Epic Office Furniture Agile Flip User manual

Agile Flip
Assembly Instructions

Agile Flip Assembly Instructions
2
Agile Flip
Components List
Components QTY Part No.
1 Steel Leg Flip Table Frame x2 AGFLIP...
2 Agile Flip Mechanism x2 AGFLIPMECH
3 Main & Pull Rail x1 AGFLRAIL...
4 Flip Rail Bracket x1
5 Worktop x1
Screws QTY
6 Screw x4
7 Wortktop Screw x12
8 Washer & Screw x2
5
2
7
1
8
4
3
3
6

Agile Flip Assembly Instructions 3
Agile Flip
Assembly Instructions
STEP 1:
Fit the pull bar to the top of the mechanism. Find the correct work top depth on the guide, and
place it down over the locater pin.

Agile Flip Assembly Instructions
4
Assembly Instructions
STEP 2:
Qty = 4
Agile Flip

Agile Flip Assembly Instructions 5
Assembly Instructions
STEP 3:
Qty = 12
Agile Flip

Agile Flip Assembly Instructions
6
Assembly Instructions
STEP 4:
Qty = 2
For tables with a work top deeper that 700mm, attach the pull bar to the work top using the screw & washer
supplied. Leave the screw a single turn from tight so the pull bar will operate smoothly.
Agile Flip

Agile Flip Assembly Instructions 7
Assembly Instructions
STEP 5:
Agile Flip

Agile Flip Assembly Instructions
8
Assembly Instructions
Complete:
Agile Flip

Agile Flip Assembly Instructions 9
Assembly Instructions
Agile Flip
C
L
138mm 138mm
170mm
64 A 64
Table Top Length
Table Top
Width
B 114mm 294mm B
C
2 - 2mmØ x 12mm h
12 - 2.5mmØ x 15mm h
Width - 600mm A B C
1200mm 796 96 N/A
1500mm 1096 96 N/A
1800mm 1396 96 N/A
Width - 750mm A B C
1200mm 796 171 100
1500mm 1096 171 100
1800mm 1396 171 100
Width - 900mm A B C
1200mm 796 246 175
1500mm 1096 246 175
1800mm 1396 246 175

Agile Flip Assembly Instructions
10
Assembly Instructions
C
L
200 20073 73
17
17
17 17
36.5
36.5
1.2mm pilot hole
Locked connector link Unlocked connector link
Agile Flip
Care Instructions:
Please visit our website for Care & Maintenance instructions
www.olgoffice.com
