Epson Stylus NX230 Installation guide

EASY
WIRELESS
PRINTING
BUILT TO PE R FORM
S P E E D | Q U A L I T Y | R E L I A B I L I T Y
• Easy Epson Wireless — connect to your wireless
network in seconds1
• Epson Connect — get instant wireless printing of
photos and attachments right from smartphones,
iPads, tablets and popular mobile devices2
• Small-in-One — space-saving design; great
performance
• Quiet operation — focus on what’s important
• Truly touchable photos and documents —
instant-dry ink for smudge, fade and water
resistant prints
• Wireless printing and scanning — share
one Small-in-One at home, now with
Wi-Fi CERTIFIED™ n1
• Replace only the color you need — individual
ink cartridges available in different sizes to suit
your needs3
• Better image enhancement tools — red-eye
removal and photo restoration
• Quick, high-quality scanning up to 2400 dpi —
scan important papers, recipes, photos and more
• Manual two-sided printing4 — a great way
to save paper
• Product protection you can count on — one-
year limited warranty and quick product exchange
Epson Stylus®
NX230 Small-in-One™
Print | Copy | Scan | Wi-Fi®
DESIGNED FOR SIMPLICITY

Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada Limited
185 Renfrew Drive, Markham, Ontario L3R 6G3
www.epson.com
www.epson.ca
Epson Stylus® NX230 Small-in-One™SpecificationsPrint I Copy I Scan I Wi-Fi®
PRINT
Printing Technology 4-color (CMYK) drop-on-demand MicroPiezo® inkjet technology
Printer Language Epson ESC/P® Raster, Epson ESC/P-R
Maximum Print Resolution 5760 x 1440 optimized dpi
ISO Print Speed† Black 4.3 ISO ppm
Color 2.2 ISO ppm
Minimum Ink Droplet Size 4 picoliters
COPY
Copy Quality Color/Black-and-White; Draft/Normal
Copy Quantity 20 sheets (fixed)
Maximum Copy Size 8.5" x 11"
SCAN
Scanner Type Color flatbed
Photoelectric Device Color CIS line sensor
Optical Resolution 1200 dpi
Hardware Resolution 2400 dpi
Maximum Resolution 9600 x 9600 dpi interpolated
Scanner Bit Depth 48-bit color/24-bit output
CONNECTIVITY
Connectivity Hi-Speed USB 2.0
Wi-Fi CERTIFIED (b/g/n)1
Operating Systems Windows® 7 (32-bit, 64-bit)
Windows Vista® (32-bit, 64-bit)
Windows XP SP1 or higher (32-bit)
Windows XP Professional x64 Edition
Mac4 OS® X 10.4.11, 10.5.x, 10.6.x, 10.7.x
PAPER HANDLING
Maximum Paper Size 8.5" x 44"
Paper Sizes 4" x 6", 8.5" x 11", 8.5" x 14", A4, half letter, A6, user definable,
8" x 10", 5" x 7", 16:9 wide
Borderless Photo Sizes 4" x 6", 5" x 7", 8" x 10", letter
Paper Types Supports plain paper, Epson Bright White Paper, Brochure and
Flyer Paper Matte Double Sided, Presentation Paper Matte,
Premium Presentation Paper Matte, Premium Photo Paper
Semi-gloss, Photo Paper Glossy, Premium Photo Paper Glossy,
Ultra Premium Photo Paper Glossy, Ultra Premium Presentation
Paper Matte, Photo Quality Self-adhesive Sheets, Iron-on Cool
Peel Transfer Paper
Envelope Types No. 10
Input Paper Capacity 100 sheets plain paper
GENERAL
Temperature Operating: 50 ° to 95 °F (10 ° to 35 °C)
Storage: -4 ° to 140 °F (-20 ° to 40 °C)
Relative Humidity Operating: 20 – 80%
Storage: 5 – 85% (no condensation)
Sound Level 42 dB(A)
Rated Voltage AC 100 – 120 V / 220 – 240 V
Rated Frequency 50 – 60 Hz
Rated Current 0.5 AMP
Power Consumption Approx. 15 W ISO 10561 (Standalone copy printing)
Approx. 0.3 W (Standby mode)
ENERGY STAR® qualified
Safety Approvals Safety standards UL60950, CSA C22.2 No. 60950
EMI FCC Part 15 subpart B class B,
CAN/CSA-CEI/IEC CISPR 22 class B
Country of Origin Indonesia
Weight and Dimensions (W x D x H) Printing: 15.4" x 20.8" x 11.0"
Storage: 15.4" x 11.8" x 5.7"
Weight: 9.0 lb
What’s In The Box Epson Stylus NX230 Small-in-One, instruction booklet, CD-ROM
with drivers, power cord, four DURABrite® Ultra Ink cartridges
(one 124 Black ink cartridge and three 124 color ink cartridges:
Cyan, Magenta, Yellow)
Software Included Epson printer driver, Epson Scan
Warranty One-year limited warranty in the U.S. and Canada
INK
Ink Type DURABrite Ultra pigment ink
(smudge, fade and water resistant)
Ink Palette Cyan, Magenta, Yellow and Black
Ink Cartridge Configuration 4 individual ink cartridges
Fade Resistance / Print Longevity5 Up to 118 years
Replacement Ink Cartridges3 124 Moderate-capacity Black, Cyan, Magenta, Yellow
125 Standard-capacity Black, Cyan, Magenta, Yellow
ECO FEATURES
• ENERGY STAR qualified
• RoHS compliant
• Designed to be recycled6
• Smaller product and package than previous models —
uses less natural resources
• Epson America, Inc. is a SmartWaySM Transport Partner7
Epson, Epson ESC/P, Epson Stylus and MicroPiezo are registered trademarks, Epson Exceed Your Vision is a registered logomark and Better Products for a Better Future is a trademark of Seiko
Epson Corporation. DURABrite is a registered trademark and Small-in-One is a trademark of Epson America, Inc. The Wi-Fi CERTIFIED Logo is a certification mark, Wi-Fi is a registered mark and Wi-Fi
CERTIFIED is a mark of the Wi-Fi Alliance. Windows, Windows Vista and the Windows logos are trademarks of the Microsoft group of companies. SmartWay is a service mark of the U.S. Environmental
Protection Agency. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks.
Copyright 2011, Epson America, Inc. CPD-34429R1 7/11
† ISO ppm is based on ISO 24734. Black and color print speeds are determined in default, single-side mode, in accordance with ISO/IEC 24734. Actual print times will vary based on system
configuration, software, and page complexity. See www.epson.com/printspeed for details, including complete ISO reports.
1 Wi-Fi 802.11 b/g/n certified; level of performance subject to the range of the router being used.
Visit www.wi-fi.org/files/11nbasics_glossary.pdf for more information.
2 See www.epson.com/connect regarding compatible devices and apps.
3 For details, see www.epson.com/cartridgeinfo. Yields based on ISO/IEC 24711 tests in default mode printing continuously. Actual yields will be lower with higher-density images, hot or dusty
conditions, less frequent printing, or printing predominantly with one color. All ink colors are used for printing and all-in-one maintenance, and all colors have to be installed for printing. For print
quality, part of the ink from the included cartridges is used for printer startup and a variable amount of ink remains in the cartridges after the “replace cartridge” signal.
4 Some applications and/or functions, like two-sided printing, may not be supported under Mac® OS X.
5 Display permanence based on accelerated testing of prints displayed under glass in indoor display conditions; album permanence based on accelerated testing of prints in dark storage conditions.
Actual print stability will vary according to media, printed image, display conditions, light intensity, temperature, humidity and atmospheric conditions. Epson does not guarantee the longevity of
prints. For maximum print life, display all prints under glass or UV filter or properly store them.
6 See our website for convenient and reasonable recycling options at www.epson.com/recycle.
7 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
