Epson Stylus SX210 Series Assembly instructions

Basic Operation Guide
- for use without a computer -

2
About This Guide
Follow these guidelines as you read your instructions:
w c QR&
Warning:
Warnings must be followed
carefully to avoid bodily injury.
Caution:
Cautions must be observed
to avoid damage to your
equipment.
Must be observed to avoid
bodily injury and damage to
your equipment.
Note:
Notes contain important
information and hints for using
the printer.
Indicates a page number where
additional information can be
found.

3
Copyright Notice
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Seiko Epson Corporation. The information contained herein is designed only for use with this product. Epson is not responsible for any use of this information as applied to other
printers.
Neither Seiko Epson Corporation nor its aliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of
accident, misuse, or abuse of this product or unauthorized modications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and
maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson
Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as Epson Approved
Products by Seiko Epson Corporation.
EPSON and EPSON STYLUS®are registered trademarks, and Exceed Your Vision and EPSON ME are trademarks of Seiko Epson Corporation.
SDHC™is a trademark.
Memory Stick, Memory Stick Duo, Memory Stick PRO, Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick Micro, MagicGate Memory Stick, and MagicGate Memory Stick Duo are trademarks
of Sony Corporation.
xD-Picture Card™is a trademark of Fuji Photo Film Co., Ltd.
General Notice: Other product names used herein are for identication purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks.

4
Important Safety Instructions............................................................................................................................. 5
Guide to Control Panel.......................................................................................................................................... 6
Using the LCD Screen.............................................................................................................................................7
Power Saving Function..........................................................................................................................................7
Handling Media
Selecting Paper..................................................................................................................................................10
Loading Paper....................................................................................................................................................11
Inserting a Memory Card ...............................................................................................................................12
Placing Originals ...............................................................................................................................................14
Copying/Printing/Scanning
Copying Photos or Documents ...................................................................................................................16
Printing Photos..................................................................................................................................................18
Printing Photos from an Index Sheet ........................................................................................................20
Scanning to a Computer................................................................................................................................23
Maintenance
Checking/Cleaning the Print Head.............................................................................................................26
Aligning the Print Head..................................................................................................................................28
Changing Language & Resetting................................................................................................................30
Solving Problems
Error/Warning Messages ...............................................................................................................................32
Replacing Ink Cartridges................................................................................................................................33
Paper Jam ............................................................................................................................................................36
Print Quality/Layout Problems.....................................................................................................................38
Contacting Customer Support.....................................................................................................................39
Contents

5
Important Safety Instructions
Use only the power cord that
comes with the printer. Use of
another cord may cause re or
shock. Do not use the cord with
any other equipment.
Make sure the power cord
meets all relevant local safety
standards.
Place the printer near a wall
outlet where the power cord
can be easily unplugged.
Use only the type of power
source indicated on the label.
Do not let the power cord
become damaged or frayed.
Do not open the scanner unit
while copying, printing, or
scanning.
Do not use aerosol products
that contain ammable gases
inside or around the printer.
Doing so may cause re.
Except as specically explained
in your documentation, do not
attempt to service the printer
yourself.
Keep ink cartridges out of the
reach of children and do not
drink the ink.
If ink gets on your skin, wash
it o with soap and water. If it
gets in your eyes, ush them
immediately with water. If
you still have discomfort or
vision problems, see a doctor
immediately.
Do not shake ink cartridges
after opening their packages;
this can cause leakage.
If you remove an ink cartridge
for later use, protect the ink
supply area from dirt and
dust and store it in the same
environment as the printer. Do
not touch the ink supply port
or surrounding area.

6
Guide to Control Panel
a b c d e
POn r• JCopy Print photos Index Sheet uScan
Turns on/o printer. Selects to copy photo/
documents.
Selects to view and print
photos.
Selects to print photos
using index sheet.
Selects to scan and save
documents.
f g h i
+, - oCopy l, rPaper select
Sets the number of copies. Changes the zoom settings for
copying.
Selects photos and menus. Selects between A4 plain
paper and 10×15/4”×6”photo
paper for the paper loaded in
the sheet feeder.
Control panel design varies by area.
j k
xStart yStop/Clear
Starts copying/printing. Stops copying/printing or
resets settings.

7
Using the LCD Screen
a b
Use Copies + or - to set the
number of copies.
Press lor rto select the
setting item, or change the
photo displayed on the LCD
screen.
Power Saving Function
After 13 minutes of inactivity, the screen turns black to save
energy. Press any button (except POn) to return the screen
to its previous state.

8

9
Handling Media

10
Selecting Paper
The availability of special paper
varies by area.
If you want to print
on this paper...
Choose this on
the control panel
Loading capacity
(sheets)
a Plain paper A4
Plain Paper
[12 mm] *¹ *²
b Epson Bright White
Ink Jet Paper
A4
Plain Paper
80 *²
c Epson Premium Ink
Jet Plain Paper
A4
Plain Paper
80 *²
d Epson Premium
Glossy Photo Paper
10×15/4”×6”
Photo Paper
20
e Epson Premium
Semigloss Photo
Paper
10×15/4”×6”
Photo Paper
20
f Epson Ultra Glossy
Photo Paper
10×15/4”×6”
Photo Paper
20
g Epson Glossy
Photo Paper
10×15/4”×6”
Photo Paper
20
h Epson Photo Paper 10×15/4”×6”
Photo Paper
20
*1 Paper with a weight of 64 to 90 g/m².
*2 30 sheets for paper that already has printing on one side.

11
Loading Paper
Open and slide out. Flip forward.
Load printable side up. Fit.
A B
C D
Do not use paper with binder
holes.
Q
See the online User’s Guide when
using Legal size paper.
Align the edges of the paper
before loading.
Q
Do not load paper above the H
arrow mark inside the edge guide.
Q

12
Do not try to force the card all the
way into the slot. It should not be
fully inserted.
c
Inserting a Memory
Card A B
Insert one card at a time. Check the light stays on.
Removing a Memory
Card
Check the light stays on.
A B
Remove.
On Flashing
Q

13
If the memory card needs an adapter then attach it before
inserting the card into the slot, otherwise the card may get stuck.
c
*Adapter required
xD-Picture Card
xD-Picture Card Type M
xD-Picture Card Type M+
xD-Picture Card Type H
SD
SDHC
MultiMediaCard
MMCplus
MMCmobile *
MMCmicro *
miniSD *
miniSDHC *
microSD *
microSDHC *
Memory Stick
Memory Stick PRO
MagicGate Memory Stick
Memory Stick Duo *
Memory Stick PRO Duo *
Memory Stick PRO-HG Duo *
MagicGate Memory Stick Duo *
Memory Stick Micro *

14
Placing Originals
Place face-down horizontally.
A B
Slide to the corner.
You can reprint photos from
30 × 40 mm to 127 × 178 mm.
Q

15
Copying/Printing/Scanning

16
Copying Photos or
Documents AR&11 BR&14 C
Load paper printable side up. Place original horizontally. Select Copy.
F
Select paper type/size.Select a color mode.
D E
Set the number of copies.
To clear the number of copies,
press the r·JCopy button.
Q

17
G
Start copying.
After step F, if you want to
change the copy zoom, press the
oCopy button as shown in (1),
and then use + or - to change the
zoom manually as shown in (2). Or,
press the lbutton to select AUTO
to t to your paper size.
Q
You can speed up plain paper
copying, however print quality
declines. In step G, hold down
xbutton until the Plight starts
ashing.
Q

18
Printing Photos AR&11 BR&12 C
Load photo paper. Insert a memory card. Select Print photos.
E
Set the number of copies.
D
Select a photo.
To clear the number of copies,
press the button.
Q
To select more photos, repeat
steps Dand E.
Q

19
G
Start printing.
F
Select 10×15/4”×6”.

20
D
Print the index sheet.
C
Select Index Sheet.Load A4-size plain paper.
AR&11
Printing Photos from
an Index Sheet
You can print photos using an A4
index sheet. First print an index sheet,
mark the photos that you want to
print, and then scan the index sheet
to print your photos.
All of the photos on the card are
printed in groups of 30 thumbnails
per index sheet. You may need
several sheets of A4 plain paper.
Q
BR&12
Insert a memory card.
