Equalizer Systems Auto Level Guide

Auto-Level -Troubleshooting & Warranty Guide
Contents
Operation / Manual & Auto-Level ...................................Page 1
Setting the Null.................................................................Page2
Helpful Hints ....................................................................Page 2
Panel Indicators ................................................................Page 3
Manual Override...............................................................Page4
Troubleshooting................................................................Page 5
Warranty ...........................................................................Page 7

Priortooperatingthesystemitisrequiredthattheoperatorperformaphysicalcheckaroundandundertheunittoassurethat
nothingornoonecouldbeharmedbythejacksextendingorretractingandthevehiclemovingupordown
Manual Operation using the Equalizer Systems Auto-Level keypad
Power on: Push and release the Power keypad button to engage power. All lights should come on then most
will go out. The LED light next to the Power button should be lit RED when power is on. If you attempt to extend
jacks by pressing the Down keypad buttons or all the jacks with the Auto-Level button, you will hear a “deny”
tone from the keypad if the ignition key is in the improper position or the park brake needs to be set and if
equipped the LED lights for these will be on (see section below on panelLED’s)
Planting the jacks: Using the Down keypad buttons, extend the jacks until they contact the ground (this is
referred to as “planting” the jacks). As you extend the jacks, an LED light on the keypad will indicate the jack(s)
out of the “stowed” position. jacks may be operated individually or in pairs depending on the system supplied.
Do not manually overextend individual jacks. This may cause unwanted stress on the coach or the jacks.
Leveling the coach: Use a bubble level on a flat surface in the center of the coach. Level the vehicle by using
the Down or Up keypad buttons until the vehicle is level. Jacks may be operated individually or in pairs
depending on the system supplied as long as they are operated in the same direction. Do not attempt to lift the
vehicle’s tires off the ground. The keypad may be left on once level has been achieved. The keypad will enter
“sleep mode” after five minutes of inactivity.
Note: There maybe specific instances when manual extension of one or more jacks may inhibited (deny tone
when Down is depressed). This situation is caused by the ‘anti-twist’ protocol in the software installed in the
controller. Simply stated, the ‘anti-twist’ protocol denies jack extension if the system senses that a specific corner
of the coach is approximately 3 degrees higher than the rest. You will be able to extend the other jacks to
overcome the slope. If the system incorrectly senses excessive slope, this can be overcome by re-setting the null.
This will allow manual extension of all jacks.
Retracting the jacks: Use the All Retract button to retract the jacks prior to travel.
The Equalizer System does provide the ability to retract the jacks using the UP buttons for jacks. However, these
buttons are not intended to be used for retracting the jacks to their stowed position prior to travel. The Up arrows
are to be used only for retracting the jacks to help level the coach. The All Retract button must be pressed to
insure the system is ready/safe for travel. All jacks (rear only) will automatically retract and return to stowed
position when the ALL RETRACT button is pressed and released. Tthe front jacks will need to be retracted using
the UP arrow(s) to the stowed position after coupling to the tow vehicle. When All retract is pressed the pump
will run in retract for approximately 5 seconds after the last (rear jack) jack has been fully retracted- or until a
time limit of 90 seconds has been reached.
*It is always the responsibility of the coach operator to visually confirm that the jacks
are fully retracted and safe for travel*
Dual Leg Switch and Harness
Your system includes a dual leg switch and harness that allows the independent operation of the front jack legs.
This is primarily so that the front legs can be extended to lift and support the trailer from the tow vehicle. This
dual leg switch control includes a key switch to disconnect it so that unauthorized operation of the front jacks can
be avoided. During travel this key switch must be turned to the off position and the key removed. To operate
insert the key turn it to the on position then the rocker switches can be used to operate the front jacks
independently or as a pair up or down. Do not attempt to operate jacks in opposite directions at the same time.
1
Operation

Auto-Level Operation
Power on: Push and release the Power keypad button to engage power. All lights should come on then most
will go out. The LED light next to the Power button should be lit RED when power is on. Other lights should go
out, if they do not refer to the keypad LED section. If the jacks down lights are on they must be cleared by
pressing the all retract button prior to performing Auto-Level.
Front Jacks: It is required that tow vehicle be disconnected from the trailer prior to leveling with Auto-Level.
Use the down arrow(s) on the control panel (or use the dual leg switch) to extend the front jacks to support the
trailer and lift the trailer from the tow vehicle. After the tow vehicle is removed, lower the front of the trailer so
that the trailer is level front to rear (visually level). Generally, it will work best if the front is slightly lower that
the rear. This is somewhat a trial and error/learning as all trailer units seem be slightly different.
Auto-Level: Press the Auto-Level button and release. The system will send out a continuous series of beeps and
the “Operating” LED will flash RED to let you know Auto-Level is operation the rear legs will be deployed and
then the system will use the front and the rear legs to automatically level the coach. When completed, the keypad
will signal the successful completion with a dual-stage tone. The keypad may be left on once level has been
achieved. The keypad will enter “sleep mode” after five minutes of inactivity. If the unit is not level after the
process is complete see the section on setting the Null.
Retracting the Jacks: Use the ALL RETRACT button to retract the jacks prior to travel
The Equalizer System does provide the ability to retract the jacks using the UP buttons for jacks. However, these
buttons are not intended to be used for retracting the jacks to their stowed position prior to travel. The Up arrows
are to be used only for retracting the jacks to help level the coach. The All Retract button must be pressed to
insure the system is ready/safe for travel. All jacks (rear only) will automatically retract and return to stowed
position when the ALL RETRACT button is pressed and released. The front jacks will need to be retracted using
the UP arrow(s) to the stowed position after coupling to the tow vehicle. When All retract is pressed the pump
will run in retract for approximately 5 seconds after the last (rear jack) jack has been fully retracted- or until a
time limit of 90 seconds has been reached.
*It is always the responsibility of the coach operator to visually confirm that the
jacks are fully retracted and safe for travel*
If the coach is not level following an attempt to Auto-Level, you will need to level the coach and reset the null. To
set the null, push and release the Power button on the Keypad to engage power. The LED light next to the Power
button should be lit RED when the power is on. Level the coach by deploying jacks manually, or by simply
parking the coach on a level site. You do not need to have the jacks deployed to set the null. Use a bubble level on
a flat surface in the center of the coach as a reference. Once the coach is level, turn the power off at the panel.
Depress and hold the Auto-Level button and press and release the Power button and listen for a series of beep.
After the Keypad has beeped 5 to 6 times, release the Auto-Level button (the Keypad will continue to beep as
long as the Auto-Level button is held). You should receive 2 beeps indicating that the new Null has been set the
panel will maintain this setting. Press and release the All Retract button to retract the jacks to the stowed position.
Do not allow excessive motion in the unit during the Auto-Level operation (don’t move around in the unit).
This could cause the system to level improperly.
The Auto-Level is a microprocessor controlled system. Proper and adequate battery voltage and permanent
chassis ground are essential.
Your system may be equipped with a manual override option. Refer to the procedure for proper operationof
this option. It is usually better to review this procedure prior to its actual use, rather than having to learn a
new procedure in difficult environments.
If the system has not been used (with the jacks stowed) for over 24 hours, it is recommended that youengage
the All Retract button prior to travel in order to re-pressurize the system.
A lubricant, like WD40, may be used to clean and lubricate the cylindershafts.
2
Setting the Null: Null is the term used to indicate the levelness of the coach
Helpful Hints

There are a total of ten (10) LED indicators on the Equalizer Keypad. The function of
these LED's is detailed below.
During typical operation, the LED's on the bottom left hand corner of the keypad should NOT be
illuminated. The only LED that should light is the “OPERATING' LED, which should flash during
operation.
'POWER’ LED...................................................ON Red when power is ON
OFF when power is OFF
FLASH every 1 sec. In Sleep Mode
'JACK' LED (4 each) .................................... ON Red when jack(s) are deployed
OFF when jack(s) are stowed
'OPERATING' LED ......................................FLASHING Red w/ Auto Level or All Retract
OFF when keypad is idle or 'sleeping'
'LOW VOLTAGE' LED ................................ON Red when voltage is below 10.5 VDC
OFF when voltage is above 10.5 VDC
'ENGAGE PARK BRAKE' LED ...................ON Red when park brake is not set
May not be present onnewer trailer OFF when park brake is set.
version units -See Step 9 (installation)
'IGNITION ON' LED ....................................ON Red when ignition is in the ON position
May not be present onnewer trailer OFF when ignition is off
version units- See Step 8 (installation)
'EXCESS SLOPE' LED .................................ON Red following an Auto-Level attempt if
system cannot overcome slope
OFF when slope is not excessive
If the LOW VOLTAGE, ENGAGE PARK BRAKE, IGNITION ON or EXCESS SLOPELED's
illuminate, you have an 'error' condition that must be corrected prior to operating thejacks.
If the jacks down status lights are on (rear lights on trailer version) AutoLevel will be denied.Press
the all retract to clear.
3
Panel Indicator LED's

Your hydraulic motor is equipped with a manual override output shaft. You must use a drill with
a 7/16" socket driver.
The drill must be capable of producing a minimum of 2000 r.p.m. for the pump to develop
appropriate pressure output.
Care must be taken to ensure neither the drill nor the socket contact any wires or hydraulichoses
while in use.
END VIEW OF MOTOR
To operate your jack(s) using the manual override
The individual cartridge valves are clustered together on the side of the pump manifold. Theyare
labeled 1 thru 4. Locate the screws on the appropriate cartridge valve(s). Using a small flat blade
screwdriver or 1/8” Allen wrench,(depending on valve type) turn the screw(s) clockwise until
seated in.
Remove the black plastic cap from the end of the motor. Use a small flat head screwdriver.Place
the drill with the 7/16" socket on the manual override shaft located at the end of the motor.
To retract your jack(s) run the drill in the counter-clockwisedirection.
To extend your jack(s), run the drill in the clockwise direction.
When manual override is complete, return the cartridge valve(s) to the normal position(s).
Reinstall black plastic cap on motor.
Caution: Following manual override operation, failure to return all valves to normal position may result
in one or more jack legs drifting down from their retracted (stowed) position. For cartridge valves, rotate
the center screw fully counter-clockwise.
*Note* The normal operating position of the screw in the cartridge valve is the counter-clockwise 'out'
position. The only time the valve should be shifted manually is when attempting to operate jack(s) via
manual override.
4
Manual Override Procedure

Troubleshooting Guide
Symptom
Possible Cause
Corrective Action
Keypad will not turn on
Blown fuse at pump harness
Replace fuse
Faulty ground or power wire
Trace and repair
Low battery voltage
Charge chassis and/or coach batteries
Defective Keypad or Controller
Call Equalizer Systems
Defective Keypad or Controller Harness
Trace and repair
Keypad truns on, Jacks will
not operate
Low battery voltage to pump
Charge chassis and/or coach batteries
Faulty electrical connection
Trace and repair
Defective Keypad or Controller
Call Equalizer Systems
Defective pump motor or solenoid
Replace motor and/or solenoid
Other system defect
Call Equalizer Systems
Jacks will retract but will
not extend
Low battery voltage to pump
Charge chassis and/or coach batteries
Park brake not set
Set park brake
Bad motor or solenoid
Replace motor and/or solenoid
Anti-twist software protocol has been
initiated
Lower opposite side of coach and/or re-set
Null and level coach
Ignition switch in wrong position
Check and change as needed
Defective Keypad or Controller
Call Equalizer Systems
Faulty electrical connection
Trace and repair
System defect
Call Equalizer Systems
Jacks will extend but will
not retract
Low battery voltage
Charge chassis and/or coach batteries
Incorrect hose connection at pump or
jackleg
Trace and repair
Defective Keypad or Controller
Call Equalizer Systems
Bad motor or solenoid
Replace motor and/or solenoid
Auto-Level will not level
System Null not set
Set Null
Controller installed improperly or has
moved
Check controller orientation
Ignition switch in wrong position
Check and change as needed
Damaged or defective Keypad or
Controller harness
Call Equalizer Systems
Defective Keypad or Controller
Call Equalizer Systems
Other system defect
Call Equalizer Systems
5

Possible Cause
Corrective Action
Auto-Level stops mid-cycle
Low battery voltage
Charge chassis and/or coach batteries
Excessive vehicle motion during leveling
sequence
Reset Keypad and re-try
Damaged or defective Controller
Check and change as needed
Damaged or defective Keypad or
Controller harness
Call Equalizer Systems
Other system defect
Call Equalizer Systems
Jack LED's on keypad stay
on
Defective pressure switch or wiring
Trace and repair or replace
Defective Keypad, Controller, or Pump
harness
Trace and repair or replace
Defective Keypad or Controller
Call Equalizer Systems
Low system pressure caused by fluid leak
or low fluid level
Correct leak or fluid level
Hydraulic pump inoperative
Low battery voltage
Charge chassis and/or coach batteries
Blown fuse or breaker at fuse panel
Replace fuse or reset breaker
Faulty electrical connection
Trace and repair
Defective pump motor or solenoid
Replace
Jack(s) bleed down from
leveled or stowed position
Air in hydraulic system
Purge air
External fluid leak
Trace and repair
Defective valve in pump
Clean or replace valve
Defective jackleg
Replace jackleg
Jack(s) are jerky when
retracting
Air in hydraulic system
Purge air
Fluid level low
Check fluid level and add
Jack(s) will not retract from
extended position
Low battery voltage at pump
Charge chassis and/or coach batteries
Low battery voltage or poor ground
Charge chassis and/or coach batteries and
ensure proper grounding
Damaged/defective harness from Keypad to
Controller or Controller to pump
Trace and repair
Fluid level low
Check fluid level and add
Defective pump motor or solenoid
Replace
Avoid headaches, always ensure & verify proper charge of the batteries.
Proper and adequate grounding of the pump is essential
80% of the calls we receive are found to be a discharged battery or poor ground
If your problem is not listed, call Equalizer Systems at [phone]
Prior Authorization for warranty is required
6

Equalizer Systems Limited Warranty Policy
October 2010
1. Only warranty claims with prior written or verbal authorization from Equalizer Systems will be recognized, all other claims will be denied.
2. Equalizer Systems warrants slide out and leveling system components for a period of one year from the date of original sale of the vehicle. This
warranty covers defects in material and workmanship only. Equalizer Systems is not liable for any damage due to abuse, neglect, misuse, negligence,
misapplication, error of operation, accidental or purposeful damage or damage due to an “act of God” such as, wind or rain damage, flood, lightning or other
natural occurrence of the like. Equalizer Systems limited warranty is applicable to the Equalizer Systems components only and does not apply to the
vehicle, apparatus or property to which it is attached. Warranty parts will be shipped at no charge if the repair is authorized by an Equalizer Systems
representative. Purchased components used in authorized warranty repairs will be reimbursed at the original purchase price.
3. Labor and freight expenses due to warrantable parts defects or workmanship will be reimbursed for a period of one year from the date of original sale of
the vehicle. Freight expenses will either be prepaid by Equalizer Systems or reimbursed at the UPS Ground rate only. Any additional shipping charges or
requirements are the obligation of the vehicle owner or service center performing the warranty repair. The owner or service center’s obligation may include
overseas shipping charges, border fees, brokerage fees and any other additional fee of the like.
4. Warranty labor will be reimbursed only for claims that have prior written or verbal authorization from an Equalizer Systems representative. Warranty
labor compensation is required to correspond with the “Warranty Parts Replacement Time Guideline” published by Equalizer Systems. Any warranty repair
not listed on this guideline will require prior authorization from an Equalizer Systems representative. A reasonable time allowance will be determined by
the Equalizer Systems representative. Any warranty repair that is not listed on this guideline that is performed without prior authorization will be denied
without exception. Time associated with learning about the repair or excessive diagnostic and installation time will not be reimbursed. Warranty labor will
be reimbursed at the authorized service center’s published shop rate if the rate is reasonable
for that region. Overtime labor will not be reimbursed without exception.
5. Labor, parts and freight credit (if applicable) will be sent after the parts are tested and the warranty claim is validated. Returned parts that are found to be
in normal operating condition are not warrantable and will be charged to the owner or service center. Equalizer Systems reserves the right to charge back
the service center for labor claim payments previously submitted if the installation ofthe warranted part is found to be inadequate at a later date.
6. Claims will be denied if the date submitted is greater than 30 days from the repair date.
7. Prior authorization is required before parts may be sent back to Equalizer Systems. A Return Authorization Number is required for items to be accepted.
8. Complete systems are not warranted unless authorized by an Equalizer Systems representative. There are absolutely no exceptions to this clause.
9. Consideration should be taken regarding the location and protection of Equalizer Systems’ components prior to installation. Please reference our
installation manuals for recommended locations and maintenance, or visit www.equalizersystems.com for more information. The failure of any Equalizer
Systems’ component due to extreme environmental conditions, improper installation, or lack of maintenance will not be covered under warranty.
10. Warranty coverage for parts or systems sold by non-authorized resellers (such as live or internet auctions) will be at the discretion of Equalizer Systems.
11. This warranty begins upon the original sale date of the vehicle and is transferable, with limitation, to subsequent owners upon furnishing the original
sale date of the vehicle and proof of purchase. Only the remainder of the one year parts warranty is applicable. Warranty labor and freight are only
applicable to original owner of thevehicle.
12. Equalizer Systems is not liable for loss of time, manufacturing costs, labor, material, loss ofprofits, direct or indirect damages incurred bythe vehicle
manufacturer.
13. Excessive warranty labor resulting from inadequate access to the Equalizer Systems product will not be reimbursed.
14. Equalizer Systems will not pay a markup on warranty parts unless required by law.
15. Travel expenses, hotel, telephone, fuel or any other expenses ofthe like are not covered under warranty.
Replacement Parts:
1. Replacement parts are warranted under the same guidelines listed above for the remainder of the original warranty or 90 days, whichever is longer. Proof
of warranty repair date and original vehicle purchase date are required.
No additional warranties, expressed or implied, are authorized by Equalizer Systems
This warranty voids all previous issues.
Questions concerning this warranty should be directed to:
Equalizer Systems
55169 CR 3 North
Elkhart, IN 46515
1-[phone]
1-[phone] fax
To activate your warranty, please visit our website at http://equalizersystems.com/service/activate-warranty
OM010-AR1
7
