Epic Office Furniture Boost Static Return User manual

1
Boost Static Return Fixed Height Workstation Frame
Instruction Manual
Table of Contents
Component parts ............................................................................................................................................ 2
Assembly Instructions ……................................................................................................................................ 3
Boost Static Return Frame
Boost Static Single Frame

2
Component parts
NO.
Component Name
PCS
NO.
Component Name
PCS
1
Bolt: M6x16
5
9
Top frame-1
1
2
Leveling pads
2
10
Bolt: M6x10
3
3
Table feet
1
11
Centre bracket
1
4
Column
1
12
Center rails
2
5
Bolt: M6x12
4
13
Top frame-2
1
6
Screw:ST4x20
13
14
Hand bolts M6x10
2
7
Side brackets
1
15
Allen Wrench(4mm)
1
8
Rubber pad
10
16
Cable tie
2

3
Assembly Instructions
Step 1
Loosen the pre-installed bolts and Adjust the length of the top frame to match the size of the table top.
Step 2
Inset the column to the top frame.
- First fix 2pcs screws M6x12 like Cdisplayed
- And then tighten the pre-installed bolts like Bdisplayed
A
B
C

4
Step 3
Install the table feet Screws 4 pcs M6x16,install the 4 leveling pads.
Step 4
Install the side bracket with Screws 2 pcs M6x12,
Step 5

5
Connect the return frame to the single workstation and fixed with 2 hand bolts.
Fix the centre brackets with 2pcs screws M6x10.
Step 6
Mount the tabletop and fix it with 24 pcs screws ST4x20
Tighten the bolts on top frame to fix it.
D
