Epson EMP 7600 User manual

EPSON EMP-7600 Specifications
ModelEMP-7600
Projection System RGB Liquid Crystal Shutter Projection
System
Projection Method Front / Rear / Ceiling Mount
Specification of Main Parts
LCD
Size
Driving Method
Pixel Number
Native Resolution
Aspect Ratio
Pixel Arrangement
Projection Lens
Type
F-number
Focal Length
Zoom Ratio
Lens cover
Lamp Type
Optical System
1.3 inches (x3)
Poly-Silicon TFT Active Matrix
786,432 dots
(1024x768)x3
XGA
4:3
Stripes
Manual : zoom / Focus
1.7 to 2.3
49 to 63 mm
1:1.3
It’s attached by the string
200WUHE
Dichroic Mirror Separation & Prism Combine
Method
Screen Size
(Projected Distance) 28to 300 inch (1.0 to 14.5m)
Keystone Correction Ratio 19:1Fixed Fixed19:
Brightness 2200 ANSI
Lumens
ContrastRatio 400:1
Brightness Uniformity
85%
Color Reproductivity
Full Color(1,677 Million Colors)
Sound Output
3W +3W
Effective Scanning Frequency Range
Pixel Clock
Horizontal
Vertical
14Mhz to 230Mhz
15KHz to 107KHz
43Hz to 120Hz
Adjustment Function
Projector / Remote Control
Tilt Angle
Keystone correction
Keystone / Brightness / Contrast/ Tint /
Sound / Input signal etc.
0 to 11Degrees
-30 to +50 Degrees
Analog RGB I/O
Display Performance
Native
Resize
Input Signal
Signal Type
Video Signal
1024 x 768 dots
1600x1200 / 1280x1024 / 800x600 /
Separate Signal
Analog (0.7Vp-p, 75Ω/ Mac0.714Vp-p, 75Ω)
640x480 dots

Sync Signal
Audio Signal
Input Terminal
Video
Audio
Output Signal
Video Signal
Sync Signal
Output terminal
Video
Separation (positive & negative 1/5Vp/p) /
Composite (positive & negative 1/5Vp/p) /
Sync. on green (negative, 0.2/0.4Vp/p)
500m Vrms / 47k
Mini D-sub 15 pin x1 (Select with manual
switch exclusive to DVI Type D)
Stereo Mini Jack (for Mini D-sub 15 pin)
Analog (0.7Vp/p, 75Ω/Mac0.714/p, 75Ω)
Separation (positive & negative TTL) /
Composite (positive & negative TTL) / Sync-on-
green (negative, 0.2-0.4Vp/p)
Mini D-sub 15 pin x1
Digital RGB Input
Display
Native
Resize
Input Signal
Video Signal
Audio Signal
Input Terminal
Video
Audio
1024 x 768 dots
1280x1024 / 800x600 / 640x480 dots
Digital
500m Vrms / 47k
DVI Type D x1
(Select with manual switch / Exclusive to D-sub
15)
Stereo mini jack
Video I/O
Display Performance
Input Signal
Video Standard
Video Signal
Audio Signal
Input
Video
NTSC : 550 Line PAL : 550 Line
NTSC / NTSC4.43 / NTSC 50 / PAL / M-PAL /
N-PAL / PAL60 / SECAM
Composite Video (1.0Vpp / Sync. negative,
75Ω) / S-video (Luminous 0.714pp,
Chrominous 0.286Vpp, 75Ω) / Component
Video (Analog Y level 0.7V 75Ω/ CrCb level+
/ -0.35V 75Ω/ sync. negative 0.3V or 3-
state+ / -0.3V on Yz) / Video-RGB (0.7Vp/p,
75Ω/ MA)
500m Vrms / 47k
Composite Video: RCA x1 / S-video: Mini Din x
1 / Composite Video: MiniSub 15pin x1 / Video
RGB: Mini Din-sub 15 pin x1 common with
Component Video.

Audio
Output Signal
Video Signal
Output Terminal
Video
RCAx2 (for composite Video / S-video /
component Video) / Stereo mini jack (for
Video-RGB)
Analog RGB (Composite Video, S-Video,
Component Video, Video-RGB are
Converted to Analog RGB) / Separate HV(TTL)
Mini Dsub 15 pin x1 (Common with Analog
RGB)
Control I/O
Mouse / Serial
I/O Terminal
Mouse
Input
Remote Control
Output
D-Sub9 pin (RS-232C) x1
Round 10pin x1 (PS/2, USB)
Stereo Mini Jack
Stack Out
Operating Temperature 5°C to 40°C (41°to 104°F)
Power Supply Voltage 100-120V / 200-240V AC ±10%, 50 / 60Hz
AC
Power Consumption 120V 3.4A 50/60Hz / 200-240V 1.7A 50/60 Hz
Dimension
Exclude Projection Lens & Feet
Maximum Dimensions
277 (W) x 143 (H) x 361 (D) mm
280 (W) x 156 (H) x 403 (D) mm
Weight 14.9lbs / 6.8kg
Accessories Power cable (3m),
Computer Cable (1.8m),
Audio Cable (RCA Audio-Cable, 1.8m/3.5 mini-
pin stereo audio-cable),
Audio Video Cable (RCA Composite-video-
cable 1.8m),
Remote Control Unit,
Battery (AA x 2),
User’s Manual,
PS/2 Mouse Cable (Round 10pin-Mini-Din
6pin),
USB Mouse Cable (Round 10pin-USB 4pin)
