Epson 822p/83c User manual

PowerLite®822p/83c
Multimedia Projector
User’sGuide

2
Important Safety Information
WARNING: Never look into the projector lens when the lamp is turned on; the bright light can damage your eyes.
Never let children look into the lens when it is on. Never open any cover on the projector, except the lamp and
filter covers. Dangerous electrical voltages inside the projector can severely injure you. Except as specifically
explained in this User’s Guide, do not attempt to service this product yourself. Refer all servicing to qualified service
personnel.
WARNING: The projector and its accessories come packaged in plastic bags. Keep plastic bags away from small
children to avoid any risk of suffocation.
Caution: When you replace the lamp, never touch the new lamp with your bare hands; the invisible residue left by
the oil on your hands may shorten the lamp life. Use a cloth or glove to handle the new lamp.
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Seiko Epson Corporation. The information contained herein is designed only for use with
this Epson product. Epson is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of
this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to
strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original Epson Products or Epson Approved Products by
Seiko Epson Corporation.
Trademarks
Epson and Instant Off are registered trademarks, and Epson Exceed Your Vision and Duet are trademarks of Seiko
Epson Corporation.
PowerLite and PrivateLine are registered trademarks; SizeWise is a trademark; and Epson Store and Extra Care are
service marks of Epson America, Inc.
Pixelworks, DNX, and the DNX logo are trademarks of Pixelworks, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. Epson disclaims any and all rights in those marks.
The contents of this manual are subject to change without notice.
© 2007 Epson America, Inc. 9/07

3
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Getting the Most from Your Projector . . . . . . . . . . . . . . . . . 8
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . 9
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . 9
Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 10
Unpacking the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Projector Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Additional Components . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Optional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1Setting Up the Projector . . . . . . . . . . . . . . . . . . . . 15
Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Other Installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting to a Computer. . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting with the VGA Cable . . . . . . . . . . . . . . . . . 18
Connecting with a VGA-5BNC Cable. . . . . . . . . . . . . 20
Connecting an External Monitor . . . . . . . . . . . . . . . . . 21
Playing Sound Through the Projector . . . . . . . . . . . . . 22
Connecting External Speakers . . . . . . . . . . . . . . . . . . . 23
Connecting to Video Sources . . . . . . . . . . . . . . . . . . . . . . . 24
Connecting a Composite Video Source . . . . . . . . . . . . 25
Connecting an S-Video Source . . . . . . . . . . . . . . . . . . 26
Connecting an RGB Video Source. . . . . . . . . . . . . . . . 27
Connecting a Component Video Source . . . . . . . . . . . 28
Playing Sound Through the Projector . . . . . . . . . . . . . 29

4
2Projecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Turning On Your Equipment . . . . . . . . . . . . . . . . . . . . . . . 34
Turning On the Projector . . . . . . . . . . . . . . . . . . . . . . . 34
Selecting the Image Source. . . . . . . . . . . . . . . . . . . . . . . 36
What To Do If You See a Blank Screen . . . . . . . . . . . . . 36
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Focusing and Zooming Your Image. . . . . . . . . . . . . . . . 38
Adjusting the Height of Your Image . . . . . . . . . . . . . . . 39
Adjusting the Image Shape. . . . . . . . . . . . . . . . . . . . . . . 40
Adjusting the Brightness . . . . . . . . . . . . . . . . . . . . . . . . 40
Correcting Computer Images. . . . . . . . . . . . . . . . . . . . . 41
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Shutting Down the Projector . . . . . . . . . . . . . . . . . . . . . . . . 42
3Using the Remote Control . . . . . . . . . . . . . . . . . . . 43
Controlling the Picture and Sound. . . . . . . . . . . . . . . . . . . . 44
Switching Between Picture Sources . . . . . . . . . . . . . . . . 44
Adjusting the Color Mode . . . . . . . . . . . . . . . . . . . . . . . 45
Turning Off the Picture and Sound. . . . . . . . . . . . . . . . 46
Stopping Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Zooming Your Image. . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Changing the Image’s Aspect Ratio . . . . . . . . . . . . . . . . 47
Replacing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4Fine-tuning the Projector. . . . . . . . . . . . . . . . . . . . 49
Using the Projector’s Menu System . . . . . . . . . . . . . . . . . . . 50
Changing Menu Settings . . . . . . . . . . . . . . . . . . . . . . . . 51
Adjusting Colors and Clarity . . . . . . . . . . . . . . . . . . . . . . . . 52
Adjusting the Input Signal . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Customizing Projector Features . . . . . . . . . . . . . . . . . . . . . . 56
Selecting Projector Setup Options . . . . . . . . . . . . . . . . . . . . 58
Selecting Network Settings. . . . . . . . . . . . . . . . . . . . . . . . . . 60
Viewing Lamp Usage and Other Information. . . . . . . . . . . . 60

5
Using the Projector’s Security Features. . . . . . . . . . . . . . . . . 62
Creating Your Own Screen Logo. . . . . . . . . . . . . . . . . . 63
Setting a Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Turning On the Password and User’s Logo . . . . . . . . . . 65
Starting the Projector with a Password. . . . . . . . . . . . . . 66
Disabling the Projector’s Buttons . . . . . . . . . . . . . . . . . 67
Installing Security Locks . . . . . . . . . . . . . . . . . . . . . . . . 67
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . . . . 68
5Maintenance and Transportation . . . . . . . . . . 69
Cleaning the Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Cleaning the Projector Case . . . . . . . . . . . . . . . . . . . . . . . . . 70
Cleaning and Replacing the Air Filter . . . . . . . . . . . . . . . . . 70
Replacing the Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Resetting the Lamp Timer . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Transporting the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . 76
6Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Using On-Screen Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
What To Do When the Lights Flash . . . . . . . . . . . . . . . . . . 78
Solving Problems with the Image or Sound . . . . . . . . . . . . . 80
Solving Password Problems . . . . . . . . . . . . . . . . . . . . . . . . . 85
Solving Problems with the Remote Control . . . . . . . . . . . . . 86
Solving Network Problems. . . . . . . . . . . . . . . . . . . . . . . . . . 87
Where To Get Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Speak to a Support Representative. . . . . . . . . . . . . . . . . 88
7Monitoring the Projector Over a Network. . 89
Installing the Network Software. . . . . . . . . . . . . . . . . . . . . . 90
Windows System Requirements . . . . . . . . . . . . . . . . . . 90
Installing the Software on a Windows System . . . . . . . . 90
Connecting to the Network . . . . . . . . . . . . . . . . . . . . . . . . . 91
Selecting Network Settings. . . . . . . . . . . . . . . . . . . . . . . . . . 92
Using Projector E-mail Alerts . . . . . . . . . . . . . . . . . . . . 93

6
Using EMP Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Opening and Closing EMP Monitor . . . . . . . . . . . . . . . 94
Registering a Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Monitoring Your Projector . . . . . . . . . . . . . . . . . . . . . . 95
Using E-mail Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Using a Browser to Monitor the Projector . . . . . . . . . . . . . . 99
ATechnical Specifications . . . . . . . . . . . . . . . . . . . . 101
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Projection Lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Safety and Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Compatible Video Formats . . . . . . . . . . . . . . . . . . . . . . . . 104
Compatible Computer Display Formats. . . . . . . . . . . . . . . 105
BNotices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . 109
FCC Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . 111
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

7
-
Welcome
The PowerLite®822p/83c is a portable projector that weighs less
than 7 pounds. The projector offers 2600 ANSI lumens (822p) or
2200 ANSI lumens (83c) of brightness. From classrooms to
boardrooms, your full-color presentations and videos will be bright
and vibrant even in ordinary indoor lighting.
Images are displayed at a native resolution of 1024 × 768 pixels.
Epson®3LCD technology ensures accurate color and remarkable
saturation, even in well-lit rooms.
You can connect the projector to a wide range of computers, including
IBM®-compatible PCs and laptops, Apple®Macintosh,
®
PowerPC®
and Intel®Core™Macintosh computers, PowerBook®
computers, and
many iMac®and iBook®series systems. With Epson’s patented
SizeWise™technology, the projector supports computer displays
ranging from VGA through UXGA.
You can use any of the following video sources: HDTV, VCR, DVD
player, gaming console (such as Microsoft®Xbox,
™Sony®
PlayStation®3, and Nintendo Wii™), camcorder, or digital camera.
The projector supports NTSC, PAL, and SECAM video formats.
You can also connect the projector to a LAN (local area network) so
you can monitor the projector from a remote network computer using
the included EMP Monitor software.
You can connect up to four devices to the projector at the same time.
With the projector’s Source Search button, you don’t even have to
identify your input source. Just press the button until you see the
image you want on the screen.

8Welcome
To prevent unauthorized use of the projector, you can assign a
password, create a user logo which is displayed at startup to identify
the projector, and disable the projector’s buttons through a full or
partial Operation Lock feature. For more information about security
features, see page 62.
Getting the Most from Your Projector
Depending on your presentation, you can take advantage of any or all
of these options:
■Connecting to a laptop or other computer
If you want to connect the projector to a laptop or desktop
computer, see page 18. For additional presentation control, you
can connect an external monitor to view the presentation on your
computer simultaneously.
■Connecting to video sources
You can connect a DVD player, VCR, HDTV, camcorder, digital
camera, and other video sources to your projector. See page 24 for
instructions.
■Using the remote control
The remote control lets you switch from computer to video
sources, zoom in on part of your image, freeze or mute the
presentation, and adjust many other projector features. For
details, see Chapter 3.
■Enhancing sound in your presentation
By connecting your projector to external speakers, you can
enhance the audio impact of your presentations.

Welcome 9
Using Your Documentation
In addition to this manual, your documentation includes a Quick
Setup sheet, warranty brochures, and an Epson PrivateLine®Support
card.
The Quick Setup sheet gives instructions to quickly set up your
projector and connect it to a computer or video device.
This book contains all the information you need to set up and use
your projector. Please follow these guidelines as you read through it:
■Warnings must be followed carefully to avoid bodily injury.
■Cautions must be observed to avoid damage to your equipment.
■Notes contain important information about your projector.
Getting More Information
Need tips on giving presentations? How about quick steps for setting
up your projector? Here’s where you can look for help:
■www.presentersonline.com
Includes a library of articles covering presentation tips, tricks, and
technology. The site provides templates, clip art, and sound clips,
as well as Presenters Services to use on the road. Even more
resources and services are available if you register to join the
Presenters Club—and it’s free.
■Built-in help system
Press the Help button on the remote control or projector to get
quick solutions for common problems. See page 78 for details.
■epson.com/support
Download FAQs (frequently asked questions) and e-mail your
questions to Epson support on the PowerLite 822p or
PowerLite 83c.
If you still need help after checking this User’s Guide and the sources
listed above, you can use the Epson PrivateLine Support service to get
help fast. Call [phone] and enter the PIN on your PrivateLine
Support card. See page 87 for more information.
note
The instructions here apply
to the PowerLite 822p and
PowerLite 83c projectors
and cover both projectors,
unless noted.

10 Welcome
Registration and Warranty
Your projector comes with a basic carry-in warranty and an
international warranty that let you project with confidence anywhere
in the world. For details, see the warranty brochures that came with
your projector.
In addition, Epson offers Extra CareSM Road Service at no additional
charge. In the unlikely event of an equipment failure, you won’t have
to wait for your unit to be repaired. Instead, Epson will ship you a
replacement unit anywhere in the United States or Canada, usually
within one business day. See the Extra Care Road Service brochure for
details.
To register, complete the registration form that came with your
projector and mail it to Epson. Or register your product online using
your projector CD, or at:
http://www.epson.com/webreg
Registering also lets you receive special updates on new accessories,
products, and services.
Unpacking the Projector
After unpacking the projector, make sure you have all these items:
Save all packaging in case you need to ship the projector. Always use
the original packaging (or equivalent) when you send the projector to
another location. See page 76 for transportation instructions.
Projector Remote control
and batteries
VGA computer cable Power cord
Password Protected
Sticker

Welcome 11
Projector Parts
Control panel
Lamp cover
Air exhaust
vent
Front adjustable
foot Foot release lever
Remote control
sensor
Focus ring
Zoom ring
Security slot
Monitor Out port
(for Computer1
port output only)
Computer 1 and 2
(Component Video) ports
S-Video port
Video portLAN port
Remote
control sensor
Speaker
Audio L-R
input ports
Rear adjustable
foot
Power
inlet
A/V mute
slide lever
A/V mute
slide
RS-232C
serial port
Audio 1 and 2
input ports
Audio Out
port
Air
filter
Hole for
ceiling
mount
bracket
Holes for
ceiling
mount
bracket
Security
lock slot
Front
Back
Bottom

12 Welcome
Additional Components
Depending on how you plan to use the projector, you may need
additional components:
■To receive an S-Video signal, you need an S-Video cable. One is
usually provided with your video device or you can purchase it
from Epson. See page 13.
■To receive a component video signal from a VCR or other video
device, you need a D-sub, 15-pin, component-to-VGA video
cable, which is available from Epson. See page 13.
■Some older PowerBooks and Macintosh desktop models may
need a Macintosh video adapter; see your computer dealer. Older
iMac systems may need a special adapter to provide a VGA output
port; see your computer dealer.
■To receive an audio signal, you need a commercially available
audio cable; see your computer or electronics dealer.
Control Panel
Indicate
projector
status
Turns projector
on and off
Searches for
source image
Opens menu system
Left/right arrows
and
Volume down/up
Up/down arrows and
keystone correction
Opens help
system
Cancel/exit
Automatically
adjusts computer
images

Welcome 13
Optional Accessories
To enhance your use of the projector, Epson provides the following
optional accessories:
You can purchase screens, carrying cases, or other accessories from an
Epson authorized reseller. To find the nearest reseller, call
800-GO-EPSON (800-463-7766). Or you can purchase online at
www.epsonstore.com (U.S. sales) or www.epson.ca (Canadian sales).
Product Product number
Replacement lamp VI3H010L42
Air filter set (includes 2 filters) V13H134A13
Component-to-VGA video cable
S-Video cable
ELPKC19
ELPSV01
Distribution amplifier ELPDA01
50-inch portable screen (4:3 aspect ratio)
60-inch portable pop-up screen (4:3 aspect ratio)
80-inch portable pop-up screen (4:3 aspect ratio)
83.6-inch hanging pull-down screen
(4:3 aspect ratio)
Duet™Ultra Portable Projector screen
(4:3 and 16:9 aspect ratio)
ELPSC06
ELPSC07
ELPSC08
ELPSC09
ELPSC80
ELPDC05 high resolution document imager V12H162020
Kensington®security lock ELPSL01
Ceiling mount (gyro lock with suspension adapter)
False ceiling plate
Suspension adapter
Security bracket/cabling for gyro lock mounts
Adjustable ceiling channel
ELPMBUNI
ELPMBFCP
ELPMBAPL
ELPMBSEC
ELPMBACC
note
To purchase a replacement
remote control, call
[phone] (U.S.) or
[phone] (for dealer
referral in Canada).

14 Welcome

15
1
Setting Up the Projector
This chapter tells you how to set up the projector and connect it to a
computer or video source. You can connect up to four devices
simultaneously: four video sources, or two computer and two video
sources.
You’ll find instructions for the following in this chapter:
■Positioning the projector
■Connecting to a computer
■Connecting to video sources

16 Setting Up the Projector
Positioning the Projector
Before connecting the projector, you
need to decide where to place it. If
you’re setting up the projector yourself
and it isn’t already installed in the
room you’re using, you’ll probably
want to place it on a table in front of
the screen, as shown.
This lets you stand in the front of the room, face the audience, and
remain close enough to the equipment to be able to control it. Try to
leave as much space as possible between the projector and the screen to
get a good-size image.
Place the projector somewhere between 3 and 30 feet from the screen.
Use the figure below to help you determine exactly how far. Image size
increases with distance, but can vary depending on how you’ve
adjusted the optical zoom and other settings.
Also keep these considerations in mind:
■Place the projector on a sturdy, level surface.
■Make sure there is plenty of space for ventilation around and
under the projector. Do not set the projector on top of loose
papers that could block the vents under the projector.
■Make sure the projector is within 6 feet (2 meters) of a grounded
electrical outlet or extension cord.
note
You can download the
Projection Distance
Calculator program from
the Drivers and Downloads
section of Epson’s web site:
www.epson.com/support
28 to 34 ft (4:3)
31 ft (16:9; wide only)
5.6 to 6.8 ft (4:3)
6.1 to 7.3 ft (16:9)
2.7 to 3 ft (4:3)
3 to 3.6 ft (16:9)

Setting Up the Projector 17
Try to place the projector directly in front of the center of the screen,
facing it toward the screen squarely. If the projector isn’t positioned
this way, the image will be “keystone” shaped, instead of square or
rectangular.
If you place the projector below the level of the screen, you’ll have to
tilt it up by extending the front adjustable foot, as described on
page 39. This also causes the image to lose its rectangular shape. You
can adjust the shape using the buttons on the projector (see page 40),
or using the projector’s menu system (see page 49).
The Auto Keystone feature corrects the distortion automatically. See
page 57 for more information about Auto Keystone correction. If
necessary, you can adjust the image shape manually as described on
page 40.
Other Installations
You can also project from behind the screen or from the ceiling, with
the projector mounted upside-down:
To project from overhead, you’ll need the optional ceiling mount
hardware. (See page 13 for ordering information.) You’ll also need to
select Front/Ceiling or Rear/Ceiling for the Projection option in the
Extended menu. To project from the rear, select Rear. See page 58 for
more information.
Front/ceiling projectionRear projection (using a
translucent screen)
Rear/ceiling projection (using
a translucent screen)

18 Setting Up the Projector
Connecting to a Computer
You can connect the projector to any computer that has a standard
VGA or BNC monitor port, including PC notebook and laptop
computers, Macintosh PowerBooks and iBooks, and hand-held
devices.
Follow the instructions in this section to:
■Connect the projector to your computer with the VGA cable
included with the projector.
■Connect the projector to your computer with a commercially
available VGA–5BNC cable.
After connecting the projector to your computer, you may also
want to:
■Connect a monitor to the projector so you can view your
presentation close-up as well as on-screen (not necessary if you’re
using a laptop); see page 21.
■Connect the projector to your computer with a commercially
available audio cable to play computer audio; see page 22.
Connecting with the VGA Cable
Follow these instructions to connect to your computer with the VGA
cable that came with your projector. Before you start, make sure your
computer and the projector are turned off.
1. If you are connecting the projector to a desktop computer,
disconnect the monitor cable from your computer.
2. Locate the VGA computer cable that came
with the projector.
note
If you have an iBook with
an RCA video-out port,
follow the instructions for
connecting to a video device
on page 25.
VGA computer cable

Setting Up the Projector 19
Connect one end of the cable to the projector’s Computer1 or
Computer2 port.
3. Connect the other end of the cable to your computer’s video-out
or monitor port.
If you’re using a PowerBook or iBook and you can’t connect the
cable, you may need to use an optional Macintosh video adapter;
see your computer dealer.
4. If you connected the computer to the Computer1 port and you
want to view the display simultaneously on your computer
monitor and the projector screen, see “Connecting an External
Monitor” on page 21.
5. To play audio from your computer through the projector
speakers, see “Playing Sound Through the Projector” on page 22.
6. Tighten the screws on the connectors.
If you don’t need to make any other connections, you can plug in
your projector and turn it on. See page 34 for instructions.
If more than one device is connected to the projector, select the
correct source after projection starts by pressing the Source Search
button on the projector or remote control. See page 36.
Computer1 and Computer2 ports

20 Setting Up the Projector
Connecting with a VGA-5BNC Cable
If your computer provides video output through BNC connectors,
follow these instructions to connect the projector to your computer
with an optional VGA-5BNC cable. Before you start, make sure your
computer and the projector are turned off.
1. Disconnect the monitor cable from your computer.
2. Connect the cable’s VGA connector to the projector’s
Computer1 or Computer2 port.
3. Connect the BNC connectors to your computer’s BNC ports.
4. If you want to view the display simultaneously on your computer
monitor and the projector screen, see “Connecting an External
Monitor” on page 21.
5. To play audio from your computer through the projector
speakers, see “Playing Sound Through the Projector” on page 22.
6. Tighten the screws on the VGA connector.
If you don’t need to make any other connections, you can plug in
your projector and turn it on. See page 34 for instructions.
If more than one device is connected to the projector, select the
correct source after projection starts by pressing the Source Search
button on the projector or remote control. See page 36.
VGA-5BNC cable
Computer1 and Computer2 ports
