EPSON
ACTIONSCANNER™II
Getting Started
for Macintosh
@
printed on recycled paper with at least 10% post-consumer content

A Note Concerning Responsible Use of
Copyrighted Materials
Like photocopiers, scanners can be misused by improper copying of copyrighted material.
Although Section 107 of the U.S. Copyright Act of 1976 (Title 17, United States Code), the
“fair use” doctrine, permits limited copying in certain circumstances, those circumstances
may not be as broad as some people assume. Unless you have the advice of a
knowledgeable attorney, be responsible and respectful by not scanning published material
without the permission of the copyright holder.
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical, photocopying.
recording, or otherwise, without the prior written permission of Seiko Epson Corporation.
No patent liability is assumed with respect to the use of the information contained herein.
Neither is any liability assumed for damages resulting from the use of the information
contained herein.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this
product or third parties for damages, losses, costs, or expenses incurred by purchaser or
third parties as a result of: accident, misuse, or abuse of this product or unauthorized
modifications, repairs, or alterations to this product.
Seiko Epson Corporation and its affiliates shall not be liable against any damages or
problems arising from the use of any options or any consumable products other than those
designated as Original EPSON Products or EPSON Approved products by Seiko Epson
Corporation.
ActionScanning is a trademark of Epson America, Inc.
EPSON is a registered trademark of Seiko Epson Corporation.
General notice: Other product names used herein are for identification purposes only and may be
trademarks of their respective companies. EPSON disclaims any and all rights in those mark.
Copyright 0 1995 by Epson America, Inc.
Torrance, California, USA 12/95

Contents
Introduction ...........................
1
System and Memory Requirements
............. 2
Setting Up the Scanner
..................... 2
Connecting the Scanner to Your Macintosh
......... 4
Installing the EPSON Scanning Utilities
........... 6
Installing Adobe PhotoDeluxe
................ 8
Installing Maxsoft-Ocron Wordlinx .............
9
Scanning Images
........................ 9
Putting It Together
.......................
11
Calibrating Your System
..................
12
Selecting the Correct Resolution
.............
18
iii

Introduction
This package contains everything you need for professional
quality color scanning:
Q EPSON® ActionScanner™ II color scanner, which scans in
full color (24 bit) or grayscale monochrome (8 bit) at
300 dpi (dots per inch)
Q SCSI system cable
CI EPSON Scanning Utilities for Macintosh® (EPSON Scan! II
and EPSON TWAIN), which let you capture scanned
images, export the images in a variety of formats, calibrate
your scanner, and use the scanner’s advanced features with
software programs that support the industry standard
TWAIN interface
P Adobe® PhotoDeluxe,® a powerful, imageediting program
(supplied on a CD) that lets you edit color digital images
captured with your scanner or a digital camera, or copied
to a PhotoCD.
Cl Maxsoft-Ocron™ Wordlinx,™ an optical character
recognition (OCR) program that lets you scan printed text
and convert it into a text file you can edit and format.
This booklet tells you how to set up your scanner, install the
software, and scan an image. If you need more detailed
information after you begin scanning, consult the manuals and
online documentation for the ActionScanner II, EPSON
Scanning Utilities for Macintosh, PhotoDeluxe, and Wordlinx.
1

System and Memory Requirements
For the scanner and your software to work properly, your
system must include the following minimum configuration:
D Apple® Macintosh or Power Macintosh™ computer with a
68030 or 68040 processor
P Apple system software 7.0 or higher
Q 8MB of system RAM; 4MB of application RAM
Note:
8MB is the minimum amount of RAM; graphics applications run
faster and more efficiently with at least 12MB of RAM.
0 At least 100MB of free hard disk space for scanner
applications and images, depending on the size of the
images
0 A color monitor (one with a 24-bit video card is
recommended)
4 For PhotoDeluxe, a double-speed or faster CD-ROM drive.
Setting Up the Scanner
Follow these steps to set up the scanner:
1. Take the scanner out of its box and place it on a flat, stable
surface with the rear panel facing you.
2. Remove the tape securing the scanner cover and pull out
the paper underneath the cover.
2

3.
Locate the round screw in the middle of the rear panel and
turn it counterclockwise. If necessary, use a coin to loosen it.
4.
Remove the screw and push it into the storage hole marked
STOCK; do not screw it in.
5.
Connect one end of the power cable to the power inlet on
the rear of the scanner and plug the other end into an
appropriately grounded electrical outlet as shown below.

If the scanner comes on when you plug it in, turn it off by
pressing the OPERATE button.
Warning:
Whenever you turn off the scanner, wait at least 10 seconds
before turning it back on. Rapidly turning it on and off can
damage the scanner.
Connecting the Scanner to Your
Macintosh
Follow the steps below to connect the scanner directly to the
SCSI port on your Macintosh using the SCSI cable included
with the scanner. This cable has a 25-pin connector on one end
and a 50-pin connector on the other. The SCSI ID is already set
to 2 and the SCSI terminator is on.
If you are already using the SCSI port on your computer for
another SCSI device, such as an external hard disk, you need a
SCSI cable with a 50-pin connector on both ends. You can then
connect the scanner to your other SCSI device and set the SCSI
ID and terminator as necessary; follow the instructions in
Chapter 1 of your scanner User’s Guide.

1.
2.
3.
4.
5.
Turn off your Macintosh, scanner, and all peripheral devices.
Caution:
Be sure that your Macintosh, scanner, and all peripheral devices
are turned off before you plug in the SCSI cable.
Plug the 25-pin connector into the SCSI port on the Macintosh
with a e icon above it. Tighten the two screws on the
sides of the connector.
Connect the 50-pin end of the cable to either the top or
bottom SCSI connector on the scanner; then fasten the
connector with the wire clamps on its side.
Turn on the scanner by pressing the OPERATE button. The
green OPERATE light comes on on the top right side of the
scanner. The READY light comes on when the scanner has
warmed up.
Then turn on your Macintosh. (Always turn on the scanner
before turning on the Macintosh.)

Installing the EPSON Scanning Utilities
The EPSON Scanning Utilities include EPSON Scan! II and
EPSON TWAIN for the Macintosh. Scan! II uses TWAIN to
capture images and then saves and exports these images in a
variety of file formats. It also calibrates your scanner and
output devices to produce images nearly identical to the
originals.
EPSON TWAIN is a set of drivers designed to access your
scanner’s advanced features for any software that supports
TWAIN for Macintosh. TWAIN drivers are an industry
standard for acquiring image data from a variety of external
sources without leaving your application program.
Follow these steps to install the EPSON Scanning Utilities:
1.
2.
3.
4.
5.
6.
Turn on the scanner.
Hold down the Shift key while turning on the Macintosh to
turn off any extensions.
Insert the EPSON Scanning Utilities Disk 1 in a diskette drive.
Double-click the Disk 1 icon on the desktop.
Double-click the Installer icon in the Disk 1 folder.
After a few moments, you see the initial setup screen.
Choose OK to continue.
6

You see the Easy Install screen:
7.
8.
9.
Easy install
Click Install to place the It
l Scanner Utility Program EPSON Scan! II
on the hard disk named
63 ZFP 320
I Customize
1
If you want to install all the program components, click
Install. To select only one or two components, click
Customize. Then highlight the components on the next
screen and click install.
The program begins copying files. Insert the diskettes as
prompted.
When installation is complete, you see a success message.
Click Restart to restart your Macintosh.
The program creates an EPSON Scan! II folder on your hard
disk containing a Scan! II and Scan! II Help icon.
10. Raise the scanner’s cover and place an image face down on
the upper right comer of the glass surface. Then carefully
close the cover.
11. To test your software, click the Scan! II icon.
12. From the File menu, select Acquire.
7

You see the EPSON TWAIN easy screen:
a
F SONTWl3IN
9
Document Source : [ Flatbed
v
image Type :
Color Photo 7
Destination : Screen
13. Click Scan. After a moment, you see the image in the
Scan! II Image 1 screen.
If you do not see it, click Close and repeat all the scanner
setup steps, beginning on page 2.
14. Click Close and then exit Scan! II.
Installing Adobe PhotoDeluxe
If you have a CD-ROM drive, follow these steps to install
Adobe PhotoDeluxe:
1.
If necessary, hold down the Shift key while turning on the
Macintosh to turn off any extensions.
2.
Insert Adobe PhotoDeluxe CD in your CD-ROM drive.
3.
Double-click the Install Adobe PhotoDeluxe icon.
4. Click Continue.
5.
On the next screens, follow the displayed instructions to
install the entire program, and click Install.
8

6. When you see an installation completion message, click Quit
to exit the Installer.
7. Restart your Macintosh.
See the online documentation that comes with PhotoDeluxe for
instructions on using the program.
Installing Maxsoft-Ocron Wordlinx
Follow these steps to install Wordlinx:
1. If necessary, hold down the Shift key while turning on the
Macintosh to turn off any extensions.
2. Insert the Wordlinx Program Disk 1 in a diskette drive.
3. Double-click the Installer icon in the Disk 1 folder.
4. You see the initial program screen. Click Install.
5. The program copies the files and when it is finished, displays
a success message. Click Quit.
The program creates a Wordlinx 2.0 folder. See the Wordlinx
documentation for instructions on using Wordlinx.
Scanning Images
Now you are ready to start scanning. First, choose an image to
scan. The best choice is a color photograph. Printed pictures,
such as those in magazines, do not scan as well as photographs
because of the dot patterns used in the printing process.
When selecting an image or text to scan, respect the rights of
the copyright holders. Don’t scan published materials without
first checking the copyright status.
9

After you choose an image, follow these steps to scan it:
1.
2.
3.
4.
5.
6.
Raise the document cover on the scanner and place the
image face down on the glass surface.
Carefully close the document cover so that you do not
disturb the position of the photograph on the glass.
Insert the Adobe PhotoDeluxe CD in your CD-ROM drive.
Start PhotoDeluxe.
Click the Scan Photo button.
Select TWAIN-Acquire from the Acquire Module List.
10

You see the EPSON TWAIN easy screen:
r:: LPSON TUIRIN
Docwnmt Sourer: [ Flatbed
I
lmaqe Type :
COlc4- Photo
v
Dniination : Screm
.
7. Select Scan. TWAIN pre-scans and then scans your image.
8. In a few moments, the scanned image is imported into
PhotoDeluxe. If you like, you can now modify the image
using any of the PhotoDeluxe features.
Putting It Together
Once you have scanned images and text, you can put them
together in reports, newsletters, brochures, presentations, or a
myriad of other formats.

Several factors affect how closely your scanned image reflects
the original, especially when you print the images on paper.
The next sections discuss basic calibration techniques and
resolution settings you can use in EPSON Scan! II to help you
achieve the results you want. See your EPSON Scanning
Utilities User’s Guide for Macintosh for information on other,
more sophisticated methods of modifying your scan.
Calibrating Your System
Calibration allows you to match your scanner and your output
device so you can reproduce color images that are very close to
the originals.
Because monitors use a different method to display color
images than printers use to print them, images look different
when displayed than when printed. Also, each output device
may produce different printed results. For example, an image
printed on an electronic color printer looks dramatically
different when printed on a printing press.
EPSON Scan! II calibrates your scanner with your monitor,
application, and printer by analyzing the results of a calibration
sample at each stage of the process.
The basic calibration process consists of:
P Calibrating your monitor to your scanner
0 Enabling screen calibration
0 Exporting a calibration chart to your application
0 Creating calibration profiles for your printer(s)
Q Scanning using the calibration profile.
These procedures are described in the following sections.
12

Calibrating your monitor to your scanner
Follow these steps to calibrate your monitor to your scanner:
1.
Select EPSON Scan! II in the EPSON Scan! II folder.
2.
Choose Screen Calibration from the Calibrate menu. You
see this screen:
Screen Calibration
Adjust the slider below until the gray
areas appear the same.
3.
Look at the display from a distance and adjust the slide bar
until the separate rows have the same basic color intensity.
4. Choose OK.
Enabling screen calibration
Now follow these steps to enable screen calibration so EPSON
TWAIN can use it when you scan images:
1.
From the File menu, choose Acquire to start EPSON TWAIN.
2.
Choose Advanced. You see the advanced TWAIN screen.
3. Select
Configuration; you see the Configuration dialog box.
13

4. Select the EPSON Calibration radio button to enable screen
calibration.
5. Choose OK.
6. Close the EPSON TWAIN screen.
Exporting a calibration chart
To calibrate your printer to your scanner, you need to export a
calibration chart from Scan! II to your application and then
create a calibration profile.
Note:
If you have any of these EPSON Stylus® ink jet printers, Scan! II
provides printer calibration profiles for you so you do not have to
create them:
EPSON Stylus COLOR
EPSON Stylus COLOR IIs
EPSON Stylus Pro XL
EPSON Stylus COLOR II
EPSON Stylus Pro
See page 17 now for steps on scanning using these profiles.
Follow these steps to export a calibration chart:
1. Select Export Calibration Chart from the Calibrate menu.
14

You see the following screen:
2.
3.
4.
5.
6.
7.
8.
Export Calibration Chart...
This function calibrates your scanner/software/printer system by passing
a calibration sample through each stage and analyzing the results.
Select a file format you can import into the software you plan to use and
click on ‘Export’.
Import the resulting Calibration Chart file into your software and print i
on your printer.
Then return to EPSON Scan!Il and select ‘Create Calibration Profile....’ from
the ‘Calibrate’ menu.
t3 EPSON Scan!II v
Export image as: Untitled - 1
Export File Format: 1 PlCl
7 [
(E.ncsl)
In the Export File Format pull-down menu, select the PICT
file format, if necessary.
In the Export image as field, type the name you want to use
for the calibration chart file, such as COLOR1.
Choose Export to create the calibration chart file in the
EPSON Scan! II folder.
Exit EPSON Scan! II.
Insert the Adobe PhotoDeluxe CD in your CD-ROM drive
and start PhotoDeluxe.
Open the calibration chart file you exported to the EPSON
Scan! II folder.
The calibration chart appears in the Photoshop window.
It contains nine blocks of color gradations, some grayscale
gradations, and a black border on three sides.
Save the chart within Photoshop by selecting Save from the
File menu.
15

9. Print the calibration chart on your color printer. If you have
more than one printer, print the chart on each one.
10. Exit PhotoDeluxe.
Creating printer calibration profiles
Follow these steps to create a calibration profile for each printer:
1. Start EPSON Scan! II, if necessary.
2. Place the printed calibration chart face down on the glass
surface of the scanner.
3. Choose Create Calibration Profile from the Calibrate menu.
You see the following screen:
Create Calibration Profile...
Place the Calibration Chart you printed In the
scanner. Make sure it is aligned properly. Enter a
file name for the file.
lifter you click ‘Continue’, the EPSON TWAIN
dialog appears. Make sure it is set for
Calibration. Finally, click on the ‘Scan’ button.
Filename:
Your printer
4. In the Filename field, type the filename of the calibration
file you want to create, such as COLOR1 PRINTER.
5. Choose Continue. You see the EPSON TWAIN advanced
screen. (If you see the easy screen, select Advanced.)
6. If necessary, select Color Photo from the Image Type
pull-down menu.

7. Select Calibration Profile from the Destination pull-down
menu.
8. Choose the Scan icon. The program scans the calibration
chart and creates a calibration profile. You see the main
Scan! II program screen.
Now you can use this calibration profile when you scan images.
Scanning using calibration
Follow these steps to use a calibration profile when you scan:
1. Choose Acquire from the File menu of EPSON Scan! II or
choose Scan Photo in PhotoDeluxe. In PhotoDeluxe, then
select TWAIN-Acquire also.
You see the EPSON TWAIN advanced screen. (If you see the
easy screen, select Advanced.)
2. Choose the Destination button; you see the Destination
dialog box.
3. If you have one of the EPSON ink jet printers listed in the
Note on page 14, select the printer from the Destination
Name
pull-down menu. The Calibration description is
assigned automatically. Go to step 5.
If you just created a calibration profile for your printer, type
a unique name for the profile, such as Color1 Profile, in the
Destination Name field. Go to step 4.
4. From the Calibration pull-down menu, select the description
of the printer you used when you scanned the profile (for
example, COLOR1 PRINTER).
5. Choose Save.
6. Choose OK. You see the EPSON TWAIN advanced screen.
17
