INTRODUCTION AND SPECIFICATION
Thank you for choosing the TMH pneumatic chain hoist.
 Providedthatthehoistisusedandmaintainedinaccordancewiththismanualitwilla󰀨ordyoumanyyearsofreliableservice.
 RedRoosterhoistscomplywiththelateststandardsandaredesignedforsafeande󰀩cientoperation.
 Beforeinstallingtheunit,pleaseensurethatboththepersonnelresponsibleforinstallation,maintenanceandoperationarefullyacquainted
with the sections of this manual which are relevant to them.
 Thismanualshouldbeaccessibleatalltimestotherelevantperson,incaseoflossaskyourdealerforanewcopy.
 Specicationsheetgivesfulldetailsofactualmodelsupplied.
 Thenameplatettedtothehoistgivesthedetailstoidentifyandgivesfurtherinformationonthehoist.
Notations: The following notations are used throughout this manual.
Failure to follow this instruction may result in a dangerous occurrence or fatal injury
Failure to follow this instruction may result in premature wear of the hoist or a component part of the hoist
SWL
(TONNE) MODEL CHAIN FALLS
WEIGHT (KG) FULL LOAD
LIFTING
SPEED
(M/MIN)
FLR
SIZE
MINIMUM
HOSE SIZE
(ID)
3M HOL EXTRA P/M
25 TMH-25T 2 581 24.4 1.4 1 1/2" 1 1/2"
30 TMH-30T 2 581 24.4 1.0 1 1/2" 1 1/2"
37.5 TMH-37.5T 3 1300 36.6 0.9 1 1/2" 1 1/2"
50 TMH-50T/4 4 1800 48.8 0.7 1 1/2" 1 1/2"
DANGER
CAUTION

5
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
GETTING STARTED - UNPACKING & SPECIFICATION
1.1 UNPACKING THE HOIST
 Thehoistwillhavebeenpalletised(seeweightdetailsinspecication)
 Handlingofallmodelsofhoist&trolleywillrequireliftingequipmentandshouldn’tbemovedbyhand.
WHEN UNPACKING:
 Ensurethatbothhoistandanyancillaryequipmentarerecoveredfromthepackaging.Smallordelicateitemsmayhavebeenpacked 
 separately.Checkthecontentsagainstthesupplier’sdeliverynoteandadvisethesupplierimmediatelyofanyshortages.
 Ensurethatthehoistandancillaryequipmentareundamaged.Ifthegoodsdonotreachyouinperfectcondition,notifyyoursupplier 
immediately of any damage. Do not proceed with installation if the goods are damaged.
 EnsurethatacerticateofThoroughExaminationtogetherwithaUKCAoraCEDeclarationofConformityisincludedwiththegoods.Handthese
 toa‘responsibleperson’forsafekeeping.Checkthattheidentifyingmark(serialnumber),theSafeWorkingLoad(RatedLoad)andthatthe 
UKCA or CE marking appears on the hoist or hoist and trolley.
SUPPLIER / MANUFACTURER Red Rooster Lifting Ltd Red Rooster Lifting Ltd
ADDRESS Nauta House, The Meadows Unit 26 Kelvin Way Trading Estate
  Oldmeldrum,Aberdeenshire KelvinWay,WestBromwich  
UK, AB51 0EZ West Midlands, U.K. B70 7TW
TEL NO 01651 872101 0121 525 4162
MODEL TMH-50T/4
SERIAL NO
SWL 50 Tonne
DATE OF PURCHASE
NAME PLATES
 Thenameplategivesimportantinformationwhichmustberetained.Hoistserialnumber,SWL,model,airpressure,airow,hoistrating,chain
size, speed, year of manufacture and the manufacturers name and address.
 UKEx/ATEX-Explosiveprotection
 IntheUKtheuseofnon-electricalequipmentinahazardousareaiscoveredby‘ProductsIntendedforuseinPotentiallyExplosiveAtmospheres
 2016(UKSI2016No1107asamendedbyUKSI2019No696)
 InEuropeandseveralotherpartsoftheworldtheuseofnon-ElectricalequipmentinahazardousareaiscoveredbytheATEXDirective
2014/34/EU.
 ThemainstandardscoveringboththeUKExandATEXarecurrentlythesame:BSEN80079-36,BSEN80079-37,BSEN1127-1and 
BS EN 1127-2.
  StandardhoistsaresuitableforuseinZONE2GasareascertiedasExGroupII3GExhIIBT4Gc
  StandardhoistsaresuitableforuseinZONE22DustareascertiedasExGroupII3DExhIIIBT135°CDc
  WithextraprotectioncanbeusedinZONE1GasareascertiedasExGroupII2GExhIIBT4Gb
  WithextraprotectioncanbeusedinZONE21DustareascertiedasExGroupII2DExhIIIBT135°CDb
  FurtherprotectionallowsthehoisttoworkinZONE1GasareascertiedasExGroupII2GExhIICT4Gb
  FurtherprotectionallowsthehoisttoworkinZONE21DustareascertiedasExGroupII2DExhIIICT135°CDb
  (notsuitableforTCRMiniorTCSrange,IICorIIICareas)
 Thefollowingmodelscanalsoberatedformining(ExGroupIM2ExhIMb)–TCR-500toTCR-2000/2andTMHmodels.These
 hoistscanbeusedaccordingtoEquipmentGroupICategoryM2whereequipmentisintendedtobede-energisedintheeventofanexplosive
atmosphere.
 TheTCR-250,TCR-500/2,TCS-500andTCS-980/2modelscannotberatedformining.
CERTIFICATION
 Allnewhoistsaresuppliedwithstandardcertication:ThoroughExamination,EUorUKCADeclarationofConformity,whichcanincludeeither
 ATEXorUKExcerticationwhererequired.Otherdocumentationisavailablebyagreement.
IN THE EVENT OF ANY PROBLEMS OR SHOULD YOU REQUIRE ASSISTANCE CONTACT THE SUPPLIER AS DETAILED ABOVE
QUOTING THE HOIST MODEL AND SERIAL NUMBER.
PACKAGING MATERIALS SHOULD BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL REGULATIONS.
DANGER

6
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
GETTING STARTED - OPERATION
1.2 OPERATION
Red Rooster pneumatic hoists and trolleys are designed for the lifting and lowering of loads within the capacity of the model selected. The range
 ofhoistsandtrolleyscanbeUKCA,orCEmarkedandconformwith‘SupplyofMachinery(Safety)Regulations2008(Astheyapplytomachinery
 beingsuppliedinorintoGreatBritainfrom1stJanuary2021)forUKCAmarkingandalsotheMachineryDirective2006/42/ECforCEmarking.At
 presentboththeUKandEUusethesamestandardswithBSEN14492-2beingthemainstandardforpoweredhoistingequipment.
 Ourrangeofhoistsandtrolleysareavailableashooksuspensionunits,trolleymounted,builtintolowheadroomunitsandcranes.Nearlyall
 hoistmodelsarealsoavailableasExZONE1or2hoistsforuseinhazardousareas,withcorrosionprotection,andcanworkintemperatures
of -20°C to +60°C.Whenusedoutdoororo󰀨shorehoistsshouldbeprotectedagainsttheweatherandexaminationandmaintenanceinterval 
 shouldbereduced.
 Ourhoistsareextremelyrobustbeingdevelopedovermanyyearsintheharshestofenvironmentsandwillrequirelittlemaintenanceifkept 
 lubricatedonaregularbasis.Noiselevelscanbefoundinthetechnicalspecicationandasmotorlubricatingoilissuppliedthroughthe
 lterlubricatorttedtothehoisttherewillbeasmallamountofoilescapingintotheatmospherethroughtheexhaustair:thiscanbepipedaway
 orcollectedusinganexhaustcleaner.Incertaincircumstancesandtemperaturesthereisadangeroficingofthemotorandexhaustsilencer.
 Thiscanbepreventedbyusingananti-icinglubricantsuchasSilkairorbyttingadryertotheairsupplytoremovemoisturefromtheair 
supply. Some anti-icing oil may damage air hoses and the o-ring in the hoist valve.
CAUTIONCAUTION

7
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
GETTING STARTED - CHECKS BEFORE USE & HOSE SUPPORT BRACKET
1.3 CHECKS BEFORE USE
 Thesechecksshouldbecarriedoutduringinstallationandonafrequentandregularbasisthereafter.Ifthehoistisuseddailythenitis 
 recommendedthattheyarecarriedoutdailyasthecheckstakeonlyminutestocompleteandnotonlyhelpavoidrepairbillsbutsignicantly 
 reducethepossibilityofanaccidentordangerousoccurrence.Thoroughlyexaminetheequipmentpriortoinstallationtoensurethatno 
 damagehasoccurredduringtransit.HoistsandtrolleysshouldnotbealteredinanywaywithoutcontactingRedRoosterforclearance,asthis
 maya󰀨ectthecerticationoftheunit.
AIR SUPPLY CHECKS:
 ▪ Inletpressure:5to6bar(therewillbepressurelossesacrosstheairsetandonlonghoses)Thesupplypressureshouldnot 
  exceed7barasthismaya󰀨ecttheloadlimiter.
 ▪ Airow:Checkairowrequirementandminimumhosediameteralsocheckthatsmallborettingsarenotstranglingtheairow.
 ▪ Keepthelubricatortoppedupwithalightturbineoil(ISOVG3256).
 ▪ Theltershouldbecheckedregularlyandmanualunitsdrainedofwaterasrequired.
 ▪ THE AIR HOSE SHOULD BE SUPPORTED SO THAT THE WEIGHT OF HOSE IS NOT HANGING FROM THE AIR SET AND
`FITTINGS. THE AIR SET IS NOT DESIGNED TO SUPPORT THE WEIGHT OF THE HOSE. SEE PAGES 7 AND 12 IF A HOSE
SUPPORT BRACKET AND MANIFOLD IS FITTED TO THE HOIST.
 ▪ Theairsupplyshouldbecleanandrelativelydry.Wherethecompressorproducesalotofwateractionshouldbetakentoremove 
  theexcesswater.
 ▪ Checkairconnectionsizeandtypearecompatible.
 ▪ Checksecurityofairhoseconnection.
AIR SUPPLY CONNECTION:
 Everyinstallationisdi󰀨erent,sothecorrectmethodofsupportingtheairhoseshouldbereviewedwhileinstallingthehoist.Thisneedsto 
 takeintoaccounttheweightandsizeofthehose,obstructionsbothatdeckandhoistlevel,connections,operatingconditionsandanylikely 
movement of the hoist and air hose.
 Thettingsandlterlubricatorarenotdesignedtotaketheweightofthehose.
 Iftheairsupplyhoselengthisover10metresthehoseIDshouldbeincreasedtothenextsize.
AIR SUPPLY:
 Vanetypeairmotorsaredesignedtofunctionusingclean,dry,lubricatedair.Theinstallationofan‘inline’airserviceunitalthoughessential 
cannot in itself compensate for serious contamination in the air supply. When operating the compressor in moist (humid) or dusty atmospheres
 seektheadviceofyourcompressorsupplierwithregardtothettingofadryerandlter.
AIR PRESSURE:
 Thehoistisdesignedtooperatebestinthepressurerangeof5to6bar(72to90p.s.i).Thespeedsquotedonthemanufacturer’sliterature 
 areobtainableonlyat6bar(90p.s.i)inletpressure.Thehoistwilloperateatmuchreducedspeedatpressuresbelowthisgure.
AIR FLOW:
 Refertothehoistdatasheet,toselectthehosediameterwhichensuresadequateairow.Failuretoprovideadequateairowwillresultina 
 pressuredropinthesupplylineandcausethehoisttostallandthebraketoapplyuntilthepressureincreases.Inaddition,thebrakewillnot 
 releasecleanlyandwilloverheat.(Althoughnotinitselfahazard[thebrakefailssafe]itmayprovefrustratingtotheoperatorandahazard 
 mayariseasaconsequence.)
HOSE SUPPORT BRACKET:
 Whereahosesupportbracketandmanifoldhavebeenttedtothehoisttotaketheweightofanairsupplyhose,severalchecksmustbedone.
 ▪ Checkthehosehangsfreelyanddoesnotinterferewiththehoistchain.
 ▪ Checkthehoseisclearoftheloadtobelifted.
 ▪ Checkthependanthoseisnotobstructedbytheairsupplyhose.
 ▪ Checktheairhoseissupportedbythehoseclamp/former/festoonsystem.
 ▪ DOuseexclusivelycorrectlyratedandcertiedpneumatichosesandttingsintheairsupplyline.
 ▪ DOsupporttheairlineuptothehoist,asthettingandlter/lubricatorarenotdesignedtotakealoadandmaynotsupportthe 
weight of the hose.
 ▪ DOmaintaintheinternaldiameter(asperthetablethroughoutthesupplylength)orreducefromthelargerdiametertothe 
smaller diameter in the direction of the hoist.
 ▪ DON’Tusehydraulicttings.Theseoftenhaveareducedoricesizeresultinginadownlinedropinairpressure.
 ▪ DON’Tincreasefromsmallertolargerdiameterorinsertalengthofsmallerdiameterhoseinthesupplylineasthiswillresultin 
 reducedowandpressure.
 ▪ DON’Tcreatelowpointsintheairsupplylinewherewatermaybetrapped(orifunavoidableinstalladraintap).
 ▪ DON’Trelyonpneumaticttingstosupportairlines;theyarenotdesignedforthispurpose.
 ▪ DON’Tshortenthependantbyformingalooporacoil.Thiswillpreventthestrainerwirefromsupportingthependantandwill 
 causethehosestobecomedetachedorkinked.
CAUTIONCAUTION
CAUTIONCAUTION
DANGER

8
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
GETTING STARTED - INSTALLATION & TECHNICAL CHARACTERISTICS
1.4 HOIST ASSEMBLY
 Normallyourhoistorhoistandtrolleyswillarrivecompletereadytobettedintoposition,butsometimesfortransportationitmaybe 
necessary to disconnect the chain collector, trolley or the pendant control system.
 ▪ Chaincollectorswillbesuppliedwiththenecessaryboltsandttingstoassembleonsitealongwithanysafetyslingsasshownin 
section 1.8 and chain collectors in section 7.4.
 ▪ Duetothesizeofsometrolleysitiseasiertoshipsplitfromthehoist,thetrolleyGAdrawingsshowtheloadbarandtopeyedetails
  forrettingandthecontrolandsupplyairlinesarenumberedorcolourcodedforre-connection.
 ▪ Wherelongcontrolsarefittedtoahoisttheyarecolourcodedforre-connectiononsite.
 ▪ Whenliftingintopositioneitherusetheliftingpointsonthehoistorhoistandtrolley,ifthehoistdoesnothaveliftingpointsfitted 
  securelyfitslingstothebodyofthehoistorusethetophookifpossible.Donotliftbythecontrols,valves,ortheairset.
MOUNTING THE HOIST
 TheairhoistisdesignedasaLIFTINGMACHINEandassuchisdesignedexclusivelyfortheliftingloadsvertically.Nonverticalliftingwill 
result in premature wear of the chain and chain guide and may result in damage to the limit arms or a failure of the limit arms to operate.
 ▪ Sitethehoistimmediatelyabovetheloadwhichistobelifted.
 ▪ Ensurethatthepointfromwhichthehoistissuspendedhasbeendesignedandtestedtoatleastthesamesafeworkingloadas 
the hoist itself.
 ▪ Ensurethatthesuspensionpointorshackletssnuglyintothebowlofthehoisttophookandthatthesafetycatchclosesto
prevent escape.
 ▪ UseonlycertiedliftinggearwithaSWLinexcessoftheloadtobeliftedtoconnecttotheloaditself.
 ▪ Ensurethattheliftinggeartssnuglyintothebowlofthehoistbottomhookandthatthesafetycatchclosestopreventescape.
 ▪ Ensurethatthecontrollength(pendantorcords)isadequatetoallowtheoperatortostandawayfromtheload,inasafeand 
secure position with the cords or pendant at waist height.
CLOSE HEADROOM WORKING
The lower hook of the TMH hoist includes a swivel arrangement. This allows the load to turn without twisting the chain. However, when
 repeatedlyhandlingloadswiththebottomhookclosetothehoist,especiallywhenrotationoftheloadisprevented,thereistendencyforthe 
 chaintoattempttoentertheguideatanangle.Thisisparticularlypronouncedontwofallunits.Ifthisproblemisnoticedwhendoingatriallift,
 ahighqualityballbearingswivelshouldbemountedbelowthebottomhookofthehoist.
CHAIN COLLECTORS
 Ifthehoisthasbeensuppliedwithachainbucket,andthechainhasbeenstoredwithinitduringshipment,removeallthechainfromthecollector
 byhand,andremoveanyknotsortwists.
 Inallcasescarefullyfeedthechainovertheloadwheelallowingittollthecollectorwithoutanyinterferenceasitemergesfromthewheel. 
 Thiswaythecollectorwillllnormally.Ifthechainwithinthecollectorisdisturbedgreatcaremustbetakenthenexttimethatthechainisfed 
 outofthecollectortoensurethatitisnottwistedorknotted.ChainbucketsarettedwithoneortwobracketsdependingonthemodelandHOLof
the hoist. See additional instructions (Section 6) for large collectors.
1.5 TECHNICAL CHARACTERISTICS
 TheWLLofthehoistwillbemarkedonthehoistnameplateandalsointhehoistspecicationsupplied.
 Thereactionsonthepoweredhoistonthesupport,runwaybeamorcraneshouldhavebeentakenintoaccountinthedesignofthestructure.
 Thestructureshouldbeatleast25%strongerthanwhenusingmanualequipmentduetotheshockloadingappliedbytheoperationalspeeds
and the starting and stopping of the hoist.
 AllRedRoosterhoistsarettedwiththefollowingsafetyfeatures
 ▪ Upperandlowermechanicallyoperatedtravellimits.Theseareultimatestopsandshouldnotbeusedtostopthehoistonaregular
  basis.
 ▪ Loadlimitingvalve.Afterassemblyandprooftesttheloadlimitingvalvesetissettostoptheoperationofthehoistifanoverloadis 
  detected.Thehoistwillstopliftingbutwillstilllowertheload.
 ▪ Thediscbrakeisspringappliedsowhenthecontrolsarenotoperatedorintheeventoflossofairsupplythebrakeisapplied 
holding the load in position.
 ▪ Onpendantcontrolledhoistsanemergencystopbuttonisfittedwhichconnectstoanormallyopenvalveeitherlocatedinthehoist 
  valvechamberorconnectedtothehoist.Whentheemergencystopbuttonispushedoriftheairsupplytothehoistiscutoffthen 
the valve will close stopping the hoist.
 ▪ RedRoosterhoistshavea5:1factorofsafety.
DANGER
DANGER

9
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
GETTING STARTED - HOIST CHECKS
1.6 HOIST CHECKS BEFORE USE
HOIST CHECKS (AIR SUPPLY OFF)
 ▪ Hookswivelssatisfactorilyandthesafetycatchesworkcorrectly.
 ▪ Loadchainisundamagedandlubricated(lightmineraloil).
 ▪ Theloadchainisnottwistedthrough(twofallormoremodels)andthattheloadchainpassedthroughthelimitlever(Allmodels).
 ▪ Theloadchainanchorissound(bothliveandslackend).
 ▪ Checkfordamagetothehoist,pendantandcontrollines.
 ▪ Donotoperatebelow-20°Corabove60°C without contacting Red Rooster.
HOIST CHECKS (AIR SUPPLY ON)
 ▪ Thependantbuttons,leversorcordsshouldbesmoothtooperateandreturntoneutralwhenreleased(hoiststopsanddoesnot 
run on).
 ▪ Thehoistisrunupanddownonaregularbasis.Wherehoistsarehanginginadryandprotectedareatheyshouldberunweekly, 
  wherethehoistisoutsideandnotprotecteditshouldbechecked,lubricatedandrundaily.
 ▪ Theemergencystopbutton/valveoperatesimmediately.
 ▪ Upperandlowerlimitswitches/leversworksatisfactorily.
 ▪ Loadchainsrunsmoothlyoverthepocketwheel.
 ▪ Theloadchainshouldbeexaminedperiodicallyforcracks,gougesandwear.
 ▪ Chaincollectorsshouldbecheckedforsecurityandchaincapacity.
 ▪ Checkchainrunsinandoutofthechaincollectorsmoothly.
 ▪ Forhoistswithalongdropofchainoralargechaincollectoraseparatesuspensionpointmayberequired(seesection1.8).
 ▪ Cordcontrolhoistsshouldhavethetogglesmarkedforraiseandlower.
 ▪ Oncordcontrolscheckthespoolvalvereturnstoneutralandthehoiststopswhenthecordisreleased.(hoiststopsanddoesnot 
run on).
 ▪ Checkthesilencerisnotpartiallyblockedbycomparingtherunningspeedwithoutloadagainstthespeedinthemanual.
NEVER RELEASE THE EMERGENCY STOP BUTTON UNTIL IT IS SAFE TO DO SO
Hoist swivels satisfactorily.
Hoist safety claws functional and undamaged.
Safety claw
Chain undamaged
Chain not twisted through (two fall models see sketch)
twisted
DANGER
DANGER
correct
DANGER

10
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
GETTING STARTED - HOIST CHECKS & INSTALLATION INSTRUCTIONS
1.7 HOIST CONTROLS
 Airhoistscanbecontrolledbyeitherapullcordorapendantcontroloperatingthespoolvalveofthehoistoperatingraiseandlower.The
 diagraminsection1.8showsthesetupforbothtypesofcontrolandthelocationonthehoistbody.
 Cordorpendanthoselengthsshouldbelongenoughfortheoperatortostandawayfromundertheloadbutstillwiththecordtogglesorthe 
 pendantsuspendedataheightofaround1metrefromtheoperatinglevel.Wherethecontrolshavetobetothesideofthehoistor  
 wheretheoperatorcannotseetheloadtravellingthefullrangeoftheliftabanksmanshouldbeappointedtoassisttheoperatorusinga 
 reliablemeansofcommunication.
 Bothtogglesonthecordcontrolsshouldbemarkedforcorrectoperationofthehoist.Theemergencystopbuttononthependantcontrol 
 shouldalsobemarked.
1.8 ADDITIONAL INSTALLATION INSTRUCTIONS
Hook suspension with long chain drops.
 Problem:
 Whenalongheavychainistted,andthe‘raise’ispressedwiththehoistinanunloadedcondition,duetothecentrelineofthehoisthaving 
 beena󰀨ectedbytheweightofchain,theupperlimitswitch,mayfailtooperate.Inaddition,theslackloadchainmayonsomemodulesfoul 
the limit lever arms, thus preventing it from returning to the centre (neutral position).
Resolution:
 Ashortlengthofwirerope,6mmdiameter,isttedtothehoistsandbulldoggripshavebeensupplied.
 Suspendthehoistinitsnallocationandwithasmuchchainaspossibleinuse.Applyasmallloadtothehoistandliftitclearoftheground.
 Connectthewireropeslingtothesupportsteelalongsidethetophookusingbulldoggrips.
 Thetensioninthisslingshouldbeenoughtocounteractmostoftheweightoftheslackchainproducedinthefullyraisedposition,butitmust 
 notbetensionedsuchthatitiscarryinganyoftheloadsupportedbythehoist.i.e.ifttedcorrectly,inanunloadedcondition,theslingwillbe 
 tensionedwiththehoistALMOSTintheverticalposition.Whentheloadisapplied,thetensionintheslingwillbeslack.
THE SLING IS NOT CAPABLE OF HOLDING THE LOADS CARRIED BY THE HOIST

11
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
GETTING STARTED
STANDARD HOSE CONNECTION
PENDANT CONTROL OR
HOIST WITH EXTERNAL
EMERGENCY STOP VALVE
STANDARD HOSE CONNECTION
CORD CONTROL OR
HOIST WITH INTERNAL
EMERGENCY STOP VALVE

12
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
GETTING STARTED
*
*Somehoistsarettedwithinternalemergencystopvalves

13
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
LUBRICATION
2.1
Note 1
 Inallcasesoilwillbeexpelledfromthehoistexhaust.Theamountdischargedisproportionaltothedeliveryrateofthelubricator.In 
 environmentswhereoilintheexhaustcannotbetolerated,theexhaustcanbepipedawaytoasafearea,butthisrequiresspecialist 
 modicationofthehoist(Seeairserviceequipment)-CONSULTYOURDEALER.
Note 2
 AllRedRoosterhoistchainmustbelubricatedtopreventwear.
 Keepingloadchaincleanandlubricatedwillgreatlyincreasethelifetimeofthechainandpreventcostlyreplacement.Verylittlelubricantis 
 neededandcanbeeasilyappliedtothechainbycloth,brushorspray.
 Inareasofhighcorrosion,platedchaincanbeusedalongwithspeciallubricantstopreventcorrosionfromseawaterandspray.Chainsused
 intheseareasshouldbere-lubricatedonaregularbasis.
 NEVERuseheavygreaseorbitumenbasedproductstolubricatethechainasthesewillfoulthechainguide,idlerandloadwheelsand 
 bearings.
 RemovedustandwaterdropsontheLoadChainandthenapplylubricant.ApplicationoflubricationinuencesonthelifeoftheLoad 
 Chainconsiderably.Applythelubricantsu󰀩ciently.
AIR SUPPLY FILTER, REGULATOR AND LUBRICATOR LOAD CHAIN LUBRICATION
Item Oil Type Frequency
LubricatorUnit
Main Air Supply
Atlub
Mediumtolightturbineoil
ISO VG 32-56
Oranyqualityairlinelubricant
(See note 1)
10 to 15 drops per minute
Donotallowlubricatortorunoutofoil
Load Chain Normal industrial - any light mineral oil
Cleanareas-waxbased,semisetting
Foodindustry-suitablevegetableoil
(See note 2)
Weekly/monthlysubjecttoenvironment/use
Limit Lever Linkages
and Anchor pins
No. 2 grease Monthlyormorefrequentlyinaggressive
environments
Gearbox High temperature EP2 grease Only at major overhaul
DANGER
CAUTIONCAUTION
DANGER
Applied
Position
Load
Filter Regulator Lubricator
Air In Air Out

14
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
SAFE OPERATION
3.1 Thecontentsofthissectionaredesignedfortheguidanceofpersonnelusingthehoist.Forthemostpart,theyare‘commonsense’ 
 procedures.Mostdangerousoccurrencesinvolvingliftingmachinesarenotasaresultofdefectdevelopinginthemachineitselfbutareasa 
 resultofanerrororactofcarelessnessbytheoperator.Assuch,thevastmajorityofaccidentsordangerousoccurrencesareavoidable.The 
 operatorisresponsibleforhissafetyandthesafetyofothersintheareaofthehoist.
 Itisfurtherrecommendedthatonlyauthorisedpersonnelshouldbepermittedtousethehoistandthatallsta󰀨shouldbeproperlytrainedand 
 haveadequateknowledgeinbothsafeuseandvisualexamination.
ALWAYS - follow company procedures, work safely, report faults and comply with regulations.
GUIDELINES FOR PERSONNEL USING AIR HOIST
 ▪ Readtheinstructionmanualbeforeuse.
 ▪ Testruntheequipmentpriortoapplicationofaloadandensurethattheequipment,includingitscontrolandsafetydevicesare 
functioning correctly.
 ▪ Donottouchthehoistbodyimmediatelyafterextensiveuse,asitmaybehotorverycold.
 ▪ Donotwearlooseclothing(ties,scarvesetc.)whichmaygetdraggedintothehoistorbottomblock.
 ▪ Wearsafetybootsorshoes(togetherwithasafetyhelmetifliftingoverhead).
 ▪ Ensurethatapositivelyengagedisolatorrequiringanappropriateoperationtore-engage,isttedbetweentheairsupplyand
  themachine(lever,buttonorquarterturnvalve).Theisolatorshouldisolateonlythemachineitselforwherethesafetyofother 
 machinesmaybea󰀨ectedbyisolationofthemachine,allmachinesa󰀨ectedmustbeisolatedatthesametime.
 ▪ Largehoistsandtrolleyshaveliftingeyesthatcanbeusedforhandlingandinstallation.Wherenoliftingeyesaretted,asling 
 maybettedroundthehoistbodyusingachokerhitch.
 ▪ Ensurethattheloadissecurelysupportedbycertiedliftinggear(slingsandshackles)withahighersafeworkingloadinthe 
 congurationused,thantheloadtobeliftedandthatitcannot‘escape’whilstbeinglifted.
 ▪ Standclearoftheloadwhenliftingorloweringandensurethatthepointatwhichyouarestandingissecure.Donottouch 
moving chain.
 ▪ Whenthereisabriefpauseintheliftingoperationwheretheoperatorletsgoofthependantcontrol,hemuststayintheareaand 
 makesurethependanthangsverticallyandcannotswingorgetblownagainstanything.
 ▪ Whenthereisalongerbreakintheliftingoperationandtheloadhasbeenlanded,thentheemergencystopbuttonshouldbe 
 actuatedsothatapositiveactionisrequiredbeforethehoistorhoistandtrolleycanbeoperated.
 ▪ Ifthehookisstillattachedtoanitemthenasignshouldbeattachedtothependantanddependingonthecircumstancesthe 
 powersupplylockedo󰀨.
 ▪ Ensurethatotherpersonnelcannotentertheimmediateareawheretheliftistakingplace.
 ▪ Neverlifttheloadhigherthannecessary.
 ▪ Ensurethatthecontrollength(cordorpendant)isadequatetoallowtheoperatortostandawayfromtheloadinapositiontosee 
the load at all stages of lift.
 ▪ Thependantshouldhangfromthehoistandnotbeplacedontoobjectswherethecontrolscouldbeactivated.
 ▪ Ifitisnotpossibletositeyourselfinapositionwhereyoucanseetheloadatallstages,appointa‘banksman’tocoverthearea 
 whichyoucannotseeandestablishareliablemethodofcommunication(verbalorhandsignals)beforestartingthelift.
 ▪ Ifyoususpectthattheequipmentisdefectiveorisdevelopingafault,stoptheliftingoperationimmediately.
 ▪ Intheeventofanemergencymaketheareasafebyreturningtheloadtoarestposition,butifthisisnotpossibletheareashould 
 becordonedo󰀨andtheadviceofyoursuperiororsafetyo󰀩cersought.Neverrepairahoistwiththeloadsuspended.
 ▪ Ifitisnotpossibletoloweraloadtothegroundtomakeitsafe,thenaliftingplanmustbeinplacetorecovertheloadormakeit 
safe in case of hoist failure.
 ▪ Inthecaseofcomplexliftingoperationsaliftingplanmustbeinplacetocontroltheliftstipulatingthehoiststobeused,
  operatingconditions,operatorinstructionsandthedi󰀨erentpartsofthelifttakingpartintheagreedsequence.Carryouta 
 practiceliftwithasmallloadifnecessarytoconrmtheliftingoperation.
 ▪ Thestartingandstoppingofthehoistandtakingupofslackchainathighspeedcanapplyhighforceswhichcouldbehigher 
 thantheloadbeinglifted.Alwaysoperatehoistssmoothlyandinacontrolledmanner.
 ▪ Theattachmentpointsmustbecapableofwithstandingtheexpectedforces.
 ▪ Externalvibrationcana󰀨ectthehoistandcancausedamageandwear.
 ▪ Donotusethehoistoutsideinhighwinds,badweatherconditions,orwhentemperaturesarelikelytobeoutsidetheoperating 
temperature of the hoist.
 ▪ Onlyusethehoisttomakealiftsafewhenawarningalarmhasbeenactivatedintheareaandthenisolatethehoist.
AT ALL TIMES THINK BEFORE YOU ACT - PLAN EVERY LIFT
DANGER

15
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
SAFE OPERATION - HOIST OPERATORS
3.1 ▪ Hoistoperatorsmustbehealthyandnotundertheinuenceofalcohol,drugsormedicationwhenoperatingthehoist.
 ▪ Hoistoperatorsshouldbetrainedintheoperationofhoistsproperriggingproceduresfortheattachmentofloadstothehoist.
 ▪ Theoperatorisalwaysresponsibleforhisownsafetyandanybodyelseintheoperatingarea.
 ▪ Alwaysstarttheloweringorliftingmovementslowlyandsmoothly.
 ▪ Whenusingthehoistjointlywithanotherperson,usesignalsagreeduponatthejobsite(standardizedsignals).
 ▪ Whenusingthehoistwithoutchaincollector,avoidtheslackchaintofall,catchorimpactasthiscancausehazards.
 ▪ Incaseofairpressureloss,securetheloadandarea.Ensurethatturningtheairsupplybackoncannotresultinadangerous 
occurrence.
 ▪ Stopusingthehoistincaseofabnormalsounds.
SAFE OPERATION - FORESEEABLE INCORRECT USE
3.1▪ Wherethesupportingsteelworktransfersavibrationoroscillationthroughthehoistthiscancauseincreasedwearbetweenthe 
links of the load chain.
 ▪ Wherethehoistorhoistandtrolleysarettedwithliftingpointstheyshouldonlybeusedforliftingthehoistandtrolley,theyare 
not designed to take the full WLL of the hoist.
 ▪ Beforecarryingoutanyworkonthehoistthemainairshouldbeturnedo󰀨andtheresidualareventedorthehoistrunto
dissipate the air pressure.
 ▪ DonotexceedthestatedSWLordutyrating.(Fig.A)
 ▪ Operatethehoistsmoothly.Donotsuddenlychangedirectionasthismayexertbothshockloadsaccelerationforcesmaywellin 
 excessoftheweightoftheloadbeinglifted.
 ▪ Donotusethehoisttolift/lowerpersonnel.(Fig.B)
 ▪ Onlyusethehoisttoliftaloadvertically.Itisnotdesignedtopullordragloadswithoutmodicationandoraliftplanbeingused 
for special lifting operations, such as cross hauling. (Fig. C)
 ▪ Ensurethattheloadissecurelysupportedbyitsliftinggear(slingsshacklesetc.)andthatitcannotescapewhilstbeinglifted.
 ▪ Ensurethattheliftingassembly(slings,shacklesetc.)hasahighersafeworkingloadinthecongurationusedthantheloadto 
 belifted.
 ▪ Ensurethatthepointatwhichthehoististobesuspendedhasanequalorgreatersafeworkingloadthanthehoist.
 ▪ Ensurethattheloadisfreetomoveandwillclearallobstructions.
 ▪ Avoidswingingtheloadorhook.
 ▪ Donotusethehoistifthechainisdamaged,twisted,kinkedorworn.
 ▪ Ensurethattheloadisstableandinbalanceatstartingliftingorsettingdownastiltingorfallingloadscancauseaccidents.
 ▪ Neverallowloadsto“fall”intotheloadchain.(Fig.D)
 ▪ Neverlockthecontrolelementsofthependantorcontrols.
 ▪ Neverusethechain,hooksorhoistasanelectricalgroundforweldingorelectricity.
 ▪ Donotusethelimitsasameansofstoppingthehoist(thesearesafetydevices).
 ▪ Donotusecontrolsasameansofmovingthehoist(thependantisdesignedtosupportitsownselfweightonly).
 ▪ Standclearoftheloadwhenliftingandloweringandensurethatthepointatwhichyouarestandingissafeandsecure.(Fig.E)
 ▪ Donotholdontotheloadchainwhencontrollingaload(tatagtotheloadifnecessarytoensurethattheloadiscontrolled).
▪ DonotapplyaloadtothetipoftheBottomHookortheHookLatch.(Fig.F)
 ▪ Donotbindaloadwiththeloadchaindirectly.(Fig.G)
 ▪ DonotoperatetheLoadChainwhileitisincontactwithanysharpedges.(Fig.H)
DANGER CAUTION
DANGER
over load
Fig. A Fig. B Fig. C Fig. D Fig. E Fig. F Fig. G Fig. H

16
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
SAFE OPERATION
3.2 SAFETY EQUIPMENT - PPE
 Safesystemsofworkshouldbeappropriatefortheworkingconditionsthatthehoistisbeingusedinwithmethodstatementsstatingwhat 
thehoistisbeingusedfor,theauthorisationofsta󰀨tooperatehoistsandthePPErequirementsinplace.Ingeneraloveralls,safetyshoes, 
hearingprotectionandglovesarenormalbutothersiteswillrequiresafetyglassesandhardhats.
3.3 LIFTING GEAR BELOW THE HOIST
 Whereliftinggearisconnectedintothebottomhookofthehoistitshouldbesizedforatleastthecapacityofthehoistandphysicallytwell 
intothebodyofthehookallowingthesafetycatchtoclose.
 Wherealargeritemsuchasaspreaderbeamisusedthismayhaveane󰀨ectontheliftingcapacityofthehoist,sotheSWLshouldbe 
reducedtoreectthis.
3.4 MOUNTING ON TROLLEYS
▪ Ensurethatthetrolleyisproperlymountedonthebeamandsetcorrectlyforthebeamwithadequatewheelclearance.
 ▪ Ensurethatthestopsforthetrolleymountedontherunwaybeamarecorrectlypositionedandsecurelyinstalled.
 ▪ Ensurethatthetophookorlinkplateofthehoisttsproperlyonthesuspensionpointofthetrolleyandisassembledproperly 
 withthehoistatthecentreoftheloadbar.
 ▪ Ensurethattheloadbarandtiebarnuthavebeensecuredandthetrolleysideplatesaresetparalleltothebeamweb.
 ▪ Ensurethatthetiebarsarecorrectlyadjustedintheslotswiththeanti-tiltrollercloseunderthebeamwithenoughclearanceto 
 allowthetrolleytorunalongthebeam.
3.5 OPERATIONAL BREAKDOWN OR ACCIDENT
 Ifanunloadedhoiststopsworkingthenitshouldberemovedfromlocationandsentforrepairifnoneoftheremediesinthetrouble
 shootingguidehaveane󰀨ect.
 Whenthehoistisstillholdingaloadthenanadditionalhoistshouldbeusedtotaketheweightoftheloadsoitcanbesafelyloweredand 
thefaultyhoistremovedforrepair.Ifanotherhoistcannotbeusedtolowertheloaditispossibletoreleasethebrakebyslackeningthe 
brakecoverscrewsbutthisshouldonlybedonebyaRRLengineerorafterdiscussionswithRedRoosterasitisnotalwayspossibleor 
safe to do so.
 Themainairsupplylinetothehoistshouldbettedwithaneasilyaccessiblevalvetocuto󰀨theairsupplytothehoistincaseof
 emergencyorformaintenance.Pendantcontrolhoistsalsohaveamainairshuto󰀨valve.
 Thereshouldbeasafeaccesstothehoisttocarryoutmaintenance,inspectionandlubrication.
DANGER
DANGER
DANGER
DANGER
120º or less Angleexceeding120º
Angle too wide
Hooking of the load
at the tip of the hook
Improper hooking
position of the lifted
load or the sling
HOW TO SLING THE LOAD PROPERLY DO NOT CARRY OUT DANGEROUS HOOKING AS SHOWN BELOW
Sling the load at
theextendedline
of the hook shaft
Unableclosingof
the hook latch

17
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
MAINTENANCE
4.1 TheTMHrangeofhoistsareheavydutypneumatichoistsandbuilttorequirelittlemaintenanceiftheyarekeptlubricatedandmaintained. 
 Themaintenancerequiredwilldependondailyoperatingtimes,theconditions,qualityoftheairsupplyandthepercentageoftheWLL 
 regularlybeinglifted.Theoperatorsdailychecksandthemonthlymaintenancechecksarenecessarytochecktheconditionofthehoist. 
 Maintenanceworkshouldbecarriedoutbytrainedandqualiedpersonnel.
It is recommended that in the case of the TMH hoist and air trolleys inspections are carried out in accordance with the following schedule,
 althoughthefrequencyofthe‘sixmonthinspection’shouldbeincreasedinhighriskenvironments,aggressiveenvironmentsorwheretheusage
 isparticularlyheavytobetweenoneandthreemonths.
EVERY DAY / WEEK (DEPENDING ON USAGE)
 Theitemslistedunder‘checksbeforeuse’inSection1(GettingStarted)ofthemanualshouldbeexamined.
 Itisrecommendedthatthelubricatoris‘toppedup’asapartofthisinspectionroutine.
AT LEAST ONCE PER MONTH FOR HOISTS IN CONSTANT USE OR EVERY THREE MONTHS LIGHTLY USED UNITS
 LOADCHAIN-Thoroughlyexaminethroughoutitslengthforwearinthelinks,corrosion,cracksordistortion.Ifthewearinthelinks
 exceedsthatstatedinthechart,thechainshouldbereplaced.Ifthereareanyvisiblecracksordistortionthechainshouldbereplaced.
 Anywearshouldbemeasuredandcheckedagainstsection10.1.
 BRAKE-Withaloadappliedcheckthebrakee󰀩ciency.Ifthereisanydelayinactuationorslippage,thebrakeisdefectiveandthehoist 
mustbethoroughlyoverhauledbeforebeingreturnedtoservice.
 HOOKS,SWIVELSANDCLAWS-Examinehooksforwear,deformation(refertochart),nicksandgouges.Ensurethatthehooksswivel 
smoothly and that the safety claw opens fully and closes under spring tension.
 CHAINANCHORPIN-Examineforwearanddeformation.
 NUTSANDBOLTS-UsingsuitablespannerandAllenkey,checkforanyloosenutsandbolts.
 UPPERANDLOWERLIMIT-Ensurethatitfunctionscorrectlyinboththefullyraisedandfully(chainlever)loweredpositions.
CHAIN COLLECTOR - Check security and condition.
 Itisrecommendedthattheloadchainandlinkagesarelubricatedaspartofthisinspectionroutine.
 WhenrepairingRedRoosterairhoistsonlyoriginalRedRoosterproductsshouldbeused.
4.2 Onlyminorrepairssuchassilencers,safetycatches,pendantrepairs,replacingshorterlengthsofloadchainandinspectionsshouldbedone
 inlocationafterthisthehoistshouldbeloweredtogroundlevelandtakentoaworkshop.
 Ifthehoististakenoutofserviceitshouldbesenttoanapprovedrepairertobefullydismantled,repairedandtested.
 OnlyRedRoosterapprovedpartsshouldbettedtothehoistbutgoodqualityEuropeanorJapaneseloadchainandbearingscanbeused 
 butotherthanthatonlyRedRoostersuppliedpartsshouldbeused.
 Hoistandtrolleysareheavyalongwithsomepartsofsomehoistsosuitableliftingequipmentshouldbeusedtodismantleandassemble 
hoists.
DANGER
CAUTIONCAUTION
CAUTIONCAUTION
CAUTIONCAUTION
CAUTIONCAUTION
CAUTIONCAUTION
DANGER
DANGER

18
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
SAFE OPERATION
4.3 SILENCING
 TheTMHhoististtedwithaninternalsilencer;thenoiseoutputbeinglessthan82dBatonemetre(thisconformstoE.C.noiseregulations).
TMH-50T/4
 Thesetypesarettedwitha2stagesilencer;rststagecomprisesofasinglepieceoffelt,thesecondstagecomprisesof5piecesofnylonand
2 pieces of felt..
 Thelifeexpectancyofthesilencercorrelatescloselywiththequalityofairsupplied.
 Thenylonpadmaybewashedwithde-greaserandre-usedoncedecontaminated.
 Periodicexaminationofthesilencerisnotrequired,norisitrecommended(seebelow).Asthesilencerbecomescontaminatedareduced 
 speedofoperationwillbenoted.Atthispointthenylonsilencershouldbecleanedorreplacedandthegauzesilencershouldbechanged.
4.4 CHANGING THE SILENCER(S) - see parts list.
TMH-50T/4
 Locatedontheendofthehoistabovecontrolvalveistheexhaustcover.Removethe4xM6screwstoremovetheperforatedplate.Replace
 2xnylonand1xfeltdisc.Removethe4xM8outerboltsholdingthemainexhaustcoveron.Replacethe3xnylonand1xfeltpads.
 TherststagesilencercanonlybereplacedbyRedRoosterLiftingtrainedpersonnel.
ADJUSTMENTS AND MAINTENANCE OPERATIONS
 Beforecarryingoutanyworkonthehoistthemainairsupplyshouldbeturnedo󰀨andtheresidualairventedorthehoistruntodissipate 
the air pressure.
 RedRoosterhoistsnormallydonotrequireanyadjustmentasthebrakespringstakeupanywearandtheloadlimiterandlimitsshouldnot 
need adjustment once set.
 Thelubricatorshouldbecheckedandtoppedupweeklyinnormaluseordailywhenheavilyused.
 Theloadchainshouldbecheckedmonthlyforlubricationandoiledifnecessary.Wheretheloadchainisnotlubricatedforoperational 
reasonsthechainshouldbeinspectedweeklyasadrychaincanwearrapidly.
 Thetopandbottomhooksshouldonlybelubricatedifrequiredduringchecks.
 Thehoistgearboxisgreasedduringassemblyorrepairandshouldnotneedgreasedduringoperation.
 TherearenohazardoussubstancesinRedRoosterhoists.
CAUTION
4 X M8 OUTER BOLTS 4xM6SCREWS
PERFORATED PLATE

19
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪
M01-AH28 REV2
MAINTENANCE
4.5 FITTING OR REPLACING LOAD CHAIN
 Thehoistwillrequiretobehungupwithanairlineconnected.
 Thechainmustbefedoverthepocketwheelfromtheslackendanchorsidewiththeweldofeverysecondlinkfacingawayfromthewheel 
 axisi.e.weldoutwards.
 Caremustbetakennottotwistthechainduringinstallation.Thisisbestachievedbyholdingtheliveendofthechainasitemergesfromthe 
 hoist,ifthehoistisreevedontwopartsofchain,feedthroughthebottomblockwheelandagainasitemerges,thereafterfeedingituptothe
 anchorpin.Ifthechaincannotbettedtotheanchorwithoutrotatingitthrough90degrees,theendlinkshouldberemoved.
 Runthechainthroughthehoist,leavingashorttailatthe‘slack’end.Anchortheslackendwithouttwistingthechain.
 Onsinglefallhoiststheliveendissecuredinthebottomhookholder4xM12capheadboltsandnuts.
Feed the chain over the load wheel.
 Itisveryeasytotrapordamagethechainifextremecareisnotexercised.Alwaysexaminetherstlinkofchainafterpassingitovertheload
wheel. If damaged, remove the damaged link(s).
REPLACING EXISTING CHAIN
Cut away the centre portion of a link of the old chain to allow a chain diameter to pass through. Connect the spare link to the last link of the old
 chainandtherstlinkofthereplacementchain.Usetheoldchaintodrawthereplacementchainthoughthehoist.(Retainthesparelinktobe
re-used).
FITTING CHAIN TO AN UNCHAINED HOIST
 Ahandytoolcomprisesalengthofeithersoftinsulatedwire(about2mmdiameter)orapieceofexiblenylontubeofthesamediameter 
 approximately500mmlong.Totheendofthisattachasimilarlengthofstrongtwine.
 Thesoftwireortubeisfedoverthewheel,itsexibilityallowsittofollowthechainguideandre-emergeattheoppositeside.Thetwine
is attached to the end of the chain and drawn through, pulling the chain against the wheel. By applying power VERY SLOWLY in the
 samedirectionofwinding,theloadchainisdraggedintotherstpocketandovertheloadwheel.Ifanyresistanceisfeltasthechainattempts
 toenterthepocketitisimperativethatthechainisreleasedfromthepocketbeforetryingagain.Otherwisethechainwillbecometrapped 
and damaged.
 OnlyusequalityloadchainapprovedbyRedRoosterforuseonourhoists.
ITEM CHECK METHOD CRITERIA WHEN FAILED
Deformation
Flaw
Entanglement
▪Checkvisually
▪Checkvisuallyfornoforeignmatter
as attached sputter.
▪Nodeepnotch
▪Nodeformationsuchastwist
▪Noattachedsputter
▪Noentanglement
▪Nocrack
▪Wear(see4.6+4.8)
Replace the load chain
DANGER
DANGER
DANGER
DANGER
Crack
Flaw
Wear

20
USER MANUAL
▪ Red Rooster Lifting Limited ▪Nauta House, The Meadows, Oldmeldrum, Aberdeenshire, AB51 0EZ ▪Tel: [phone] ▪M01-AH28 REV2
MAINTENANCE
4.6 TYPES OF CHAIN
 Onlythecorrectsizeandgradeofloadchainshouldbeused.
All chain is to EN818/7 - ANNEX B
TMH-50T/4 HEAVY DUTY
RUD RT+
Nominal diameter: 23.5 + 0.3 / - 1.1 mm
Pitch: 66.0 + 0.7 / - 0.3 mm
 Maxdiaatweld: 24.6 mm
 Minbreakingforce: 750 kN 
Surface hardness: ca390-420HV10
Grade: EN818/7 ISO 3077
 Whensuppliednew,onlyqualitychainfromareputablesupplierhasbeenttedtothehoist.Yoursupplierwillbeabletoo󰀨erreplacement 
 chainoflikequality.
DANGER
