planks with the open side up.6.
Align the mounting holes in one of the Bench Legs7.
with the holes in one end of the Bench Channel and
Bench Bracket. Insert one of the provided 5/16”
Bolts, with a Washer, through the Bench Leg, Bench
Channel, and the Bench Bracket, with the Bolt head
on the outside surface of the Bench Leg. Install a
Washer and Nut on the inside end of the Bolt.
Leave the hardware nger tight so that adjustments8.
can be made to aid assembly.
Install a Bolt with Washer through the other mounting hole in9.
that Bench Leg, Bench Channel, and the Bench Bracket and
add a Washer and Nut to the end of the Bolt. Again, leave the
hardware nger tight.
Repeat this for the other end of the Bench. Leave the hardware10.
nger tight so adjustments can be made.
Position one of the Bench Gusset Brackets so the single mounting11.
hole is aligned with the hole in the raised tab on one of the Cast Iron
Bench Legs. Before attaching the Bracket, make sure it is oriented so
the mounting hole tab will lie at over the predrilled holes near the
center of one of the Planks. Insert one of the provided 5/16” Bolts,
with a Washer, through both the Bracket and Cast Iron Leg. Install
a Washer and Nut on the other end of the Bolt and hand tighten the
Nut. Attach the other Gusset Bracket on the other Bench Leg in the
same manner.
Position the loose end of one of the Gusset Brackets so that the holes12.
in the mounting tab line up with predrilled holes in the Center Plank.
IMPORTANT: Use a square to keep the Bench Leg vertical while attaching the
Gusset Brackets. Driving the Pan Head Screws may tend to push or
pull the end of the Leg.
Start a No. 12 Pan Head Screw through the hole in the Gusset Bracket13.
tab that is closer to the Bench Leg. Continue to torque the Screw all
the way down, tight to the head of the Screw. Install the second Pan
Head Screw into the mounting tab and Plank.
Secure the Gusset Bracket on the other end of the bench in the same14.
manner.
Aer both Gusset Brackets have been secured, tighten the 5/16”15.
Bolts in the Bench Legs, Channel, and Brackets.
Install two Lag Screws through the holes in the Channel, into the16.
center Planks.
Check that all hardware is tight before turning the bench upright17.
and placing it on site for use.
