Crosley CO6109 User manual

Outdoor Arm Chair
CO6109

PART LIST
A B CD
F
Back Panel
1 PC
Seat Panel
1 PC
Right Arm Panel
1 PC
HARDWARE LIST
#2 #3 #5
Short Bolt
4 PCS
Medium Bolt
2 PCS 4 PCS
Flat Washer
10 PCS
M6*30mm M6*45mm
EXTRA HARDWARE LIST
M6mm
E
Cover of Seat
Cushion *
1 PC
Core of Seat
Cushion
1 PC
Cover of Back
Cushion *
1 PC
Core of Back
Cushion
1 PC
G H
*Please note cushion covers will
ship separately.
Left Arm Panel
1 PC
#1 #2 #3 #4
Flat Washer
1 PC
M6mm
#1
M6*15mm
#4
Allen Wrench
1 PC
M6mm
Short Bolt
1 PC 1 PC 1 PC
M6*30mm M6*45mm M6*15mm
Long Bolt
Long Bolt
Medium Bolt
2

Step 1.
Attach back panel (part A) to left arm panel (part D) using long bolts (part #3), flat
washers (part #4) and allen wrench (part #5).
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Lay left arm panel (part D) down on a soft flat surface, such as carpet, as shown below.
Step 2.
short bolts (part #1), medium bolts (part #2), flat washers (part #4) and allen
wrench (part #5).
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Attach seat panel (part B) to left arm panel (part D) and back panel (part A) using
#4 x2
#3
#5 x1
x2
#5
#3
#4
A
D
#5
#1
#4
#4
#2
#5
#4 x4
#1
#5 x1
x2
#2 x2
A
D
B
3

Step 3.
bolts (part #1), long bolts (part #3), flat washers (part #4) and allen wrench (part #5).
NOTE: Please fully tighten all bolts at this time.
Attach right arm panel (part C) to back panel (part A) and seat panel (part B) using short
FE
HG
Step 4. Insert core of seat cushion (part F) into cover of seat cushion (part E).
lnsert core of back cushion (part H) into cover of back cushion (part G).
#4 x4
#1
#5 x1
x2
#3 x2
A
B
D
C
4
#5
#3
#4
#5
#1
#4

Step 5. Carefully turn unit upright and add cushions as shown below.
5
