Epson DS-410 User manual

User's Guide
NPD5669-02 EN

Copyright
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of
Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained
herein. Neither is any liability assumed for damages resulting from the use of the information herein. e
information contained herein is designed only for use with this Epson product. Epson is not responsible for any
use of this information as applied to other products.
Neither Seiko Epson Corporation nor its aliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or
abuse of this product or unauthorized modications, repairs, or alterations to this product, or (excluding the U.S.)
failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.
Seiko Epson Corporation and its aliates shall not be liable for any damages or problems arising from the use of
any options or any consumable products other than those designated as Original Epson Products or Epson
Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that
occurs from the use of any interface cables other than those designated as Epson Approved Products by Seiko
Epson Corporation.
© 2017 Seiko Epson Corporation
e contents of this manual and the specications of this product are subject to change without notice.
User's Guide
Copyright
2

Trademarks
❏EPSON
®
is a registered trademark, and EPSON EXCEED YOUR VISION or EXCEED YOUR VISION is a
trademark of the Seiko Epson Corporation.
❏Microso, Windows, Windows Server, and Windows Vista are either registered trademarks or trademarks of
Microso Corporation in the United States and/or other countries.
❏Apple, macOS, and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.
❏Adobe, Adobe Reader, and Acrobat are registered trademarks of Adobe Systems Incorporated.
❏Intel
®
is a registered trademark of Intel Corporation.
❏Epson Scan 2 Soware is based in part on the work of the Independent JPEG Group.
❏libti
Copyright © 1988-1997 Sam Leer
Copyright © 1991-1997 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this soware and its documentation for any purpose is
hereby granted without fee, provided that (i) the above copyright notices and this permission notice appear in
all copies of the soware and related documentation, and (ii) the names of Sam Leer and Silicon Graphics
may not be used in any advertising or publicity relating to the soware without the specic, prior written
permission of Sam Leer and Silicon Graphics.
THE SOFTWARE IS PROVIDED “AS-IS” AND WITHOUT WARRANTY OF ANY KIND, EXPRESS,
IMPLIED OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER OR NOT ADVISED
OF THE POSSIBILITY OF DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING OUT OF OR IN
CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
❏General Notice: Other product names used herein are for identication purposes only and may be trademarks
of their respective owners. Epson disclaims any and all rights in those marks.
User's Guide
Trademarks
3

Contents
Copyright
Trademarks
About This Manual
IntroducingtheManuals.....................6
MarksandSymbols.........................6
DescriptionsUsedinthisManual...............6
OperatingSystemReferences..................7
Important Instructions
SafetyInstructions..........................8
RestrictionsonCopying......................9
Scanner Basics
PartNamesandFunctions...................10
ButtonsandLightsontheControlPanel.........12
ButtonsandLights.......................12
ErrorIndicators.........................13
PageSeparationLever...................... 13
InformationonApplications..................14
EpsonScan2...........................14
Document Capture Pro / Document Capture. . . .14
EPSONSowareUpdater..................15
Option Items and Consumables Information. . . . . . 15
CarrierSheetCodes......................15
RollerAssemblyKitCodes.................16
Specications of Originals and
Placing Originals
Specications ofOriginals................... 17
General Specications for Originals being
Scanned.............................. 17
Types of Originals that Require Attention. . . . . . 20
Types of Originals that Must Not be Scanned. . . .21
PlacingOriginals..........................22
StandardSizeOriginals................... 22
LongPaper............................25
Receipts...............................28
PlasticCards...........................29
LargeSizeOriginals......................32
IrregularShapedOriginals.................37
Photographs........................... 40
Envelopes............................. 43
MixtureofOriginals......................45
Basic Scanning
ScanningUsingEpsonScan2.................48
Required Settings for Special Originals in
EpsonScan2...........................51
Setting a Resolution at Suits the Scanning
Purpose...............................51
Scanning Using Document Capture Pro
(Windows)...............................52
Scanning Using Document Capture (Mac OS). . . . . 57
Enabling a Job to Run from the Control Panel
(ButtonAssignment).......................63
Assigning a Job to the Control Panel
(Windows).............................64
Assigning a Job to the Control Panel (Mac OS). . 64
ScanningUsingaScannerButton..............65
Advanced Scanning
Scanning Dierent Sizes or Types of Originals
OnebyOne(AutomaticFeedingMode).........66
CreatingScannedImagestoSuitYourNeeds......67
ImageAdjustmentFeatures................ 67
SavingasaSearchablePDF.................73
Saving as an Oce Format File (for Windows
Only)................................ 74
SettingaJob(Scan,Save,andSend)............ 76
Creating and Registering a Job (Windows). . . . . .76
Creating and Registering a Job (Mac OS). . . . . . .77
SeparationFeature(forWindowsOnly)..........77
Sorting and Saving Scanned Images into a
SeparateFolder.........................79
Maintenance
CleaningOutsidetheScanner.................85
CleaningInsidetheScanner..................85
ReplacingtheRollerAssemblyKit..............89
ResettingtheNumberofScans..............93
EnergySaving............................94
TransportingtheScanner....................95
UpdatingApplicationsandFirmware...........96
User's Guide
Contents
4

Solving Problems
ScannerProblems......................... 98
ScannerLightsIndicateanError.............98
e ScannerDoesNotTurnOn.............98
ProblemsStartingScanning..................98
CannotStartEpsonScan2.................98
Pressing a Scanner Button Does Not Start the
CorrectApplication......................99
Paper Feeding Problems. . . . . . . . . . . . . . . . . . . . . 99
MultipleOriginalsAreFed.................99
Removing Jammed Originals from the Scanner. . 99
e Original Jams in the Scanner Frequently. . . 101
DetectDoubleFeedDoesNotWork.........101
PaperProtectionDoesNotWork........... 102
e OriginalsGetDirty..................102
ScanningTakesaLongTime...............102
ScannedImageProblems...................103
Straight Lines Appear when Scanning from
ADF................................103
eImageQualityisRough...............103
ColorsBleed.......................... 103
Expanding or Contracting the Scanned Image. . 104
Oset Appears in the Background of Images. . . 104
TextisBlurred.........................104
Moiré Patterns (Web-Like Shadows) Appear. . . 105
e Edge of the Original is Not Scanned
when Automatically Detecting the Size of the
Original..............................105
Text is Not Recognized Correctly when
SavingasaSearchablePDF................105
Cannot Solve Problems in the Scanned Image. . 106
UninstallingandInstallingApplications........ 107
UninstallingYourApplications.............107
InstallingYourApplications...............108
Technical Specications
General Scanner Specications...............109
DimensionalSpecications..................110
Electrical Specications.................... 110
ScannerElectricalSpecications............110
AC Adapter Electrical Specications.........110
EnvironmentalSpecications................110
SystemRequirements......................111
Standards and Approvals
Standards and Approvals for U.S. Models. . . . . . . .112
Standards and Approvals for European Models. . . 112
Where to Get Help
TechnicalSupportWebSite..................113
ContactingEpsonSupport..................113
BeforeContactingEpson................. 113
HelpforUsersinEurope..................113
HelpforUsersinSingapore............... 114
HelpforUsersinailand................ 114
HelpforUsersinVietnam.................114
HelpforUsersinIndonesia................115
HelpforUsersinMalaysia................ 116
HelpforUsersinIndia...................117
HelpforUsersinthePhilippines............117
User's Guide
Contents
5

About This Manual
Introducing the Manuals
e latest versions of the following manuals are available from the Epson support website.
http://www.epson.eu/Support (Europe)
http://support.epson.net/ (outside Europe)
❏Setup Guide (paper manual)
Provides you with information on setting up the product and installing the application.
❏User's Guide (digital manual)
Provides instructions on using the product, maintenance, and solving problems.
As well as the manuals above, see the help included in the various Epson applications.
Marks and Symbols
!
Caution:
Instructions that must be followed carefully to avoid bodily injury.
c
Important:
Instructions that must be observed to avoid damage to your equipment.
Note:
Provides complementary and reference information.
Related Information
&Links to related sections.
Descriptions Used in this Manual
❏Screenshots for the applications are from Windows 10 or macOS Sierra. e content displayed on the screens
varies depending on the model and situation.
❏Illustrations used in this manual are for reference only. Although they may dier slightly from the actual
product, the operating methods are the same.
User's Guide
About This Manual
6

Operating System References
Windows
In this manual, terms such as "Windows 10", "Windows 8.1", "Windows 8", "Windows 7", "Windows Vista",
"Windows XP", "Windows Server 2016", "Windows Server 2012 R2", "Windows Server 2012", "Windows Server 2008
R2", "Windows Server 2008", "Windows Server 2003 R2", and "Windows Server 2003" refer to the following
operating systems. Additionally, "Windows" is used to refer to all versions and "Windows Server" is used to refer to
"Windows Server 2016", "Windows Server 2012 R2", "Windows Server 2012", "Windows Server 2008 R2", "Windows
Server 2008", "Windows Server 2003 R2", and "Windows Server 2003".
❏Microso
®
Wi n d o w s
®
10 operating system
❏Microso
®
Wi n d o w s
®
8.1 operating system
❏Microso
®
Wi n d o w s
®
8 operating system
❏Microso
®
Wi n d o w s
®
7 operating system
❏Microso
®
Wi n d o w s Vi s t a
®
operating system
❏Microso
®
Wi n d o w s
®
XP operating system Service Pack 3
❏Microso
®
Wi n d o w s
®
XP Professional x64 Edition operating system Service Pack 2
❏Microso
®
Wi n d ow s S e r v e r
®
2016 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2012 R2 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2012 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2008 R2 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2008 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2003 R2 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2003 operating system Service Pack 2
Mac OS
In this manual, "Mac OS" is used to refer to macOS Sierra, OS X El Capitan, OS X Yosemite, OS X Mavericks, OS X
Mountain Lion, Mac OS X v10.7.x, and Mac OS X v10.6.8.
User's Guide
About This Manual
7

Important Instructions
Safety Instructions
Read and follow these instructions to ensure safe use of this product and options. Make sure you keep this manual
for future reference. Also, be sure to follow all warnings and instructions marked on the product and options.
❏Some of the symbols used on your product and options are to ensure safety and proper use of the product. Visit
the following Web site to learn the meaning of the symbols.
http://support.epson.net/symbols
❏Place the product and options on a at, stable surface that extends beyond the base of the product and options
in all directions. If you place the product and options by the wall, leave more than 10 cm between the back of
the product and options and the wall.
❏Place the product and options close enough to the computer for the interface cable to reach it easily. Do not
place or store the product and options or the AC adapter outdoors, near excessive dirt or dust, water, heat
sources, or in locations subject to shocks, vibrations, high temperature or humidity, direct sunlight, strong light
sources, or rapid changes in temperature or humidity.
❏Do not use with wet hands.
❏Place the product and options near an electrical outlet where the adapter can be easily unplugged.
❏e AC adapter cord should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place
objects on top of the cord and do not allow the AC adapter or the cord to be stepped on or run over. Be
particularly careful to keep the cord straight at the end.
❏Use only the power cord supplied with the product and do not use the cord with any other equipment. Use of
other cords with this product or the use of the supplied power cord with other equipment may result in re or
electric shock.
❏Use only the AC adapter that comes with your product. Using any other adapter could cause re, electrical
shock, or injury.
❏e AC adapter is designed for use with the product with which it was included. Do not attempt to use it with
other electronic devices unless specied.
❏Use only the type of power source indicated on the AC adapter’s label, and always supply power directly from a
standard domestic electrical outlet with the AC adapter that meets the relevant local safety standards.
❏When connecting this product and options to a computer or other device with a cable, ensure the correct
orientation of the connectors. Each connector has only one correct orientation. Inserting a connector in the
wrong orientation may damage both devices connected by the cable.
❏Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and o.
❏If you use an extension cord with the product, make sure the total ampere rating of the devices plugged into the
extension cord does not exceed the cord’s ampere rating. Also, make sure the total ampere rating of all devices
plugged into the wall outlet does not exceed the wall outlet’s ampere rating.
❏Never disassemble, modify, or attempt to repair the AC adapter, product, or product options by yourself except
as specically explained in the product’s guides.
❏Do not insert objects into any opening as they may touch dangerous voltage points or short out parts. Beware of
electrical shock hazards.
❏If damage occurs to the plug, replace the cord set or consult a qualied electrician. If there are fuses in the plug,
make sure you replace them with fuses of the correct size and rating.
User's Guide
Important Instructions
8

❏Unplug the product, options, and the AC adapter, and refer servicing to qualied service personnel under the
following conditions: e AC adapter or plug is damaged; liquid has entered the product, options, or the AC
adapter; the product or the AC adapter has been dropped or the case has been damaged; the product, options,
or the AC adapter does not operate normally or exhibits a distinct change in performance. (Do not adjust
controls that are not covered by the operating instructions.)
❏Unplug the product and the AC adapter before cleaning. Clean with a damp cloth only. Do not use liquid or
aerosol cleaners except as specically explained in the product’s guides.
❏If you are not going to use the product for a long period, be sure to unplug the AC adapter from the electrical
outlet.
❏Aer replacing consumable parts, dispose of them correctly following the rules of your local authority. Do not
disassemble them.
Restrictions on Copying
Observe the following restrictions to ensure the responsible and legal use of your product.
Copying of the following items is prohibited by law:
❏Bank bills, coins, government-issued marketable securities, government bond securities, and municipal
securities
❏Unused postage stamps, pre-stamped postcards, and other ocial postal items bearing valid postage
❏Government-issued revenue stamps, and securities issued according to legal procedure
Exercise caution when copying the following items:
❏Private marketable securities (stock certicates, negotiable notes, checks, etc.), monthly passes, concession
tickets, etc.
❏Passports, driver’s licenses, warrants of tness, road passes, food stamps, tickets, etc.
Note:
Copying these items may also be prohibited by law.
Responsible use of copyrighted materials:
Products can be misused by improperly copying copyrighted materials. Unless acting on the advice of a
knowledgeable attorney, be responsible and respectful by obtaining the permission of the copyright holder before
copying published material.
User's Guide
Important Instructions
9

Scanner Basics
Part Names and Functions
Front
AADF (Automatic Document Feeder) Feeds loaded originals automatically.
BEdge guides Feeds originals straight into the scanner. Slide to the edges of the
originals.
CInput tray Loads originals. Pull out the tray extension if originals are too big
for the input tray. This prevents paper from curling and causing
paper jams.
DInput tray extension
EOutput tray Holds originals ejected from the scanner. Pull out the extension
tray to the length of the originals.
FOutput tray extension
GStopper Prevents ejected originals from falling o the extension tray. Adjust
it to the length of the originals.
User's Guide
Scanner Basics
10

Back
ASecurity slot Inserts a security lock for theft prevention.
BUSB port Connects a USB cable.
CDC inlet Connects the AC adapter.
Inside
AScanner cover Pull the cover open lever and open the scanner cover when
cleaning inside of the scanner and removing jammed paper.
BCover open lever Pull the cover open lever and open the scanner cover.
CPickup roller Feeds originals. This needs to be replaced when the number of
scans exceeds the service number of papers.
Replace both upper and lower rollers.
DSeparation roller Feeds originals separately one by one. This needs to be replaced
when the number of scans exceeds the service number of papers.
Related Information
&“Cleaning Inside the Scanner” on page 85
&“Replacing the Roller Assembly Kit” on page 89
User's Guide
Scanner Basics
11

Buttons and Lights on the Control Panel
Buttons and Lights
APower button Turns the scanner on or o.
Power light On: The scanner is ready to be used.
Flashing: The scanner is scanning, waiting to scan, processing,
or sleeping.
O: The scanner cannot be used because the power is o
or an error has occurred.
BAutomatic Feeding Mode
light
The scanner is in Automatic Feeding Mode. Scanning starts when an
original is placed in the input tray.
CError light An error has occurred. See “Error Indicators” for more details.
DStop button ❏Cancels scanning.
❏Finishes Automatic Feeding Mode.
EStart button ❏Starts scanning.
❏Press this when cleaning the inside of the scanner.
Related Information
&“Error Indicators” on page 13
&“Scanning Dierent Sizes or Types of Originals One by One (Automatic Feeding Mode)” on page 66
&“Cleaning Inside the Scanner” on page 85
User's Guide
Scanner Basics
12

Error Indicators
Scanner errors
Indicators Situation Solutions
Flashing
On
A paper jam or double feed occurred. Open the scanner cover, and then re-
move jammed originals. Close the cov-
er to release the error. Load the origi-
nals again.
The scanner cover is opened. Close the scanner cover.
Flashing
Flashing
Flashing simultaneously
A fatal error has occurred. Turn the power o and on again. If the
error continues to occur, contact your
local dealer.
O
On
On
The scanner has started in recovery
mode because the rmware update
failed.
Follow the steps below to try to up-
date the rmware again.
1. Connect the computer and the scan-
ner with a USB cable. (During recovery
mode, you cannot update the rm-
ware over a network connection.)
2. Visit your local Epson website for fur-
ther instructions.
Related Information
&“Removing Jammed Originals from the Scanner” on page 99
Page Separation Lever
Change the position of the page separation lever depending on the type of document you are going to scan.
User's Guide
Scanner Basics
13

Separation feeding You should normally use separation feeding. Documents with
multiple pages are fed one sheet at a time.
Non Separation feeding Use this when scanning special documents such as folded
documents, plastic cards, carrier sheets, and so on.
Scanning is performed without separating the documents.
Information on Applications
is section introduces the soware products available for your scanner. e latest soware can be installed at the
Epson Web site.
Epson Scan 2
Epson Scan 2 is a driver for controlling your scanner, enabling a variety of scan settings. is also allows you to
start either as a standalone application or by using TWAIN-compliant application soware.
See the Epson Scan 2 help for details on using the application.
Document Capture Pro / Document Capture
Document Capture Pro is an application that allows you to easily digitize originals such as documents and forms.
You can save scanned images to a specied folder, send by email, and perform copying functions by linking to a
printer. You can also split documents by using separation information such as barcodes and automatically process
new les. is allows you to streamline the way electronic documents are handled, such as reading large
documents and making best use of network capabilities.
Document Capture Pro is for Windows only. For Mac OS, use Document Capture.
See the Document Capture Pro help (Windows) or Document Capture help (Mac OS) for details on using the
application.
Note:
Document Capture Pro does not support Windows Vista, Windows XP, and Windows Server.
Job:
When performed in order, the following operations are known as a job: 1. Scan > 2. Save > 3. Send.
By registering a series of operations in advance as a job, you can perform all of the operations by simply selecting
the job. By assigning a job to the scanner’s control panel, you can start a job from the control panel (Button
Assignment).
User's Guide
Scanner Basics
14

Separation Function:
You can automatically process complicated sorting or organizing by using a variety of detection methods such as
blank pages with/without barcodes which are inserted between the originals, or barcodes on the originals.
You can also sort multiple scanned images as separate les and save each le in specic folders by using these
methods or by setting specic pages.
EPSON Software Updater
EPSON Soware Updater is an application that checks for new or updated applications on the internet and installs
them.
You can also update the scanner’s digital manual.
Note:
Windows Server operating systems are not supported.
Option Items and Consumables Information
Carrier Sheet Codes
Using a Carrier Sheet allows you to scan irregular shaped originals or photos that can be easily scratched. You can
scan originals larger than A4 size with a carrier sheet by folding it in half.
Part name Codes
*
Carrier Sheet B12B813431
* You can only use the carrier sheet with the code.
Related Information
&“Specications for Originals Using the Carrier Sheet” on page 19
&“Placing Large Size Originals with the Carrier Sheet” on page 35
&“Placing Irregular Shaped Originals” on page 38
&“Placing Photographs” on page 40
User's Guide
Scanner Basics
15

Roller Assembly Kit Codes
Parts (the pickup roller and a separation roller) should be replaced when the number of scans exceeds the service
number. Use dedicated parts with the roller axis in blue. You can check the latest number of scans in Epson Scan 2
Utility.
A1: upper pickup roller, A2: lower pickup roller, B: separation roller
Part name Codes
*1
Life cycle
Roller Assembly Kit B12B819381
B12B819391 (China only)
B12B819401 (India only)
100,000
*2
*1 You cannot use any parts except for the codes specied.
*2 This number was reached by consecutively scanning using Epson test original papers, and is a guide to the replacement
cycle. The replacement cycle may vary depending on dierent paper types, such as paper that generates a lot of paper dust
or paper with a rough surface that may shorten the life cycle.
Related Information
&“Replacing the Roller Assembly Kit” on page 89
&“Resetting the Number of Scans” on page 93
User's Guide
Scanner Basics
16

Specications of Originals and Placing
Originals
Specications of Originals
is section explains the specications and conditions of originals that can be loaded in the ADF.
General Specications for Originals being Scanned
Type of Original Thickness Size
Plain paper
Fine paper
Recycled paper
Post card
Business card
Envelopes
Plastic cards complying with ISO7810
ID-1 type (with or without emboss)
50 to 209 g/m
Plastic cards: 1.24 mm (0.05 in.) or less
(including emboss)
Maximum (single sided): 215.9×3,048
mm (8.5×120 in.)
Maximum (double sided): 215.9×2,032
mm (8.5×80 in.)
Minimum: 50.8×50.8 mm (2.0×2.0 in.)
The loadable size varies depending on
the type of originals.
Note:
❏All originals must be at and straight at the leading edge.
❏Make sure
A
is less than 5 mm, if the leading edge of the original is curled.
if
A
is from 5 mm or less than 30 mm, and
B
is 30 mm or more, the original may not be scanned successfully.
You cannot scan originals for which
A
is 5 mm or more, and
B
is less than 30 mm.
Try to atten the curled originals before scanning.
❏Even when the original meets the specications for originals that can be placed in the ADF, it may not feed from the ADF
or the scan quality may decline depending on the paper properties or quality.
User's Guide
Specications of Originals and Placing Originals
17

Specications of Standard Size Originals
e list of the standard size originals you can load on the scanner.
Size Measurement Thickness Paper Type Loading Capacity
*
Legal 215.9×355.6 mm
(8.5×14 in.)
50 to 209 g/m Plain paper
Fine paper
Recycled paper
Thickness of the originals stack:
under 8 mm (0.31 in.)
80 g/m: 50 sheets
The loading capacity varies
depending on the paper type.
Letter 215.9×279.4 mm
(8.5×11 in.)
Thickness of the originals stack:
under 8 mm (0.31 in.)
50 g/m: 70 sheets
80 g/m: 50 sheets
130 g/m: 30 sheets
209 g/m: 15 sheets
The loading capacity varies
depending on the paper type.
A4 210×297 mm
(8.3×11.7 in.)
B5 182×257 mm
(7.2×10.1 in.)
A5 148×210 mm
(5.8×8.3 in.)
B6 128×182 mm
(5.0×7.2 in.)
A6 105×148 mm
(4.1×5.8 in.)
A8 52×74 mm
(2.1×2.9 in.)
Business Card 55×89 mm
(2.1×3.4 in.)
210 g/m Thickness of the originals stack:
under 8 mm (0.31 in.)
15 sheets
* You can rell the originals up to the maximum capacity during scanning.
Specications of Long Paper
e specication of long paper you can load into the scanner.
User's Guide
Specications of Originals and Placing Originals
18

Size Thickness Paper Type Loading Capacity
Width: 50.8 to 215.9 mm
(2.0 to 8.5 in.)
Length (single sided): 393.8 to 3048.0
mm
(15.5 to 120.0 in.)
Length (double sided): 393.8 to 2032.0
mm
(15.5 to 80.0 in.)
50 to 130 g/m Plain paper
Fine paper
Recycled paper
1 sheet
Specications of Receipts
e specications of receipts that you can load into the scanner.
Size Thickness Paper Type Loading Capacity
Width: 76.2 to 215.9 mm
(3.0 to 8.5 in.)
Length: 76.2 to 393.7 mm
(3.0 to 15.5 in.)
50 to 130 g/m Plain paper
Fine paper
Recycled paper
Thermal paper
*
50 sheets
Width: 76.2 to 215.9 mm
(3.0 to 8.5 in.)
Length: 393.8 to 3048.0 mm
(15.5 to 120.0 in.)
50 to 130 g/m Plain paper
Fine paper
Recycled paper
Thermal paper
*
1 sheet
* Thermal paper may not be successfully scanned.
Specications of Plastic Cards
e specication of plastic card you can load into the scanner.
Size Card Type Thickness Loading Capacity Loading Direction
ISO7810 ID-1 Type
54.0×85.6 mm
(2.1×3.3 in.)
With embossing 1.24 mm (0.05 in.) or
less
1 card Horizontal (Landscape)
Without embossing 1.00 mm (0.04 in.) or
less
1 card
Specications for Originals Using the Carrier Sheet
e optional Carrier Sheet is a sheet designed to transport originals through the scanner. You can scan originals
that are larger than A4/Letter size, important documents or photos which must not damaged, thin paper, irregular
shaped originals, and so on.
e following table provides the conditions for using the Carrier Sheet.
User's Guide
Specications of Originals and Placing Originals
19

Type Size Thickness Loading Capacity of
the Carrier Sheet
Originals that cannot be
loaded directly into the
scanner
A3
*1
A4
B4
*1
Letter
Legal
*1
B5
A5
B6
A6
A8
Custom size:
❏Width: up to 431.8 mm (17 in.)
*2
❏Length: up to 297 mm (11.7 in.)
*3
0.3 mm (0.012 in.) or less
(excluding the thickness of
the Carrier Sheet)
1 sheet
*1 Fold in half to set.
*2 Originals that are wider than 215.9 mm (8.5 in.) need to be folded in half.
*3 The leading edge of the original must be placed at the binding part of the Carrier Sheet when scanning an original
approximately 297 mm (11.7 in.) long. Otherwise, the length of the scanned image may be longer than intended as the
scanner scans to the end of the Carrier Sheet when you select Auto Detect as the Document Size setting in Epson Scan 2.
Related Information
&“Carrier Sheet Codes” on page 15
Specications of Envelopes
e specication of envelopes you can load into the scanner.
Size Measurement Thickness Loading Capacity
C6 114×162 mm (4.49×6.38 in.)
(standard size)
0.38 mm (0.015 in.) or less 1 envelope
DL 110×220 mm (4.33×8.66 in.)
(standard size)
Types of Originals that Require Attention
e following types of originals may not be successfully scanned.
❏Originals with an uneven surface such as letter head paper.
❏Originals with crinkles or fold lines
❏Original with labels or stickers
User's Guide
Specications of Originals and Placing Originals
20
