Panasonic DMP-MST60 User manual

Operating Instructions
(Detailed Information)
Streaming Player
Model No. DMP-MST60
DMP-MS10
Unless otherwise indicated, illustrations in these operating instructions are of DMP-MST60.
Model number suffix “EB” denotes UK model.
チ
VQT4X77-1
F0213QK1043
EB

- 2 -
Table of contents
Getting started
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Unit and media care . . . . . . . . . . . . . . . . . . . . .3
Control reference guide . . . . . . . . . . . . . . . . . .4
Connections and Settings
Connecting to a TV . . . . . . . . . . . . . . . . . . . . . .7
Connecting to the AC adaptor . . . . . . . . . . . . .7
Connecting to an amplifier/receiver . . . . . . . . .8
Connecting to the network . . . . . . . . . . . . . . . .8
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Playback
HOME menu . . . . . . . . . . . . . . . . . . . . . . . . . .13
Enjoying Network Service. . . . . . . . . . . . . . . .14
Using Miracast™ . . . . . . . . . . . . . . . . . . . . . .15
Home Network feature . . . . . . . . . . . . . . . . . .16
Playing back USB devices . . . . . . . . . . . . . . .18
Operations during playback . . . . . . . . . . . . . .19
Enjoying 3D . . . . . . . . . . . . . . . . . . . . . . . . . .20
“HDMI CEC” . . . . . . . . . . . . . . . . . . . . . . . . . .20
Multi User Mode . . . . . . . . . . . . . . . . . . . . . . .21
Settings
Option menu . . . . . . . . . . . . . . . . . . . . . . . . . .22
Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . .24
Reference
LED indicators . . . . . . . . . . . . . . . . . . . . . . . .28
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Troubleshooting guide . . . . . . . . . . . . . . . . . .29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . .32
≥Firmware updates (>12)

- 3 -
Getting started
Getting started
Accessories
Check the supplied accessories before using this
unit.
≥Product numbers provided in these operating
instructions correct as of January 2013. These
may be subject to change.
1 Remote control
[MST60] (N2QAYB000891)
[MS10] (N2QAYB000886)
2 Batteries for remote control
1 AC adaptor
(VSK0812)
≥For use with this unit only. Do not use it with
other equipment.
≥Do not use any other AC adaptors except
the supplied one.
1 HDMI cable
(K1HY19YY0012)
Unit and media care
∫Clean this unit with a soft, dry
cloth
≥Never use alcohol, paint thinner or benzine to
clean this unit.
≥Before using chemically treated cloth, carefully
read the instructions that came with the cloth.
∫To dispose or transfer this unit
The unit may keep the user settings information in
the unit. If you discard this unit either by disposal
or transfer, then follow the procedure to return all
the settings to the factory presets to delete the
user settings. (>29, “To return all settings to the
factory preset.”)
≥The operation history may be recorded in the
memory of this unit.

- 4 -
Getting started
Control reference guide
[MST60] 1 Turn the unit on and off
2 TV operation buttons
You can operate the Panasonic TV using the
unit’s remote control. Some buttons may not
work depending on the TV.
[ÍTV] : Turn the TV on and off
[AV] : Change input
[ijVOL] : Adjust the volume
3 Enter numbers or characters
4 Cancel
5 Select audio (>19)
6 Basic playback control buttons (>19)
7 Show Top menu (>19)
8 Show Miracast™ screen (>15)
9 Show Option menu (>22)
10 Coloured buttons (red, green, yellow, blue)
Used for various purposes depending on the
display.
11 Transmit the remote control signal
12 Show status messages (>19)
13 Show Setup menu (>24)
14 Show Home Network menu (>16)
15 Show the Home screen of the Network
Service
16 Exit the menu screen
17 Show Netflix screen (>14)
18 Show HOME menu (>13)
19 [3,4,2,1] :
Move the highlight for selection
[OK] : Confirm the selection
20 Return to previous screen
Remote control
1
2
3
6
4
5
7
8
19
10
920
18
16
15
17
14
13
12
11

- 5 -
Getting started
[MS10] 1 Turn the unit on and off
2 TV operation buttons
You can operate the Panasonic TV using the
unit’s remote control. Some buttons may not
work depending on the TV.
[ Í TV] : Turn the TV on and off
[AV] : Change input
[ijVOL] : Adjust the volume
3 Enter numbers
4 Cancel
5 Select audio (>19)
6 Basic playback control buttons (>19)
7 Show Top menu (>19)
8 Show Miracast screen (>15)
9 Show Option menu (>22)
10 Coloured buttons (red, green, yellow, blue)
Used for various purposes depending on the
display.
11 Transmit the remote control signal
12 Show status messages (>19)
13 Show Setup menu (>24)
14 Show Home Network menu (>16)
15 Show the Home screen of the Network
Service
16 Exit the menu screen
17 Show Netflix screen (>14)
18 Show HOME menu (>13)
19 [3,4,2,1] :
Move the highlight for selection
[OK] : Confirm the selection
20 Return to previous screen
リワヱヶヵ
ンユヵヶンワ
ヰヱヵリヰワ
ユヹリヵ
ヵヰヱ
ヮユワヶ
ヴレリヱ ヴレリヱ
リワヵユンワユヵ
ュロワモ
ヴユヵヵリワヨヴ
ヴヵモヵヶヴ
ヱロモヺ
ヱモヶヴユ
ヴヵヰヱ
ヴユモンヤラ ヴユモンヤラ
モヷ
チ
ラ
ヰ
ヮ
ユ
チ
ヤモワヤユロ モヶュリヰ
1
2
3
6
4
5
7
8
19
10
920
18
16
15
17
14
13
12
11
チ
ヮ
リ
ン
モ
ヤ
モ
ヴ
ヵ

- 6 -
Getting started
Front View
Rear View
1 Remote control signal sensor
Distance: Within approx. 7 m
Angle: Approx. 20eup and down, 30eleft and
right
2 POWER LED
Blinks when the power is turned on.
Wait for the LED to turn solid green before
using this unit.
3 INFO LED (>28, “LED indicators”)
Displays the various states of this unit.
4 USB port (>18)
5 DC IN terminal (>7)
6 LAN port (>9)
7 HDMI AV OUT terminal (>7)
8Standby/on switch (Í/I)(>10)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
still consumes a small amount of power.
The Unit
POWER INFO
4
1
23
MST60
MS10
567 8
5678

- 7 -
Connections and Settings
Connections a nd Settings
Connecting to a TV
≥Before making any connections, we
recommend that you temporarily disconnect all
the units from AC power.
≥Use the High Speed HDMI cables.
Non-HDMI-compliant cables cannot be utilized.
The HDMI-compliant cable is supplied with this
unit.
It is recommended that you use Panasonic’s
HDMI cable. When outputting 1080p signal,
please use HDMI cables 5.0 meters or less.
AHDMI cable (supplied)
Connecting to the AC
adaptor
Connect the AC adaptor after making all other
connections.
AAC adaptor (supplied)
BTo a household mains socket
≥This unit consumes a small amount of AC
power (>32) even when turned off. For the
purpose of power conservation, the unit can be
disconnected if you will not be using it for
extended period of time.
HDMI IN




- 8 -
Connections and Settings
Connecting to an
amplifier/receiver
AHDMI cable (supplied)
BAmplifier/receiver
CHDMI cable
≥Set “Digital Audio Output” (>25).
≥When using the TV or amplifier/receiver that
does not have the indication of “(ARC)”
(non-ARC-compatible) on the HDMI terminal,
the amplifier/receiver and TV must also be
connected using an optical digital cable in order
to enjoy the TV’s sound through the amplifier/
receiver.
≥[MST60] When connecting to a non-3D
compatible amplifier/receiver, connect this unit
to a TV, then connect the TV and the amplifier/
receiver.
Connecting to the
network
The following services can be used when this unit
is connected to broadband.
≥Firmware can be updated (>12)
≥You can enjoy Network Service (>14)
≥You can access other devices (Home Network)
(>16)
≥This unit supports Wi-Fi Direct™ and can make
a wireless connection to wireless devices
without router. You can use this function when
enjoying Home Network feature, etc. Internet
access is not available while connected via
Wi-Fi Direct™. (>16, 25)
For details about connection method, refer to the
instructions supplied with the connected
equipment.
HDMI IN
(ARC)
HDMI OUT
(ARC)
HDMI IN




- 9 -
Connections and Settings
This unit has built-in Wi-Fi®and can be connected
to a wireless router.
AWireless router, etc.
BInternet
≥For up-to-date compatibility information on your
wireless router, refer to
http://panasonic.jp/support/global/cs/
(This site is in English only.)
≥The unit is not compatible with public wireless
LAN services (Hotspot etc.) provided in airports,
stations, cafes, etc.
≥See “Operating Instructions (Essential
Information)” for the precautions for wireless
LAN connection.
ALAN Cable
BBroadband router, etc.
CInternet
≥Inserting any cable other than a LAN cable in
the LAN port can damage the unit.
Wireless LAN connection


LAN cable connection




- 10 -
Connections and Settings
Settings
After connecting your new unit for the first time
and pressing [Í], the basic settings screen will
appear.
Preparation
Turn on the TV and select the appropriate
video input.
1Press [Í].
Setup screen appears.
2Follow the on-screen instructions to
continue with the settings.

≥You can perform this setup anytime by selecting “Easy
Settings” in the Setup menu. (>27)
After completing “Easy Settings”, you can perform
“Easy Network Setting”.
Select “Wired” or “Wireless” and press [OK].
∫“Wired” connection
Follow the on-screen instructions to establish
your connection settings.
∫“Wireless” connection
Before beginning wireless connection setup
≥Obtain your network name (SSID*1).
≥If your wireless connection is encrypted,
please be sure that you know your
encryption key.
Select “Search for wireless network” or “WPS
(PUSH button)” and press [OK], then follow
the on-screen instructions to continue with
the settings.
Easy Settings
Easy Network Setting
Easy Network Setting
Wired
Wireless
Select a connection mode.
OK
RETURN
Wireless Settings
Select a connection method to wireless access point.
Please refer to the operating instructions of your wireless
access point about connection methods.
Search for wireless network
WPS (PUSH button)
