EPSON PRODUCT SUPPORT BULLETIN
Date: 04/20/2009 Originator: JAM
PSB #: PSB.2009.06.001 Authorization:
Reference: TI 09-05e Rev. A/B Total Pages: 5
Product(s): PowerLite 735c / Cinema 500 / 737c / 745c / 755c / 765c / 830p / 835p /
1705c / 1715c / 6100i / 6110i / 7800p / 7850p / 7900NL / 8300i / 8300i with
EasyMP.net module / 9300NL / 1815p / 1825 / 822p / 83c / 822+ / 83+ /
G5000 / Pro G5150 / Pro G5350 / Pro G5200W / 1725 / 1735W / 400W /
410W / 84 / 85 / 825 / 826W
PowerLite 61p / 81p / 82c / 821p / 1810 / 260d (Latin America) / 280d (Latin
America) with TCP/IP to Serial converter
Subject: Release of EMP Monitor for Windows version 4.30
This bulletin was created to inform you of the release of the new version 4.30 of the Epson
EMP Monitor software utility.
Description of Change:
Improvements have been made to the EMP Monitor software utility.
Note: For the PowerLite 61p / 81p / 82c / 821p / 1810 / 260d (Latin America) / 280d (Latin
America) models, a serial to TCP/IP conversion adapter is necessary. The function of Auto
Update does not work for these models. You need to manually click on refresh to get an
updated status of projectors.
Reason:
The improved points of version 4.30 are as follows:
Application EMP Monitor
Version
upgraded Version 4.22 ÆVersion 4.30
Improved
points (1) Addition of 7 new languages
-Indonesian, Croat, Slovak, Bulgarian, Malay, Vietnamese, and
Hebrew
Existing 27 languages
-Chinese (Traditional), Netherlands, Danish, Polish, Hungarian,
Czech, Romanian, Slovene, Norwegian, Swedish, Finnish, Russian,
Ukrainian, Greek, Turkish, Arabic (Windows NT4 does not support),
English, Japanese, French, German, Italy, Spanish, Portuguese,
Chinese (Simplified), Korean, Catalan, Thai
Page 1 of 4
PSB.2009.06.001

(2) Addition of Input Source (Only PowerLite 84 / 85 / 825 / 826W)
Previous version of EMP Monitor included USB Display, USB and LAN as
one source: EasyMP.
The input source buttons for USB display, USB, and LAN are available as
separate input sources as shown below:
- Old version - EMP Monitor V4.22
EMP Monitor V4.22
- New version - EMP Monitor V4.30
EMP Monitor V4.30
.
(3) New feature for the PowerLite 84 / 85 / 825 / 826W.
Displays projector’s serial number in the Menu settings
-The projector’s serial number is now displayed in the projector’s
menu under “info”,
-EMP Monitor can also display the projector’s serial number as
shown below:
Page 2 of 4
PSB.2009.06.001

Limitations When the PowerLite1725 / 1735W exhibit a Lamp Cover Open error state,
EMP Monitor cannot detect the error. The reason is that when the lamp
cover is opened, the primary power source that reports the error state to
EMP Monitor is turned off immediately. This is different from other models
which make the secondary power source turn off under the same condition.
Note: EMP Monitor Ver. 4.xx is not compatible with EMP Monitor Ver. 3.05 and earlier
versions. EMP Monitor Ver. 4.xx cannot read the setting files of EMP Monitor Ver. 3.05
and earlier versions.
System Requirements:
OS •Windows 98 SE / Me / NT 4.0 (SP6) *Except Arabic and
Hebrew / Windows 2000 Pro / XP Home Edition / XP
Professional (32 bit) / Vista Home Basic / Home Premium /
Ultimate / Business / Enterprise (32 bit) *Except Ukrainian /
Vista SP1 Home Basic / Home Premium / Ultimate /
Business / Enterprise (32 bit)
•Internet Explorer Ver. 5.0 or later must be installed
CPU Minimum: Pentium MMX 166 MHz (Recommended: Pentium II
233 MHz or higher)
Memory At least 64 MB (Recommended: 128 MB or above)
Available hard disk
space At least 50 MB
Display SVGA (800×600) or higher resolution, 32 bit or higher display
color
Obtaining the Update:
Download epson13055.exe from www.epson.com to get the version 4.30 update for EMP
Monitor. The files are extracted and copied to C:\EPSON\epson13055_emp_monitor_430.
This file is a self-extracting archive and will start the installation utility for EMP Monitor. Follow
the on-screen instructions during the installation process.
Page 3 of 4
PSB.2009.06.001

Software Upgrade History:
Version Release date Remarks
3.00 December
25,2002 Supported PowerLite 735c
3.01 February
26,2003 Supported PowerLite 7800p / 8300i
3.02 April
18,2003 Supported PowerLite 7850p / 8300i with EasyMP.net option module
3.03 November
21,2003 Supported PowerLite Cinema 500
3.04 April
1, 2004 Supported Serial -TCP/IP conversion adapter for PowerLite 61p / 81p
4.01 October
18, 2004 Supported projectors that are configured on a large-scale network.
4.02 August
29, 2005 Addition of timer function and auto search function by specifying IP addresses.
Improvement of communication logs size.
4.10 May
8, 2006 Addition of new functions, Improvement of usability, and Corresponding to PowerLite 6100i.
4.20 May
15, 2007 EMP NS Connection V2.20 supports Windows Vista (Home Basic / Home Premium / Ultimate / Business / Enterprise).
4.21 September
26, 2007 Supported 25 languages
4.22 March 31, 2008 Supported 27 languages
Addition of new Error Information
Supported Video (BNC)
4.30 April 3, 2009 Supported 34 languages
Additional Input Sources
Displays projector’s serial number in Menu settings
Page 4 of 4
PSB.2009.06.001

Page 1 of 5
PSB.2007.09.001
EPSON PRODUCT SUPPORT BULLETIN
Date: 09/25/2007 Originator: DJS
PSB #: PSB.2007.09.001 Authorization:
Reference: TI 06-91e Rev. B Total Pages: 5
Product(s): PowerLite 755c / 765c / 835p / 1705c / 1715c / 1815p
Subject: EPSON Projector control for Win V.1.00 release
This bulletin was created to inform you on the release of the new Epson Projector Control
software version 1.00.
Description:
EPSON Projector Control lets you control the projector from your computer with a one-on-one
connection between your computer and the projector over a network. It allows you to perform
operations, such as turning the projector on/off and switching sources, from your computer
without using the projector’s remote control.
Function:
EPSON Projector Control has 2 modes: Advanced Mode and Simple Mode.
Although there is a difference in main display layouts between the two modes, their operation
procedures are almost the same. The difference is as follows:
Advanced Mode: Each source has each source button. Therefore source can be selected
by clicking each source button directly.
Simple Mode:  Source buttons are toggle-type. Therefore source can be switched every
time the toggle-type button is pressed.
[1] Advanced Mode
The main display is larger than that of Simple Mode. Each source has a source button,
so the source can be selected by clicking the applicable source button directly.

Page 2 of 5
PSB.2007.09.001
Button Functions
For Advanced Mode
Button Function
Power Turns the projector power on/off.
Computer1 Switches the input source to the Computer1
input port.
Computer2 Switches the input source to the Computer2
input port.
EasyMP Switches the input source to EasyMP.
Video Switches the input source to the Video input
port.
S-Video Switches the input source to the S-Video input
port.
A/VMute Turns the A/V Mute function on/off on the
projector.
Freeze Turns the Freeze function on/off on the
projector.
CC Displays the selection menu for Closed
Caption.
Select one of the following: "OFF," “CC1,” or
“CC2."
This function may not be available depending
on the projector models.
Volume  Turns the volume up on the projector.
Volume  Turns the volume down on the projector.
Switches between Advanced Mode and Simple
Mode.
[2] Simple Mode
•You need to switch sources by using the toggle-type button but the main display is
simpler.

Page 3 of 5
PSB.2007.09.001
For Simple Mode
There is a difference in the following buttons between
Simple Mode and Advanced Mode.
Button Function
Computer Switches the input sources among the Computer
input port, the Computer1 input port, the
Computer2 input port, and EasyMP.
Every time you click the button, the source
changes in the following order.
Computer input port or Computer1 input port->
Computer2 input port→EasyMP-> Computer
input port or Computer1 input port…
Video Switches the input sources between the Video
input port and the S-Video input port.
Every time you click the button, the source
changes in the following order.
Video input port-> S-Video input port-> Video
input port
Item Function
Register at startup Check this for EPSON Projector Control to start
up automatically when the computer starts.
Projector IP Address Enter the IP address for the projector to be
connected. You need to do this only when you
make a connection for the first time or when
you want to change to another projector to be
connected.
Monitor Password Enter the Monitor Password that is set on the
projector. You do not need to do this when the
Monitor Password is not set on the projector.
OK Click this to reflect the setting changes that you
made. The setting screen is saved and closed.
Or
Click × on the title bar not to reflect the setting
changes.
Cancel Click this to abort the setting changes.

Page 4 of 5
PSB.2007.09.001
Settings Display
Uncheck the boxes for
the buttons that you do
not want to display in
Simple Mode.
Uncheck the boxes for the buttons
that you do not want to display in
Advanced Mode.
[3] How to set up EPSON Projector Control software
[Note] Be sure to set the projector to Network ON in Standby Mode in the Extended Menu.
1) Download “Epson12378.exe” from Epson website. This file contains
“ProjectorControlSetup.exe” which is used to install EPSON Projector Control for
Windows V.1.00 on the computer.
2) Set up your computer and the projector to connect over a network.
3) Start the EPSON Projector Control software as follows: “Start”Æ“Program”Æ“EPSON
Projector”Æ“Projector Control V1.00.” Then the main screen is displayed. Click
“Tool”Æ“Settings” on the main screen. The setting screen is displayed.
4) Enter the Projector IP Address, click “OK” to save, and close the setting screen.

Page 5 of 5
PSB.2007.09.001
Operation Environment
[EPSON Projector Control V.1.00]
Operation Environment:
OS Windows 2000 SP4 / XP SP2 32-bit (Professional / Home) /
Vista 32-bit (Business / Enterprise / Home Basic / Home
Premium / Ultimate)
CPU At least Pentium MMX 166MHz
(Pentium II 233MHz or later recommended)
Memory At least 64MB
HDD space At least 50MB
Display SVGA (800×600) or higher resolution / At least 32-bit color
Additional Note:
Other Epson projector models supported:
PowerLite 6100i / 830p / 83c / 822p
Projector models not supported:
PowerLite 735c / 732c / 737c / 745c / 7800p / 7850p / 7900p / 8300i with the
EasyMP.net Option Module installed/ 9300i

Page 1 of 1
PSB.2006.04.002
EPSON PRODUCT SUPPORT BULLETIN
Date: 04/20/2006 Originator: AP
PSB #: PSB.2006.04.002 Authorization:
Reference: TI 05-95e Rev. A Total Pages: 1
Product(s): PowerLite 735c / 737c / 745c / 755c / 765c / 835p / 7850p
Subject: Animation converter issue found with EMP SlideMaker2 version 1.12
This bulletin was created to inform users of the EMP SlideMaker2 version 1.12 software of a
problem converting certain animations from Microsoft PowerPoint into a Scenario file.
Details:
In the previous EMP SlideMaker2 version 1.11, certain PowerPoint animations were supported
in the Scenario files which are created by EMP SlideMaker2. Table 1 shows the list of
animations supported in EMP SlideMaker2 version 1.11:
Table 1
Table 2 shows the list of animations from Table 1 that will not be ported from PowerPoint into
the Scenario file by EMP SlideMaker2 version 1.12:
Table 2
Countermeasure:
If it is necessary to use these animations in the Scenario files, use EMP SlideMaker2 version
1.11. Versions of EMP SlideMaker2 subsequent to version 1.12 are expected to incorporate
the animations shown in Table 1 above.
EMP SlideMaker2 version 1.11 may be downloaded at www.epson.com. Download
epson10855.exe to get this version of the software.
If it is not necessary to use these animations listed in Table 2 above, continue to use the EMP
SlideMaker2 version 1.12. Download epson11217.exe at www.epson.com for EMP
SlideMaker2 version 1.12.
- Fly - Blinds - Box - Checkerboard
- Crawl - Dissolve - Peek - Random Bars
- Spiral - Split - Stretch - Strips
- Swivel - Wipe - Zoom
- Crawl - Peek
- Spiral - Stretch
- Swivel - Zoom

Page 1 of 2
EPSON PRODUCT SUPPORT BULLETIN
Date: 06/30/2000 Originator: ESC
PSB #: PSB.2000.07.001 Authorization:
Reference: N/A Total Pages: 2
Product(s): Multimedia Projectors
Subject: Multimedia Projector Accessories – Ceiling Mounts and Suspension Adapters
This bulletin provides specification and warranty information on Ceiling Mounts and
Suspension Adapters for EPSON Multimedia Projectors:
CEILING MOUNTS:
Part Number: ELPMB31
Compatibility: PowerLite 5300, 5350, 7200, 7250, 7300, 7350,
8000i, 8000NL, 9000i and 9000NL
Dimension: 11.6” x 10.8” x 1.5”
Part Number: ELPMB32
Compatibility: PowerLite 500C, 700C and 710C
Dimension: 7.2” x 9” x 1.5”
Part Number: ELPMB33
Compatibility: PowerLite 5500C, 5550C, 7500C, and 7550C
Dimension: 10.7” x 9.6” x 1.8”
Warranty: 30-days whole unit exchange
Description: Epson’s ceiling mounts provide the added flexibility of
mounting a PowerLite projector on the ceiling. They are
designed to be installed easily and include a quick release
feature for removal of the projector so it’s easy to change the
lamp, or remove the projector for portable use. The ceiling
mounts can also be used for rear projection applications.
Each ceiling mount is custom designed for use with a specific
Epson projector.

Page 2 of 2
SUSPENSION ADAPTERS:
Part Number: ELPMBAST
Compatibility: ELPMB31, ELPMB32 and ELPMB33
Dimension: 1 l/2” Pipe
Part Number: ELPMBAPS
Compatibility: ELPMB32 and ELPMB33
Dimensions: 1” Pipe
Warranty: 30-days whole unit exchange
Description: Adjustable tubing extensions to increase the distance from the
ceiling to the projector—adjustable from 12” to 46”.

Page 1of 1
EPSON PRODUCT SUPPORT BULLETIN
Date: 06/02/2000 Originator: ESC
PSB #: PSB.2000.06.001 Authorization:
Reference: N/A Total Pages: 1
Product(s): Multimedia Projectors
Subject: Projector Compatibility with iMac’s
This bulletin provides useful information on how to connect EPSON Multimedia Projectors to
iMac models that have no external video port and have Mac OS 8.1, 8.5 or 8.6 factory
installed.
Problem:
The earlier versions of the iMac’s do not have an external video port to connect an EPSON
projector. It is possible to output video signal from the iMacs by using a third party external
video adapter.
Resolution:
The current line of EPSON's multimedia projectors do support the iMacs, using the
recommended third party external video adapter from PowerR, at the supported video
resolution 1024 x 768 with refresh rate of 75Hz. The iPresenter video adapter is
a compact device that installs into an Apple iMac computer.
iPresenter RGB Video Adapter for iMac
Model: iP-10
Power R Inc.
756 Aloha Street
Seattle, WA. 98109
[phone]
www.powerr.com
Supports iMac version:Supported Video Resolution
Versions A,B,C,D – no video out 1024 x 768, 75Hz

Page 1of 1
EPSON PRODUCT SUPPORT BULLETIN
Date: 05/18/2000 Originator: AP
PSB #: PSB.2000.05.001 Authorization:
Reference: N/A Total Pages: 1
Product(s): Multimedia Projectors
Subject: Multi-Monitor Support Function of Newer Macintosh Notebook Computers
This bulletin provides configuration procedures for the newer Macintosh notebook computers
with the EPSON Multimedia Projectors.
Problem description:
When the projector is connected to an Apple notebook, part of the Mac OS desktop may not
display on either the LCD panel or the projector. Often, only the desktop wallpaper is visible on
one screen, with the other containing the complete video output.
Reason:
Newer Macintosh notebook computers are often configured for extended desktop video output
instead of video mirroring. This results in partial information being sent to either the LCD
panel or the projector. This feature has been observed on Powerbook and G3 Powerbook
models running Mac OS 8.x and later, but it is possible the issue has been experienced by
other Macintosh users.
Resolution:
1. Click the Apple Menu to select the Control Panels, Monitors and Sound option.
When the projector is powered on while connected to the computer, there will be an
“Arrange” icon in the Monitors and Sound control panel.
2. Click the “Arrange” icon to access that control. In the “Arrange” control view window, there
should be icons for two monitors.
3. Click one of the monitor icons and drag it on top of the other monitor icon. Release that
icon on the other icon. This enables dual display support where both screens receive and
display all video information.
