Epson FX-870 User manual

User’s Guide Update
Please update your User’s Guide with the following information.
These page-length settings have been added to your printer:
5.5, 7, 17, 14, 8, 6, 4, 3.5, and 3 inches.
See “Default-Setting Mode” in Chapter 3 for the groups of
available printer features. The page length feature has been
deleted from Group 1 and now appears in a new group
(Group 1 Extension). See the following table for a complete
list of Group 1 Extension settings.
Group 1 Extension Settings
Page length
11, 12, 8.5, 70/6(A4), 5.5, 7, 17, 14, 8, 6, 4,
3.5, and 3 inches
Changing Group 1 Extension default settings
1. Make sure the printer is turned off.
2. To enter the Group 1 Extension default-setting mode, turn
on the printer while you hold down the FONT and
PAPER FEED buttons. The printer beeps once.
3. Load single-sheet or continuous paper. The printer then
automatically loads the paper and prints a quick
reference.
Copyright © 1995 by Seiko Epson Corporation.
4004313
CO1 -00

Group
Feature
Page
length
Exter
FONT
light
OFF
ON
4. Press the FONT button to select the page length. The FONT,
CONDENSED, and READY lights turn on, off, or blink to
show your selection.
For example, if you select 8 inches, the FONT light is on and
the CONDENSED and READY lights are off.
5. After you have made your selection, exit the Group 1
Extension default-setting mode by turning off the printer.
Note:
If you want to check the new default settings, enter the
default-setting mode again and print the quick reference. After
that, turn off the printer to exit the default-setting mode.
