ePropulsion MD4830N06 User manual

Please read this manual carefully before use.
This manual is subject to update without prior notice, please visit our
website www.epropulsion.com for the latest version.
2023.11 Version 1.1
SET
E Battery Solar Charger
48V 1600W
Model：MD4830N06

Introduction
Thank you for purchasing ePropulsion E Battery Solar Charger 48V-1600W.
The E Battery Solar Charger 48V-1600W is a product designed for the E-Series Battery.
Declaration of conformity
Object of the Declaration:Product:
Product:DC & Solar Charge Controller
Model: MD4830N06
We Guangdong ePropulsion Technology Limited, hereby, declares that this equipment is compliance with the applicable Directives
and European Norms, and amendments.
The object of the declaration is in conformity with the following directives:
Electromagnetic Compatibility (EMC) 2014/30/EU
DirectiveLow Voltage Directive (LVD) 2014/35/EU
Applied Standards:
EN IEC 61000-6-3:2021
EN IEC 61000-6-1:2019
EN IEC 61000-3-2:2019+A1:2021
EN 61000- 3- 3:2013+A1:2019+A2:2021
EN 62109-1: 2010
EC REP
Name: REP Europe GmbH
Address: Werner-von-Siemens-Str. 264319 Pfungstadt Germany
Phone: [phone]
[e-mail]
Manufacturer
Name: Guangdong ePropulsion Technology Limited
Address: Room 801, Building 1, 11 Daxue Road, Songshan Lake, Dongguan, Guangdong Province, China
Signature: Date: 2023/10/18
Shizheng Tao, Chief Executive Officer & Cofounder of
Guangdong ePropulsion Technology Limited
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
Interface description
No. Item
1 LED indicator light
2 Battery communication interfaces
3 Positive interface for Solar Panel
4 Common negative interface
5 Positive interface for Battery
6 Fixed hole
E Battery Solar Charger
48V 1600W
Model：MD4830N06
2
1
3 4 5 6
Product dimensions：233*262*100mm
Mounting dimension：215*132mm
Fixing hole position：φ6mm
215.00
202.40
233.00
172.00
60.53
100.00
φ6.00
262.08
31 .1 mm29
2
1
3 4 5 6
Product dimensions：233*262*100mm
Mounting dimension：215*132mm
Fixing hole position：φ6mm
215.00
202.40
233.00
172.00
60.53
100.00
φ6.00
262.08
31 .1 mm29
2
1
3 4 5 6
Product dimensions：233*262*100mm
Mounting dimension：215*132mm
Fixing hole position：φ6mm
215.00
202.40
233.00
172.00
60.53
100.00
φ6.00
262.08
31 .1 mm29
Dimensions

Notes
Do not reverse the input and output cable.
Do not reverse the positive and negative poles of the Solar Charger.
Use the Solar Charger within the specified voltage range.
The Solar Charger Input Cable (Negative) and the Solar Charger Output Cable (Negative) are both connected to the GND of the
Solar Charger.
When paralleling multiple solar panels, please ensure that the specifications of the solar panels are consistent.
Before connecting the E Battery Solar Charger 48V-1600W with the third party product, please contact ePropulsion authorized
distributor.
If the E battery is charged by the solar charger without a communication cable, it may not be fully charged to 100%.
Installation process requires the following tools: Phillips screwdriver, wire crimping pliers (1- 5mm²).
Operations
1. Please follow the wiring diagram below to perform wiring operations without power on.
2. After connecting the wires, please turn on the battery system to power on, and then close the switch between the solar charger and
the battery
Before connecting, please prepare following products:Main Switch（>50A）、Solar Panel
If there are more complex parallel operating conditions, please contact ePropulsion Technology's authorized dealers.
a.When only using a solar charger to charge the E60/E163, you will need to purchase the following additional materials:
Solar Charger communication Cable
Mian
Switch
Solar Charger Input Cable
(Positive & Negative)
Solar Panel
E battery DC output cable 2.5m
(w aviation connector)
Solar Charger Output Cable
(Positive)
Item
E Battery DC output
cable 2.5m
(w aviation connector)
Qty. 1 set
Specifications
Specifications PV Input Protection Environment Dimension
Rated
voltage 51.2 Vdc Power 1600W Overcharge protection,
overcurrent protection,
overtemperature
protection, reverse
connection protection
of solar panel, reverse
charging protection
at night. No reverse
connection protection
for backup battery
(external fuse is needed)
Operating
temperature
-35℃to
65℃
Weight 5.3 kg
Charging
Voltage
Range
41.6 -57.6
Vdc
Maximum
input current
of PV
50A Altitude ≤3000m
Maximum
PV input
voltage
60 Vdc Protection
grade IP65
Dimen-
sions
233*262*100
mm
Maximum
CC Charging
Current 30A Efficiency ＞99% Certification CE、
RoHS
Packing List
Item Qty. Note
E Battery Solar Charger 48V-1600W 1 pcs /
Ring Terminals SC35-8 6 pcs /
Solar Charger Output Cable (Positive) 1 pcs Connect Solar Charger to E Battery or Busbar
Solar Charger Output Cable (Negative) 1 pcs
Solar Charger Input Cable (Positive) 1 pcs Connect Solar Charger to Solar Panel
Solar Charger Input Cable (Negative) 1 pcs
Remote Switch Extension Cable Without Resistance 1 pcs When connecting multiple devices, connect the Remote
Switch to E60/E163
MC4 Parallel Connector 4 in 1 1 set Contains positive and negative
E Battery Solar Charger 48V-1600W Manaul 1 pcs /
MC4 Connector Spanner 1 pcs /
Solar Charger communication Cable 1 pcs Suitable for E60/E163

LED Indicator
Status description of indicator lights
Battery Comm Cable
T Connector
AC～
Mian
Switch
Solar
Panel
Bus Bar 150A
Negative
Positive
Remote Switch E Battery Charger
Remote Switch Extension Cable
Without Resistance
E Battery Bridging Cable
(Positive & Negative)
Solar Charger Output Cable
(Positive & Negative)
Solar Charger Input Cable
(Positive & Negative)
Solar Charger
communication Cable
Indicator light of battery
Color of indicator
light Green Yellow Red Indicating method Description
Indicating method Normal ON Normal ON Normal ON Slow flash Fast flash
Description Battery fully charged Normal battery
voltage
Battery
undervoltage
Battery over-
discharge
Battery overvoltage/battery
over-temperature
If the indicator light of battery types remains in a steady cyan state, indicating that the connection to the E Battery is normal.
Warranty
ePropulsion E Battery Solar Charger 48V-1600W is guaranteed against any manufacturing defects for TWO years from date of delivery of
products to end customers.
Free warranty is only validated upon the presentation of legal serial number, Warranty Card, and evidence of purchase from an authorized
ePropulsion dealer.
Conditions
Valid date of purchase should be established by the first-hand purchaser with original sales slip.
Free warranty is not transferable and will not be reissued.
The warranty is valid only when the information is correct and complete.
Warranty does not cover
Minor faults producing no influence on the intended function of the product.
Faults resulting from any improper operation that contradicts the user manual.
Accessories supplied with the product.
Damage caused by accident, misuse or unauthorized repair.
Damage caused by dropping, improper care or storage.
If warranty expires, users can still enjoy maintenance services from ePropulsion authorized dealers with minimum maintenance charge.
Indicator light of solar panel
Color of
indicator light Red
Indicating
method
Normal
ON
Slow
flash
Single
flash Fast flash Double flash OFF
Description MPPT
charging
Boost
charging
Floating
charging
Equalizing
charging
Current-limited
charging
Not in
charging
b.When the solar charger is connected to E60/E163 and other devices as well, E60/E163 will prioritize charging using the E battery charger.
In this case，you will need to purchase the following additional materials:
Item E Battery Bus Bar 150A E Battery Bridging Cable Battery Comm Cable T Connector Remote Switch E Battery Charger
Qty. 1 set 1 set 1pcs 1pcs 1 set
SET
Indicator light of solar panel ①
N/A ②
Indicator light of battery ③
Indicator light of battery types ④
