Epson 5000XB - PowerLite SVGA LCD Projector User manual

EPSON PowerLite 5000XB Multimedia Projector
1/2/98 PowerLite 5000XB Multimedia Projector - 1
Projector Specifications
General
Type of display Poly-silicon liquid crystal panel,
Thin FilmTransistor (TFT)
Brightness 750 ANSI lumens
Contrast ratio 300:1
Size of liquid
crystal panels 1.32 inches (33.6 mm)
Resolution 800 (horizontal) ×600 (vertical) pixels
Image size 23 to 300 inches (0.6 to 7 meters)
Color
reproduction 24 bit; 16.7 million colors
Projection
distance 3.28 to 32.8 feet (1 to 10 meters)
Projection lens Focus and manual zoom controls
Projection
method Front, rear, and upside-down projection
Tilt angle Adjustable (0° to 15°)
Remote control
range 33 feet (10 meters)
Internal speaker
system 2 ×2 W 3D stereo
Optical aspect
ratio 4 ×3 (horizontal ×vertical)
Zoom ratio 1:1.3
Video interface
standards NTSC, PAL, SECAM
Projector lamp
Type Ultra High Efficiency (UHE)
Power 150 W
Part number ELPLP04
Mechanical
Height 6.3 inches (159 mm)
Width 9.7 inches (245 mm)
Depth 15.0 inches (380 mm) with lens
Weight 14.5 lb (6.5 kg)
Electrical
Voltage 100 to 120 VAC and 200 to 240 VAC
Rated frequency 50/60 Hz
Power supply 100 to 120 VAC, 2.7 A, 50/60 Hz
200 to 240 VAC, 1.6 A, 50/60 Hz
Power
consumption 240 W (operating)
28 W (standby)
Environmental
Temperature Operation: 41 to 104° F (5 to 40° C),
non-condensing
Storage: 14 to 140° F (–10 to 60° C),
non-condensing
Humidity Operation: 20 to 80% RH,
non-condensing
Storage: 10 to 90% RH,
non-condensing
focus ring
zoom ring
foot release
lever
foot
remote control
receiver
control panel operat
i
ona
l
status
indicators
remote contro
l
receiver

EPSON PowerLite 5000XB Multimedia Projector
2 - PowerLite 5000XB Multimedia Projector 1/2/98
Supported monitor resolutions
The projector displays images at a resolution of 800 ×600
pixels. To display a higher resolution image, the projector
compresses it to 800 ×600. The following table lists the
display formats supported by the projector:
Note: The frequencies of some computers may not allow the image
to be displayed correctly.
Note: This projector is compatible with DDC-capable graphic
sub-systems and boards only.
*The projector uses a patent-pending technology to resize the
image to 800 ×600.
Supported sync rates
Horizontal sync 15 to 60 KHz
Vertical sync 56 to 85 Hz
Supported sync types
Separate Sync, Composite Sync, Sync-on-Green
Projector Placement Guidelines
The distance between the projector and the screen determines
the actual image size. Use the general guidelines in the table
below to determine the proper distance.
Projector Status Indicators
The power and lamp indicators at the top of the projector let
you know the projector’s operating status, as described below.
Note: If you press the Power button to turn the projector back on
while the power indicator is flashing orange, there may be a delay
before the projected image appears.
Computer type Formats Resolutions
IBM PC and
IBM PC compatible
VGA, VESA, EGA
CGA
640 ×480
640 ×200
640 ×400
800 ×600
1024 ×768*
Apple Macintosh Standard 8- and
24-bit color monitor
640 ×480
832 ×624
1024 ×768*
NEC PC 640 ×480
800 ×600
Horizontal distance from the projector screen
Image size
(diagonal) Minimum Maximum
300 inches 393.7inches (10 m)
200 inches 263.8 inches (6.7 m) 342.5 inches (8.7 m)
100 inches 129.9 inches (3.3 m) 169.3 inches (4.3 m)
80 inches 106.3 inches (2.7 m) 137.8 inches (3.5 m)
60 inches 78.7 inches (2 m) 102.4 inches (2.6 m)
40 inches 51.2 inches (1.3 m) 66.9 inches (1.7 m)
30 inches 39.4 inches (1 m) 51.2 inches (1.3 m)
23 inches 39.4 inches (1 m)
Status indicator Function
Power indicator
Steady orange: Sleep mode. (The projector is plugged in,
but not projecting.)
Steady green: Power and lamp are on.
Flashing orange: The projector is hot.
Steady red The projector is too hot and has turned off.
Flashing red Internal projector problem.
Projection lamp indicator
Steady green Projection lamp is on.
Flashing green The projector is warming up.
Orange and red
flashing alternately
Projection lamp needs replacing.
Flashing orange Projector lamp is cooling down.
Steady red Projector lamp has burned out. Replace it
to project images.
Flashing red Problem with projection lamp or lamp
power supply.

EPSON PowerLite 5000XB Multimedia Projector
Monitorand ComputerIn 1/2
Connector Pin Assignments
TheMonitor and Computer In 1/2 connectorsare female
videoRGB,15-pin micro-D-style connectors. The pin
assignments are:
Information Reference List
Engineering ChangeNotices
None.
Technical Information Bulletins
None.
Product Support Bulletins
None.
RelatedDocumentation
Input pin
Monitorconnector
signals
ComputerIn 1/2
connectorsignals
1Red out / red video Red video
2Green out/ green video Green video
3Blue out / blue video Blue video
4Reserved Monitor (IDbit 2)
5GNDGND
6GNDRed video GND
7GNDGreen video GND
8GNDBlue video GND
9Reserved +5 V
10 GNDSynchronous GND
11 Reserved Monitor (IDbit 0)
12ReservedSDA
13 Horizontal sync Horizontal sync
14 Vertical sync Vertical sync
15 Vertical sync SCL
CPD5869 EPSON PowerLite7000XB/5000XB
Multimedia Projector User’sGuide
CPD5870 EPSON PowerLite7000XB/5000XB
Easy Setup
SM-ELP5100 EPSON PowerLite5000XB Multimedia
Projector ServiceManual
PL-ELP5100 EPSON PowerLite5000XB Multimedia
Projector PartsPriceList
