M3 Mobile A-CHH-ATYP-150-R00 User manual

M3 Charging Holster
User Guide
Product Model:
A-CHH-ATYP-150-R00
Compatible Device:
M3 RED, GREEN, SKY and ORANGE
Version 2.1
Released in March 2013

Contents
Copyright and Agreement
Notice
Warnings and Cautions for Safety
1. Checklist
2. Usage
Description
Specification
How to use
Services and Support
............. 3
…………………………………. 4
. 6
………………………….. 8
…………………………..….. 9
........................................ 9
..................................... 11
...................................... 12
……............ 13
2

Copyright and Agreement in Usage
All contents of this user manual are protected by the
copyright laws, and M3 Mobile Co., Ltd. owns all rights
related to them.
Any part of this document cannot be copied, reproduced,
modified, or translated to other languages without the
prior written consent of M3 Mobile.
The contents of this user manual were written based on
the “current state” of the product, and the details of this
manual are subject to change without the prior notice.
M3 Mobile does not provide any guarantee including the
implied guarantee on the product’s characteristics in this
user manual and suitability for special purposes, and any
other guarantees not limited to them.
Microsoft, Windows, MS Office, Outlook, ActiveSync,
Internet Explorer, Windows Logo, and Windows CE,
Windows Mobile Logos are registered trademarks or
trademarks of Microsoft in the USA or other countries. The
license for OEM of Microsoft products was provided by
Microsoft Licensing Inc., subsidiary company of Microsoft.
M3 Charging Holster is a trademark of M3 Mobile.
All product names and services used in the manual and
product are company names, service marks, trademarks,
or registered trademarks of the corresponding right
owners.
3

Notice –General Notices
The contents of this user manual were made based on the
“current state” of the product, and this manual may
contain technical and editing errors or omissions.
When separate application programs are developed and
provided by the product providers using the product, refer
to the program user’s manual provided by the product
providers.
The companies that produce separate application
programs besides the basic installation programs must
include the contact telephone number for inquiring about
these programs on the product, program, or product box
separately when distributing the equipment.
M3 Mobile does not guarantee the quality of the programs
produced by third party software companies installed after
the release from the factory of M3 mobile.
M3 Mobile may request programs from the program
manufacturers in order to guarantee the quality of the
product to meet the requests of mobile network service
providers.
4

Notice –Revision History
Version 2.1 –March, 2013
Change address and M3 Mobile technical support webpage
Version 2.0 –Feb, 2011
Second release of user manual for renewal charging holster.
Version 1.0 –May, 2010
First release of printed version.
5

Warnings and Cautions for Safety
Before You Begin
Please read the warnings and cautions for safety carefully
before you begin to avoid any damages or accidents. If
you are not certain on any information given in this
manual, please contact your supplier.
Customer Cautions
If the device is lost or stolen, then immediately report the
incident to the service provider.
Refrain from using the device while driving.
When service for the product is required, request services
through the designated service center of M3 Mobile.
For inquires about the application programs and other
work programs besides the hardware and the basic
installation, directly contact the corresponding program
manufacturers.
Do not use any battery adapter or accessories other than
the designated ones provided with the product.
Free warranty service may not be allowed if failures occur
due to unauthorized use or misuse of the product.
6

Warnings and Cautions for Safety –Cntd.
Cautions in Carrying and Storing
Do not use the product in high temperature or high
humidity environments as this may quickly cause damage
to the product.
The product was designed to be suitable for work
environments, but avoid impacts or dropping the product.
This may cause fatal damage to the product.
Fully charge the battery before using the product for the
first time.
Do not modify the product
Do not try to modify the product by any means.
Modifications may cause fire, injury, electric shock, or
serious damage to the equipment and users.
The warranty service is not provided for troubles due to
unauthorized modification.
7

1. Checklist
Thank you for selecting M3 Charging Holster. This guide will help you
on basic usage of the product. Please check if all the contents shown
below are nearby for use. Power Supply is needed for charging.
8
Charging Holster
Power Supply
Belt Clip
If you don’t have everything, contact your supplier immediately.
Caution
Please use the correct power supply
provided by M3 Mobile. Compatibility with
other power supply source is not
guaranteed.

2. Usage –Description
A-CHH-ATYP-150-R00 is one of the M3 Mobile’s optional accessories for convenience of charging a PDA.
Description
Refer to next images (A-CHH-ATYP-150-R00) for Charging Holster parts and descriptions.
9
1. Device Slot
2. LED Connection
Indicator
3. LED Charging
Indicator
4. Hook
5. Power
Connector
6. 9Pin POGO
Connector
7. Insert Detector
8. Belt Clip Holder

2. Usage –Description continued.
10
1
2
3
4
5
6
7
8
9
USB D-
USB D+
USB VBUS
COM6_DET (N/A)
RXD (N/A)
TXD (N/A)
USB ID
GND
5V
1. Device Slot –A PDA slides into the slot for charging. Please note the sliding direction.
2. LED Connection Indicator –Connection status of a PDA and the Charging Holster is displayed.
Note that the LED on the PDA will show the charging status of PDA.
3. LED Charging Indicator –Charging status of the Charging Holster is displayed.
4. Hook –Press and hold to slide out PDA from Charging Holster.
5. Power Connector –DC power supply connector.
6. POGO Pin Connector –Used for charging a PDA.
7. Insert Detector –Detects the PDA insertion so that the holster starts charging the PDA.
8. Belt Clip Holder –Belt clip fits on this holder for portable PDA charging.
LED Color
Meaning
RED
The Charging Holster is being charged.
GREEN
The Charging Holster is fully charged.
LED Color
Meaning
RED Blink
The Charging Holster is discharged.
GREEN
PDA is connected to the Charging Holster and being charged.

11
2. Usage –Specification
Model
Charging Holster
Compatible PDA(s)
M3 RED, GREEN, SKY and ORANGE
Internal Battery
4,500mAh
Charging Period
Holster –About five hours and thirty minutes
PDA –About five hours
Holster & PDA –About five hours each
Note that a PDA will be charged first and then the holster battery will be charged.
Connection LED
Red blink - The Charging Holster is discharged.
Green - Connected between the PDA and the Charging Holster
Charging LED
Red –Charging
Green –Fully Charged
Adapter Input
AC 100 ~ 240V
Adapter Output
DC 9.0V / 3A
Power Connector
DC Jack Type
Charging Holster/PDA
connector
9 PIN POGO Connector. Refer to ‘Usage – Description No.6 Pin Connector’ for pin I/O information.

2. Usage –How to use
How to use
12
Step 1. Plug in the AC
adaptor plug to wall jack
and DC Jack to power
connector of charging
holster.
Step 2-1. Reversely slide
in PDA to the Charging
Holster.
It clicks when a PDA is on
the right position.
Step 2-2. In case of
charging a PDA and the
charging holster together,
PDA will be charged first.
Step 3. After use, press
and hold the Hook to slide
out the PDA from
Charging Holster.

Services and Support
13
Should you require any services or technical support on M3 Mobile’s products, contact your supplier or visit M3 Mobile
technical support webpage http://itc.m3mobile.net. Desired or relevant manuals can be downloaded from Knowledge
Center or FAQ in technical support webpage.
For DOA or RMA, please send the defective product to suitable address AFTER consulting the supplier.
M3 Mobile Co., Ltd.
Headquarter & Service Center
M3 Bldg., 735-45,
Yeoksam-Dong, Gangnam-Gu,
Seoul, 135-080, Korea
Tel: [phone] Fax: [phone]
Service Center
Chun-ui Techno Park 201-610,
202, Chun-ui Dong, Won-Mi gu, Buchoen,
Gyeonggi Do, Korea , 420-857
Tel: [phone] Fax: [phone]
Thank you for choosing M3 Mobile’s product!
