Epson 1735W - PowerLite WXGA LCD Projector User manual

• Lightweight and travel friendly—weighsunder4.0lb
• Ultra bright—3000lumenscolorand3000lumenswhitelightoutput
• Brilliant widescreen performance—nativeWXGA(1280x800)resolution(16:10)
• Rich, vibrant color—3-chipopticalengine
• Reliable performance —3LCDtechnology
• Plug 'n Play—USBconnectionprojectsvideoandplaysaudiofromaPC
• Easy wireless setup with USB connection key—justplugthekeyintothePCandthenproject
• Added flexibility—WindowsVista®NetworkProjectorcompatible
• Impressive presentations, without a computer—convenientUSBmemorydeviceconnectivity
PowerLite®
1735W
MultimediaProjector
The ultimate choice in wireless, widescreen ultraportable projectors.

SPECIFICATIONS
Projection System
Epson3LCD,3-chipopticalengine
Projection Method
Front/rear/ceilingmode
Driving Method
EpsonPoly-siliconTFTActiveMatrix
Pixel Number
1,024,000dotsx3(1280x800)LCDs
White Light Output**
3000lumens(ISO21118Standard)
Color Light Output**
3000lumens
Aspect Ratio
16:10(supports4:3and16:9)
Native Resolution
1280x800(WXGA)
Resize
640x480(VGA),800x600(SVGA),
1024x768(XGA),1280x1024(SXGA),
1400x1050(SXGA+),1440x900(WXGA+),
1680x1050(WSXGA+),1600x1200(UXGA)
Lamp Type
E-TORL™170WUHE
Lamp Life*
Upto4000hours(LowLightOutputMode)
Upto3000hours(HighLightOutputMode)
Throw Ratio Range
0.98–  1.20
Size (projected distance)
30"–300"(2.1’–27.1’)
Keystone Correction Automatic
Automatic:Vertical:± 30degrees
Manual:Vertical:±30degrees
Contrast Ratio
Upto2000:1
Color Reproduction
16.77millioncolors
Plug 'n Play
ProjectorisMaccompatibleviaDVItoVGA
adapter(notincluded)
PROJECTION LENS
Type
Manualfocus/(optical)zoom
F-number
1.58–1.68
Focal Length
16.1–19.3mm
Zoom Ratio
Opticalzoom1.0–1.2
OTHER
Display Performance
NTSC:560line
PAL:560line
(dependsonobservationofthe
multi-burstpattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/SECAMSDTV/HDTV
Interfaces
Computer/componentvideo:
MiniD-subHD15pinx1
S-video:MiniDINx1
Compositevideo:RCAx1
Audioin:Ministereox1inoroutuser
selectable
Variableaudioout:Ministereox1inorout
userselectable
USBconnector:TypeBx1(USBdisplay
withaudioandmouse/keyboardcontrol)
TypeAx1(forUSBmemorydevice)
WirelessLANmodule:802.11a/b/g
Audio Output
1Wmonospeaker
Audio Signal
500mVrms/47Kohm
Operating Temperature
41˚to95˚F(5˚to35˚C)
Power Supply Voltage
100–240V±10%,50/60HzAC
Power Consumption
Networkon:243W,9Wstandby
Networkoff:4Wstandby
Fan Noise
HighLightOutputMode:39dB 
LowLightOutputMode:30dB
Security
Kensington-stylelockprovision
DIMENSIONS (W x D x H)
Includingfeet:11.2"x7.9"x2.8"
Excludingfeet:11.2"x7.9"x2.6"
Weight:3.96lb/1.8kg
REMOTE CONTROL
Features
Power,sourcesearchselection,computer,
S-video,video,EasyMP,A/Vmute,freeze,
userID,auto,aspect,colormode,num,page
upanddown,E-zoom,volume,help,menu,
enter,escandpointerfunctions
Operating Angle
Right/left:
Front:±60degrees
Rear:±30degrees
Upper/lower:
Front:-30to+45degrees
Rear:±30degrees
Operating Distance
19.7ft(6m)
SUPPORT — THE EPSON CONNECTIONSM
Pre-salessupport
U.S.andCanada 800-463-7766
Internetwebsite www.epson.com
Service Programs
Two-yearlimitedwarranty,EpsonRoad
Serviceprogram,EpsonPrivateLine®
dedicatedtoll-freesupport(U.S.and
Canadaonly)and90-daylampwarranty
Contents
WirelessLANmodule,QuickWireless
ConnectionUSBkey,powercable,computer
cable(VGA),audioadapter,projectorremote
controlwithbatteries,USBcable,softcarrying
case,usermanualCD,EasyMPsoftwareCD,
QuickSetupSheet,PrivateLinesupportcard,
registrationcard,passwordprotectionsticker
andsecurityscrew
ACCESSORY PART NUMBERS
Distributionamplier ELPDA01
Imagepresentationcamera (ELPDC05)
 V12H162020
ReplacementQuickWirelessConnection
USBkey V12H005M04
WiredLANmodule V12H005M0B
ReplacementwirelessLAN  
module V12H306P11
ComponenttoVGAvideocable ELPKC19
S-videocable ELPSV01
SwissGear®backpack ELPKS63
Wheeledsoftcase ELPKS62
Softshouldercasefor ELPKS61
projectorandlaptop
Moldedhardshellcase ELPKS58
50"portablescreen ELPSC06
60"portablepop-upscreen ELPSC07
80"portablepop-upscreen ELPSC08
Duet™screen ELPSC80
EpsonDC-10sdocumentcamera ELPDC10S
Kensingtonsecuritylock ELPSL01
Universalceilingmount ELPMBPJF
 
Epson America, Inc.
3840KilroyAirportWay,LongBeach,CA90806
Specicationsandtermsaresubjecttochangewithoutnotice.Epsonisaregisteredtrademark,EpsonExceedYourVisionisaregisteredlogomarkandE-TORLisatrademarkofSeikoEpsonCorporation.PowerLiteis
aregisteredtrademark,DuetandPlug‘nProjectaretrademarksandEpsonConnectionandPrivateLineareservicemarksofEpsonAmerica,Inc.Allotherproductandbrandnamesaretrademarksand/orregistered
trademarksoftheirrespectivecompanies.Epsondisclaimsanyandallrightsinthesemarks.Copyright2008EpsonAmerica,Inc.CPD-259237/08PDF
Epson Canada, Ltd.
3771VictoriaParkAvenue,Toronto,OntarioM1W3Z5
ORDERING INFORMATION
Product Name Product Code UPC
PowerLite1735W V11H270020  010343869554
ReplacementLamp V13H010L48  010343869561
ReplacementAirFilter V13H134A19  010343869578
PowerLite 1735W
MultimediaProjector
PACKAGING SPECIFICATIONS
PowerLite 1735W
Dimensions19.4"x14.2"x7.6"(WxDxH)
Weight10.56lb
Replacement Lamp
Dimensions 5.1"x5.5"x5.6"(WxDxH)
Weight0.24lb
MasterCarton
Dimensions11.5"x26.0"x6.8"(WxDxH)
Weight3.96lb
UnitsPerMasterCarton10
Replacement Air Filter
Dimensions 3.5"x4.8"x1.9"(WxDxH)
Weight0.08lb
MasterCarton
Dimensions 7.3"x10.1"x5.7"(WxDxH)
Weight1.3lb
UnitsPerMasterCarton10
S-video Computer/Component Video
Audio
Composite Video
USB Type B
Power
BACK PANEL
USB Type A
* Lampliferesultswillvarydependinguponmodeselected,environmentalconditionsandusage.Lampbrightnessdecreasesovertime.
** Lightoutputvariesdependinguponcolorandbrightnessmodesselected.
Lamp Cover
Speaker
Kensington®Lock Port
