1
Welcome!
Your EPSON Stylus®Photo printer delivers state-of-the-art print quality for both
professional and home office users. With resolutions up to 2880 × 720 dpi, it’s the
ideal output device for everything from exhibition prints to family photos. You can
print edge-to-edge, borderless prints on a variety of roll paper sizes, or on single sheets
of special EPSON®photo papers available in popular print sizes.
PRINT Image Matching and Exif Print
Your EPSON Stylus 1280 printer supports both digital image formats to give you the
best photo prints possible.
■PRINT Image Matching™(both P.I.M. and P.I.M. II)
■Exif Print
About PRINT Image Matching
EPSON’s revolutionary PRINT Image Matching (P.I.M.) technology lets your digital
camera and printer work together automatically to produce the best prints possible.
Digital camera manufacturers that support PRINT Image Matching include EPSON,
Casio,
®JVC, ®Konica, ®Kyocera, ®Minolta, ®Nikon, ®Olympus, ®Panasonic, ®Pentax, ®
Ricoh,
®Sanyo, ®and Toshiba. ®Go to www.printimagematching.com to see if your
camera supports PRINT Image Matching.
Even if your camera doesn’t include PRINT Image Matching technology, your
EPSON Stylus Photo 1280 still gives great photo printing results. You just won’t have
the automatic adjustments that P.I.M. provides.

2
With PRINT Image Matching, the digital camera manufacturer can set specific
printing options for each camera model. These options include:
■Contrast, sharpness, and brightness
■Gamma level, color space, and color saturation
■Shadow point, highlight point, and color balance
The camera saves this information in each image file. Your printer—along with
EPSON Software™Film Factory™and P.I.M. II Plug-in for Adobe®Photoshop®—
uses the information to ensure the most accurate image reproduction.
About Exif Print
The Exif (Exchangeable Image File) Print format includes information about your
digital camera settings in JPEG files so your printer and application can use the data
to create accurate print settings. Most digital cameras store Exif Print information
such as shutter speed, metering, flash, exposure settings, resolution, and lens use in the
JPEG image file. Your printer—along with EPSON Software Film Factory and the
P.I.M. II Plug-in for Adobe Photoshop—uses the information to ensure the most
accurate image reproduction.
About Your Software
The printer software CD-ROM that came with your printer includes all the software
you need for printing. (You must have a CD-ROM or DVD drive installed on your
computer.)
■Your printer driver runs your printer and lets you control how your documents
look. You can’t use your printer without it.
Note: It’s a good idea to check EPSON’s support web site periodically for
possible updates to your printer driver. Visit http://support.epson.com and check
the section for your product to see if there is a new driver available, free of
charge, for downloading to your computer. Download instructions are posted for
your convenience.

3
■Your bonus photo software includes these applications:
EPSON Software Film Factory
Photo management software that lets you organize, beautify, and
print your photos in a flash. Supports PRINT Image Matching
(both P.I.M. and P.I.M. II) and Exif Print.
Adobe Photoshop Elements (Windows®XP, 98, Me, 2000,
and NT 4.0, and Macintosh®OS 8.6 or later)
Offers unique features designed specifically for amateur
photographers, hobbyists, and business users who want an
easy-to-use yet powerful digital imaging solution.
Adobe Photoshop LE (Windows 95 and Macintosh OS 8.5x)
Your gateway to the Photoshop experience, Adobe Photoshop
Limited Edition provides a basic set of the image-editing tools
preferred by graphic design professionals.
P.I.M. II Plug-in for Adobe Photoshop (Windows®XP, 98,
Me, 2000, and NT 4.0, and Macintosh®OS 8.6 or later)
Lets you retain PRINT Image Matching and Exif Print image
quality when you import JPEG or TIFF files from your P.I.M.,
P.I.M. II, or Exif Print-enabled digital camera. (Works with
Photoshop 6.0 and 7.0, and Photoshop Elements 1.0 and 2.0.)
Monaco Systems™MonacoEZcolor™software offer (Windows
XP, 98, Me, and 2000, and Macintosh OS 8.6 or later)
Lets you build ICC device profiles for accurate color between
scanned, displayed, and printed images. Your printer CD-ROM
contains a demo version of the software.
EPSON PhotoCenter is EPSON’s free photo-sharing web site
where you can store, organize, and share your photos; print
high-resolution photos straight from the web; and order prints
and custom photo gifts. Your printer software installer lets you
add a link to the EPSON PhotoCenter on your desktop.

4
About Your Documentation
To set up your printer and install its software, see the Start Here sheet. This book
contains system requirements, important safety information, and instructions on:
■Viewing your on-screen Reference Guide
■Printing with Windows or on a Macintosh
■Maintaining the printer
■Solving basic problems
Warnings, Cautions, Notes, and Tips
Please follow these guidelines:
Warning: Warnings must be followed carefully to avoid bodily injury.
Caution: Cautions must be observed to avoid damage to your equipment.
Note: Notes contain important information about your printer.
Tip: Tips contain additional hints for better printing.
Viewing Your On-Screen Reference Guide
Your printer software CD-ROM includes an on-screen Reference Guide for your
printer. The manual is in HTML format, so you need a browser—such as Microsoft®
Internet Explorer 3.0 or later or Netscape Navigator™3.0 or later—to view it. If you
are using a different browser, the pages may not display correctly. (A browser is not
included on the printer software CD-ROM.)
Follow these steps to copy the Reference Guide to your computer:
1. Insert your printer software CD-ROM.

5
2. Windows: (If you’re using Windows XP, first click Start.) Double-click My
Computer, double-click your CD-ROM or DVD drive icon, then
double-click the EPSON icon.
Macintosh: Double-click the EPSON icon in your CD-ROM window. (You
may have to double-click the EPSON icon on your desktop first.)
3. On the Install Menu, click Install Reference Guide.
A shortcut icon for your guide appears on your desktop. To view the guide, just
double-click the icon.
When you first open the Reference Guide, you see this screen:
Click here to
expand the
table of
contents

6
Click a topic on the left to expand the table of contents. After expanding the table of
contents, you can click on the topic you want to view.
If there’s a right arrow , click it to view subtopics, then click on a topic to go to it.
Click the down arrow to close a subtopic list.
Note: If you see an icon for a graphic when viewing your Reference Guide in
Netscape Navigator, click the Reload button to load the graphic.
Closed list,
click to
expand
Click to go
to topic

7
Loading Paper
This chapter explains how to load plain paper and envelopes. It also describes how to
load, remove, and store roll paper, and what to do if your roll paper jams or feeds
incorrectly. For instructions on loading special media, see your on-screen Reference
Guide.
Follow the instructions in these sections:
■“Loading Sheets” below
■“Loading Envelopes” on page 8
■“Loading Roll Paper” on page 10
Loading Sheets
Make sure your printer and computer are turned on.
1. Place your paper against the right edge of the sheet feeder and slide the left edge
guide against the paper. (Don’t push the paper down into the feeder.)
2. Pull out the output tray extensions.
Slide the left edge guide against the paperDon’t load paper above
this arrow
Pull out the output tray
extensions

8
Follow these guidelines when loading paper:
■Load the printable side face up. It’s usually whiter or brighter than the other side.
■Always load the short edge first, even when printing in landscape mode.
■Load letterhead or preprinted paper top edge first.
■Load up to 20 sheets of EPSON Photo Paper, Glossy Photo Paper, or Matte
Paper Heavyweight.
■Load EPSON Premium Glossy, Semigloss, and Luster Photo Paper one sheet
at a time.
■Don’t load paper above the arrow on the left edge guide.
Loading Envelopes
You can load up to 10 envelopes at a time, flap edge first and printable side up.
Tip: For best results, press each envelope flat before loading it, or load one
envelope at a time.
1. Place the envelopes against the right edge of the sheet feeder and slide the left edge
guide against them.
Load with the
printable side
up and the
flap side down

9
2. Set your printer’s thickness lever to the +position. (Remember to move the
thickness lever back to the 0position when you’re done printing envelopes.)
3. Select Plain paper as the Media Type setting and choose the correct envelope size
as the Paper Size setting. See page 16 (Windows), page 22 (Macintosh OS X), or
page 19 (Macintosh OS 8.5.1 to 9.x) for more information.

10
Loading Roll Paper
This procedure illustrates how to load 4-inch wide roll paper, but you can follow the
same steps to load wider roll paper. Before you begin, turn on your computer and
printer.
1. Remove the paper support and lower the output tray. Then insert the paper
support adapter into the positioning slots on the back of the printer, as shown.
(The down arrows on the adapter should be positioned above the slots.)
2. Set the roll paper onto the roll paper holders. Avoid touching the printable side of
the roll paper as much as possible.

11
3. Before loading the paper, make sure
the edge is cut cleanly—at a 90
degree angle in each corner—to
ensure proper loading. If necessary,
trim the edge using a straight-edge
tool or triangle.
Note: Make sure that the end of the roll paper is cut perpendicular to the edges. A
diagonal cut may cause paper feeding problems.
4. If necessary, uncurl the paper. Locate the uncurling sheet that came inside the
printer box. Insert the paper inside the uncurling sheet and roll it in the direction
opposite to the paper’s curl. (This step is especially important with roll paper that
is wider than 4 inches.)

12
5. Insert the tabs on the roll paper holders into the slots on the paper support
adapter. As you face the front of the printer, insert the tab on the right roll paper
holder into the slot at the right end of the adapter, and the tab on the left roll
paper holder into the appropriate slot to the left.
Note: It’s important to insert the tab on the right roll paper holder into the slot at
the right end of the adapter. Otherwise your roll paper won’t load correctly, and
you may see an error.
6. Feed the end of the paper into the printer as far as it will go, then slide the left
edge guide against the paper.
7. Gently rotate the roll backward to remove any slack from the paper.
8. Make sure the output tray is open but the extensions are closed, and leave ample
room at the front of the printer for your paper to eject smoothly.
Slot at right end
of the adapter

13
9. Gently hold the paper in place as you press and release the z roll paper button to
feed the paper into the printer.
Note: Don’t force the paper to feed into the printer. Allow the paper to move
automatically.
Make sure to press the zroll paper button when you feed roll paper. Pressing the b
maintenance button by mistake may cause paper feeding problems.
If the Roll Paper Jams or Feeds Incorrectly
If the paper feeds incorrectly, do the following:
1. Press the z roll paper button for three seconds to rewind the paper. (You may
have to do this more than once to rewind the paper completely.)
If the paper is jammed and won’t rewind, turn the printer off. Then cut the roll at
a point a few inches away from where it exits the printer. Make your cut as
straight as possible to avoid further feeding problems. Gently pull the roll
backward to rewind it, and then turn the printer on again.
2. After you rewind the paper, the b maintenance light comes on. Press the
bmaintenance button to turn the light off.
3. Reload the paper, making sure the end is straight and not damaged. If necessary,
trim the end again before reloading.

14
Removing and Storing Roll Paper
When you finish a print job on roll paper, you can position the paper for another
print job or remove it from the printer. Follow these steps:
1. Press the z roll paper button. The printer
prints a small line on the roll paper to show you
where to cut it and feeds the paper forward.
2. If you want to continue printing on roll paper,
press the z roll paper button again; the paper
feeds back into the printer. Then send the next
print job; the paper will move into the correct
loading position before printing.
If you’re finished printing on roll paper, follow
the rest of the steps to remove it.
3. Cut the roll paper on the side of the line facing away from the printer. Make your
cut as straight as possible to avoid feeding problems.
Note: Don’t pull on the paper as you cut it; you may damage your printout.
It’s a good idea to use a ruler or straight edge to make sure the end of the roll
paper is cut at right angles. A diagonal cut may cause paper feeding problems.
4. Hold down the z roll paper button for about three seconds. The roll paper feeds
backward, so you can remove it from the sheet feeder. (You may need to repeat
this step to back it all the way out.)
5. Remove the roll paper from the holder and return the unused roll to its original
package.
Store your printout in a resealable plastic bag. Keep both printed and unused roll
paper away from high temperatures and humidity and out of direct sunlight.
Note: After you rewind the roll paper, the bmaintenance light remains on. You
must press the bmaintenance button to turn the light off before you can resume
printing.
Roll paper button
