The industry’s lightest wireless presentation solution to date,
the 4.4 lb EPSON PowerLite®735c offers remarkable control flexibility
with 802.11b wireless technology. Designed to facilitate quick setups and
easy network management, this 2000 ANSI lumen, ultra portable
projector also offers remote diagnostics and monitoring.
In addition, its newly improved EasyMP™technology enables convenient
PC-free presentations with incredible PowerPoint®functionality and
brilliant high-speed transitions.
With EPSON 3-LCD technology and XGA resolution, this full-featured
performer delivers exceptional image quality in any situation.
Newly improved EPSON EasyMP
•PC–free presenting
•More animation and PowerPoint functionality than ever before
• High-speed image transfers
Convenient connectivity options, including
wireless capability!
•No video cable required – Laptop and projector can be positioned
independently for optimal viewing and control.
•802.11b wireless technology (WiFi™ certified)
•Two wireless modes for individual or LAN users
•Easy administration via web browser access
•Simple Network Management Protocol (SNMP) – for easy network
management and maintenance
•Control flexibility – displays images on up to four projectors
simultaneously
•Security features – safeguards the display screen for uninterrupted
presentations
Incredible brightness-to-weight ratio!
•2000 brilliant ANSI lumens
•Weighs just 4.4 lb
Superior image quality
•Three 0.9" high-aperture EPSON LCDs with Micro Lens Array,
for rich color saturation across the screen
•XGA (1024 x 768) resolution for sharp, vivid detail
•400:1 contrast ratio for blacker blacks and whiter whites
Easy setup and operation
•Easy-to-use remote control that’s stored within the projector
•Exclusive auto keystone correction
•Color-coded VGA cables and connectors
•HDTV-ready
•Optical zoom
•Start Here Kit gets first time users projecting in just minutes
Renowned EPSON service and support
(free for the duration of the warranty)
•Comprehensive two-year warranty
•90-day bulb warranty for added dependability
•EPSON Road Service Program provides a replacement projector,
typically within 24 hours
•EPSON PrivateLineSM dedicated toll-free support line available from
6 a.m. to 6 p.m. PST Monday - Friday
(Calls are answered live, typically in about a minute.)
•International warranty in over 45 countries
CYAN
MAGENTA
YELLOW
BLACK
PANTONE 519 CV
PANTONE 5483 CV
CVPANTONE 519 CV
EPSON PowerLite®735c
Wireless Presentation at its Best
EPSON®
Front View
Back View
high
performance,
low profile
computer / component video
S-video
composite video
audio-in
USB mouse
convenient remote control storage
PCMCIA slot for Wireless LAN
and Memory Card wired/Ethernet card
zoom lens
full–featured IR
remote control
stylish metallic
silver finish
PL735c cat sheet c15540 2/14/03 1:38 PM Page 1 (2,1)

Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount
LCD
Size 0.9"
Driving Method EPSON Poly-Silicon TFT Active Matrix
Pixel Number 786,432 dots x3 (1024 x 768) LCDs
Native Resolution XGA
Aspect Ratio 4:3 (supports 16:9, 5:4)
Pixel Arrangement Stripe
Projection Lens
Type Manual: zoom/focus
F-number 1.9 to 2.1
f-number 31 – 36mm
Zoom ratio 1:1.16
Lamp
Type 150W UHE
Life (typical) 1500H (can last about 5 yrs. based on
6 hours/week x 50 weeks/year)
Screen Width Ratio: (distance/width) 1.63 to 1.89:1
Screen Size (projected distance) 30" to 300" (1.0m to 11.7m)
Keystone Correction +/- 15 degrees
Brightness (typical) 2000 ANSI lumens
Contrast Ratio 400:1
Brightness Uniformity (typical) 85%
Color Reproduction 24 bit; 16.7ml
Sound Output 1W
Operating Temperature 5°C to 35°C (41°F to 95°F)
Power Supply Voltage 100-120V, 200-240V +/-10%, 50/60Hz AC
Power Consumption 225W / 5.5W at sleep mode
Maximum Dimensions D x W x H
(includes lens and feet) 7.5" x 10.9" x 3.1"
(excludes lens and feet) 7.5" x 10.9" x 2.7"
Weight 4.4 lbs/1.9kg
Fan Noise 39db
Effective Scanning Frequency Range
Pixel Clock 13.5MHz to 162MHz
Horizontal 15KHz to 92KHz
Vertical 50Hz to 85Hz
Remote Control
Features Keystone, special effects, source selection,
power, color mode, page up/down,
volume, presets
Operating Angle +/_ 30° horizontally
+/_ 15° vertically
Operating Distance 20ft (6m)
RGB Analog RGB I/O
Display performance
Native 1024 x 768
Resize 1600 x 1200
1280 x 1024
800 x 600
640 x 480
Input terminal
Video Mini D-sub 15pin x 1
Audio Stereo mini jack
Card I/O
PC card slot PCMCIA type I/II
Memory card Compact Flash, Smart Media, Memory Stick,
compatibility SD, MMC, 3.3 volts type ATA Flash card,
5 volts type ATA Flash card, IBM MicroDrive™
Other Wireless LAN card (standard accessory only)
Wired LAN card
Video I/O
Display performance 550 TV Line
Input signal NTSC/NTSC4.43/PAL/M-PAL/
N-PAL/PAL60/SECAM
Input terminal
Video HDTV: 480i, 480p, 720p,1080i
Composite Video: RCA x 1
S-Video: Mini DIN
Component Video: Mini D-sub 15pin
(in common with Analog RGB connector);
Video RGB: Mini D-sub 15pin
(in common with Analog RGB connector)
Audio Stereo mini jack
(in common with Analog RGB audio jack)
Audio signal 500m Vrms/47Kohm
Control I/O
I/O terminal USB type B x 1 (for mouse, keyboard control
and RS-232 communication)
Security Kensington®-style lock provision
Warranty
Standard two year limited warranty, 2-year international warranty, 90-day
lamp warranty, EPSON Road Service Program and EPSON PrivateLine
dedicated toll-free support (U.S. and Canada only)
Supplied Accessories
Power cable, card type remote control with lithium battery, computer cable
HD15/HD15, RCA video cable, USB mouse cable, Wireless LAN card, Start
Here Kit, CD-Rom, soft carrying case
Product/Accessory Part Numbers
EPSON PowerLite 735c Projector V11H103020
Replacement lamp V13H010L18
Samsonite wheeled soft case (16.75" x 15" x 9") ELPKS24
Soft shoulder bag ELPKS31
Notebook/projector soft shoulder bag ELPKS32
ATA wheeled hardshell notebook/projector case ELPKS42
Ceiling mount ELPMB37
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Distribution amplifier ELPDA01
Component video cable ELPKC19
S-video cable ELPSV01
Mac adapter set ELPAP01
50" portable projection screen ELPSC06
60" portable pop-up screen ELPSC07
80" portable pop-up screen ELPSC08
High resolution document imager ELPDC02
High resolution document camera V12H064020
Kensington security lock ELPSL01
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
SM
EPSON PowerLite 735c Specifications
Specifications and terms are subject to change without notice. EPSON is a registered trademark and EasyManagement is a trademark of Seiko Epson Corporation. PowerLite is a registered trademark, SizeWise is a
trademark and Epson Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective
companies. Epson disclaims any and all rights in these marks. © Copyright 2003 Epson America, Inc. CPD-15540 25K 2/03 CL Printed on Recycled Paper
