EOS EMOTEC B6000 User manual

Made in Germany
IPX4 Druck Nr. 29342340en 10.12
EMOTEC B6000
GB Assembly and operating instruction

2GB
English
Table of Contents
Package contents ...................................................................................................3
Technical data.........................................................................................................3
General information concerning sauna bathing ......................................................4
General safety precautions.....................................................................................5
Assembly of the control unit....................................................................................6
Wall mounting....................................................................................................6
Electrical connection...............................................................................................7
Connecting the sauna oven ....................................................................................7
Connecting the sauna lamp ....................................................................................7
Installation diagram ...........................................................................................8
Connection of the sauna heater ........................................................................8
Connecting the sensor lines..............................................................................9
Mounting the oven sensor.................................................................................9
Operation ..............................................................................................................10
Button Functions .............................................................................................10
Symbol description..........................................................................................10
Unit initialization....................................................................................................11
Finnish sauna operation .......................................................................................12
Temperature indicator ...........................................................................................12
Default parameters ...............................................................................................12
Heating time..........................................................................................................12
Important notes when programming .....................................................................13
Delayed startup.....................................................................................................13
Deactivating the preset time............................................................................14
Heating time limiter ...............................................................................................14
Changing the default temperature .......................................................................15
Programming fan operation ..................................................................................16
Programming current time ....................................................................................17
The control unit switch ..........................................................................................18
Error display..........................................................................................................18
Additional errors not displayed and their causes: ...........................................18
Service Address:...................................................................................................19
Guarantee.............................................................................................................19
Handling procedures for return shipments (RMA) - Details for all returns ! ..........20

3
GB
Package contents
(subject to change)
Included with the control unit are:
1. An heater-sensor board with overheat shutoff protection, KTY-sensors with sensor housing
, two 3x25 mm fastening screws and a 2,0 m long sensor cable, red and white.
2.A plastic bag with three 4 x 20 mm fastening screws.
3.A replacement overheat protection module.
Technical data
Rated voltage: 400 V 3 N 50 Hz AC
Schaltleistung: max 9 kW resistive load (AC 1 operation)
upgrade to 36 kW possible through connection to power cont-
rol units
Heating time shut-off: 6 h
Display: LCD, backlit
Protection type: IPx4 in accordance with EN 60529, splashproofing
Control range,
sauna operation: 30 to 115°C
Sensor system: KTY-Sensor with overheat shutoff protection at 142° C
Control characteristics: digital two-step control
Fan capacity:: max. 100 W, max. 450 mA (only fan without capacitor)
Light: max. 100 W, max. 450 mA (only ohm resistive load)
Error display: blinking warning triangle and error code on LCD
Environmental temperature:-10°C to +30°C
Storage temperatures: -20°C to +70°C

4GB
Dear customer,
with purchase of this sauna control unit you
opted for a superior quality, high-tech elec-
tronic device which was developed and
manufactured according to the highest stan-
dards and guidelines.
Please note that an optimal interaction of
sauna cabin, sauna oven and sauna control
unit is mandatory for a pleasant sauna cli-
mate in your cabin.
With this superior sauna control unit you can
„operate“ your sauna system, and thanks to
the many individual programming settings
you will surely soon find the setting that suits
you best.
Perception in the sauna is very subjective,
therefore it really requires your own percep-
tion, or that of your family to find the most
suitable settings.
By default the finnish sauna is preset to
95°C. For steam operation the values are
set to 60°C and 60% humidity.
The following operation instructions describe
how to pre-select „your“ climate in the cabin.
Read these instructions carefully, so that you
quickly and easily find your way though the
programming process.
Please note the variation in temperatures in
the cabin while sauna bathing. The hottest
area is directly under the cabin ceiling, whe-
reas there is a steady temperature gradient
towards the floor of the cabin. Inversely, the
relative humidity is lowest directly under the
cabin ceiling and the highest on the cabin
floor.
For safety reasons the temperature sensor
with the overheat safety shutdown is located
on the cabin ceiling above the oven, since
this is the hottest area in the cabin.
Therefore there will always be temperature
variations between the temperature sensor
of the control unit and the thermometer in
the cabin.
General information concerning sauna bathing
For the cabin light use only light bulbs. Do
not use fluorescent lamps, energy saving
lamps and gas discharge lamps.
For example, when pre-setting the cabin
temperature to 100°C, the thermometer in-
side the cabin may easily show 85°C - 90°C.
This complies with the typical climate inside
the cabin.
Always observe hygiene. Always use hand-
or bathing towels, to avoid getting perspirati-
on on the wood.
To protect your cabin from possible dama-
ges due to steam operation, we recommend
reheating or drying the cabin after every
steam bath.
In addition, a fan can help to dissipate used
humid air in badly ventilated areas.
To avoid the perception of draft, you should
avoid using any ventilation system while
sauna bathing. It should only be used if re-
commended by the cabin manufacturer
Always make sure no objects are
located on the sauna oven before
starting the heating cycle.

5
GB
General safety precautions
• his device has not been designed for being
used by persons (including children) that
are physically or mentally handicapped
or have sensory disabilities. Moreover, it
is not allowed to use this device without
sufficient experience and/or knowledge,
unless these persons will be supervised
by persons responsible for their security
or in case they have been instructed how
to use this device.
• Children are to be supervised in order to
make sure that they do not play with this
device.
• Attention: It is forbidden to install
the control box in a closed switch ca-
binet or behind a wooden panelling!
• The electrical installation may be done
only by a qualified electrical technician.
• You must comply with the regulations of
your power supply company and applica-
ble VDE regulations (DIN VDE 0100).
• WARNING: Never attempt repairs
or installations yourself, as this could
result in serious injury or death. Only a
qualified technician may remove the hou-
sing cover.
• Please note the dimensions in the assem-
bly instructions, especially when installing
the temperature sensor. The temperature
above the oven is critical for the tempera-
ture setting. The temperature can be held
within operating parameters and a mini-
mal temperature gradient inside the bench
area of the sauna cabin can be achieved
only if unit is assembled correctly.
• The device may only be used as intended
as a control unit for sauna ovens up to 9
kW. (Up to 36 kW when combined with a
breaking capacitor).
• Completely disconnect the control unit
from the electrical circuit, i.e. flip all circuit
breakers or the main circuit breaker during
each installation or repair.
• Please note the safety and installation in-
formation from the sauna oven manufac-
turer.
• Always heed the specifications and in-
structions of the cabin manufacturer, too.
Attention!
Dear customer,
according to the valid regulations, the
electrical connection of the sauna hea-
ter and the control box has to be carried
out through the specialist of an authori-
zed electric shop
We would like to mention to the fact
that in case of a warrenty claim, you
are kindly requested to present a copy
of the invoice of the executive electric
shop.
When using control units that offer the
possibility of external access (GSM-module,
remote button, etc.) or time-delayed swit-
ching (preselection time, weekly timer, or
similar) a trigger guard with covered heating
unit is required. (cover protection type 1-5 or
S-Guard).

6GB
Assembly of the control unit
Wall mounting
Mount the control unit outside the sauna
cabin only. The most practical mounting
point would be the wall area onto which
the sauna oven is mounted on the inside,
except on the outside of the cabin. If elec-
trical conduits are present, mount the con-
trol unit accordingly. To mount the control
unit, please follow these instructions:
Illust. 1
1. Remove the cover of the control unit. To
do this press the fastening tab inwards
with a flat screwdriver and remove the
housing top by pivoting it upwards (Il-
lust.1). Drill the threaded holes for the
included 4 x 20 mm wood screws accor-
ding to Illust. 3 & 3.1.
2.Insert one of the wood screws into the
upper middle hole. This screw will be the
mounting point for the control unit. Make
sure the screw is projecting out from wall
about 3 mm. (Illust. 3.2)
3.Hang the control unit onto the 3 mm pro-
jecting screw. Insert the included rubber
sleeves into the openings on the back
side of the housing and lead the electri-
cal cable through these openings. Screw
the lower part of the housing onto the ca-
bin wall using the lower threaded holes.
(Illust. 4)
Illust. 3
eye level
Illust . 3.2
3
Illust . 4
feed-through channel for
power supply lead wire
oven supply line
vaporizer supply line
lamp
fan
feed-through
channel for
sensor lines
upper threaded hole
threaded holes
Illust. 3.1
ca. 34 cm
17,4 cm
19 cm
eye level

7
GB
Assemble the sauna oven according to the
instructions provided by the manufacturer in
front of the air intake opening.
Lead the silicone wire to the power control
unit through the ducts and connect them to
the corresponding terminals according to cir-
cuit diagram.
Note: If no ducts are available, bore a hole
next to the air inlet opening and pull the sto-
ve wire/s to the outside to lead them to the
corresponding terminals in the control unit.
In order to protect the silicone wire from ex-
ternal impacts it should be covered. There-
fore use a suitable cable duct or a PVC pipe
in which you lead the wire/s to the power
control unit.
Lead the power cord to the control unit and
connect it to the power inlet terminal.
Electrical connection
The electrical connection may only be
done by a qualified electrical technician
under authority of the regulations of the
local power supply company and those
of the VDE.
In general, there can only be one permanent
connection to the power supply network, to
include a device which allows the unit to be
disconnected from the power source with a
contact distance of at least 3 mm from all
terminals.
All electrical installations and connector ca-
bles inside the cabin must be able to with-
stand temperatures up to 170°C.
The sauna lamp must be splashproof (by
Standard IPx4) and resistant to ambient
temperature. The sauna lamp can be moun-
ted anywhere except in the area of the rising
hot air above the oven. Only bulbs should
be used!
Connecting the sauna
oven
Connecting the sauna
lamp

8GB
4
335
4
5
= alternativ
400 V 3 N AC 50 Hz
LSG
Emotec
Installation diagram
Connection of the sauna heater
AC 400 V 3N
w
KTY 11/5
142°C
r
r
w
U V W N N N L1 L2 L3 S1 light fan
DC 12 V / 24 V
limiter
sensor
LSG
max. 100 W max. 100 W
P max. 9 kW
400 V 3N AC 50 Hz

9
GB
20 cm
Illust. 7
Illust. 8 Illust. 9
Connecting the sensor lines
ou should not install sensor and power sup-
ply lines together, or lead them through the
same conduit. This can lead to interferences
in the electronics, such as „fluttering“ in the
relays. If it is absolutely necessary to install
them together, or the wire is longer than 3m,
you should use a shielded sensor line such
as the LIYLY-O x 0.5 mm²). Connect the
shielding to mass in the control unit.
Please note that the following measure-
ments are based on values provided by
the unit quality assurance by the European
Standard EN 60335-2-53. In principle, you
must mount the oven sensor where tempe-
ratures are expected to be the highest. Il-
lust. 7 gives you an overview of the moun-
ting point of the sensor..
1. Mount the oven sensor in cabins up to 2
x 2m according to Illust. 7 and 8, in larger
cabins according to Illust. 7 and 9.
2.Drill a hole to lead the cable through, pre-
ferably through the middle of one of the
wooden boards.
3.Lead the sensor cable through the drilled
hole and attach it to the sensor line accor-
ding to Illust. 10.
4. Attach the lines for the shutoff (white) and
the temperature sensor (red) according to
Illust. 11 to the sensor board. Then insert
the sensor board into the housing.
5.After you are finished installing and have
made sure the control unit is functioning
properly, check the line for overheat shut-
off protection for short circuits. To do this,
release one of the white lines in the sensor
housing. The safety relay of the control
unit should now fall; i.e. the heating circuit
should now be interrupted.
Hole
Sauna ceiling
Center sensor housing
on middle section
Sensor line
Terminals in the
control unit
Illust. 10
Ô
Housing
red
red
Senso r-
board
Illust. 11
Sensor
white (Limiter
white (Limiter)
Mounting the oven sensor

10 GB
Button Functions
Operating
switch on - off
Lamp
on - off
Program button Selection
buttons
Operation
Symbol description
TimeF1
P1 Pre-selected time
P2 Heating time
P3 Heating (dry)
P4 Ventilation function
Mode
If the control box does not pick off voltage after closure, please check the position of
the control box switch (Switch-Off). See chapter about „control box switch (Switch-
Off)“ at the end of this manual.

11
GB
12:00
20:00
20:00
20:00
Unit initialization
After checking all connections once more,
connect the unit to the power supply by swit-
ching on the fuse and the main switch.
On the display appears
and the clock symbol begins to blink.
After a short time (30 seconds) you can start
with programming.
You may now set the current time using
the and buttons during the
blinking of the clock symbol.
To accept the selected time, press the
MODE-button until the selected time
begins to blink.
Briefly F1 appears on the display.
After that, the current time is displayed and
the unit is ready for operation.

12 GB
p r e s e l e c t e d
temperature
Current tempera-
ture in cabin
20:00
05:58
20:20
Turn on the unit by pressing the left but-
ton. Simultaneously, this turns on the cabin
lighting and the backlit display.
Finnish sauna operation
After switching on the unit, the display al-
ternates between the time of day and the
remaining heating time.
Temperature indicator
The temperature is displayed on the right-
hand side of the display by a thermometer
symbol.
An arrow on the right side of the thermome-
ter displays the pre-selected temperature.
The colored area of the thermometer dis-
plays the current temperature in the cabin.
During the heating cycle the thermometer
rises to the preset temperature. Once rea-
ched, the control phase begins.
Default parameters
Heating time
By default the heating time is limited to 6
hours. After 6 hours, the unit will shut down
for safety reasons.
The remaining heating time alternates with
the current time of day on the display.
If you wish to end your sauna bath prema-
turely, press the button.
The symbol on the display then disap-
pears.

13
GB
Using the time preset , you can set your
sauna system to start up within 24 hours.
Always check for objects on
the sauna oven before starting
up the sauna. Fire hazard!
P 1
15:00
17:10
P 1
Important notes when programming
Every modification of the preset parameters must be confirmed by pressing the „MODE“
button.
If you do not press the „MODE“ button, the unit will automatically default back to the pre-
vious parameters.
If you do not touch the unit for a longer period of time during programming, the display will
default back to standard and the illumination will cease after a short time.
To select an alternate start-up time, press
the „MODE“ button. The selection symbol
P1 appears on the display.
Press the „MODE“ button again and you
see the actual start-up time.
Using the selection buttons and you
can now set heating time.
Please consider, though, that the cabin
needs 40-50 minutes for warming up, to
create a pleasant climate in the cabin. For
example, if you wish to take your sauna bath
at 6 p.m., then you should set the startup
time to 5:10 p.m.
Confirm the selected time by pressing the
„MODE“ button. P1 briefly appears on the
display.
As long as P1 is shown on the display, press
the button to start the delayed start-up
sequence.
Delayed startup

14 GB
P 2
06:00
03:00
20:00
17:10
After a short time, the display alternates
between current time and startup time. The
display illumination goes out.
When the pre-selected start-up time is
reached, the sauna switches itself on.
After the designated heating time it then
shuts itself back off automatically.
Heating time limiter
If you wish to individually set the heating time
for your sauna system, press the
„MODE“ button and choose P2 using the
selection buttons or .
Press the „MODE“ button again.
Now you may set the heating time using the
selection buttons.
Confirm your input by holding the „MODE“
button pressed continuously until the new
heating time and the symbol expire on the
display.
To deactivate the preset time, press the button. This switches the sauna heater on. Pres-
sing the button again switches the sauna heater off.
Deactivating the preset time

15
GB
P 2
P 3
85
95
85
Changing the default temperatu-
re
By default the temperature for Finnish opera-
tion is set to 95°C. To change this parameter,
press the „MODE“ button.
P1 then appears on the display in the pro-
gramming area.
Press the button repeatedly until P3 and
the heating symbol appear on the display,
and confirm this with the „MODE“
button.
The thermometer symbol appears, and the
heating symbol begins to blink.
Use the selection buttons and to set the
temperature. The arrow on the thermometer
symbol displays the selected temperature
level.
Finally, press and hold the „MODE“ button
until the heating symbol besides the entered
value begins to blink.
This confirms the entered value.
Afterwards P2 shortly appears, then the dis-
play returns to default readout. The maximum
heating time now matches the entered value
until changed again (re-start required). 20:00

16 GB
without symbol =no fan operation
with symbol = fan operation
P 3
P 4
0
1
20:00
This control unit lets you operate a fan.
By factory default, „no fan operation“ is
specified.
To program the fan function, first press the
„MODE“ button to reach the programming
mode.
Px then appears on the display.
Press the button repeatedly to reach the
program level P4. The fan symbol appears
on the display.
Confirm by pressing the „MODE“ button.
A „0“ appears on the display (no fan ope-
ration).
By pressing the button, you can set a „1“
(fan operation).
Confirm your selection by pressing the
„MODE“..button. On the display appears
shortly P4, then the unit returns to its default
readout and in set value „1“ the fan symbol
appears on the display.
Programming fan ope-
ration

17
GB
F 1
20:00
21:00
21:00
To reach this program level, press the
„MODE“ button and the button simul-
taneously until F1 is displayed, as well as
the clock symbol.
You can change the time with function F1.
Confirm with the „MODE“ button and the
previously set time begins to blink with the
clock symbol.
Set the current time using the and
buttons (e.g. when adjusting daylight-
savings time).
Confirm your selection by pressing and hol-
ding the „MODE“ button, until the entered
value begins to blink.
F1 briefly appears on the display, then the
unit returns to its default readout.
Programming current
time

18 GB
Error display
To quickly diagnose possible errors, use the error code explanation below to ascertain the
type of error.
Error code Error
E 100 temperature sensor interruption/disconnection
E 101 temperature sensor short circuit
E 211 overheat safety shutoff interruption/disconnection
The warning symbol blinks whenever an error message is displayed, so you may easily
recognize an error.
Additional errors not displayed and their causes:
Blank display - display not backlit
Check the power supply! All three phases L1, L2, L3 must be connected to 230 V AC.
Check all fuses.
Control unit switch
= unit swit-
ched on
= unit swit-
ched off
= light swit-
ched on
The control unit switch
The control unit switch can be found on the
top end of the unit. Using this
switch, you can isolate the electronics from
the mains supply in case of a breakdown.
Please note that operating the control unit
switch returns all settings to the factory
settings.
In case of breakdown, press the control unit
switch on the left part of the rocker to the
first position (switch position 0). The unit is
now completely switched off.
In order to switch on the light in the sauna
when the unit is switched off, press on the
left part of the rocker to the second position
(switch position II).
In order to put the unit back into operation,
switch back to the starting position (switch
position I).

19
GB
Service Address:
EOS Saunatechnik GmbH
Adolf-Weiß-Straße 43
35759 Driedorf-Mademühlen, Germany
Fon: [phone]
Fax: [phone]
[email protected]
www.eos-sauna.de
Guarantee
The guarantee is taken over according to
the legal regulations at present.
Manufacturer’s warrenty
- The period of warrenty starts from the
date of purchase and lasts up to 2 years
for commercial use and 3 years for priva-
te use.
- Always include the completed warrenty
certificate when returning equipment.
- The warrenty expires for appliances
which have been modified without
manufacturer’s explicit agreement.
- Damages caused by incorrect operation
or handling through non-authorized per-
sons are not covered under the terms of
warranty.
- In the event of a claim, please indicate the
serial number as well as the article code
number and type name with expressive
description of the fault.
- This warrenty covers damaged parts but
no defects due to wear and tear.
In case of complaint please return the
equipment in its original packaging or other
suitable packaging (caution: danger of
transport damage) to our service depart-
ment.
Always include the completed warrenty
certificate when returning equipment.
Possible shipping costs arising from the
transport to and from point of repair cannot
be borne by us.
Outside of Germany please contact your
specialist dealer in case of warranty claims.
Direct warranty processing with our service
department is in this case not possible.
Equipment start-up date:
Stamp and signature of the authorized
electrician:
Please keep this address in a safe place to-
gether with the installation guide.
To help us answer your questions quickly
and competently, please provide data prin-
ted on the ID plate, to include system type,
article no. and serial no., in all inquiries.

20 GB
Handling procedures for return shipments (RMA) - Details for all returns !
Dear customer
we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an
exeption, please follow the procedures specified below.This enabling us to ensure a quick and smooth
handling of the return shipment.
Form of complaint:
Please absolutely respect for all returns!
• Please add the available RMA-voucher always completely filled out together with an
invoice copy to the return shipment! Do not stick it on the goods or on the packaging.
We do not accept the return shipment without these papers.
• Not prepaid parcels will be refused and returned to Sender! Please always ask for the
RMA-No. for the cheapest return.
• Please pay attention that the goods have to be sent back without visible marks of
use in the original scope of delivery and in original packing.
• We recommend to use an additional solid and break-proof covering box which
should be padded out with styrofoam, paper or similar. Transport damages as a result of
faulty packing are for the sender‘s account.
2) Faulty goods
• The implied warrenty pe-
riod is 2 years.Please
contact your dealer in
case of faulty or wrong
articles or missing ac-
cessories. He will discuss
with you the individual
case and try for immediate
and customer-friendly so-
lution.
• For economic returns
within Germany you will
get an RMA-number
from the manufacturer.
• All returns have to be in
the original packing of
the goods with corre-
sponding accessories.
Please repack the goods
to avoid damages. In case
of wrong delivery, please
do not use this article !
3) Problems of installation
and functioning
• Please read the manual
carefully first of all and
pay attention to the indica-
ted assembly or installing
instructions.
• Your dealer should be
the first contact person
because he knows his
products best and also
knows possible problems.
• In case of function
problems with an arti-
cle, please check at first
whether there is an obvi-
ous material defect. The
quality system in our fac-
tory reduces malfunctions
of new appliances to al-
most zero.
.
1) Transport damage
• Please check the content
of your parcel immediately
and advise the forwarding
company of a claim (par-
cel service/ freight forwar-
der)
• Do not use damaged
goods!
• Ask the forwarder for a
written acknowledge-
ment of the damages.
• Report the claim promp-
tly by phone to your
dealer. He will discuss
with you how to act in this
case.
• If the transport box has
been damaged, please
use an additional covering
box. Do not forget to add
the acknowledgement of
the damage of the for-
warding company !
