Epson SMFBz1 User manual

Streaming Media
Player
SMFBz1(DTP9757)

Main Feature
·Google Official Certified Android TV 11.0（AOSP）
·Support HEVC/VP9 @p60 Decoding and HDR
·Support Playready DRM
·Support Dual band 2T2R 2.4G/5G Wi-Fi
·Support Bluetooth 5.1 and BLE
CE&UKCA Support Frequency Bands and Power:
BT 2402-2480 MHz ＜8dBm
WLAN 2412-2472 MHz＜20dBm
WLAN 5150-5350 MHz ＜20dBm
Acknowledgements of Trademarks
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the
United States and other countries.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the
double-D symbol are registeredtrademarks of Dolby Laboratories Licensing
Corporation.
Google, Android, Google Play, Youtube and other marks are trademarks of Google
LLC.

Safety Instructions
· Please read this user manual carefully before using.
· Operating Temperature: ≤45℃.
· Please do not use other types of batteries, and please dispose of waste batteries
properly.
· Connected by in-line equipment and power supply plug.
· Do not remove the cover to prevent electrical shock or damage.
· If the Receiver remains unused for a long time please unplug power cord to prevent
from fire or electrical shock. Do not use a damaged power cord.
· Never allow liquids, spray or other materials to enter inside the Receiver.
· Please place the Receiver horizontally to prevent damage.
· Do not allow the Receiver to be exposed to extreme heat, cold or humid conditions.
· Do not put any heavy object on the Receiver.
· When the Receiver is moved to another place with a sharp temperature difference,
please turn on the Receiver after a gap of 1-2 hours.
· Use a soft and dry cloth to clean casing. Prior to cleaning, please pull out the power
cord.
· Non-professional personnel are forbidden to open the Receiver. Unauthorized
opening may result in electrical shock.
Introduction
The user manual will guide you through the operations of the DTP9757 product.
Packing List：
□HD Digital Receiver * 1

Description of the Receiver
Connection
● Connection to rear panel
Step 1 Connect the Power supply (or PJ Power supply with Micro-USB Plug) to the
Micro-USB port of the Receiver.
Step 2 Connect HDMI cable between the Receiver and TV Set.
No.
Name
Description
1
USB-A
Universal Serial Bus
2
USB-A
Universal Serial Bus
3
Micro-USB
Micro USB power supply interface
4
HDMI
High Definition Multimedia Interface

Remote Control Unit
Key
Description
Power
AV Mute
Voice
Home
Esc
Apps Menu
Up Down Left Right
Enter
Enter
Color Mode
Menu
Input
Volume-
Volume+
Keystone

Initial Setup
The dongle is put in projector and connect projector with HDMI. Projector HDMI support
CEC feature, and then if test alone with the dongle, you should connect BT RCU.
Step 1.
Bluetooth Remote Pairing
Press Setting icon by USB mouse and enter Setting. Click “Remotes & accessories”
enter pair page. Press and hold “Enter” and “ ” Key for 3 seconds, the RCU will enter
pairing mode.
Note

Step 2.
Enable developer options
Enter Settings - Devices Preferences - About page. Move focus on item of “Android TV
OS build ”. Keep click until the prompt “You are now a developer! ”
Step 3.
WiFi connection
Enter Settings - Developer options - Network & Internet page. Select your WiFi and
connect.

Home Menu Operations
You can access the required functions through Homemenu when you press
(Home) button. Use to select a required content or type and press OK.
My Apps
List all installed application on the unit. You can access the APP you want to launch by
remote.

Settings
You can enter settings by pressing Setting button. There are three function entrance:
Apps, Devices Preferences and Remote & accessories.

Notes on Network Connection
•Many wireless home network connection problems during set up can often be fixed
by re-setting the access point or wireless router. After connecting the unit to the
home network, quickly power off and/or disconnect the power cable of the home
network router. Then power on and/or connect the power cable again.
•Depending on the Internet service provider(ISP), the number of devices that can
receive Internet service may be limited by the applicable terms of service. For details,
contact your ISP.
•Our company is not responsible for any malfunction of the unit and/or the Internet
connection feature due to communication errors/malfunctions associated with your
broadband Internet connection, or other connected equipment.
•Some Internet content may require a higher bandwidth connection.
•Even if the unit is properly connected and configured, some Internet content may not
operate properly because of Internet congestion, the quality or bandwidth of your
Internet service, or problems at the provider of the content.
•Some Internet connection operations may not be possible due to certain restrictions
set by the Internet service provider (ISP) supplying your broadband Internet
connection.
•Any fees charged by an ISP including, without limitation, connection charges are
your responsibility.
•The use of a “Router” may not be allowed or its usage may be limited depending on
the policies and restrictions of your ISP. For details, contact your ISP directly.
•The wireless network operates at 2.4 GHz radio frequencies that are also used by
other household devices such as cordless telephone, Bluetooth devices, microwave
oven, and can be affected by interference from them.
•Turn off all unused network equipment in your local home network. Some devices
may generate network traffic.
•For the purpose of the better transmission, placing the unit from the access point as
close as possible.
•In some instances, placing the access point or wireless router at least 0.45 m above
the floor may improve the reception.
•Move closer to the access point if possible or re-orient the unit so there is nothing
between it and the access point.
•The reception quality over wireless depends on many factors such as type of the
access point, distance between the unit and access point, and the location of the
unit.
•Set your access point or wireless router to Infrastructure mode. Ad-hoc mode is not
supported.

This equipment complies with radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter. This
equipment should be installed and operated with minimum distance 20cm
between the radiator& your body.
Après examen de ce matériel aux conformité ou aux limites d’intensité de
champ RF, les utilisateurs peuvent sur l’exposition aux radiofréquences et la
conformité and compliance d’acquérir les informations correspondantes. La
distance minimale du corps à utiliser le dispositif est de 20cm.
warning：
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
SIMPLIFIED EU DECLARATION OF CONFORMITY
The simplified EU declaration of conformity referred to in Article 10(9) shall
be provided as follows:
Hereby, [Seiko Epson Corporation] declares that the radio equipment type
[DTP9757] is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
http//www.epson.com
The simplified UK declaration of conformity referred to in Regulation 8& 14
shall be provided as follows:
Hereby, [Seiko Epson Corporation] declares that the radio equipment type
[DTP9757] is in compliance with Directive RER 2017 (S.I.2017/1206)..
The full text of the UK declaration of conformity is available at the following
internet address: http//www.epson.com

CE&UKCA Warning：
