Epson EB-L1750U User manual

User's Guide

Notations Used in This Guide
•Safety indications
The documentation and the projector use graphical symbols to show how to use the projector safely.
The indications and their meaning are as follows. Make sure you understand them properly before reading the guide.
Warning
This symbol indicates information that, if ignored, could possibly result in personal injury or even death due to incorrect handling.
Caution
This symbol indicates information that, if ignored, could possibly result in personal injury or physical damage due to incorrect handling.
•General information indications
Attention
Indicates procedures which may result in damage or injury if sufficient care is not taken.
a
Indicates additional information and points which may be useful to know regarding a topic.
sIndicates a page where detailed information regarding a topic can be found.
g Indicates that an explanation of the underlined word or words in front of this symbol appears in the glossary of terms. See the "Glossary"
section of the "Appendix".
s"Glossary" p.288
[Name] Indicates the name of the buttons on the remote control or the control panel.
Example: [Esc] button
Menu Name Indicates Configuration menu items.
Example:
Select Brightness from Image.
Image - Brightness

Make sure you read the following before you use the projector.
sSafety Instructions
Warning and Cautions on Installation
An optional ceiling mount is required when suspending the projector from
a ceiling.
s"Optional Accessories" p.242
Warning
•Do not use or install the projector where it may be subject to water or rain,
or high humidity, such as outdoors, in a bathroom, or shower room, and so
on. Otherwise, it could cause a fire or electric shock.
•Do not install in locations where it could be subject to salt damage, or in
locations subject to corrosive gas such as sulphuric gas from a hot spring.
Otherwise, the projector could fall due to corrosion. It could also cause
damage to the projector.
•A special method of installation is required when suspending the projector
from a ceiling (ceiling mount). If installation work is not carried out
correctly, the projector could fall down. This may result in injury or
accidents. Contact your local dealer or the nearest address provided in the
Epson Projector Contact List.
sEpson Projector Contact List
•If you use adhesives on the ceiling mount fixing points to prevent the screws
from loosening, or if you use things such as lubricants or oils on the
projector, the projector case may crack causing it to fall from its ceiling
mount. This could cause an accident or injury to anyone under the ceiling
mount.
When installing or adjusting the ceiling mount, do not use adhesives,
lubricants, oils, and so on to prevent the screws from loosening.
Warning
•Failure to install the ceiling mount and projector may cause the projector to
fall.
After installing the specific Epson mount that supports your projector, make
sure you secure the projector and the mount using wire that is strong enough
to hold their weight.
•Do not cover the projector's air intake vent or air exhaust vent. If either of
the vents are covered, the internal temperature could rise and cause a fire.
•Do not place flammable objects in front of the lens. If you set the schedule to
turn on the projector automatically, any flammable objects placed in front of
the lens could cause a fire.
•Do not tie the power cord and other connection cables together. Otherwise, it
could cause a fire.
•Only use the specified power-supply voltage. Otherwise, it could cause a fire
or electric shock.
•Be careful when handling the power cord. Otherwise, it could cause a fire or
electric shock. Note the following when handling the power cord.
- Do not plug multiple power cords in a single electric outlet.
- Do not plug in the power cord if there are any foreign substances, such
as dust, stuck to it.
- Make sure you insert the power cord all the way in.
- Do not plug in or unplug the power cord with wet hands.
- Do not pull the cord when unplugging the power cord. Make sure you
hold it by the plug.
•Do not use a damaged power cord. Otherwise, it could cause a fire or electric
shock. Note the following when handling the power cord.
- Do not alter the power cord.
- Do not place any heavy objects on the power cord.
- Do not bend, twist, or pull the power cord forcibly.
- Do not layout the power cord near a heating device.
Safety Warning and Cautions
3

Caution
Do not place the projector on an unstable surface, such as on an unstable table
or tilted surface. When projecting vertically, install the projector appropriately
to prevent the projector from falling.
Otherwise it may cause an injury.
Attention
•Do not install the projector in a location that is subject to vibration or
shock.
•Do not install the projector near a high-voltage line or object that generates
magnetism. Otherwise the projector may not work correctly.
•Do not use or store the projector in a location that is subject to extreme
temperatures. Also, avoid sudden temperature changes.
Make sure you use or store the projector in a place that is within the
following operating or storage temperature ranges.
- Operating temperature range
0 to +50˚C (Altitude of 0 to 1,500 m, no condensation)
0 to +45˚C (Altitude of 1,501 to 3,048 m, no condensation)
- Storage temperature range: -10 to +60˚C (No condensation)
•When using at an altitude that exceeds 1,500 m, set High Altitude Mode to
On.
sExtended - Operation - High Altitude Mode p.151
•The projector can be installed at any angle. There is no vertical or horizontal
limit to how the projector can be installed.
•You may need dedicated installation mounts to tilt and install the projector.
Contact a professional and prepare the mount.
•Plan so that the mount does not fall.
Safety Warning and Cautions
4

Attention
•Make sure you secure the following space around the projector so as not to
block the air exhaust vent and the air intake vent.
•When setting up multiple projectors, make sure there is a gap of at least
50 cm between the projectors. Also, make sure that the heat from the air
exhaust vent does not go into the air intake vent.
•Do not use two projectors at the same time when stacking two projectors
directly on top of each other. Install the projector so that there is no danger
that it will fall.
Attention
•Use commercially available M6 screws (up to a depth of 12 mm) to fix the
projector's ceiling mount fixing points and the mount at four points.
•When installing the projector with the air intake vent facing down, make sure
there is a gap of at least 10 cm between the projector and the floor and so
on. Make sure there is a space of 50 x 20 cm for the base so that the air
intake vent is not blocked.
a
•We recommend setting the focus, zoom, and lens shift at least 20
minutes after you start the projection, because images are not stable
right after turning on the projector.
Wait for at least 20 minutes.
•When adjusting the image height with the vertical lens shift, adjust
by moving the image from the bottom to the top. If it is adjusted
from the top to the bottom, the image position may move down
slightly after adjusting.
Safety Warning and Cautions
5

Warning and Cautions on Usage
Warning
•Do not cover the projector's air intake vent or air exhaust vent. If either of
the vents is covered, the internal temperature could rise and cause a fire.
•Do not look into the lens while projecting. The powerful light emitted could
cause damage to eyesight. Take particular care when there are children
present. When turning on the projector at a distance using the remote
control, make sure there is no one looking into the lens.
•During projection, do not block the light from the projector with the lens
cover (removable) or a book and so on.
If the light from the projector is blocked, the area on which the light shines
becomes hot which could cause it to melt, burn, or start a fire. Also, the lens
may get hot due to the reflected light which could cause the projector to
malfunction. To stop projection, use the A/V Mute function, or turn off the
projector.
•Do not open the projector's case. Never disassemble or remodel the projector.
There are high-voltage components inside the projector that could cause fire,
electric shock, or an accident.
•If an error occurs, disconnect the power cord from the electrical outlet, and
contact your local dealer or the nearest address provided in the Epson
Projector Contact List. If you continue using the projector as it is, it could
cause an electric shock, fire, or even damage to eyesight.
sEpson Projector Contact List
Caution
Do not place objects that may become warped or otherwise affected by heat
near the air exhaust vent and do not put your face or hands near the vent
while projection is in progress.
Attention
•Only remove the lens unit when necessary. If dust or dirt enter the projector,
projection quality deteriorates and it could cause a malfunction.
•Try not to touch the lens section with your hand or fingers. If fingerprints or
oils are left on the surface of the lens, projection quality deteriorates.
•Store the projector with the lens unit installed.
If the projector is stored without the lens unit, dust and dirt may get inside
the projector and cause malfunctions or lower the quality of projection.
•When storing, make sure you remove the batteries from the remote control.
If the batteries are left in the remote control for an extended period of time,
they may leak.
Safety Warning and Cautions
6

a
•About the LCD panel
- The LCD panel may contain pixels that are missing or appear bright all
the time. This is not a sign of an error.
- When a high-powered laser beams through the surface of the projection
lens even when it is not being used, it can cause a malfunction in the
LCD panel. Attach the lens cover when storing the projector.
•About the light source
The projector uses a laser as the light source. The laser has the
following characteristics.
- Depending on the surroundings, the brightness of the light source may
decline. The brightness declines a lot when the temperature gets too
high.
- The brightness of the light source declines the longer it is used. You can
change the relationship between usage time and decline in brightness in
Brightness Settings.
s"Relationship between Brightness Level and light source operation
time" p.80
•Light Source Calibration
- Whenever the usage time reaches 100 hours, calibration starts
automatically for the light source when the projector is turned off.
However, this does not start automatically when the projector is used
continuously for more than 24 hours, or when direct shutdown is used
regularly. Set Light Source Calibration in the scheduling function.
s"Scheduling Function" p.117
- When performing light source calibration, the difference between the
white balance and the brightness level for the light source is corrected.
Warning and Cautions on the Laser
Warning
•Laser warning labels are attached inside the projector and on the side of the
projector.
Inside
Safety Warning and Cautions
7

Warning
Side
Warning
•Do not open the projector's case. The projector contains a high-powered
laser.
•Do not look into the lazer beam being emitted from the projection lens while
projecting. (Based on the RG2 IEC/EN 62471-5: 2015)
•This projector may become RG3 when an interchangeable lens with a throw
ratio grater than 2.5 (EB-L1755U/EB-L1750U/EB-L1715S/EB-L1710S) or 3.0
(EB-L1505UH/EB-L1500UH/EB-L1495U/EB-L1490U/EB-L1515S/EB-L1510S) is
installed. Refer to the manual for the lens list and hazard distance before
operation. Such combinations of projector and lens are intended for
professional use only, and are not intended for consumer use.
Caution
•This projector is a Class 1 laser product that complies with the IEC/
EN60825-1: 2014 international standard for lasers.
•Do not disassemble the projector when disposing of it. Dispose according to
your local or national laws and regulations.
Safety Warning and Cautions
8

Notes on Transporting
There are many glass parts and precision components inside the projector.
To prevent damage due to impacts when transporting, handle the projector
as follows.
Caution
The projector should not be carried by one person. At least two people are
needed to unpack or carry the projector.
Attention
•Moving Nearby
- Turn off the power to the projector and disconnect all cables.
- Attach the cover to the lens.
•When Transporting
After checking the points in "Moving Nearby", prepare the following and then
pack up the projector.
- Remove the lens unit if an option lens is installed.
- If the projector does not have a lens, attach the cover that was on the
lens mount when you purchased the projector.
- Attach the lens if the projector has a built-in lens. Upon purchase,
attach the protective pad that is attached around the lens unit.
- Move the lens position to the home position.
s"Adjusting the Position of the Projected Image (Lens Shift)"
p.34
- Enclose the projector securely in packaging material to protect it from
shock, and place it into a strong container. Be sure to notify the carrier
company that it is precision equipment and that it needs to be kept
horizontally during transportation.
Safety Warning and Cautions
9

Notations Used in This Guide ........................ 2
Introduction
PartNamesandFunctions .................................. 16
Front/Top...................................................16
Rear.......................................................17
Interface...................................................18
Base......................................................19
ControlPanel................................................20
RemoteControl...............................................21
Handyremotecontroloperations ................................24
Replacingtheremotecontrolbatteries.............................24
Remotecontroloperatingrange.................................25
Connectingacabletotheremotecontrol...........................26
Preparing the Projector
Installing the Projector ..................................... 28
RemovingandAttachingtheProjectorLensUnit ........................28
Attaching.................................................28
LensCalibration............................................29
Removing.................................................30
InstallationSettings............................................ 30
Changingthedirectionoftheimage(projectionmode).................30
ScreenSettings ...............................................31
Adjustingthepositionoftheimageontheprojectedscreen..............32
DisplayingaTestPattern........................................33
AdjustingthePositionoftheProjectedImage(LensShift)..................34
EB-L1755U/EB-L1750U/EB-L1505UH/EB-L1500UH/EB-L1495U/EB-L1490U . . . . . 34
EB-L1715S/EB-L1710S/EB-L1515S/EB-L1510S . . . . . ....................36
AdjustingtheImageSize ........................................38
CorrectingtheFocus ...........................................39
CorrectingDistortion(ImageWarping).............................39
RegisteringandLoadingLensAdjustmentValues.......................41
AdjustingtheHeightoftheProjectedImage(forNormalInstallment)..........43
AdjustingtheHorizontalTilt(forNormalInstallment).....................43
IDSettings..................................................44
SettheprojectorID..........................................44
CheckingtheprojectorID ...................................... 44
SettingtheremotecontrolID...................................45
SettingtheTime..............................................45
OtherSettings ................................................47
Settingsrelatedtobasicoperations ...............................47
Settingsrelatedtodisplay......................................47
Connecting Equipment ..................................... 49
ConnectingaComputer......................................... 49
ConnectingImageSources.......................................51
ConnectingExternalEquipment...................................53
ConnectingaLANCable.........................................54
ConnectinganHDBaseTTransmitter................................55
InstallingtheWirelessLANUnit .................................... 56
AttachingtheCableCover.......................................57
Attaching.................................................57
Basic Usage
Turning On the Projector ................................... 60
HomeScreen ................................................61
Turning Off the Projector ................................... 62
ProjectingImages ......................................... 63
Automatically Detecting Input Signals and Changing the Projected Image (Source
Search) ....................................................63
SwitchingtotheTargetImagebyRemoteControl.......................64
AdjustingtheVolume..........................................65
AdjustingProjectedImages ................................ 66
CorrectingDistortionintheProjectedImage...........................66
H/V-Keystone..............................................67
QuickCorner ...............................................68
Contents
10

CurvedSurface.............................................69
CornerWall ................................................ 73
PointCorrection ............................................76
SelectingtheProjectionQuality(SelectingColorMode)...................78
SettingtheBrightness..........................................78
GuidetoEstimatedRemains....................................80
Relationship between Brightness Level andlightsourceoperationtime......80
SettingtheAmountofLightoftheProjectedImage ......................81
ChangingtheAspectRatiooftheProjectedImage.......................82
Changingmethods.......................................... 82
AdjustingtheImage...........................................85
Hue,Saturation,andBrightnessadjustment.........................85
Gammaadjustment.......................................... 86
FrameInterpolation..........................................88
AdjustingImageResolution(ImageEnhancement).......................89
4K Enhancement (EB-L1755U/EB-L1750U/EB-L1505UH/EB-L1500UH/EB-L1495U/
EB-L1490Uonly)............................................89
ImagePresetMode ..........................................90
NoiseReduction............................................90
MPEGNoiseReduction........................................91
Super-resolution ............................................91
DetailEnhancement.........................................92
Projecting 3D Images (EB-L1505UH/EB-L1500UH/EB-L1495U/EB-L1490U/EB-
L1515S/EB-L1510S only) . . . . . ....................................92
Useful Functions
Multi-Projection Function . ................................. 94
AdjustmentProcedure..........................................94
Adjustingautomaticallyonline..................................94
Adjustingmanuallyoffline .....................................95
Tiling......................................................95
Performingtilingautomatically..................................95
Performingtilingmanually.....................................97
EdgeBlending...............................................98
BlackLevel ................................................. 100
ScreenMatching ............................................. 103
Operatingconditionsforautoadjustmentfunctions...................103
Automaticallycorrectthebrightnessandtintformultipleprojectors ........ 104
ColorMatching ............................................ 105
DisplayingaScaledImage.......................................106
ProjectionFunctions ...................................... 108
ProjectingTwoImagesSimultaneously(SplitScreen).................... 108
InputSourcesforSplitScreenProjection ...........................108
Operatingprocedures....................................... 109
Restrictionsduringsplitscreenprojection..........................111
HidingtheImageandSoundTemporarily(A/VMute) .................... 111
FreezingtheImage(Freeze)..................................... 112
EnlargingPartoftheImage(E-Zoom) ............................... 113
SavingaUser'sLogo ........................................... 114
MemoryFunction ......................................... 115
Saving/Loading/Erasing/ResettingtheMemory........................ 115
SchedulingFunction ...................................... 117
SavinganEvent ..............................................117
SettinganEvent........................................... 117
CheckinganEvent..........................................118
EditinganEvent........................................... 119
Security Functions ........................................ 121
ManagingUsers(PasswordProtection) .............................. 121
KindsofPasswordProtection .................................. 121
SettingPasswordProtection ................................... 121
Enteringthepassword....................................... 122
RestrictingOperation.......................................... 123
ControlPanelLock.......................................... 123
LensLock ................................................ 124
Remotecontrolbuttonlock ....................................124
Anti-TheftLock .............................................. 125
Installingthewirelock ....................................... 125
Contents
11

Using the Projector on a Network
WiredNetworkProjection ................................. 127
SelectingWiredNetworkSettings................................. 127
Wireless Network Projection . . ............................. 130
SelectingWirelessNetworkSettingsManually......................... 130
SelectingWirelessNetworkSettingsinWindows....................... 133
SelectingWirelessNetworkSettingsinOSX.......................... 133
SettingUpWirelessNetworkSecurity............................... 133
SupportedClientandCACertificates ............................. 135
UsingaQRCodetoConnectaMobileDevice ..........................136
UsingaUSBKeytoConnectaWindowsComputer ...................... 137
SecureHTTP ............................................. 138
ImportingaWebServerCertificateUsingtheMenus ..................... 138
SupportedWebServerCertificates ...............................139
Configuration Menu
Using the Configuration Menu ............................. 141
ListofFunctions .......................................... 142
ConfigurationMenuTable...................................... 142
Networkmenu............................................ 143
ImageMenu ................................................ 145
SignalMenu ................................................ 147
SettingsMenu ...............................................149
ExtendedMenu.............................................. 151
NetworkMenu .............................................. 156
NotesonoperatingtheNetworkmenu ............................157
Softkeyboardoperations ..................................... 158
Basicmenu ............................................... 158
WirelessLANmenu......................................... 159
WiredLANmenu........................................... 163
Notificationsmenu......................................... 163
Othersmenu ..............................................165
Resetmenu............................................... 166
InfoMenu(DisplayOnly) ........................................166
ResetMenu .................................................168
BatchSetup .............................................. 169
SetupUsingaUSBFlashDrive .................................... 169
SavingsettingstotheUSBflashdrive ............................. 169
Reflectingsavedsettingstootherprojectors........................ 171
Setup by Connecting the Computer and Projector with a USB Cable . . . . . . . . . . 173
Savingsettingstoacomputer .................................. 173
Reflectingsavedsettingstootherprojectors........................ 174
WhenSetupFails .............................................175
Troubleshooting
UsingtheHelp ........................................... 177
Reading the Indicators . . . . . . .............................. 179
Reading the Status Display ................................ 186
ExplanationsoftheDisplayContent ................................187
ProblemSolving .......................................... 194
ProblemsRelatingtoImages ..................................... 195
Noimagesappear.......................................... 195
Movingimagesarenotdisplayed ................................196
Projectionstopsautomatically.................................. 196
TheEDIDisnotset.isdisplayed................................. 196
Notsupported.isdisplayed .................................... 196
NoSignal.isdisplayed....................................... 197
Imagesarefuzzy,outoffocus,ordistorted......................... 197
Interferenceordistortionappearinimages......................... 198
The image is truncated (large) or small, the aspect is not suitable, or the image has
beenreversed.............................................198
Imagecolorsarenotright ..................................... 199
Imagesappeardark ......................................... 200
Automaticadjustmentsarenotperformedcorrectly...................200
ProblemswhenProjectionStarts.................................. 201
Contents
12

Theprojectordoesnotturnon................................. 201
OtherProblems ..............................................202
Nosoundcanbeheardorthesoundisfaint ........................ 202
Theremotecontroldoesnotwork............................... 203
Nothingappearsontheexternalmonitor.......................... 204
Iwanttochangethelanguageformessagesandmenus................ 204
Emailisnotreceivedevenifaproblemoccursintheprojector............ 204
Thebatterythatsavesyourclocksettingsisrunninglow.isdisplayed....... 205
The projector did not turn off correctly. An instantaneous voltage drop may have
occurred.isdisplayed........................................205
Detailedlogsanderrormessagearenotdisplayed.................... 205
CannotchangethesettingsusingaWebbrowser.....................205
AboutEventID ........................................... 206
Maintenance
Cleaning ................................................. 209
CleaningtheProjector'sSurface ...................................209
CleaningtheLens............................................ 209
CleaningtheAirFilter..........................................209
Cleaningtheairfilter........................................ 209
ReplacingConsumables ................................... 212
ReplacingtheAirFilter......................................... 212
Airfilterreplacementperiod ................................... 212
Howtoreplacetheairfilter .................................... 212
ImageMaintenance ....................................... 214
ColorCalibration............................................. 214
PanelAlignment ............................................. 215
ColorUniformity ............................................. 217
Appendix
Monitoring and Controlling ............................... 220
EpsonProjectorManagement.................................... 220
ChangingSettingsUsingaWebBrowser(EpsonWebControl).............. 220
DisplayingtheEpsonWebControlScreen ..........................220
BasicControlScreen .........................................222
OSDControlPadScreen...................................... 222
LensControlScreen......................................... 223
StatusInformationScreen ..................................... 225
RemoteCameraAccessscreen ..................................226
SettingacertificateusingaWebbrowser .......................... 228
UsingtheMailNotificationFunctiontoReportProblems..................229
Readingerrornotificationmail ..................................229
ManagementUsingSNMP ...................................... 230
ESC/VP21Commands..........................................230
Commandlist ............................................. 230
Cablelayouts............................................. 231
AboutPJLink ................................................232
About Crestron RoomView
®
..................................... 232
Operatingaprojectorfromyourcomputer......................... 233
Art-Net....................................................237
Channeldefinitions......................................... 237
Optional Accessories and Consumables .................... 242
OptionalAccessories.......................................... 242
Consumables............................................... 242
Screen Size and Projection Distance ........................ 243
Projection Distance for EB-L1755U/EB-L1750U/EB-L1505UH/EB-L1500UH/EB-
L1495U/EB-L1490U . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
ELPLM15/ELPLM09/ELPLS04 ................................... 243
ELPLX02/ELPLX02W .........................................244
ELPLU03.................................................245
ELPLU04/ELPLU02.......................................... 246
ELPLW05................................................ 246
ELPLW06/ELPLW04......................................... 247
ELPLW08................................................ 248
Contents
13

ELPLM10/ELPLM06......................................... 249
ELPLM11/ELPLM07......................................... 250
ELPLL08/ELPLL07 ...........................................251
ELPLR04................................................. 251
Projection Distance for EB-L1715S/EB-L1710S/EB-L1515S/EB-L1510S . . . . . . . . . . 252
ELPLM15/ELPLM09/ELPLS04 ................................... 253
ELPLX02/ELPLX02W ......................................... 254
ELPLU03.................................................254
ELPLU04/ELPLU02.......................................... 255
ELPLW05................................................ 256
ELPLW06/ELPLW04......................................... 257
ELPLW08................................................ 258
ELPLM10/ELPLM06......................................... 259
ELPLM11/ELPLM07......................................... 259
ELPLL08/ELPLL07 ...........................................260
ELPLR04................................................. 261
Polarizer (ELPPL01) Installation Distance (EB-L1505UH/EB-L1500UH/EB-L1495U/EB-
L1490U/EB-L1515S/EB-L1510S Only) ................................262
Adjustment Range for ProjectedImages .................... 263
H/V-Keystone ............................................... 263
CurvedSurface.............................................. 263
CornerWall .................................................269
SupportedMonitorDisplays ............................... 276
EB-L1755U/EB-L1750U/EB-L1505UH/EB-L1500UH/EB-L1495U/EB-L1490U ...... 276
SDI.................................................... 279
EB-L1715S/EB-L1710S/EB-L1515S/EB-L1510S ..........................280
Specifications ............................................ 283
ProjectorGeneralSpecifications ...................................283
Appearance .............................................. 287
Glossary ................................................. 288
GeneralNotes ............................................ 290
AboutNotations............................................. 290
TrademarksandCopyrights ......................................290
List of Safety Symbols Compliant with IEC60950-1 A2 . . . . . . . 292
Index .................................................... 294
Contents
14

Introduction
This chapter explains the names for each part.

The illustrations in this guide show the lens unit attached to the projector.
Front/Top
Name Function
ARemote receiver Receives signals from the remote control.
BAir intake vent Takes in air to cool the projector internally.
Name Function
CProjection lens Images are projected through here.
Warning
Do not look into the lens while projecting. This
could cause damage to eyesight due to the power‐
ful light emitted.
Caution
When shifting the lens, do not put your hands near
the lens unit. Your fingers may get caught between
the lens unit and the projector, and cause an in‐
jury.
DBuilt-in camera This camera scans the image when correcting the
projected image automatically.
Attention
Exposing the camera to bright light may
cause a malfunction to occur.
EStatus indicators The color of the indicators and whether they are flashing
or lit indicate the status of the projector.
s"Reading the Indicators" p.179
FAir intake vent
(air filter)
Takes in air to cool the projector internally.
s"Cleaning the Air Filter" p.209
GAir filter cover tab Use this knob to open the air filter cover.
s"Replacing the Air Filter" p.212
HWireless LAN indicator Indicates the access status to the optional wireless LAN
unit.
s"Optional Accessories" p.242
ICable cover Cover for the rear interface cable connection section.
s"Attaching the Cable Cover" p.57
Part Names and Functions
16

Name Function
JLens replacement
cover
Remove when attaching or removing the lens.
s"Removing and Attaching the Projector Lens Unit"
p.28
Caution
When moving the projector, do not hold the lens
replacement cover. The lens replacement cover
may be removed and the projector may fall, which
could cause an injury.
Rear
Name Function
AAir exhaust vent Exhaust vent for air used to cool the projector internally.
Caution
While projecting, do not put your face or hands
near the air exhaust vent, and do not place objects
that may become warped or damaged by heat near
the vent. Hot air from the air exhaust vent could
cause burns, warping, or accidents to occur.
BControl panel s"Control Panel" p.20
CSecurity slot The security slot is compatible with the Microsaver
Security System manufactured by Kensington.
s"Anti-Theft Lock" p.125
DPower inlet Connects the power cord to the projector.
Part Names and Functions
17

Name Function
ECable holder Insert the cable clamp for the power cord so that the power
cord does not disconnect under its own weight.
FInterface s"Interface" p.18
GScrew holes to fix the
cable cover
Screw holes to fix the cable cover in place.
s"Attaching the Cable Cover" p.57
Interface
Name Function
ABNC port For analog RGB signals from a computer and component
video signals from other video sources.
BComputer port For analog RGB signals from a computer and component
video signals from other video sources.
CAudio3 port Inputs audio from equipment connected to the HDMI
port or the DVI-D port.
DAudio1 port Inputs audio from equipment connected to the Computer
port.
EMonitor Out port Outputs to an external monitor the analog signal from the
computer connected to the Computer port or the BNC
port. You cannot output signals input from other ports or
component video signals.
FAudio Out port Outputs audio from the currently projected image to an
external speaker.
GAudio2 port Inputs audio from equipment connected to the BNC port.
HCable holder Run a commercially available cable tie to secure cables.
Part Names and Functions
18

Name Function
IRS-232C port When controlling the projector from a computer, connect
it to the computer with an RS-232C cable. This port is for
control use and should not normally be used.
s"ESC/VP21 Commands" p.230
JRemote port Connects the optional remote control cable set and inputs
signals from the remote control. When the remote control
cable is plugged into the Remote port, the remote receiver
on the projector is disabled.
s"Optional Accessories" p.242
KSDI input port
(EB-L1755U/EB-
L1750U/EB-L1505UH/
EB-L1500UH/EB-
L1495U/EB-L1490U
only)
Inputs SDI signals from video equipment.
LService port This is used for batch settings. This port is for control use
and should not normally be used.
s"Batch Setup" p.169
MHDMI port Inputs video signals from HDMI compatible video
equipment and computers.
NDVI-D port Inputs the computer DVI-D signals.
OHDBaseT port Connects a LAN cable to the optional HDBaseT
Transmitter.
s"Connecting an HDBaseT Transmitter" p.55
s"Optional Accessories" p.242
PLAN port Connects a LAN cable to connect to a network.
Supports Art-Net.
s"Art-Net" p.237
Base
Name Function
AFront adjustable feet When setup on a surface such as a desk, extend and retract
the feet to adjust the projector's vertical and horizontal tilt.
s"Adjusting the Height of the Projected Image (for
Normal Installment)" p.43
s"Adjusting the Horizontal Tilt (for Normal
Installment)" p.43
BRear feet When setup on a surface such as a desk, turn to extendand
retract to adjust the horizontal tilt.
s"Adjusting the Horizontal Tilt (for Normal
Installment)" p.43
Part Names and Functions
19

Name Function
CSecurity cable
installation point
Pass a commercially available wire lock through here and
lock it in place.
s"Installing the wire lock" p.125
DCeiling mount fixing
points (four points)
Attach the optional ceiling mount here when suspending
the projector from a ceiling.
s"Installing the Projector" p.28
s"Optional Accessories" p.242
Control Panel
Name Function
A[] button Turns the projector on.
B[Source Search]
button
Changes to the next input source that is sending an image.
s"Automatically Detecting Input Signals and Changing
the Projected Image (Source Search)" p.63
C[Menu] button Displays and closes the Configuration menu.
s"Using the Configuration Menu" p.141
Name Function
D[] button •When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
•If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
E[]/[ ] buttons •Displays the Control Panel Lock screen allowing you to
make settings to lock the control panel buttons.
s"Restricting Operation" p.123
•If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s"Using the Configuration Menu" p.141
s"Using the Help" p.177
F[]/[ ] buttons •Displays a test pattern.
s"Displaying a Test Pattern" p.33
•If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s"Using the Configuration Menu" p.141
s"Using the Help" p.177
G[A/V Mute] button Turns the video and audio on or off.
s"Hiding the Image and Sound Temporarily (A/V
Mute)" p.111
H[Lens] button Displays the adjustment screens for lens shift, zoom,
focus, and distortion in that order each time the button is
pressed.
If pressed for more than three seconds, the lens position
moves to the home position.
Part Names and Functions
20
